04/07
|
Ganz ZC-BT3039PHA - 1/3" CCD, 480TVL, 3.0-9.0mm, F1.2 Digital Day/Night, Colour, IR CameraGANZ ZC-BT3039PHA 1/3 inch CCD, 480TVL, 3.0-9.0mm, F1.2, Digital Day/Night(colour) IR Camera.
|
|
|
|
04/07
|
ICU MSD-400 4-Channel Standalone - H.264 DVR with DVD Burner, Supports 2x SATA HDD, Pentaplex Operation, 100fps, 352x288 ICU HSD/MSD-400 4-channel Standalone H.264 DVR with DVD burner, supports 2x SATA HDD, Pentaplex Operation, 100FPS@352x288 on PAL.
ICU HSD/MSD-400 4-channel Standalone H.264 DVR with DVD burner, supports 2 x SATA HDD, Pentaplex Operation, 100FPS @352 x 288 on PAL, all channel Real Time Recording & Playback Independently, with PS/2 mouse and remote, Options to view all or selected cameras / withot affecting cameras recording, 1Color Graphic User Interface, 1 x VGA, Backup CDRW/DVDRW, Memory Stick or USB HDD (FAT32 formatted), Easy upgrade :CDRW/USB2.0, Easy P/T/Z control, Easy and Convenient high speed search with jog/shuttle, Audio : Input - 2ch, Output - 1ch (Two way audio available) **4 cameras needed for recording*
|
|
|
|
04/07
|
ICU ECS-0412 4-Channel Standalone - Real-Time DVR H.264, Supports 1x SATA HDD, 100fps, 720x576, 2x Video Output, IR Remote ICU
ECS-0412
Features
High compression with H.264
Real Pentaplex Operation
Real-Time Recording at D1 Resolution
1 x SATA HDD Internal Bay
2 Video Out (Composite, VGA)
Multiple VGA Resolution (800x600, 1024x768, 1280x1024)
Mouse / IR Remote Control
Very user-friendly Full GUI
Multiple Language
Individual Channel Recording(Resolution, Frames and Quality)
De-Interlacing feature in DVR Itself
System Automatic Rebooting by Itself for Watch-dog
Water-Mark
Digital X2 Zoom, PIP
Various PTZ Protocols
Motion / Sensor Detection
Recording, Alarm-Out and Email Scheduling
Pre / Post / Extra-Alarm Recording
Email Notification/Alarm-Out/Buzzer for Events & Video Loss
Warning Message & Buzzer for HDD Over-Temperature
Search by Time, Calendar, Events and First/Last
Fast Forward/Backward, Step Forward/Backward
Backup via USB Memory Stick & Network by CMS
Dual-Stream (Local Recording & Network Transmission)
I.E Web-Browsing, CMS (DDNS and Multi-Port Support)
3G Mobile Phones, iPhone
Specifications
| Model |
ECS-0412 |
| Compression |
Video: H.264 / Audio: G.723 |
| HDD Bay |
1 x SATA HDD (Max. 2TB) |
| Operating System |
Embedded Linux |
| Multi-Operation |
Pentaplex (Live, Recording, Playback, Backup, Network) |
| Video |
Input |
4 Ch |
| Loop-Out |
X |
| Video Out |
Monitor |
1 x Composite(BNC, 1 Vp-p, 75 Ohm), 1 x VGA |
| VGA Resolution |
VGA Resolution : 800x600, 1024x768, 1280x1024 (Selectable) |
| Audio In/Out |
1 In / 1 Out |
| Sensor In / Alalrm Out |
1 In / 1 Out |
| Port |
2 x USB 2.0, 1 x RS-485(PTZ) |
| LAN |
10/100 Base-Tx Ethernet (RJ45) : Static / DHCP / DDNS |
| Live Display Modes |
1, 4 / PIP
Digital X2 Zoom |
Recording Speed
(NTSC/PAL) |
CIF |
120/100 fps |
| Half D1 |
120/100 fps |
| D1 |
120/100 fps |
| Recording Modes |
Continuous, Schedule, Sensor-Activated / Motion Detection Recording
Pre-Alarm(0~30 Sec.) / Post-Alarm(0~120 Sec), Emergency Recording |
| Playback / Backup |
Speed |
Fast Forward/Backward(x1, x8, x32, x64, x128), Step Forward/Backward |
