| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Day/night mode | Yes |
| Certification | CE, NTRA, VCCI, KC, BSMI, FCC, IC |
| Dynamic range | 120 dB |
| Design |
|---|
| Weatherproof | Yes |
| IK code | IK10 |
| Form factor | Dome |
| Product colour | White, Black |
| Mounting type | Ceiling |
| International Protection (IP) code | IP67 |
| Housing material | Plastic |
| Camera |
|---|
| Minimum illumination | 0.005 lx |
| Field of view (FOV) angle | 107 ° |
| Tilt angle range | 0 - 85 ° |
| Pan range | 0 - 360 ° |
| Camera shutter speed | 1/3 - 1/10000 s |
| Lens viewing angle, horizontal | 90 ° |
| Lens viewing angle, vertical | 48 ° |
| Lens viewing angle, diagonal | 107 ° |
| Image sensor |
|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 1.6 |
| Detect distance | 80 m |
| Observe distance | 33 m |
| Recognize distance | 16 m |
| Identify distance | 8 m |
| Fixed focal length | 4 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 30 m |
| Infra-red wavelength | 850 nm |
| Video |
|---|
| Bit rate control | Variable Bit Rate (VBR) |
| Bit rate | 256 Kbps - 6 Mbps |
| Maximum resolution | 2880 x 1620 pixels |
| Video formats supported | H.264, H.264+, H.265, H.265+ |
| Supported graphics resolutions | 1280 x 720 (HD 720), 2048 x 1280, 2304 x 1296, 2688 x 1520, 1920 x 1080 (HD 1080), 2880 x 1620 |
| Supported video modes | 1080p, 720p, 2560p, 2880p |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Total megapixels | 5 MP |
| Video recording | Yes |
| Audio |
|---|
| Voice codecs | G.711 |
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Sample rate | 8 kHz |
| Built-in microphone | Yes |
| Network |
|---|
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| Storage |
|---|
| Compatible memory cards | MicroSD (TransFlash) |
| Built-in HDD | No |
| Maximum memory card size | 256 GB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Connectivity technology | Wired |
| Management features |
|---|
| Reset button | Yes |
| Power |
|---|
| Power source type | DC |
| Power consumption (typical) | 1.5 W |
| Power consumption (max) | 7 W |
| DC-in jack | Yes |
| Certificates |
|---|
| Certification | CE, NTRA, VCCI, KC, BSMI, FCC, IC |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Package type | Box |
| Height | 85.7 mm |
| Diameter | 11.5 cm |
| Weight | 280 g |
| Package weight | 470 g |
| Packaging content |
|---|
| Number of cameras | 1 |
| Package type | Box |
All The Colors, All The Time
5MP Full-Color Dome Network Camera24/7 Stunning Visual Experience
5MP Super-High DefinitionMonitor 24-hour clear and colorful details even in pitch dark night. VIGI Full-Color camera provides maximum 5MP resolutions and ensures colorful monitoring with its large-aperture lens, high-sensitivity sensor, and attached supplemental lights.
SmartVid-Smart Video EnhancementVIGI’s professional technologies process videos to greatly improve their quality that is vital to your monitoring, including WDR, 3D DNR, Smart IR, and Night Vision.
Human & Vehicle ClassificationIntegrated AI chips support advanced algorithms to distinguish humans and vehicles from other objects. You can flexibly customize alarm rules to match your monitoring needs and receive more accurate event notifications.
Comprehensive AI Detection with Pre-Set Rules SupportedBy setting the detection rules in advance, VIGI AI-powered cameras can accurately capture various abnormal events. This will greatly reduce false alarms and cover your specified monitoring needs in different scenarios.
People & Vehicle AnalyticsQuickly find people and vehicles of interest using a series of attributes.
People AnalyticsFilter people of interest by various attributes, such as gender, hair length, and clothing, allowing you to improve search efficiency.
Vehicle AnalyticsIdentify and search for vehicles of interest based on vehicle color and type for targeting meaningful events in a short time.
No More Silent Surveillance
Built-In MicrophoneThe VIGI camera features a built-in microphone to record anything going on within a 15-ft radius of the camera. This gives you more detailed monitoring for greater peace of mind.
IK10 Vandal-Proof & IP67 WaterproofWith vandal-resistant, rugged housing and waterproof design, this VIGI dome camera is built tough to withstand vandalism and harsh environments with rain and dust for constant security anywhere and anytime.
Smart Video Coding by H.265+
Compresses the video size without sacrificing video quality, easing the network load and saving disk space.
Flexible Storage
Local storage is available for each method, as well as onboard storage with an SD card slot (up to 256 GB).
PoE/12V DC
Two power supply ways not only give you more convenience but also make your wiring remarkably easy.
Flexible Installation
Easily route your camera’s cable into a dropped ceiling or avoid drilling by slotting it through the camera’s side outlet.
Remote ManagementTake full control over your security anytime and anywhere on the VIGI app or client.
One system. Full security.
Run your business with peace of mind.The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build – whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
