Image Product description Price Buy
Olympus E-M5MII weather proof SLV

Olympus OM-D E-M5 Mark II 16MP Digital Camera Weather Proof Kit w. 12-50mm F3.5-6.3 Lens - Silver


- 16.1MP, 4/3 Live MOS Sensor, 5-Axis In Body IS, 5FPS, 3.0" Vari-Angle Monitor, 81-Point-AF, Wifi :: E-M5MII weather proof SLV

Overview



At a glance

The E-M5 Mark II sits squarely in the sweet spot for the creative shooterwho needs a portable system with all the power to realize their creative pursuits. High-speed sensor and image processor. Large interactive EVF. Touch and Swivel LCD monitor with convenient variable angle positioning. Lightning-fast autofocus and Manual Focus options that nail everything from serious fast sports action to dramatic portraits. Plus, its all metal body is sealed for protection against dust and moisture for shooting in extreme conditions.

 16 Megapixel Live MOS Sensor

 10fps Sequential Shooting

 81-Point Selectable Autofocus

 40 Megapixel High Res Shot Mode

 Advanced 5-Axis Image Stabilization



 1/8000s High-Speed Mechanical Shutter



 Built-In Wi-Fi

 Focus Bracketing (New v2.0 Firmware)

 Lightweight, Weatherproof Body



 Full HD 1080p Video

 Fully Articulating 3.0 Touch Screen

 1/16000s Silent Electronic Shutter

THE WORLD’S MOST ADVANCED IMAGE STABILIZATION

The new OM-D E-M5 Mark II features the most sophisticated image stabilization technology ever offered in an interchangeable lens camera.* The ultra-sensitive 5-axis VCM (voice coil motor) system is so responsive and accurate, you can shoot sharp images in low light and capture silky smooth video, hand-held without a tripod. And because the IS system is in the body of the camera, youll get blur-free results regardless of which lens you use.

SERIOUS VIDEO MADE SIMPLE

Forget about obtrusive rigs that make shooting movies a production. The E-M5 Mark IIs compact size and 5-axis image stabilization make it ideal for hand-held video. Pro-level features include high bit rate recording, variable frame rate, and focusing peaking while filming, and the new Flat Color Movie mode introduced in Firmware 2.0. The E-M5 Mark II also features a 270 vari-angle LCD screen with an all-new robust touch screen interface for easy adjustments to AF point, exposure, aperture, shutter speed and more without interrupting recording.

FULLY PROOFED & PORTABLE

At nearly 40% lighter than conventional DSLRs, the bring-it-anywhere E-M5 Mark II is a highly accomplished ergonomic photographic tool whose shape and materials were chosen to keep the body slim but easy to shoot with all day. Plus, its all metal body is sealed for splashproof, dustproof and freezeproof protection. With a full array of similarly proofed accessories, including the bundled FL-LM3 swivel bounce flash and an optional powered battery grip as well as nine* M.Zuiko Digital weather-sealed lenses, youll be ready to shoot in the most extreme environments.

A LENS FOR EVERY SHOT

From starscapes to landscapes, macro to zoom, the OM-D E-M5 Mark II is ready for whatever and however you like to shoot. Build your system with lenses from our 20-strong and growing M.Zuiko Digital lens lineup and youll be ready for anything. From compact primes to powerful weatherproof telephotos with professional-grade glass, our optically superior lenses are designed to deliver spectacular images in astonishing detail.

UPGRADE YOUR IMAGES

The high-speed 16 Megapixel Live MOS sensor and TruePic VII image processor combo that has won accolades from professional publications and websites is at the heart of the E-M5 Mark IIs imaging performance. This duo makes possible the 40 Megapixel high-resolution shooting option (great for landscapes and studio shots that require the maximum possible detail), 10fps burst shooting, a blazing fast maximum shutter speed of 1/8000 sec and a high-performance electronic first curtain and a purely electronic shutter for totally silent shooting.

The"Olympus High Res Shot Raw File Photoshop Plug-in"processes High Res Shot raw files (.orf files) so they can be viewed on CS5 or newer 64-bit Adobe Photoshop.

CREATIVE SHOOTING & WIRELESS SHARING

Shoot and share like never before with features like an interactive, high-resolution and high magnification electronic viewfinder, three-inch touch-screen LCD monitor with variable angle positioning and built-in Wi-Fi for instant sharing and remote shooting. Capture stunning star trails and streetscapes with Live Composite, which automatically blends multiple exposures for incredibly detailed night scenes. In the studio? Compatibility with Advanced Olympus Capture creates a seamless interface between camera and computer for powerful camera control and image transfer.

Key Specifications

Sensor Effective Resolution / Type

16.1 Megapixel Live MOS

Processor

TruePic VII

Focusing System

F.A.S.T. AF (Contrast Detection)

Image Stabilization System

5-Axis In Body Image Stabilization

Viewfinder

2.36M dot LCD Electronic Viewfinder

Rear Monitor

3.0 Vari-Angle Touch LCD

Weatherproof

Dust, Splash, and Freeze-proof

Sequential Shooting Speed

10fps [H] mode 5fps [L] mode

mechanical shutter

11fps (silent electronic shutter)

Flash

Bundled FL-LM3 (dust & splash-proof)

Special Features

40mp Hi Res Shot Mode

Product Diagram

Link to product page    $1,519.76
Olympus E-M5MII weather proof Blk

Olympus OM-D E-M5 Mark II 16MP Digital Camera Weather Proof Kit w. 12-50mm F3.5-6.3 Lens - Black


- 16.1MP, 4/3 Live MOS Sensor, 5-Axis In Body IS, 5FPS, 3.0" Vari-Angle Monitor, 81-Point-AF, Wifi :: E-M5MII weather proof Blk

Overview



At a glance

The E-M5 Mark II sits squarely in the sweet spot for the creative shooterwho needs a portable system with all the power to realize their creative pursuits. High-speed sensor and image processor. Large interactive EVF. Touch and Swivel LCD monitor with convenient variable angle positioning. Lightning-fast autofocus and Manual Focus options that nail everything from serious fast sports action to dramatic portraits. Plus, its all metal body is sealed for protection against dust and moisture for shooting in extreme conditions.

 16 Megapixel Live MOS Sensor

 10fps Sequential Shooting

 81-Point Selectable Autofocus

 40 Megapixel High Res Shot Mode

 Advanced 5-Axis Image Stabilization



 1/8000s High-Speed Mechanical Shutter



 Built-In Wi-Fi

 Focus Bracketing (New v2.0 Firmware)

 Lightweight, Weatherproof Body



 Full HD 1080p Video

 Fully Articulating 3.0 Touch Screen

 1/16000s Silent Electronic Shutter

THE WORLD’S MOST ADVANCED IMAGE STABILIZATION

The new OM-D E-M5 Mark II features the most sophisticated image stabilization technology ever offered in an interchangeable lens camera.* The ultra-sensitive 5-axis VCM (voice coil motor) system is so responsive and accurate, you can shoot sharp images in low light and capture silky smooth video, hand-held without a tripod. And because the IS system is in the body of the camera, youll get blur-free results regardless of which lens you use.

SERIOUS VIDEO MADE SIMPLE

Forget about obtrusive rigs that make shooting movies a production. The E-M5 Mark IIs compact size and 5-axis image stabilization make it ideal for hand-held video. Pro-level features include high bit rate recording, variable frame rate, and focusing peaking while filming, and the new Flat Color Movie mode introduced in Firmware 2.0. The E-M5 Mark II also features a 270 vari-angle LCD screen with an all-new robust touch screen interface for easy adjustments to AF point, exposure, aperture, shutter speed and more without interrupting recording.

FULLY PROOFED & PORTABLE

At nearly 40% lighter than conventional DSLRs, the bring-it-anywhere E-M5 Mark II is a highly accomplished ergonomic photographic tool whose shape and materials were chosen to keep the body slim but easy to shoot with all day. Plus, its all metal body is sealed for splashproof, dustproof and freezeproof protection. With a full array of similarly proofed accessories, including the bundled FL-LM3 swivel bounce flash and an optional powered battery grip as well as nine* M.Zuiko Digital weather-sealed lenses, youll be ready to shoot in the most extreme environments.

A LENS FOR EVERY SHOT

From starscapes to landscapes, macro to zoom, the OM-D E-M5 Mark II is ready for whatever and however you like to shoot. Build your system with lenses from our 20-strong and growing M.Zuiko Digital lens lineup and youll be ready for anything. From compact primes to powerful weatherproof telephotos with professional-grade glass, our optically superior lenses are designed to deliver spectacular images in astonishing detail.

UPGRADE YOUR IMAGES

The high-speed 16 Megapixel Live MOS sensor and TruePic VII image processor combo that has won accolades from professional publications and websites is at the heart of the E-M5 Mark IIs imaging performance. This duo makes possible the 40 Megapixel high-resolution shooting option (great for landscapes and studio shots that require the maximum possible detail), 10fps burst shooting, a blazing fast maximum shutter speed of 1/8000 sec and a high-performance electronic first curtain and a purely electronic shutter for totally silent shooting.