| Search |
Intelli-Search by Time, Calendar , Events and First/Last Search |
| Backup Device |
USB Memory Stick / Network by CMS |
| Backup File Format |
AVI (With or Without Timestamp), PS (Playback in Backup-Viewer) |
| Events / Alarm |
Email Notification / Alarm-out / Buzzer for Events / Video Loss
Warning Message / Buzzer for HDD Over-Temperature
Alarm / Email Notification-Schedule for Events-Triggering |
| Network |
Transmission |
Video Dual-Stream (Local recording / Network Transmission)
Video Resolution / Frame rates adjustable
Bandwidth adjustable (64/128/256/512Kbps, 1/2/4/10Mbps, Unlimited) |
| C.M.S |
Live Monitoring(Max.64ch), Playback / Backup , PTZ Control, Local DVR Reboot |
| Web (I.E) |
Live Monitoring, Playback, Snapshot and PTZ Control |
| Other Functions |
Multi-Language, Firmware Upgrade by USB, Network, Water-Mark
Configuration Export / Import, Private Zone, Deinterlace On/Off, DST, NTP
Password Protection(1 Admin + 4 Users), 3G Mobile Phone Viewing |
| HDD Formatting Time |
Within 3 Minutes for 2TB |
| Operation |
USB Mouse, IR Remote Control |
| Power |
DC12V, 3.3A |
| Storage Temperature and Humidity |
-20~60 / 20~95% RH |
| Operating Temperature and Humidity |
5~40 / 20~80% RH |
| Dimension (WxDxH) |
340 x 253 x 60, Packing: 374 x 383 x 126 (mm) |
| Certification |
CE, FCC, MIC / RoHS |
|
|
|
|
04/07
|
GeoVision GV-VD122D IP Vandal Proof IP Camera - 1/3" Progressive Scan Low Lux CMOS, Dual Video Streams H.264, MPEG4, Up to 30fps - White GV-VD122D
GV-VD120D/121D/122D/123D 1.3M H.264 Low Lux IR Vandal Proof IP Dome
Features
- 1/3" progressive scan Low Lux CMOS
- Dual video streams from two of H.264, MPEG4 and MJPEG
- Up to 30 fps at 1280 x 1024
- IK10+ (for GV-VD120D and GV-VD121D only)
- IP66 compliant
- 3-axis mechanism (pan / tilt / roll)
- External microphone
- Built-in IR LED
- 2-way audio
- One sensor input and alarm output
- TV-out support
- Micro SD/SDHC Card Slot
- Motion detection
- Tampering alarm
- Privacy mask
- IP address filtering
- 3GPP / ISMA
- DC12V / AC24V / PoE
- Day / Night function
- Varifocal megapixel lens
- 16 languages on Web interface
Models
| Model |
Housing Cover |
| Cover Color |
Vandal Resistance |
| GV-VD120D |
Transparent cover |
IK10+ |
| GV-VD121D |
Smoked cover |
IK10+ |
| GV-VD122D |
Transparent cover |
IK7 |
| GV-VD123D |
Smoked cover |
IK7 |
Active Tampering Alarm
| Tampered |
Focus Change |
Camera Shift |
 |
 |
 |
Specification
|
Camera
|
|
Image Sensor
|
1/3" progressive scan CMOS
|
|
Picture Elements
|
1280 (H) x 1024 (V)
|
|
Minimum Illumination
|
Color
|
0.15 Lux (1/30 sec), 0.08 Lux (1/5 sec)
|
|
B/W
IR ON
|
0 Lux
|
|
Shutter Speed
|
Automatic, Manual (1/5 ~ 1/8000 sec)
|
|
White Balance
|
Automatic, Manual (2800K ~ 8500K)
|
|
Lens
|
|
Megapixel
|
Yes
|
|
Day / Night support
|
Yes
|
|
Max Aperture
|
F/1.3 5%
|
|
Focal Length
|
2.7 ~ 9 mm
|
|
Field of view
|
Diagonal
|
126 (W) ~ 38.2 (T) 5
|
|
Horizontal
|
98.5 (W) ~ 29.8 (T) 5 |
|
Vertical
|
78.7 (W) ~ 23.9 (T) 5
|
|
Operation
|
Focus
|
Manual (w / lock)
|
|
Zoom
|
Manual (w / lock)
|
|
Iris
|
DC
|
|
IR LED Quantity
|
15 IR LEDs
|
|
IR Distance
|
15 m / 50 ft (Max.)
