| Performance |
|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Number of users | 128 user(s) |
| Video input channels | 64 channels |
| Alarm input channels | 16 |
| Alarm output channels | 9 |
| Maximum resolution | 7680 x 4320 pixels |
| Video formats supported | H.264, H.264+, H.265, H.265+ |
| Supported network protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnPâ„¢, HTTP, HTTPS |
| Languages support | Multi |
| Output bandwidth | 400 Mbit/s |
| Input bandwidth | 400 Mbit/s |
| Wireless LAN features |
|---|
| Wi-Fi | No |
| Hard drive |
|---|
| Number of HDDs supported | 8 |
| Maximum storage capacity | 14 TB |
| HDD interface | SATA |
| HDD size | 3.5" |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 6, 10 |
| Storage |
|---|
| Number of HDDs supported | 8 |
| Maximum storage capacity | 14 TB |
| HDD interface | SATA |
| HDD size | 3.5" |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 6, 10 |
| Ports & interfaces |
|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Audio RCA outputs | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| PS/2 ports quantity | 1 |
| eSATA ports quantity | 1 |
| Internal SATA ports quantity | 5 |
| RS-232 ports | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| BNC video output | Yes |
| RAID levels | 0, 1, 5, 6, 10 |
| USB 2.0 ports quantity | 2 |
| Supported network protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnPâ„¢, HTTP, HTTPS |
| RS-485 ports | 1 |
| RS-232 interface | Yes |
| eSATA | Yes |
| Audio RCA inputs | 1 |
| Features |
|---|
| Rack capacity | 2U |
| Product colour | Black, Silver |
| Rack mounting | Yes |
| Certification | LOA |
| Power |
|---|
| Power consumption (typical) | 50 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| System requirements |
|---|
| Browser supported | IE11, Chrome V57, Firefox V52, Safari V12, Edge V89 |
| Technical details |
|---|
| Sustainability compliance | Yes |
| Compliance certificates | BIS, CB, CE, Federal Communications Commission (FCC), Industry Canada (IC), KC, RCM, REACH, RoHS, UKCA, UL, WEEE |
| Weight & dimensions |
|---|
| Width | 445 mm |
| Depth | 465 mm |
| Height | 93 mm |
| Weight | 10 kg |
