AXIS 02545-001 access control reader Basic access control reader Black, PoE, 12 V, DC, 802.3af, 0—12.95 W, 10/100BASE-TX, Auto-MDIX, RJ-45, 600 mA

Product May Vary From Image
Our Price:
$1,326.60
Quantity:
Part No:
536325
Brand:
AXIS
Manuf No:
02545-001

02545001
Ship Weight:
0.93 KG  Details
Usually Ships:
1-3 Days   More info
Product Description

Axis 02545-001 access control reader Basic access control reader Black

Manufacturer: Axis
Category: Home
Sub-Category: Access Control Readers
SKU: 02545-001
EAN: 8595159515045

Description

Stay flexible. Traditional and modern method of access control in a single reader. The 2N® Access Unit 2.0 Bluetooth & RFID reads both frequencies of RFID cards – 125 kHz and the smart 13.56 MHz. The users can also authenticate with their mobile phone. All they need to do is switch on Bluetooth and install the 2N® Mobile Key application. They can leave their phone in their pocket and simply tap the reader.

Specifications

Technical details
RFID frequency13.56 MHz
Recommended usageIndoor & outdoor
Ethernet LAN data rates10,100 Mbit/s
TypeBasic access control reader
Authentication typeAccess chip/card
Access chip/card readerYes
Product colourBlack
International Protection (IP) codeIP54
Near Field Communication (NFC)Yes
BuzzerYes
Ports & interfaces
Ethernet LAN (RJ-45) ports1
Power
Power over Ethernet (PoE)Yes
DC current (max)2 A
Power consumption600 mA
DC voltage range8 - 12 V
Operational conditions
Storage temperature (T-T)10 - 95 °C
Operating temperature (T-T)-40 - 60 °C
Operating relative humidity (H-H)-40 - 70%
Weight & dimensions
Width107 mm
Height130 mm
Depth28 mm
Power over Ethernet (PoE)
Power over Ethernet (PoE)Yes

Product Warranty


12 Month Return To Base