|
|
Operation
|
|
Video Codec
|
H.264, MPEG4, MJPEG
|
|
Video Streaming
|
Dual Streams from two of H.264, MPEG4 and MJPEG
|
|
Frame Rate
|
30 fps at 1280 x 1024
* The frame rate and the performance may vary depending on the number of connections and data bitrates (different scenes).
|
|
Image Setting
|
Brightness, Contrast, Sharpness, Gamma, White Balance, Flicker-less, Image Orientation, Backlight Compensation
|
|
Audio Codec
|
G.711, AAC (16 kHz / 16 bit)
* AAC is only supported by GV-System V8.5 or later
|
|
Sensor Input
|
1 Input (Dry Contact)
|
|
Alarm Output
|
1 Digital Output
|
|
Video Resolution
|
|
Main Stream
|
4:3
|
1280 x 960, 640 x 480, 320 x 240
|
|
16:9
|
1280 x 720, 640 x 360, 448 x 252
|
|
5:4
|
1280 x 1024, 640 x 512, 320 x 256
|
|
Sub Stream
|
4:3
|
640 x 480, 320 x 240
|
|
16:9
|
640 x 360, 448 x 252
|
|
5:4
|
640 x 512, 320 x 256
|
|
Network
|
|
Interface
|
10/100 Ethernet
|
|
Ethernet Protocol
|
HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, RTSP, PSIA, SNMP, QoS (DSCP)
|
|
Mechanical
|
|
Lens Mounting
|
14 mm
|
|
Rotation Axis
|
3-axis (pan / tilt / roll)
|
|
Connectors
|
Power
|
3-pin terminal block
|
|
Ethernet
|
RJ-45
|
|
Audio
|
1 In (RCA female for microphone)
1 Out (RCA female for speaker)
|
|
Digital I/O
|
I/O Wires
|
|
Auto Iris
|
DC drive
|
|
Local Storage
|
Micro SD/SDHC memory card slot
|
|
TV-Out
|
BNC connector
* The TV-Out function only works in 640 x 480 resolution. For TV-Out to work properly, you must set the video resolution to 1280 x 1024 or lower. If both streams are enabled, the Sub Stream must be set to 640 x 480.
|
|
General
|
|
Operating Temperature
|
-20 C ~ 50 C / 4 F ~ 122 F
|
|
Humidity
|
10% to 90% (no condensation)
|
|
Power Source
|
12V DC / 24V AC / PoE
|
|
Power Consumption
|
12 W (max. 1A at 12V DC)
|
|
Regulatory
|
CE, FCC, C-Tick, RoHS compliant
|
|
Dimensions
|
165 x 125 mm / 6.49 x 4.92 in
|
|
Weight
|
1.7 kg / 3.75 lb
|
|
Protection Classification
|
IP66
|
|
Vandal Resistance
|
GV-120D / GV-121D
|
IK10+
|
|
GV-122D / GV-123D
|
IK7
|
|
Power over Ethernet
|
|
PoE Standard
|
IEEE 802.3af Power over Ethernet / PSE
|
|
PoE Power Supply Type
|
End-Span
|
|
PoE Power Output
|
Per Port 48V DC, 350mA. Max. 15.4 watts
|
|
Web Interface
|
|
Installation Management
|
Web-based configuration
|
|
Maintenance
|
Firmware upgrade through Web Browser or Utility
|
|
Access from Web Browser
|
Camera live view, video recording, change video quality, bandwidth control, image snapshot, digital I/O control, audio, Picture in Picture, Picture and Picture, Privacy Mask, Visual Automation, Tampering Alarm, Wide Angle Lens Dewarping
|
|
Language
|
Czech / Danish / English / French / German / Hebrew / Hungarian / Italian / Japanese / Polish / Portuguese / Russian / Serbian / Simplified Chinese / Spanish / Traditional Chinese
|
|
Applications
|
|
Network Storage
|
GV-NVR, GV-System
|
|
3G Mobile Phone
|
Built-in player for 3GPP / ISMA
|
|
Live Viewing
|
IE , Mobile Phone
|
|
CMS Server support
|
GV-Control Center, GV-Center V2, GV-VSM, GV-Backup Center, GV-Video Gateway, GV-Recording Server
|
Note: Specifications are subject to change without notice.