The"Olympus High Res Shot Raw File Photoshop Plug-in"processes High Res Shot raw files (.orf files) so they can be viewed on CS5 or newer 64-bit Adobe Photoshop.

CREATIVE SHOOTING & WIRELESS SHARING

Shoot and share like never before with features like an interactive, high-resolution and high magnification electronic viewfinder, three-inch touch-screen LCD monitor with variable angle positioning and built-in Wi-Fi for instant sharing and remote shooting. Capture stunning star trails and streetscapes with Live Composite, which automatically blends multiple exposures for incredibly detailed night scenes. In the studio? Compatibility with Advanced Olympus Capture creates a seamless interface between camera and computer for powerful camera control and image transfer.

Key Specifications

Sensor Effective Resolution / Type

16.1 Megapixel Live MOS

Processor

TruePic VII

Focusing System

F.A.S.T. AF (Contrast Detection)

Image Stabilization System

5-Axis In Body Image Stabilization

Viewfinder

2.36M dot LCD Electronic Viewfinder

Rear Monitor

3.0 Vari-Angle Touch LCD

Weatherproof

Dust, Splash, and Freeze-proof

Sequential Shooting Speed

10fps [H] mode 5fps [L] mode

mechanical shutter

11fps (silent electronic shutter)

Flash

Bundled FL-LM3 (dust & splash-proof)

Special Features

40mp Hi Res Shot Mode

Product Diagram

Link to product page    $1,519.75
Olympus E-M5 MARK II Body Silver

Olympus OM-D E-M5 Mark II 16MP Mirroless Digital Camera - Body Only, Silver


- 16.1MP, 4/3 Live MOS Sensor, 5-Axis In Body IS, 5FPS, 3.0" Vari-Angle Monitor, 81-Point-AF, Wifi :: E-M5 MARK II Body Silver

Overview



The World’s Most Advanced Image Stabilisation Puts You on Top of Your Shot. The Olympus OM-D E-M5 Mark II.

The 5-axis VCM image stabilisation, which powerfully compensates for any type of camera shake, has improved. Not only has it achieved the world's highest*1compensation performance of 5 shutter speed steps for still images, but image stabilisation for movies has also significantly improved. The dustproof and splashproof construction, hailed as absolutely reliable by many pro photographers, is now also freezeproof for even better reliability under the harshest of conditions. This incredibly mobile body is packed with the latest technologies, including OM-D Movie for cinema-quality, hand-held interchangeable lens camera shooting, and the world's shortest*2shooting time lag, made possible by super-fast autofocusing. Furthermore, a firmware upgrade will be made available to incorporate the latest functions and performance, and to keep the E-M5 Mark II in top condition. The incredibly high performance and excellent mobility the E-M5 Mark II provides opens doors to new shooting experiences.

Features added or improved through firmware version 2.0

  1. 5-axis Sync IS for camera shake compensation equivalent to 6 shutter speed steps[*]
  2. Olympus Capture Version 1.1 tethered shooting software is now supported.
  3. S-OVF (Simulated OVF) has been added to provide a view that is similar to that of the unaided eye.
  4. 4K Time Lapse Movie has been added.
  5. Focus Bracketing has been added for shifting the focus slightly while shooting.
  6. Live Composite shooting can now be controlled remotely using the Olympus Image Share smartphone app.
  7. Dedicated movie picture mode Muted Colour" has been added for colour grading movies.
  8. A slate tone can now be added for convenient movies, has been added.
  9. Synchronised recording start/stop operation between the camera and linear PCM recorder is now supported.
  10. Disable MF clutch now supported.

Top-class, In-body 5-axis Image Stabilisation

The improved in-body 5-axis image stabilisation achieves compensation ability equal to a world's highest*1 5 steps of shutter speed, making hand-held shooting enjoyable, and making it possible to shoot at a telephoto end without worrying about camera shake even in dark locations



Dustproof & Splashproof Compact Body & Lens System

An uncompromised form, designed in pursuit of excellent operability, combines with a dustproof and splashproof camera body and lenses to make shooting in any environment possible.



OM-D Movie Delivers Hand-held Video with Cinema Quality

The further advanced in-body 5-axis image stabilisation enables stable movie recording even during active camera work. The compact, lightweight OM-D allows you to draw out natural expressions of the subjects without making them conscious of the camera. OM-D Movie achieves cinema-quality recordings and amazing mobility.



Capture Your Imagination with Phenomenal Imaging Power

Zuiko Lens Systems were designed specifically for digital cameras and boast amazing optical performance. In combination with the high-quality sensor, image processor, and amazing image stabilisation system, they provide outstanding image quality. The E-M5 Mark II introduces 40M High Res Shot, which is perfect for aritistic photos and landscapes.



Large EVF with Stunning Resolution

E-M5 Mark II features a large, high-resolution EVF that rivals that of full-frame DSLR cameras. The super large EVF display allows you to see 100% field of view with a 1.48x magnification and has a 2.36 million dot high resolution display. Numerous functions that take advantage of the EVF are included, such as Adaptive Brightness Technology for a natural view that is like an optical viewfinder, and Colour Creator for controlling colour as you like.



FAST AF for Amazing High-speed Sequential Shots

High-speed performance hasimproved further, with features such as the FAST AF system now offering the world's shortest*2 shooting time lag, and 5 fps AF-tracking RAW sequential shooting available until the card is full. The E-M5 Mark II is equipped with a high-speed 1/8000 sec. mechanical shutter  used on many high-end SLR cameras. Fast enough that you will never miss even the fastest moving subjects.



More Features

  • 14 Art Filters expand the possibilities of photographic expression
  • Photo Story lets you shoot multiple photos of the same scene to create a single image
  • Two HDR modes and HDR Bracketing (HDR-BKT)
  • Live Composite lets you capture movement of light as solid light trails
  • Live Bulb and Live Time update the image display during exposure
  • LV Boost II convenient for shooting stars
  • Keystone compensation allows tilt-shift photography with any lens
  • The digital level gauge corresponds to vertical and horizontal directions
  • Built-in Wi-Fi and Olympus Image Share
  • Camera control system and the dedicated computer app Olympus Capture
  • Olympus Viewer 3 for smart management of digital workflow
  • Quick Sleep mode enables up to 750 shots
  • Improved, easy to use GUI

Specifications

Product type

Product type

Micro Four Thirds interchangeable lens system camera

Memory

SD Memory Card (SDHC, SDXC, UHS-I, II compatible,
Eye-Fi Card compatible*)

Not compatible with Endless Memory.

Screen size

17.3mm and 13.0mm

Lens mount

Micro Four Thirds mount

Image sensor

Product type

4/3 Live MOS Sensor

Number of pixels

Approx. 16.1 million pixels.

Total number of pixels: approx. 17.20 million pixels

Aspect ratio

1.33 (4:3)

Dust reduction

Supersonic Wave Filter (image sensor dust reduction system)

Recording (still)

Recording format

DCF, DPOF compatible / Exif, PRINT Image Matching III,
MPO compatible

File format

RAW (12-bit lossless compression), JPEG, JPEG+RAW,
MPO (3D still)

Recording image size

[RAW] 4608 x 3456

[JPEG] 4608 x 3456 to 640 x 480

File size

RAW: 4608(H)x3456(V) (approx. 1/1.5 lossless compressed)
Approx. 17MB

Set1(LF): 4608(H)x3456(V)  (1/4 compressed) Approx. 7.5MB

Set2(LN): 4608(H)x3456(V)  (1/8 compressed) Approx. 3.5MB

Set3(MN): 3200(H)x2400(V) (1/8 compressed) Approx. 1.7MB

Set4(SN): 1280(H)x960(V) (1/8 compressed) Approx. 0.4MB

Image Stabilisation System

Type

Built-in 5-axis* sensor-shift image stabilisation for movie and still photos

 yaw/pitch/roll/vertical shift/horizontal shift

Mode

4 modes (S-IS AUTO, S-IS1, S-IS2, S-IS3), OFF

Live View image stabilisation

Activation by half-pressing shutter button  or  enlarging view

Focal length setting

With

5 axis Sync IS

With

When combined with 5-axis Sync IS compatible M.Zuiko Digital lenses

Stabilisation performance

5.0 EV

Based on CIPA standards, when used with M.Zuiko Digital ED 12-50mm F3.5-6.3 EZ, at focal length of 50mm (35mm equivalent focal length: 100mm), in pitch/yaw direction.

Lens IS prioritye

With

Finder

Type

Eye-level electronic viewfinder,  approx. 2.36M-dot

Field of view /
Viewfinder magnification

Approx. 100% / Approx. 1.30x*1 - 1.48x*2 (-1m-1, 50mm lens, Infinity)

1: at Finder Style 1, 2 (aspect 4:3)

2: at Finder Style 3 (aspect 4:3)

Eye point / Dioptre adjustment
range

Approx. 21mm (-1m-1, Distance from rear lens surface) /
Approx. -4 to +2m-1

Preview

Live View preview with depth of field preview lock

Display Grid

Off / normal grid / golden grid / scale / diagonal / movie grid

Level gauge display

2-axis (horizontal/vertical) level gauge

Viewfinder style

3 styles

Brightness adjustment /
Colour temperature adjustment

Automatic control of adaptive brightness technology /
manual control (7 levels)

Eyecup

Interchangeable with separately available EP-16 eyecup

S-OVF (Simulated OVF)

Expands Live View Dynamic Range

Available in the EVF when shooting in PASM modes. Art Filters,
exposure compensation adjustments, and white balance adjustments
will not be reflected.

