| Performance |
|---|
| Preset points | Yes |
| Infrared (IR) cut-off filter | Yes |
| Number of languages | 11 |
| Languages support | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Portuguese, Russian |
| Processor model | ARTPEC-7 |
| Type | IP security camera |
| Connectivity technology | Wireless |
| PTZ control | Yes |
| Placement supported | Indoor & outdoor |
| Auto-tracking | Yes |
| Tour recording | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Design |
|---|
| IK code | IK10 |
| Form factor | Dome |
| Product colour | Black, White |
| Mounting type | Wall |
| International Protection (IP) code | IP66, IP67 |
| Housing material | Aluminium, Polycarbonate (PC) |
| Camera |
|---|
| Minimum illumination | 0.1 lx |
| Tilt angle range | 0 - 220° |
| Tilt speed | 450 °/sec |
| Pan range | 0 - 360° |
| Pan speed | 450 °/sec |
| Camera shutter speed | 1/11000 - 1/3 s |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Lens viewing angle, horizontal | 65.1 – 2.00 |
| Lens viewing angle, vertical | 39.1 – 1.18 |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 4.95 |
| Auto focus | Yes |
| Minimum aperture number | 1.6 |
| Zoom capability | Yes |
| Optical zoom | 40x |
| Digital zoom | 12x |
| Focal length range | 4.25 - 170 mm |
| Night vision |
|---|
| Night vision | Yes |
| Video |
|---|
| Image quality adjustment | Brightness, Colour depth, Sharpness |
| Text caption overlay | Yes |
| Privacy masking | Yes |
| Back Light Compensation (BLC) | Yes |
| Maximum resolution | 1920 x 1080 pixels |
| Supported graphics resolutions | 320 x 180, 1920 x 1080 (HD 1080) |
| Supported video modes | 1080p |
| Video compression formats | H.264, H.265 |
| Frame rate | 60 fps |
| Video streaming | Yes |
| Video recording | Yes |
| Network |
|---|
| Bluetooth | No |
| Networking standards | IEEE 802.1x |
| Quality of Service (QoS) support | Yes |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTP/2, HTTPSa , TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, NTCIP, LLDP, CDP, MQTT, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| Storage |
|---|
| Card reader integrated | Yes |
| Compatible memory cards | SD, SDHC, SDXC |
| Built-in HDD | No |
| Internal memory | 1024 MB |
| Flash memory | 512 MB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wireless |
| Security |
|---|
| Alert notification type | E-mail |
| Video motion detection | Yes |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Password protection | Yes |
| Pixel counter | Yes |
| Digest authentication | Yes |
| Power |
|---|
| Power source type | AC, PoE |
| Power consumption (Power over Ethernet (PoE)) | 60 W |
| AC input voltage | 100 - 240 V |
| Power consumption (typical) | 14 W |
| Power consumption (max) | 66.1 W |
| Operational conditions |
|---|
| Operating temperature (T-T) | -20 - 50 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 100% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions |
|---|
| Height | 271 mm |
| Diameter | 23.2 cm |
| Weight | 3.75 kg |
| Packaging content |
|---|
| Number of cameras | 1 |
| Manual | Yes |
| Technical details |
|---|
| Doesn't contain | PVC |
| Warranty period | 5 year(s) |
| Other features |
|---|
| Video compression formats | H.264, H.265 |
| Doesn't contain | PVC |
| Warranty period | 5 year(s) |