|
|
|
|
04/07
|
OCZ 8GB Diesel Flash Drive - Cap Connector, Aluminium Housing, Lanyard Loop Hole, PnP, USB2.0 - Black Flash Drive / USB 2.0 / Aluminum Housing / 2GB - 32GB / Ultra Compact
Fuel your digital lifestyle with the Diesel USB flash drive. With plenty of room for all your favorite songs, photos, and documents when you're on-the-go, the Diesel offers up to 16GB of storage for your traveling data. For the mobilized student or professional, the OCZ Diesel is a sleek, sturdy, and affordable flash drive and offers the reliability you expect from OCZ Technology.
For a surprising amount of storage in a small package, the Diesel is available in an array of capacities to suit your personalized needs for storage in 2GB, 4GB, 8GB, 16GB, and 32GB.
- USB 2.0 Certified
- Mainstream Speeds
- Aluminum Chassis
- Lanyard loop hole
- True Plug and Play (Compatible with MAC OS X)
- Available in 2GB, 4GB, 8GB, 16GB, 32GB capacities
- 2-Year Warranty
|
|
|
|
04/07
|
OCZ 4GB Diesel Flash Drive - Cap Connector, Aluminium Housing, Lanyard Loop Hole, PnP, USB2.0 - Black Flash Drive / USB 2.0 / Aluminum Housing / 2GB - 32GB / Ultra Compact
Fuel your digital lifestyle with the Diesel USB flash drive. With plenty of room for all your favorite songs, photos, and documents when you're on-the-go, the Diesel offers up to 16GB of storage for your traveling data. For the mobilized student or professional, the OCZ Diesel is a sleek, sturdy, and affordable flash drive and offers the reliability you expect from OCZ Technology.
For a surprising amount of storage in a small package, the Diesel is available in an array of capacities to suit your personalized needs for storage in 2GB, 4GB, 8GB, 16GB, and 32GB.
- USB 2.0 Certified
- Mainstream Speeds
- Aluminum Chassis
- Lanyard loop hole
- True Plug and Play (Compatible with MAC OS X)
- Available in 2GB, 4GB, 8GB, 16GB, 32GB capacities
- 2-Year Warranty
|
|
|
|
04/07
|
Sony VPL-VW90ES 3D Home Cinema SXRD Projector - 1920x1080, 1000 Lumens, 150,000;1, VGA, 2xHDMI, RJ-45, Integrated 3D VPL-VW90ES
Full HD 3D Home Cinema Projector with Sony’s market-leading SXRD panels and outstanding dynamic contrast ratio
Overview
The VPL-VW90ES is a Full HD 3D projector designed to satisfy serious home cinema enthusiasts, with an outstanding 3D picture and a wide range of innovative Sony technologies.
Built around Sonys Cinema-Quality SXRD panel technology, the VPL-VW90ES delivers exactly what 3D connoisseurs demand: a vibrant, bright 3D picture delivered to screens as big as 300.
The system uses frame-sequential projection via IR LED-switching glasses, and with a 240Hz refresh rate, adjustable 3D settings and a true 150,000:1 Dynamic Contrast Ratio, the VPL-VW90ES delivers an immersive, natural home 3D experience.
2D performance isnt compromised either, and 2D sources can be converted to 3D; so with an ever increasing number of Blu-Ray 3D movie titles and 3D games for Playstation 3, theres no shortage of 3D content.
Sony leads the world in 3D Digital Cinema Projection, and now its SXRD panel technology has been adapted for use in home projectors for a true 3D home cinema experience.
Features
Full HD 1080p 3D Home Cinema projection system
A true 3D 1080p cinema projection system for a superb 3D cinematic experience.