Live view

Live view

Approx. 100% field of view, exposure compensation preview,
WB adjustment preview, gradation preview, face detection preview
(up to 8 faces), grid line, magnification display (x3/x5/x7/x10/x14),
Display modes: Standard, Histogram, Highlight & Shadow,
Level Gauge, Off (Image Only)

Preview

Preview with depth of field preview lock

Monitor

Monitor type

3.0-inch vari-angle monitor*

 Approx.1037k dots (3:2), electrostatic capacitance touch panel

Touch control

Shutter release, magnification, AF area selection, AF area size adjustment,
frame forward/backward, magnified playback, Live Guide,
Super Control Panel, Art Filter selection, scene mode selection,
Wi-Fi connection, selfie shutter release

Tilting capability

With (mirror display when monitor is in self portrait position)

Brightness /
Colour temperature control

7 levels / 7 levels

Colour tone select

Vivid / Natural

Focusing

AF mode

High-speed imager AF

Focus mode

Single AF (S-AF) / Continuous AF (C-AF) / Manual Focus (MF) /
S-AF + MF / AF tracking (C-AF + TR)

Full-time AF

With

Magnified frame AF /
Magnified AF

Selectable from over 800 AF points

Selectable magnification: x3, x5, x7, x10(Default), x14

Super Spot AF*

Available only when a Micro Four Thirds lens is attached

Face detection AF /
Eye detect AF

With

Eye Detection AF mode : off / nearer-eye priority / right-eye priority /
 left-eye priority

Focusing point /
Focusing point selection

81-area multiple AF / All target, group target area (9-area),
single target(normal), single target(small)

AF illuminator

With

Manual focus assist

Focus ring rotation activates Live View image magnification and/
or focus peaking when in S-AF+MF or MF mode

Peaking function

Activate with Fn button or focus ring

Change peaking settings using the Info button

Colour selection: white, black, red, yellow

Intensity selection: high, normal, low

Back light effect: on, off

Exposure Control (Still)

Metering system
(TTL Image sensor metering)

Digital ESP metering (324-area multi pattern metering),
center-weighted average metering, spot metering, spot metering
with highlight control, spot metering with shadow control

Metering area

EV -2 - 20 (using 17mm F2.8, ISO 100)

Exposure mode

iAUTO, P: Program AE (Program shift can be performed),
 A: Aperture priority AE,

S: Shutter priority AE, M: Manual, Bulb, Time, Scene select  AE,
Art Filter,

Underwater wide / macro*, My Set

Selectable from menu as a function on Fn button

My set can be set to mode dial function

Scene select AE

Portrait, e-Portrait, Landscape, Landscape + Portrait, Sport,
Hand-held Starlight*1, Night scene, Night + Portrait, Children, High Key,
Low Key, DIS mode, Macro, Nature Macro, Candle, Sunset, Documents,
Panorama, Fireworks, Beach & Snow, Fisheye Conv., Wide Conv.,
Macro Conv., Panning, 3D*2

1: 8 images automatically shot and combined into a single image composite

2: For 3D lens(H-FT012 by Panasonic) only, still photo only

ISO sensitivity

AUTO ISO : LOW(approx. 100) 25600 (customizable, Defalut:LOW-1600)

Manual ISO : LOW(approx.100), 200 - 25600, 1/3 or 1 EV steps selectable

Exposure compensation

Still photo 5 EV, movie 3 EV, with selectable EV adjustment steps
(1/3, 1/2, 1)

HDR shooting, monitor and EVF displays only up to 3 EV.

AE lock

Locks with a half-press of the shutter button
(can be set to Fn button as well)

Shutter

Shutter type

Focal-plane shutter / 1/8000 - 60 sec., with selectable EV
adjustment steps (1/3, 1/2, 1)

Bulb/Time: selectable exposure time (1/2/4/8/15/20/25/30 min.),
with 8-min. default setting

Flash

Flash intensity control method

TTL Auto, Auto*, Manual, Super FP*(FP-TTL AUTO, FP-MANUAL)

Available on the external flash

Built-in flash

-

Bundled standard flash

FL-LM3(dustproof and splashproof flash)

GN9.1(ISO100m) / GN=12.9(ISO200m)

Bounce Capability (up and down: 45, 60, 75, 90 degree /
left and right 30, 60, 90, 120, 150, 180 degree)

Powered by the camera

Flash mode

Flash Auto, Redeye, Fill-in, Flash Off, Red-eye Slow sync.(1st curtain),
Slow sync.(1st curtain), Slow sync.(2nd curtain),
Manual(1/1(FULL) - 1/64)

Synchronisation speed

1/250 sec.

 Super FP: 1/125-1/8000 sec.

Flash intensity control

Up to 3 EV in 0.3, 0.5, 1 EV steps selectable

Compatible external flash

FL-50R, FL-36R, FL-20, FL-14, FL-300R, FL-600R

Wireless flash control

Compatible external flash

FL-50R, FL-36R, FL-300R, FL-600R

Control method

Triggered and controlled by the bundled FL-LM3 or FL-600R

(Olympus Wireless RC Flash system compatible)

External Flash control mode

TTL Auto, Auto, Manual, FP-TTL-AUTO, FP-MANUAL

Channel

4 channels

Group No.

4 groups (External flash 3 groups + commander flash* )

FL-LM3 / FL-600R

Drive

Sequential shooting
maximum speed

[Sequential shooting H mode] approx 10.0 fps

IS OFF

Focus and exposure are fixed at the values for the first shot.

[Sequential shooting L mode] approx 5.0 fps

When using the M.ZUIKO DIGITAL ED 12-50mm F3.5-6.3 EZ

Max. recordable pictures

[RAW]  Max. frames (in 5.0 seq. shooting L)  Max. 16 frames (in 10.0 seq. shooting H)

 on sequential shooting*

[JPEG]  Max. frames (in 5.0 seq. shooting L)  Max. 19 frames (in 10.0 seq. shooting H)

When using the M.Zuiko Digital ED 12-40mm F2.8 PRO

With TOSHIBA SDHC UHS-II R260W240 EXCERIA PRO

Self-timer

Operation time: 12 sec., 2 sec., custom (Wait time: 1-30sec., Shot interval: 0.5/1/2/3sec., Number of shots: 1-10, Every time AF: ON/OFF)

Bracketing

Exposure bracketing

2, 3 or 5 frames in 0.3/0.7/1.0EV steps selectable,
7 frames in 0.3/0.7EV steps selectable

AE-BKT can be programmed to the Fn-button.

ISO bracketing

3 frames in 0.3/0.7/1.0EV steps selectable

White balance bracketing

3 frames in 2, 4, 6 steps selectable in each A-B/G-M axis.

Flash bracketing

3 frames in 0.3/0.7/1.0EV step selectable

Art filter bracketing

i-Enhance, Vivid, Natural, Muted, Portrait, Monotone, Custom,
Art Filters selectable

Focus Bracketing Mode

3-999 shots / 1-10 focus steps (movement differential)

Compatible with Micro Four Thirds AF lenses

Focus Stacking Mode

Not available

HDR function

HDR(Auto composite)

HDR1, HDR2 (painting-like)

Maximum shutter speed setting is 1 sec.

Exposure compensation can be performed.

Bracketing for HDR postprocess

3 or 5 frames in 2.0/3.0EV steps selectable,
7 frames in 2.0EV steps selectable.

This function does not execute HDR processing.

HDR function can be assigned to the Fn-button.

Art Filter

Mode (Variation / Effect)

Pop Art (I, II / a.b.c.d.e.f.)

Soft Focus ( - / c.e.)

Pale & Light Colour (I, II / a.b.c.d.f.)

Light Tone ( - / d.f.)

Grainy Film (I, II / b.c.d.g.h)

Pin Hole (I, II, III / d.)

Diorama ( I,II  / d.)

Cross Process (I, II / b.c.d.f.)

Gentle Sepia ( - / a.b.c.d.f.)

Dramatic Tone (I / b.c.d.e.f.)  (II / b.c.d.e.f.g.h)

Key Line (I, II / a.b.c.d.e.)

Water Colour (I, II / a.b.c.d.)

