I45
2MP Zoom Bullet with D/N, Adaptive IR, Extreme WDR, SLLS, 30x Zoom lens
Main Features
2 Megapixel with 1080p
Day & Night with Superior Low Light Sensitivity and Adaptive IR LED
30x Zoom Lens with f4.3-129mm/F1.6-5.0, DC iris, Auto Focus
Extreme WDR (145 dB)
30 fps at 1920 x 1080
Weatherproof (IP67) and Vandal Proof Metal Casing (IK10)
PRODUCT SPECIFICATION
Device Type: Bullet Camera
Image Sensor: Progressive Scan CMOS
Sensor Size: 1/2.8''
Day / Night: Yes
Effective Pixels: 1944 (H) x 1224 (V) (2.38 MP)
Superior Low Light Sensitivity: Yes
Minimum Illumination: Color: 0.1 lux at F1.6 (30 IRE, 2400°K); B/W: 0 lux (IR LED on)
Color to B/W Switch: ISP based switch, configurable
Mechanical IR Cut Filter: Yes
IR Sensitivity Range: 700~1100nm
IR LED: Adaptive IR LED (Object & Zoom Adaptive IR LED) x 27 (850 nm)
IR Working Distance: 40 m (0 lux, 30 IRE, Gain 255, Auto shutter mode)
Electronic Shutter: 1/5 ~ 1/2,000 sec (manual mode); 1/5 ~ 1/10,000 sec (auto mode)
TV Lines: 1800
S/N Ratio: 56 db
Lens
Focal Length / Aperture: Zoom, f4.3 - 129 mm / F1.6 - 5.0
Zoom Ratio / Speed: 30x optical ; 2.87 sec (wide to tele)
Iris: DC iris
Focus: Auto focus
Mount Type: Board mount
Horizontal Viewing Angle: 65.1° ~ 2.34
Video
Compression: H.264 HP, MJPEG
Max. Frame Rate vs. Resolution: 30 fps at 1920 x 1080; 30 fps at 1280 x 720; 30 fps at 800 x 600; 30 fps at 640 x 480; 15 fps at 320 x 240
Multi-Streaming: Simultaneous dual streams based on two configurations
Bit Rate: 28 Kbps-6 Mbps (per stream)
Bit Rate Mode: Constant, Variable
Image Enhancement: Extreme WDR (145 dB); White balance: automatic, hold, and manual; Brightness; Contrast; Sharpness (auto); Auto gain control; 2D+3D digital noise reduction; Flickerless; Defogging; Digital image stabilizer
Text Overlay: User defined text on video
Image Orientation: Image flip and mirror
Audio
Compression: 8kHz, Mono, PCM, 16 bit encoding, G.711
Audio-In: Terminal block
Audio-Out: Terminal block
Network
Protocol & Service: TCP, UDP, HTTP, HTTPs, DHCP, PPPoE, RTP, RTSP, IPv4, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour, Sony VISCA, Pelco-D, Pelco-P
Ethernet Port: 1, Ethernet (10/100 Base-T), RJ-45 connector
Security: IP address filtering; HTTPs encryption; Password protected user levels; Anonymous login; IEEE802.1X network access control
Alarm
Alarm Trigger: Video motion detection (3 regions); External device through digital input
Alarm Response: Notify control center; Change camera settings; Command other devices; E-mail notification with snapshots; Save video or snapshot to local storage; Upload video or snapshot to FTP server; Activate external device through digital output
Interface
Digital Input: 1, Terminal Block
Digital Output: 1, Terminal Block
Local Storage: MicroSDHC/MicroSDXC Card Slot (Card not Included)
General
Power Source / Consumption: PoE Class 3 (IEEE802.3af) and DC 12V / 7.68 W (heater, fan and IR on)
Weight: 245g (5.4 Ib)
Dimensions (W x H x D): 122.4 mm x 101.37 mm x 240.4 mm (4.8” x 4.0” x 9.5”)
Environmental Casing: Weatherproof (IP67 rated); Vandal proof metal casing (IK10)
Mount Type: Wall, Pole, Ceiling, Gang box
Starting Temperature: -40 °C ~ 50 °C (-40 °F ~ 122 °F) within 30 mins
Operating Temperature: -40 °C ~ 50 °C (-40 °F ~ 122 °F)
Operating Humidity: 10% ~ 85% RH
Approvals: CE (EN 55022 Class B, EN 55024), FCC (Part15 Subpart B Class B), IP67,NEMA 4X, IK10 (metal casing)
Integration
Unified Solution: Fully compatible with ACTi software
ISV Integration: Software Development Kit (SDK) available; ONVIF compliant
Firmware Access Browser: Microsoft Internet Explorer 8.0 or newer (full functionality) Safari with QuickTime installed, and other browserswith VLC installed (partial functionality)