Sonys New SXRD Panel technology
The VPL-VW90ES uses Sonys unique SXRD 3 panel display system for smooth, dot-free display, vivid colours and massive true dynamic contrast ratio (150,000:1). Three separate red, blue and green panels combine to give a virtuoso colour performance, with exceptional detail.
Full HD resolution in 3D mode
Sequential Frame delivery means that each frame, for each eye, is shown using the full HD resolution of the projector, so there is no loss of resolution in 3D projection mode.
Flexible 3D setting mode
You can adjust the 3D glasses shutter speed and brightness level. Also adjustable on the VPL-VW90ES is its 3D depth.
240Hz Panel Drive
This projector features SXRD panels that are refreshed at the very high rate of 240Hz, resulting in very low cross-talk from the frame-sequential 3D system. This leads to much more realistic and comfortable viewing.
2D to 3D conversion
The VPL-VW90ES uses Sonys advanced real-time technique for converting 2D source material; Blu Ray / DVD / HD Broadcast / Digital Still Picture into realistic pseudo-3D. This extremely effective process vastly increases the amount of material that can be viewed in 3D mode
Advanced Iris3 control
This is an automatic iris control feature that enhances the contrast. It maximises black levels without diminishing peak brightness.
Motionflow
Motionflowresults in smoother motion in projected images. It has two modes: one creates intermediate frames to reduce jerkiness, and the other inserts a dark frame instead of repeating frames where frame-rate conversion is taking place. This creates smoother-looking motion, and a more cinema-like appearance.
True 24p mode
True 24p modedisplays material at a genuine 24 frames per second for an authentic, film-like appearance. Watch films exactly as the creators intended.
Anamorphic Zoom mode
With this feature, you can see films in their original cinematic aspect ratio (2.35:1 for example) in full resolution, without cropping or letterbox black bands above and below the picture. This does require a third-party a third-party lens adaptor.
Electronically Adjustable Lens Shift
Electronically adjust the projectors lens shift, making it easier to install into a wide variety of locations.
Multiple Cinema Modes
Users can choose from 3 Cinema Modes to match the output of the projector with the characteristics of the projected material. Use this mode in conjunction with Gamma correction adjustments for an even higher degree of control.
Wide range of Gamma correction
A total of 11 Gamma settings provide flexibility to match the brightness curve of the projected image to the image content.
White and Black Level adjustment
Directly adjust white and black levels from the menu
10-bit colour delivery
With 10-bit colour, the VPL-VW90ES delivers smoother gradations between shades of the same colour, without the contours that are visible on other displays.
Sony Digital Video Processing System
A set of Sony-developed technologies that applies eight separate processes to video to increase sharpness and colour clarity.
Automatic motorised lens protector
The VPL-VW90ES is equipped with an automatic motorised lens protector that opens when the projector is powered on, and closes when it is powered off. This keeps the dust of the lens, without users having to remember to fit a lens cap.
Wide range of inputs
The VPL-VW90ES features a wide range of inputs for connection to a variety of sources. Inputs include HDMI 1.4 (2) VGA, Component, S-Video and Composite.
Compatibility with BRAVIA Sync (HDMI CEC)
Control not only the projector but also BRAVIA sync compatible equipment with the supplied remote control.
Extremely low fan noise (as low as 20dB)
A highly effective cooling system means that fan noise is kept to an absolute minimum. With an ultra-quiet fan, users can watch even the quietest parts of movies with no audible distractions from the projector.