Vintage (I, II, III / a.b.c.d.e.f.i)

Partial Colour (I, II, III / a.b.c.d.e.f)

Art Effect

a. Soft Focus Effect

b. Pin-Hole Effect

c. White Edge Effect

d. Frame Effect

e. Star Light Effect

f. Blur Effect (Top & bottom, Left & Right)

g. B&W Effect (None, Yellow, Orange, Red, Green)

h. Pict. Tone (None, Sepia, Blue, Purple, Green)

i. Shade Effect (Top & bottom, Left & Right)

Colour Ring (for partial colour)

18 colour selectable

Photo Story

Type (Variation / Flame /
 Number of divided parts)

Standard (I, II, III, IV / abcd / ABCD)

Fun Frame (I, II, III / / )

Speed (- / - / AEF)

Zoom in / out (, / a, c / A, G)

Layout (I, II, III, IV / / -)

Frame Effect

a. White Frame

b. White Frame & White Edge Effect

c. Black Frame

d. White Frame & Pin Hole Effect

Aspect & Window Pattern

A. 4:3, 2 frames

B. 4:3, 3 frames

C. 1:1. 2 frames

D. 1:1, 3 frames

E. 1:1, 4 frames

F. 16:9. 5 frames

G. 16:9, 2 frames

Hold function

With

Movie

Recording format

MOV(MPEG-4AVC/H.264) , AVI(Motion JPEG)

Mode / frame rate /
compression method

[MOV]

1920x1080(FHD) / 30p, 25p, 24p / ALL-I(A-I), IPB(SF, F, N)

1920x1080(FHD) / 60p, 50p / IPB(SF, F, N)

1280x720(HD) / 60p, 50p, 30p, 25p, 24p / ALL-I (A-I), IPB(SF, F, N)

60p:59.94fps, 50p:50.00fps, 30p:29.97fps, 25p:25.00fps, 24p:23.98fps

FHD ALL-I (A-I: approx. 77Mbps)

FHD IPB(SF: approx. 52Mbps, F:approx. 30Mbps, N:approx. 18Mbps)

[AVI]

1280x720(HD) / 30p

640x480(SD) / 30p

Frame rates may drop when particular Art Filters and
Movie Effect are used

Class 10 or higher SD card is recommended for shooting movies

UHS-II or UHS-I Class3 card is recommended for ALL-I shooting.

Maximum recording time

[MOV] Approx. 29min

[AVI] HD: Approx. 7min* / SD: Approx. 14min*

Excluding when particular Art Filters are used

Art Filter Movie

With*

Frame rate: lower.

Movie Effect

One-shot Echo / Multi-echo / Art Fade / Old Film

One-push Movie Digital
Conveter

x4

Time Lapse Movie

[AVI]

38402160(4K)/5fps

19201080(FHD)/5fps,10fps,15fps

1280720(HD)/5fps,10fps,15fps,30fps

Photo in Movie

With (mode1 / mode2)

mode1 is available when recording framerate is less than 30p.

Clips

1, 2, 4, 8 sec

 (Further continued shooting possible by pressing movie record button again)

Quick Movie / Slow Movie

With

IS for Movie

M-IS1(Image sensor shift and electronic image stabilizer with multi motion IS),

M-IS2(Image sensor shift with multi motion IS), Off

Field of view may be affected in M-IS1.

Grid Line / Focus Peaking

4 types of grid lines / 4 colours for focus peaking

Time code

Rec run / free run, drop frame / non-drop frame

Live View Output via HDMI

With (GUI* is shown on connected device only, and peaking function is not available when connected by HDMI.)

GUI can be hidden on the connected device by pressing down on INFO button for recording an external drive under the following condition. Movie quality: YCbCr 4:2:2 / Frame rate: same as movie setting (24p, 30p and 60p settings are not recommended.) / Sound recording: not available

Movie picture mode

Flat

Exposure Control

Program AE, aperture priority AE, shutter priority AE, manual

AE Lock

With

Recording(Sound)

Recording format

Wave Format (Stereo linear PCM/16-bit, Sampling frequency 48kHz)

Microphone / Speaker

Stereo/Mono

Microphone function

Wind noise reduction,  Recording volume, Microphone volume limiter

Audio dubbing possible for still pictures (up to 30 sec.)

Linking with Olympus
PCM Recorders

Slate Tone/Synchronised Audio Rec-Movie Rec

LS-100 compatible

White Balance

White balance mode

Auto WB, 7 Preset WBs, 4 Capture WBs, Custom WB(Kelvin setting)

White balance compensation

7 steps in each A-B/G-M axis

Except for Custom WB

Colour Mode

Colour matrix

sRGB, Adobe RGB

Picture Mode

Mode

i-Enhance, Vivid, Natural, Flat, Portrait, Black and White, Custom, e-Portrait, Colour Creator, Art Filter, Underwater

Gradation

Auto, Normal, High Key, Low Key [except Art Filters]

Keystone Compensation

Keystone Compensation

With (can be confirmed on Live View)

High Res Shot

Resolution

Equivalent to 40M pixel sensor (8 shots combined into a single JPEG using sensor shift)

Available in P/A/S/M mode, RAW+JPEG or JPEG.

JPEG: 7296 x 5472 / RAW: 9216 x 6912

RAW data can be developed in-camera.  Development by
PC is possible with the appropriate plug-in.

Shutter Type / Shutter Speed

Electronic shutter / 1/8000 - 8 sec.

Anti-shock Mode

Shutter Type / Shutter Speed

Electronic first curtain shutter  /  1/320* - 60sec

For speeds over 1/320 sec., mechanical shutter
will automatically be selected.

Shutter start delay

0,  1/8,  1/4,  1/2,  1,  2,  4,  8,  15,  30sec

Silent Mode

Shutter Type / Shutter Speed

Electronic shutter  /  1/16000 - 60sec

Shutter start delay

0, 1/8, 1/4, 1/2, 1, 2, 4, 8, 15, 30sec

Live Bulb / Live Time

Update interval time

0.5 sec - 60 sec

Live Composite

Update interval time /
composite method

0.5 sec - 60 sec / Lighten Mode (Bright area prioritization)

Interval Mode

Interval Mode

Interval Time 1sec. - 24 Hours,  Max 999 frames.

Available on making Time-lapse movie automatically

Multi Exposure

Number of picture / Function

2 frames / Auto gain, Exposing on Recorded picture(RAW)

Multi Aspect

Aspect Ratio

4:3(Default) / 3:2 / 16:9 / 1:1 / 3:4

Level Gauge

Detection

2-axis

One push Tele-converter

Magnification

x2

Wi-Fi Function

GPS info. Function

Via smartphone GPS data

Wireless Shooting*

Live View, Rec View, Wireless Touch AF shutter, Self Timer (w/Countdown guidance, Sequential shooting, movie recording capability), Wireless Release, Movie Recording, Power Off, iAuto / ART / P / A / S / M (Live Bulb, Live Time, Composite) and drive mode can be selected.* Aperture, shutter speed, exposure, ISO sensitivity, white balance can be adjusted.*

Shooting with a smartphone

When in private connection

Image Share

File Type: JPEG* , MOV

Connect to up to 4 devices simultaneously.  Marking function for image share.

Excluding MPO file

Easy Connection

QR code setting

Tetherd shooting

Tethered shooting

Via USB connection, with use of Olympus Capture tethering software
(camera can be controlled by both the camera and computer)

Playback

Playback mode

Single-frame, Information display, Index display (4/9/25/100 frames),
Calendar, Enlargement (2x - 14x), Movie (with sound, FF/REW/Pause),
Picture rotation (auto), Slideshow (with sound including BGM,
Slide show effects, replaceable BGM), Light Box display

Information display

Histogram (independent luminance / RGB available),
Highlight/Shadow point warning, AF frame, Photographic information,
OFF

Menu

Languages

34 languages selectable:

- English, French, German, Spanish, Italian, Japanese, Korean, Traditional Chinese, Simplified Chinese, Russian, Czech, Dutch, Danish, Polish,
Portuguese, Swedish, Norwegian, Finnish, Croatian, Slovenian,
Hungarian, Greek, Slovakian, Turkish, Latvian, Estonian, Lithuanian,
Ukrainian, Serbian, Bulgarian, Rumanian, Indonesian, Malay, Thai

Image Editing

Editing function

RAW data edit, Gradation auto, Monochrome, Sepia, Red-eye fix, Saturation, Resize (1280x960, 640x480, 320x240), Trimming, Aspect, e-Portrait, Image Overlay, Postrecording

RAW data edit

RAW data edit based on settings of the camera (including e-Portrait, Colour Creator, Art Filter, ART-BKT). 2 programmable settings, preview capability.

Print

Print function

Print reservation (DPOF), Direct print (PictBridge compatible)

Input/Output

USB/AV/Remote controller
connector

Dedicated multi-connector   [USB: USB2.0 Hi-Speed,  Video: NTSC/PAL selectable, Optional Remote cable RM-UC1 compatible.]

HDMI connector

Micro HDMI (Type-D)

Flash attachment

Hot shoe / Sync. terminal

Microphone input jack

3.5 stereo mini jack

Headphone connector

None / Attachment of HLD-8G optional grip allows connection

PC interface

USB2.0 Hi-Speed

TV interface

HDMI out(HD / stereo), video out(SD / mono)

DC connector

None / attachment of HLD-8 power battery holder allows connection

Power Requirements

Battery

BLN-1 Li-ion battery (included)

Power Battery Holder

HLD-8 Power Battery Holder separately available.