Technical Specifications
|
Projection system
|
New SXRD panel,1lens, projection system
|
|
Panel
|
0.61-inch (15.4mm) Full HD SXRD panel,
|
|
Contrast
|
Dynamic contrast 150,000:1
|
|
Brightness
|
1,000 ANSI Lumem
|
|
Lens
|
1.6 times zoom lens (manual),
f=18.5 to 29.6 mm / F2.50 to F3.40
|
|
Lamp Type
|
200W Ultra High Pressure Lamp
|
|
Projection picture size
|
40 to 300 inches (1,016mm to 7,620mm) (measured diagonally)
|
|
Colour System
|
NTSC3.58/PAL/SECAM/NTSC4.43/PAL-M/PAL-N system (switched automatically/manually)
|
|
Acceptable Video Signals
|
15kHz RGB/component 50/60Hz, Progressive component 50/60Hz, 480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i,1080/48i, 1080/60p(HDMI input only), 1080/50p(HDMI input only), 1080/24p(HDMI input only), Composite video, Y/C video
|
|
Video Input
|
1
|
|
Component Input
|
1
|
|
SVideo Input
|
-
|
|
PC Input
|
1
|
|
HDMI
|
2 ( Digital RGB / Y Cb(Pb) Cr(Pr) )
|
|
2D SYNC
|
RJ-45
|
|
Trigger
|
Mini jack Selectable : Power / Anamorphic zoom
|
|
Remote (RS-232C)
|
D-sub 9-pin (Female)
|
|
IR IN (control-s)
|
Mini jack
|
|
Gamma mode
|
11
|
|
Cinema mode
|
3
|
|
3D Capable
|
Yes
|
|
3D Glasses (including battery)
|
3D Glasses (2) , batteries (2)
Pouch for the 3D Glasses (2)
|
|
FIlter attachment for 3D Glasses
|
Regular size (2 pair), Small size (2 pair)
Conversion cable (3D SYNC) (1)
|
|
Projector Lamp
|
LMP-H201 (for replacement)
|
|
Remote Control
|
Remote Commander RM-PJVW85
|
|
Operating Instructions
|
Operating Instructions(1)
|
|
CD_ROM
|
Image Director3 (1)
|
|
Projector Suspension Support
|
PSS-H10
|
|
Dimensions (w/h/d)
|
470x179.2x484.9 mm
|
|
Power requirements
|
AC 100 to 240V, 3.0-1.3A, 50/60H z
|
|
Power consumption
|
Max.:320W,
Standby mode(low):0.5W ( default) Standby mode (standard): 8W
|
|
Mass
|
Approx. 12kg
|
|
|
|
|
04/07
|
Vivotek IP8151P Fixed Network Camera - 1.3MP CMOS Sensor, Real-time H.264, MPEG-4, MJPEG Compression, Supreme Night Visibility, 1280x1024, RJ45 - White
Supreme Night Visibility P-iris WDR Enhanced Focus Assist Network Camera IP8151P
Overview
VIVOTEK IP8151P represents the next-generation in video quality in network cameras. As one of the VIVOTEK's SUPREME Series products, users will be able to experience the utmost in picture clarity through utilization of SONY's latest sensor technology, dubbed "Exmor", which enables the IP8151P to capture exceptional details during daytime, as well as offer unparalleled visibility under low-light conditions through its Supreme Night Visibility feature. Together with WDR enhancement, users can identify image details in extremely bright as well as dark environments.
The IP8151P comes with a P-iris lens, which controls the iris with extreme precision with its built-in stepping motor. By using software controls, the lens maintains the iris opening at an optimal level at all times, resulting in superior sharpness and depth of field as well as image quality. In addition, the IP8151P is also equipped with a focus assist button to allow users to precisely adjust the camera focus. After pushing the focus assist button on the camera unit, an indicator will be displayed onscreen with detailed focus information, which will change in accordance with the manual adjustment. Moreover, continuing to push the button will zoom in on the target area for fine tuning, resulting in better usability and picture clarity.
Also featuring a myriad of other high-end features such as SDHC card slot, PoE, multiple streams, and more, the IP8151P camera is the ideal choice for the most demanding monitoring applications. By providing sharp, smooth video, plus exceptional performance in low-light conditions, the IP8151P can secure a variety of sites such as retail stores, school campuses, and much more.
Features
- 1.3 Megapixel CMOS Sensor
- Supreme Night Visibility
- Up to 30 fps @ 1280x1024 (1.3MP)
- 3.1 ~ 8 mm Vari-focal, P-iris Lens
- Removable IR-cut Filter for Day & Night Function
- Built-in Focus Assist Button for Precise Focus Adjustment
- Supports WDR Enhancement for Unparalleled Visibility in Extremely Bright and Dark Environments
- Real-time H.264, MPEG-4 and MJPEG Compression (Triple Codec)
- Simultaneous Multiple Streams
- ePTZ for Data Efficiency
- Activity Adaptive Streaming for Dynamic Frame Rate Control
- Built-in SD/SDHC Card Slot for On-board Storage
- Built-in 802.3af Compliant PoE
- CS- or C-mount Adjustment Ring for Flexible Lens Installation
Specifications
| System |
CPU: Multimedia SoC
Flash: 128MB
RAM: 256MB
Embedded OS: Linux 2.6 |
| Lens |
f=3.1 ~ 8 mm
F 1.2
P-iris
CS-mount
Vari-focal
Removable IR-cut filter for day & night function
|
| Angle of View |
35.2 ~ 86.7 (horizontal)
26.5 ~ 64.4 (vertical)
43.9 ~ 110.3 (diagonal)
|
| Shutter Time |
1/5 ~ 1/40,000 sec |
| Image sensor |
1/3" CMOS in 1280x1024 Resolution |
| Minimum Illumination |
0.04 Lux / F1.2 ( typical )
0.001 Lux / F1.2 ( B/W ) |
| Video |
Compression: H.264, MPEG-4 & MJPEG
Streaming:
Simultaneous multiple streams
H.264 streaming over UDP, TCP, HTTP or HTTPS
H.264/MPEG-4 multicast streaming
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 multicast streaming
MJPEG streaming over HTTP or HTTPS
Supports activity adaptive streaming for dynamic frame rate control
Supports ePTZ for data efficiency
Supports 3GPP mobile surveillance
Frame rates:
H.264: Up to 30 fps at 1280x1024
MPEG-4: Up to 30 fps at 1280x1024
MJPEG: Up to 30 fps at 1280x1024
BNC connector for video output
NTSC/PAL video output switch
Focus Assist
|
| Image Settings |
Adjustable image size, quality, and bit rate
Time stamp and text caption overlay
Flip & mirror
Configurable brightness, contrast, saturation, sharpness, white balance and exposure
AGCAWBAES
Automatic, manual or scheduled day/night mode
Supports privacy masks
BLC (Backlight compensation)
WDR(widedynamicrange) |
| Audio |
Compression
GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps
G.711 audio encoding, bit rate: 64 kbps, -Law or A-Law
Interface:
Built-in microphone
External microphone input
Audio output
External/Internal microphone switch
Supports two-way audio
Supports audio mute
|
| Networking |
10/100 Mbps Ethernet, RJ-45
ONVIF support
Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X |
| Alarm and Event Management |
Triple-window video motion detection
1 D/I & 1 D/O for external sensor and alarm
Event notification using HTTP, SMTP, or FTP
Local recording of MP4 files
Tamper Detection
|
| On-board Storage |
SD/SDHC card slot
Stores snapshots and video clips
|
| Security |
Multi-level user access with password protection
IP address filtering
HTTPS encrypted data transmission
802.1X port-based authentication for network protection
|
| Users |
10 clients on-line monitoring at the same time |
| Dimensions |
Depth: 154mm
Width: 72mm
Height: 62mm
|
| Weight |
Net: 664 g |
| LED Indicator |
System power and status indicator
System activity and network link indicator
|
| Power |
12V DC
24V AC
Power consumption: Max. 3.6 W
802.3af compliant Power-over-Ethernet (Class 2)
|
| Approvals |
CEC-TickFCCLVDVCCI |
| Operating Environments |
Temperature: -10 ~ 50 C (14 ~ 122 F )
Humidity: 90%
|
| Viewing System Requirements |
OS: Microsoft Windows 2000/XP/Vista/7
Browser: Mozilla Firefox, Internet Explorer 6.x or above
Cell phone: 3GPP player
Real Player: 10.5 or above
Quick Time: 6.5 or above |
| Installation, Management, and Maintenance |
RS-485 interface for scanners, pan/tilts
Installation Wizard 2
32-CH central management software
Supports firmware upgrade
|
| Applications |
SDK available for application development and system integration |
| Warranty |
36 months |
|
|
|
|
04/07
|
Vivotek IP8132 Fixed Network Camera - 1 Mega Pixel, 1/4" CMOS Sensor, 1280x800, Real-time H.264, MPEG-4, RJ-45, Compact Design - White
H.264 Compact Design Fixed Network Camera IP8132
Overview
VIVOTEK IP8132 is an easy-to-use network camera specifically designed for home security applications with a compact, stylish exterior. Equipped with a 1MP sensor enabling viewing resolution of 1280x800 at 30 fps, users need look no further for an all-in-one camera capable of capturing high quality, high resolution video.