 Allows attachment of an additional BLN-1.

AC Adapter

AC-3 AC adapter* separately available.

HLD-8 Power Battery Holder is required for connection.

Sleep mode

Available (1/3/5 min. off)

Number of recordable pictures

Approx. 310 shots (using BLN-1 and TOSHIBA SD with IS ON,
based on CIPA test standards)

Approx. 750 shots (using BLN-1 and TOSHIBA SD with IS ON and Quick Sleep Mode ON, based on Olympus testing using CIPA test standards)

Battery Life

Approx. 80 minutes* (under standard JEITA testing)

Approx. 150 minutes(when zoom and other operational
functions are not used)

When repeatedly recording at the maximum time of 29 minutes

Dimensions / Weight

Dimensions

123.7(W)85(H)44.5(D)

[CIPA guideline compliant, excluding protrusions]

Weight

Approx. 469g  [CIPA guideline compliant, with BLN-1 battery
and Memory card]

Approx. 417g  [body only]

Operating Environment

Temperature

-10 ~ +40 (when in operation) / -20 ~ +60 (when stored)

Humidity

30 - 90% (when in operation) / 10 - 90% (when stored)

Link to product page    $1,239.05
Olympus E-M5 MARK II Body Black

Olympus OM-D E-M5 Mark II 16MP Mirroless Digital Camera - Body Only, Black


- 16.1MP, 4/3 Live MOS Sensor, 5-Axis In Body IS, 5FPS, 3.0" Vari-Angle Monitor, 81-Point-AF, Wifi :: E-M5 MARK II Body Black

Overview



The World’s Most Advanced Image Stabilisation Puts You on Top of Your Shot. The Olympus OM-D E-M5 Mark II.

The 5-axis VCM image stabilisation, which powerfully compensates for any type of camera shake, has improved. Not only has it achieved the world's highest*1compensation performance of 5 shutter speed steps for still images, but image stabilisation for movies has also significantly improved. The dustproof and splashproof construction, hailed as absolutely reliable by many pro photographers, is now also freezeproof for even better reliability under the harshest of conditions. This incredibly mobile body is packed with the latest technologies, including OM-D Movie for cinema-quality, hand-held interchangeable lens camera shooting, and the world's shortest*2shooting time lag, made possible by super-fast autofocusing. Furthermore, a firmware upgrade will be made available to incorporate the latest functions and performance, and to keep the E-M5 Mark II in top condition. The incredibly high performance and excellent mobility the E-M5 Mark II provides opens doors to new shooting experiences.

Features added or improved through firmware version 2.0

  1. 5-axis Sync IS for camera shake compensation equivalent to 6 shutter speed steps[*]
  2. Olympus Capture Version 1.1 tethered shooting software is now supported.
  3. S-OVF (Simulated OVF) has been added to provide a view that is similar to that of the unaided eye.
  4. 4K Time Lapse Movie has been added.
  5. Focus Bracketing has been added for shifting the focus slightly while shooting.
  6. Live Composite shooting can now be controlled remotely using the Olympus Image Share smartphone app.
  7. Dedicated movie picture mode Muted Colour" has been added for colour grading movies.
  8. A slate tone can now be added for convenient movies, has been added.
  9. Synchronised recording start/stop operation between the camera and linear PCM recorder is now supported.
  10. Disable MF clutch now supported.

Top-class, In-body 5-axis Image Stabilisation

The improved in-body 5-axis image stabilisation achieves compensation ability equal to a world's highest*1 5 steps of shutter speed, making hand-held shooting enjoyable, and making it possible to shoot at a telephoto end without worrying about camera shake even in dark locations



Dustproof & Splashproof Compact Body & Lens System

An uncompromised form, designed in pursuit of excellent operability, combines with a dustproof and splashproof camera body and lenses to make shooting in any environment possible.



OM-D Movie Delivers Hand-held Video with Cinema Quality

The further advanced in-body 5-axis image stabilisation enables stable movie recording even during active camera work. The compact, lightweight OM-D allows you to draw out natural expressions of the subjects without making them conscious of the camera. OM-D Movie achieves cinema-quality recordings and amazing mobility.



Capture Your Imagination with Phenomenal Imaging Power

Zuiko Lens Systems were designed specifically for digital cameras and boast amazing optical performance. In combination with the high-quality sensor, image processor, and amazing image stabilisation system, they provide outstanding image quality. The E-M5 Mark II introduces 40M High Res Shot, which is perfect for aritistic photos and landscapes.



Large EVF with Stunning Resolution

E-M5 Mark II features a large, high-resolution EVF that rivals that of full-frame DSLR cameras. The super large EVF display allows you to see 100% field of view with a 1.48x magnification and has a 2.36 million dot high resolution display. Numerous functions that take advantage of the EVF are included, such as Adaptive Brightness Technology for a natural view that is like an optical viewfinder, and Colour Creator for controlling colour as you like.



FAST AF for Amazing High-speed Sequential Shots

High-speed performance hasimproved further, with features such as the FAST AF system now offering the world's shortest*2 shooting time lag, and 5 fps AF-tracking RAW sequential shooting available until the card is full. The E-M5 Mark II is equipped with a high-speed 1/8000 sec. mechanical shutter  used on many high-end SLR cameras. Fast enough that you will never miss even the fastest moving subjects.



More Features

  • 14 Art Filters expand the possibilities of photographic expression
  • Photo Story lets you shoot multiple photos of the same scene to create a single image
  • Two HDR modes and HDR Bracketing (HDR-BKT)
  • Live Composite lets you capture movement of light as solid light trails
  • Live Bulb and Live Time update the image display during exposure
  • LV Boost II convenient for shooting stars
  • Keystone compensation allows tilt-shift photography with any lens
  • The digital level gauge corresponds to vertical and horizontal directions
  • Built-in Wi-Fi and Olympus Image Share
  • Camera control system and the dedicated computer app Olympus Capture
  • Olympus Viewer 3 for smart management of digital workflow
  • Quick Sleep mode enables up to 750 shots
  • Improved, easy to use GUI

Specifications

Product type

Product type

Micro Four Thirds interchangeable lens system camera

Memory

SD Memory Card (SDHC, SDXC, UHS-I, II compatible,
Eye-Fi Card compatible*)

Not compatible with Endless Memory.

Screen size

17.3mm and 13.0mm

Lens mount

Micro Four Thirds mount

Image sensor

Product type

4/3 Live MOS Sensor

Number of pixels

Approx. 16.1 million pixels.

Total number of pixels: approx. 17.20 million pixels

Aspect ratio

1.33 (4:3)

Dust reduction

Supersonic Wave Filter (image sensor dust reduction system)

Recording (still)

Recording format

DCF, DPOF compatible / Exif, PRINT Image Matching III,
MPO compatible

File format

RAW (12-bit lossless compression), JPEG, JPEG+RAW,
MPO (3D still)

Recording image size

[RAW] 4608 x 3456

[JPEG] 4608 x 3456 to 640 x 480

File size

RAW: 4608(H)x3456(V) (approx. 1/1.5 lossless compressed)
Approx. 17MB

Set1(LF): 4608(H)x3456(V)  (1/4 compressed) Approx. 7.5MB

Set2(LN): 4608(H)x3456(V)  (1/8 compressed) Approx. 3.5MB

Set3(MN): 3200(H)x2400(V) (1/8 compressed) Approx. 1.7MB

Set4(SN): 1280(H)x960(V) (1/8 compressed) Approx. 0.4MB

Image Stabilisation System

Type

Built-in 5-axis* sensor-shift image stabilisation for movie and still photos

 yaw/pitch/roll/vertical shift/horizontal shift

Mode

4 modes (S-IS AUTO, S-IS1, S-IS2, S-IS3), OFF

Live View image stabilisation

Activation by half-pressing shutter button  or  enlarging view

Focal length setting

With

5 axis Sync IS

With

When combined with 5-axis Sync IS compatible M.Zuiko Digital lenses

Stabilisation performance

5.0 EV

Based on CIPA standards, when used with M.Zuiko Digital ED 12-50mm F3.5-6.3 EZ, at focal length of 50mm (35mm equivalent focal length: 100mm), in pitch/yaw direction.

Lens IS prioritye

With

Finder

Type

Eye-level electronic viewfinder,  approx. 2.36M-dot

Field of view /
Viewfinder magnification

Approx. 100% / Approx. 1.30x*1 - 1.48x*2 (-1m-1, 50mm lens, Infinity)

1: at Finder Style 1, 2 (aspect 4:3)

2: at Finder Style 3 (aspect 4:3)

Eye point / Dioptre adjustment
range

Approx. 21mm (-1m-1, Distance from rear lens surface) /
Approx. -4 to +2m-1

Preview

Live View preview with depth of field preview lock

Display Grid

Off / normal grid / golden grid / scale / diagonal / movie grid

Level gauge display

2-axis (horizontal/vertical) level gauge

Viewfinder style

3 styles

Brightness adjustment /
Colour temperature adjustment

Automatic control of adaptive brightness technology /
manual control (7 levels)

Eyecup

Interchangeable with separately available EP-16 eyecup

S-OVF (Simulated OVF)

Expands Live View Dynamic Range

Available in the EVF when shooting in PASM modes. Art Filters,
exposure compensation adjustments, and white balance adjustments
will not be reflected.

Live view

Live view

Approx. 100% field of view, exposure compensation preview,
WB adjustment preview, gradation preview, face detection preview
(up to 8 faces), grid line, magnification display (x3/x5/x7/x10/x14),
Display modes: Standard, Histogram, Highlight & Shadow,
Level Gauge, Off (Image Only)

Preview

Preview with depth of field preview lock

Monitor

Monitor type

3.0-inch vari-angle monitor*

 Approx.1037k dots (3:2), electrostatic capacitance touch panel

Touch control

Shutter release, magnification, AF area selection, AF area size adjustment,
frame forward/backward, magnified playback, Live Guide,
Super Control Panel, Art Filter selection, scene mode selection,
Wi-Fi connection, selfie shutter release

Tilting capability

With (mirror display when monitor is in self portrait position)

Brightness /
Colour temperature control

7 levels / 7 levels

Colour tone select

Vivid / Natural

Focusing

AF mode

High-speed imager AF

Focus mode

Single AF (S-AF) / Continuous AF (C-AF) / Manual Focus (MF) /
S-AF + MF / AF tracking (C-AF + TR)

Full-time AF

With

Magnified frame AF /
Magnified AF

Selectable from over 800 AF points

Selectable magnification: x3, x5, x7, x10(Default), x14

Super Spot AF*

Available only when a Micro Four Thirds lens is attached

Face detection AF /
Eye detect AF

With

Eye Detection AF mode : off / nearer-eye priority / right-eye priority /
 left-eye priority

Focusing point /
Focusing point selection

81-area multiple AF / All target, group target area (9-area),
single target(normal), single target(small)

AF illuminator

With

Manual focus assist

Focus ring rotation activates Live View image magnification and/
or focus peaking when in S-AF+MF or MF mode

Peaking function

Activate with Fn button or focus ring

Change peaking settings using the Info button

Colour selection: white, black, red, yellow

Intensity selection: high, normal, low

Back light effect: on, off

Exposure Control (Still)

Metering system
(TTL Image sensor metering)

Digital ESP metering (324-area multi pattern metering),
center-weighted average metering, spot metering, spot metering
with highlight control, spot metering with shadow control

Metering area

EV -2 - 20 (using 17mm F2.8, ISO 100)

Exposure mode

iAUTO, P: Program AE (Program shift can be performed),
 A: Aperture priority AE,

S: Shutter priority AE, M: Manual, Bulb, Time, Scene select  AE,
Art Filter,

Underwater wide / macro*, My Set

Selectable from menu as a function on Fn button

My set can be set to mode dial function

Scene select AE

Portrait, e-Portrait, Landscape, Landscape + Portrait, Sport,
Hand-held Starlight*1, Night scene, Night + Portrait, Children, High Key,
Low Key, DIS mode, Macro, Nature Macro, Candle, Sunset, Documents,
Panorama, Fireworks, Beach & Snow, Fisheye Conv., Wide Conv.,
Macro Conv., Panning, 3D*2

1: 8 images automatically shot and combined into a single image composite

2: For 3D lens(H-FT012 by Panasonic) only, still photo only

ISO sensitivity

AUTO ISO : LOW(approx. 100) 25600 (customizable, Defalut:LOW-1600)

Manual ISO : LOW(approx.100), 200 - 25600, 1/3 or 1 EV steps selectable

Exposure compensation

Still photo 5 EV, movie 3 EV, with selectable EV adjustment steps
(1/3, 1/2, 1)

HDR shooting, monitor and EVF displays only up to 3 EV.

AE lock

Locks with a half-press of the shutter button
(can be set to Fn button as well)

Shutter

Shutter type

Focal-plane shutter / 1/8000 - 60 sec., with selectable EV
adjustment steps (1/3, 1/2, 1)

Bulb/Time: selectable exposure time (1/2/4/8/15/20/25/30 min.),
with 8-min. default setting

Flash

Flash intensity control method

TTL Auto, Auto*, Manual, Super FP*(FP-TTL AUTO, FP-MANUAL)

Available on the external flash

Built-in flash

-

Bundled standard flash

FL-LM3(dustproof and splashproof flash)

GN9.1(ISO100m) / GN=12.9(ISO200m)

Bounce Capability (up and down: 45, 60, 75, 90 degree /
left and right 30, 60, 90, 120, 150, 180 degree)

Powered by the camera

Flash mode

Flash Auto, Redeye, Fill-in, Flash Off, Red-eye Slow sync.(1st curtain),
Slow sync.(1st curtain), Slow sync.(2nd curtain),
Manual(1/1(FULL) - 1/64)

Synchronisation speed

1/250 sec.

 Super FP: 1/125-1/8000 sec.

Flash intensity control

Up to 3 EV in 0.3, 0.5, 1 EV steps selectable

Compatible external flash

FL-50R, FL-36R, FL-20, FL-14, FL-300R, FL-600R

Wireless flash control

Compatible external flash

FL-50R, FL-36R, FL-300R, FL-600R

Control method

Triggered and controlled by the bundled FL-LM3 or FL-600R

(Olympus Wireless RC Flash system compatible)

External Flash control mode

TTL Auto, Auto, Manual, FP-TTL-AUTO, FP-MANUAL

Channel

4 channels

Group No.

4 groups (External flash 3 groups + commander flash* )

FL-LM3 / FL-600R

Drive

Sequential shooting
maximum speed

[Sequential shooting H mode] approx 10.0 fps

IS OFF

Focus and exposure are fixed at the values for the first shot.

[Sequential shooting L mode] approx 5.0 fps

When using the M.ZUIKO DIGITAL ED 12-50mm F3.5-6.3 EZ

Max. recordable pictures

[RAW]  Max. frames (in 5.0 seq. shooting L)  Max. 16 frames (in 10.0 seq. shooting H)

 on sequential shooting*

[JPEG]  Max. frames (in 5.0 seq. shooting L)  Max. 19 frames (in 10.0 seq. shooting H)

When using the M.Zuiko Digital ED 12-40mm F2.8 PRO

With TOSHIBA SDHC UHS-II R260W240 EXCERIA PRO

Self-timer

Operation time: 12 sec., 2 sec., custom (Wait time: 1-30sec., Shot interval: 0.5/1/2/3sec., Number of shots: 1-10, Every time AF: ON/OFF)

Bracketing

Exposure bracketing

2, 3 or 5 frames in 0.3/0.7/1.0EV steps selectable,
7 frames in 0.3/0.7EV steps selectable

AE-BKT can be programmed to the Fn-button.

ISO bracketing

3 frames in 0.3/0.7/1.0EV steps selectable

White balance bracketing

3 frames in 2, 4, 6 steps selectable in each A-B/G-M axis.

Flash bracketing

3 frames in 0.3/0.7/1.0EV step selectable

Art filter bracketing

i-Enhance, Vivid, Natural, Muted, Portrait, Monotone, Custom,
Art Filters selectable

Focus Bracketing Mode

3-999 shots / 1-10 focus steps (movement differential)

Compatible with Micro Four Thirds AF lenses

Focus Stacking Mode

Not available

HDR function

HDR(Auto composite)

HDR1, HDR2 (painting-like)

Maximum shutter speed setting is 1 sec.

Exposure compensation can be performed.

Bracketing for HDR postprocess

3 or 5 frames in 2.0/3.0EV steps selectable,
7 frames in 2.0EV steps selectable.

This function does not execute HDR processing.

HDR function can be assigned to the Fn-button.

Art Filter

Mode (Variation / Effect)

Pop Art (I, II / a.b.c.d.e.f.)

Soft Focus ( - / c.e.)

Pale & Light Colour (I, II / a.b.c.d.f.)

Light Tone ( - / d.f.)

Grainy Film (I, II / b.c.d.g.h)

Pin Hole (I, II, III / d.)

Diorama ( I,II  / d.)

Cross Process (I, II / b.c.d.f.)

Gentle Sepia ( - / a.b.c.d.f.)

Dramatic Tone (I / b.c.d.e.f.)  (II / b.c.d.e.f.g.h)

Key Line (I, II / a.b.c.d.e.)

Water Colour (I, II / a.b.c.d.)