Embedded with the VATICS "Mozart" SoC, the camera supports the industry-standard H.264 compression technology, drastically reducing file sizes and conserving valuable network bandwidth. With MPEG-4 and MJPEG compatibility also included, video streams can also be transmitted in any of these formats for versatile applications. The streams can also be individually configured to meet different constraints, thereby further reducing bandwidth and storage requirements. Users can thus receive multiple streams simultaneously in different resolutions, frame rates, and image qualities for viewing on different platforms.
With this network camera, a user can quickly and easily view children, the elderly, or even pets with live, clear videos while away from home. The IP8132 also includes tamper detection and VIVOTEK's 32-channel recording software. With all this and more, the IP8332 is the ideal solution for your surveillance needs.
Features
- Compact, Elegant Design
- 1/4" CMOS Sensor in 1280 X 800 resolution
- Real-time H.264, MPEG-4 and MJPEG Compression (Triple Codec)
- Multiple Simultaneous Streams
- Activity Adaptive Streaming for Dynamic Frame Rate Control
- Privacy Button to Pause Monitoring
- Tamper Detection for Unauthorized Changes
- Supports ONVIF Standard to Simplify Integration and Enhance Interoperability
Specifications
| System |
CPU: Multimedia SoC
Flash: 16MB
RAM: 128MB
Embedded OS: Linux 2.6 |
| Lens |
f=3.45 mm
F 2.4
Board lens
|
| Angle of View |
57.8 (horizontal)
37.8 (vertical)
66 (diagonal)
|
| Shutter Time |
1/15 ~ 1/25,000 sec |
| Image sensor |
1/4" CMOS in 1280x800 Resolution |
| Minimum Illumination |
3.0 Lux @ F2.4 ( typical )
|
| Video |
Compression: H.264, MPEG-4 & MJPEG
Streaming:
Simultaneous multiple streams
H.264 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 multicast streaming
MJPEG streaming over HTTP or HTTPS
Supports activity adaptive streaming for dynamic frame rate control
Supports 3GPP mobile surveillance
Frame rates:
H.264: Up to 30 fps at 1280x800
MPEG-4: Up to 30 fps at 1280x800
MJPEG: Up to 30 fps at 1280x800
|
| Image Settings |
Adjustable image size, quality, and bit rate
Time stamp and text caption overlay
Flip & mirror
Configurable brightness, contrast, saturation, sharpness, white balance and exposure
AGCAWBAES
Supports privacy masks
BLC (Backlight compensation)
|
| Audio |
Compression
GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
G.711 audio encoding, bit rate: 64 kbps, -Law or A-Law
Interface:
Built-in microphone
Supports audio mute
|
| Networking |
10/100 Mbps Ethernet, RJ-45
ONVIF support
Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP |
| Alarm and Event Management |
Triple-window video motion detection
1 D/I & 1 D/O for external sensor and alarm
Event notification using HTTP, SMTP, or FTP
Local recording of MP4 files
Tamper Detection
|
| Security |
Multi-level user access with password protection
IP address filtering
HTTPS encrypted data transmission
|
| Users |
10 clients on-line monitoring at the same time |
| Weight |
Net: 180 g |
| LED Indicator |
System power and status indicator
System activity and network link indicator
Privacy button on
|
| Power |
5V DC
Power consumption: Max. 3.4 W
|
| Approvals |
CEC-TickFCCLVDVCCI |
| Operating Environments |
Temperature: 0 ~ 40 C (32 ~ 104 F )
Humidity: 90%
|
| Viewing System Requirements |
OS: Microsoft Windows 2000/XP/Vista/7
Browser: Mozilla Firefox, Internet Explorer 6.x or above
Cell phone: 3GPP player
Real Player: 10.5 or above
Quick Time: 6.5 or above |
| Installation, Management, and Maintenance |
Installation Wizard 2
32-CH central management software
Supports firmware upgrade
|
| Applications |
SDK available for application development and system integration |
| Warranty |
24 months |
|
|
|
|
Previous Page
|
Next Page
|
|