Vintage (I, II, III / a.b.c.d.e.f.i)

Partial Colour (I, II, III / a.b.c.d.e.f)

Art Effect

a. Soft Focus Effect

b. Pin-Hole Effect

c. White Edge Effect

d. Frame Effect

e. Star Light Effect

f. Blur Effect (Top & bottom, Left & Right)

g. B&W Effect (None, Yellow, Orange, Red, Green)

h. Pict. Tone (None, Sepia, Blue, Purple, Green)

i. Shade Effect (Top & bottom, Left & Right)

Colour Ring (for partial colour)

18 colour selectable

Photo Story

Type (Variation / Flame /
 Number of divided parts)

Standard (I, II, III, IV / abcd / ABCD)

Fun Frame (I, II, III / / )

Speed (- / - / AEF)

Zoom in / out (, / a, c / A, G)

Layout (I, II, III, IV / / -)

Frame Effect

a. White Frame

b. White Frame & White Edge Effect

c. Black Frame

d. White Frame & Pin Hole Effect

Aspect & Window Pattern

A. 4:3, 2 frames

B. 4:3, 3 frames

C. 1:1. 2 frames

D. 1:1, 3 frames

E. 1:1, 4 frames

F. 16:9. 5 frames

G. 16:9, 2 frames

Hold function

With

Movie

Recording format

MOV(MPEG-4AVC/H.264) , AVI(Motion JPEG)

Mode / frame rate /
compression method

[MOV]

1920x1080(FHD) / 30p, 25p, 24p / ALL-I(A-I), IPB(SF, F, N)

1920x1080(FHD) / 60p, 50p / IPB(SF, F, N)

1280x720(HD) / 60p, 50p, 30p, 25p, 24p / ALL-I (A-I), IPB(SF, F, N)

60p:59.94fps, 50p:50.00fps, 30p:29.97fps, 25p:25.00fps, 24p:23.98fps

FHD ALL-I (A-I: approx. 77Mbps)

FHD IPB(SF: approx. 52Mbps, F:approx. 30Mbps, N:approx. 18Mbps)

[AVI]

1280x720(HD) / 30p

640x480(SD) / 30p

Frame rates may drop when particular Art Filters and
Movie Effect are used

Class 10 or higher SD card is recommended for shooting movies

UHS-II or UHS-I Class3 card is recommended for ALL-I shooting.

Maximum recording time

[MOV] Approx. 29min

[AVI] HD: Approx. 7min* / SD: Approx. 14min*

Excluding when particular Art Filters are used

Art Filter Movie

With*

Frame rate: lower.

Movie Effect

One-shot Echo / Multi-echo / Art Fade / Old Film

One-push Movie Digital
Conveter

x4

Time Lapse Movie

[AVI]

38402160(4K)/5fps

19201080(FHD)/5fps,10fps,15fps

1280720(HD)/5fps,10fps,15fps,30fps

Photo in Movie

With (mode1 / mode2)

mode1 is available when recording framerate is less than 30p.

Clips

1, 2, 4, 8 sec

 (Further continued shooting possible by pressing movie record button again)

Quick Movie / Slow Movie

With

IS for Movie

M-IS1(Image sensor shift and electronic image stabilizer with multi motion IS),

M-IS2(Image sensor shift with multi motion IS), Off

Field of view may be affected in M-IS1.

Grid Line / Focus Peaking

4 types of grid lines / 4 colours for focus peaking

Time code

Rec run / free run, drop frame / non-drop frame

Live View Output via HDMI

With (GUI* is shown on connected device only, and peaking function is not available when connected by HDMI.)

GUI can be hidden on the connected device by pressing down on INFO button for recording an external drive under the following condition. Movie quality: YCbCr 4:2:2 / Frame rate: same as movie setting (24p, 30p and 60p settings are not recommended.) / Sound recording: not available

Movie picture mode

Flat

Exposure Control

Program AE, aperture priority AE, shutter priority AE, manual

AE Lock

With

Recording(Sound)

Recording format

Wave Format (Stereo linear PCM/16-bit, Sampling frequency 48kHz)

Microphone / Speaker

Stereo/Mono

Microphone function

Wind noise reduction,  Recording volume, Microphone volume limiter

Audio dubbing possible for still pictures (up to 30 sec.)

Linking with Olympus
PCM Recorders

Slate Tone/Synchronised Audio Rec-Movie Rec

LS-100 compatible

White Balance

White balance mode

Auto WB, 7 Preset WBs, 4 Capture WBs, Custom WB(Kelvin setting)

White balance compensation

7 steps in each A-B/G-M axis

Except for Custom WB

Colour Mode

Colour matrix

sRGB, Adobe RGB

Picture Mode

Mode

i-Enhance, Vivid, Natural, Flat, Portrait, Black and White, Custom, e-Portrait, Colour Creator, Art Filter, Underwater

Gradation

Auto, Normal, High Key, Low Key [except Art Filters]

Keystone Compensation

Keystone Compensation

With (can be confirmed on Live View)

High Res Shot

Resolution

Equivalent to 40M pixel sensor (8 shots combined into a single JPEG using sensor shift)

Available in P/A/S/M mode, RAW+JPEG or JPEG.

JPEG: 7296 x 5472 / RAW: 9216 x 6912

RAW data can be developed in-camera.  Development by
PC is possible with the appropriate plug-in.

Shutter Type / Shutter Speed

Electronic shutter / 1/8000 - 8 sec.

Anti-shock Mode

Shutter Type / Shutter Speed

Electronic first curtain shutter  /  1/320* - 60sec

For speeds over 1/320 sec., mechanical shutter
will automatically be selected.

Shutter start delay

0,  1/8,  1/4,  1/2,  1,  2,  4,  8,  15,  30sec

Silent Mode

Shutter Type / Shutter Speed

Electronic shutter  /  1/16000 - 60sec

Shutter start delay

0, 1/8, 1/4, 1/2, 1, 2, 4, 8, 15, 30sec

Live Bulb / Live Time

Update interval time

0.5 sec - 60 sec

Live Composite

Update interval time /
composite method

0.5 sec - 60 sec / Lighten Mode (Bright area prioritization)

Interval Mode

Interval Mode

Interval Time 1sec. - 24 Hours,  Max 999 frames.

Available on making Time-lapse movie automatically

Multi Exposure

Number of picture / Function

2 frames / Auto gain, Exposing on Recorded picture(RAW)

Multi Aspect

Aspect Ratio

4:3(Default) / 3:2 / 16:9 / 1:1 / 3:4

Level Gauge

Detection

2-axis

One push Tele-converter

Magnification

x2

Wi-Fi Function

GPS info. Function

Via smartphone GPS data

Wireless Shooting*

Live View, Rec View, Wireless Touch AF shutter, Self Timer (w/Countdown guidance, Sequential shooting, movie recording capability), Wireless Release, Movie Recording, Power Off, iAuto / ART / P / A / S / M (Live Bulb, Live Time, Composite) and drive mode can be selected.* Aperture, shutter speed, exposure, ISO sensitivity, white balance can be adjusted.*

Shooting with a smartphone

When in private connection

Image Share

File Type: JPEG* , MOV

Connect to up to 4 devices simultaneously.  Marking function for image share.

Excluding MPO file

Easy Connection

QR code setting

Tetherd shooting

Tethered shooting

Via USB connection, with use of Olympus Capture tethering software
(camera can be controlled by both the camera and computer)

Playback

Playback mode

Single-frame, Information display, Index display (4/9/25/100 frames),
Calendar, Enlargement (2x - 14x), Movie (with sound, FF/REW/Pause),
Picture rotation (auto), Slideshow (with sound including BGM,
Slide show effects, replaceable BGM), Light Box display

Information display

Histogram (independent luminance / RGB available),
Highlight/Shadow point warning, AF frame, Photographic information,
OFF

Menu

Languages

34 languages selectable:

- English, French, German, Spanish, Italian, Japanese, Korean, Traditional Chinese, Simplified Chinese, Russian, Czech, Dutch, Danish, Polish,
Portuguese, Swedish, Norwegian, Finnish, Croatian, Slovenian,
Hungarian, Greek, Slovakian, Turkish, Latvian, Estonian, Lithuanian,
Ukrainian, Serbian, Bulgarian, Rumanian, Indonesian, Malay, Thai

Image Editing

Editing function

RAW data edit, Gradation auto, Monochrome, Sepia, Red-eye fix, Saturation, Resize (1280x960, 640x480, 320x240), Trimming, Aspect, e-Portrait, Image Overlay, Postrecording

RAW data edit

RAW data edit based on settings of the camera (including e-Portrait, Colour Creator, Art Filter, ART-BKT). 2 programmable settings, preview capability.

Print

Print function

Print reservation (DPOF), Direct print (PictBridge compatible)

Input/Output

USB/AV/Remote controller
connector

Dedicated multi-connector   [USB: USB2.0 Hi-Speed,  Video: NTSC/PAL selectable, Optional Remote cable RM-UC1 compatible.]

HDMI connector

Micro HDMI (Type-D)

Flash attachment

Hot shoe / Sync. terminal

Microphone input jack

3.5 stereo mini jack

Headphone connector

None / Attachment of HLD-8G optional grip allows connection

PC interface

USB2.0 Hi-Speed

TV interface

HDMI out(HD / stereo), video out(SD / mono)

DC connector

None / attachment of HLD-8 power battery holder allows connection

Power Requirements

Battery

BLN-1 Li-ion battery (included)

Power Battery Holder

HLD-8 Power Battery Holder separately available.

 Allows attachment of an additional BLN-1.

AC Adapter

AC-3 AC adapter* separately available.

HLD-8 Power Battery Holder is required for connection.

Sleep mode

Available (1/3/5 min. off)

Number of recordable pictures

Approx. 310 shots (using BLN-1 and TOSHIBA SD with IS ON,
based on CIPA test standards)

Approx. 750 shots (using BLN-1 and TOSHIBA SD with IS ON and Quick Sleep Mode ON, based on Olympus testing using CIPA test standards)

Battery Life

Approx. 80 minutes* (under standard JEITA testing)

Approx. 150 minutes(when zoom and other operational
functions are not used)

When repeatedly recording at the maximum time of 29 minutes

Dimensions / Weight

Dimensions

123.7(W)85(H)44.5(D)

[CIPA guideline compliant, excluding protrusions]

Weight

Approx. 469g  [CIPA guideline compliant, with BLN-1 battery
and Memory card]

Approx. 417g  [body only]

Operating Environment

Temperature

-10 ~ +40 (when in operation) / -20 ~ +60 (when stored)

Humidity

30 - 90% (when in operation) / 10 - 90% (when stored)

Link to product page    $1,239.05
Olympus E-M5MII Adventure Kit SLV

Olympus OM-D E-M5 Mark II 16.1MP Digital Camera Adventure Kit w. 14-150mm II Lens - Silver


- 16.1MP, 4/3 Live MOS Sensor, 5-Axis In Body IS, 5FPS, 3.0" Vari-Angle Monitor, 81-Point-AF, Wifi :: E-M5MII Adventure Kit SLV

Overview



The World’s Most Advanced Image Stabilisation Puts You on Top of Your Shot. The Olympus OM-D E-M5 Mark II.

The 5-axis VCM image stabilisation, which powerfully compensates for any type of camera shake, has improved. Not only has it achieved the world's highest*1compensation performance of 5 shutter speed steps for still images, but image stabilisation for movies has also significantly improved. The dustproof and splashproof construction, hailed as absolutely reliable by many pro photographers, is now also freezeproof for even better reliability under the harshest of conditions. This incredibly mobile body is packed with the latest technologies, including OM-D Movie for cinema-quality, hand-held interchangeable lens camera shooting, and the world's shortest*2shooting time lag, made possible by super-fast autofocusing. Furthermore, a firmware upgrade will be made available to incorporate the latest functions and performance, and to keep the E-M5 Mark II in top condition. The incredibly high performance and excellent mobility the E-M5 Mark II provides opens doors to new shooting experiences.

Features added or improved through firmware version 2.0

  1. 5-axis Sync IS for camera shake compensation equivalent to 6 shutter speed steps[*]
  2. Olympus Capture Version 1.1 tethered shooting software is now supported.
  3. S-OVF (Simulated OVF) has been added to provide a view that is similar to that of the unaided eye.
  4. 4K Time Lapse Movie has been added.
  5. Focus Bracketing has been added for shifting the focus slightly while shooting.
  6. Live Composite shooting can now be controlled remotely using the Olympus Image Share smartphone app.
  7. Dedicated movie picture mode Muted Colour" has been added for colour grading movies.
  8. A slate tone can now be added for convenient movies, has been added.
  9. Synchronised recording start/stop operation between the camera and linear PCM recorder is now supported.
  10. Disable MF clutch now supported.

Top-class, In-body 5-axis Image Stabilisation

The improved in-body 5-axis image stabilisation achieves compensation ability equal to a world's highest*1 5 steps of shutter speed, making hand-held shooting enjoyable, and making it possible to shoot at a telephoto end without worrying about camera shake even in dark locations



Dustproof & Splashproof Compact Body & Lens System

An uncompromised form, designed in pursuit of excellent operability, combines with a dustproof and splashproof camera body and lenses to make shooting in any environment possible.



OM-D Movie Delivers Hand-held Video with Cinema Quality

The further advanced in-body 5-axis image stabilisation enables stable movie recording even during active camera work. The compact, lightweight OM-D allows you to draw out natural expressions of the subjects without making them conscious of the camera. OM-D Movie achieves cinema-quality recordings and amazing mobility.



Capture Your Imagination with Phenomenal Imaging Power

Zuiko Lens Systems were designed specifically for digital cameras and boast amazing optical performance. In combination with the high-quality sensor, image processor, and amazing image stabilisation system, they provide outstanding image quality. The E-M5 Mark II introduces 40M High Res Shot, which is perfect for aritistic photos and landscapes.



Large EVF with Stunning Resolution

E-M5 Mark II features a large, high-resolution EVF that rivals that of full-frame DSLR cameras. The super large EVF display allows you to see 100% field of view with a 1.48x magnification and has a 2.36 million dot high resolution display. Numerous functions that take advantage of the EVF are included, such as Adaptive Brightness Technology for a natural view that is like an optical viewfinder, and Colour Creator for controlling colour as you like.



FAST AF for Amazing High-speed Sequential Shots

High-speed performance hasimproved further, with features such as the FAST AF system now offering the world's shortest*2 shooting time lag, and 5 fps AF-tracking RAW sequential shooting available until the card is full. The E-M5 Mark II is equipped with a high-speed 1/8000 sec. mechanical shutter  used on many high-end SLR cameras. Fast enough that you will never miss even the fastest moving subjects.



More Features

  • 14 Art Filters expand the possibilities of photographic expression
  • Photo Story lets you shoot multiple photos of the same scene to create a single image
  • Two HDR modes and HDR Bracketing (HDR-BKT)
  • Live Composite lets you capture movement of light as solid light trails
  • Live Bulb and Live Time update the image display during exposure
  • LV Boost II convenient for shooting stars
  • Keystone compensation allows tilt-shift photography with any lens
  • The digital level gauge corresponds to vertical and horizontal directions
  • Built-in Wi-Fi and Olympus Image Share
  • Camera control system and the dedicated computer app Olympus Capture
  • Olympus Viewer 3 for smart management of digital workflow
  • Quick Sleep mode enables up to 750 shots
  • Improved, easy to use GUI

Specifications

Product type

Product type

Micro Four Thirds interchangeable lens system camera

Memory

SD Memory Card (SDHC, SDXC, UHS-I, II compatible,
Eye-Fi Card compatible*)

Not compatible with Endless Memory.

Screen size

17.3mm and 13.0mm

Lens mount

Micro Four Thirds mount

Image sensor

Product type

4/3 Live MOS Sensor

Number of pixels

Approx. 16.1 million pixels.

Total number of pixels: approx. 17.20 million pixels

Aspect ratio

1.33 (4:3)

Dust reduction

Supersonic Wave Filter (image sensor dust reduction system)

Recording (still)

Recording format

DCF, DPOF compatible / Exif, PRINT Image Matching III,
MPO compatible

File format

RAW (12-bit lossless compression), JPEG, JPEG+RAW,
MPO (3D still)

Recording image size

[RAW] 4608 x 3456

[JPEG] 4608 x 3456 to 640 x 480

File size

RAW: 4608(H)x3456(V) (approx. 1/1.5 lossless compressed)
Approx. 17MB

Set1(LF): 4608(H)x3456(V)  (1/4 compressed) Approx. 7.5MB

Set2(LN): 4608(H)x3456(V)  (1/8 compressed) Approx. 3.5MB

Set3(MN): 3200(H)x2400(V) (1/8 compressed) Approx. 1.7MB

Set4(SN): 1280(H)x960(V) (1/8 compressed) Approx. 0.4MB

Image Stabilisation System

Type

Built-in 5-axis* sensor-shift image stabilisation for movie and still photos

 yaw/pitch/roll/vertical shift/horizontal shift

Mode

4 modes (S-IS AUTO, S-IS1, S-IS2, S-IS3), OFF

Live View image stabilisation

Activation by half-pressing shutter button  or  enlarging view

Focal length setting

With

5 axis Sync IS

With

When combined with 5-axis Sync IS compatible M.Zuiko Digital lenses

Stabilisation performance

5.0 EV

Based on CIPA standards, when used with M.Zuiko Digital ED 12-50mm F3.5-6.3 EZ, at focal length of 50mm (35mm equivalent focal length: 100mm), in pitch/yaw direction.

Lens IS prioritye

With

Finder

Type

Eye-level electronic viewfinder,  approx. 2.36M-dot

Field of view /
Viewfinder magnification

Approx. 100% / Approx. 1.30x*1 - 1.48x*2 (-1m-1, 50mm lens, Infinity)

1: at Finder Style 1, 2 (aspect 4:3)

2: at Finder Style 3 (aspect 4:3)

Eye point / Dioptre adjustment
range

Approx. 21mm (-1m-1, Distance from rear lens surface) /
Approx. -4 to +2m-1

Preview

Live View preview with depth of field preview lock

Display Grid

Off / normal grid / golden grid / scale / diagonal / movie grid

Level gauge display

2-axis (horizontal/vertical) level gauge

Viewfinder style

3 styles

Brightness adjustment /
Colour temperature adjustment

Automatic control of adaptive brightness technology /
manual control (7 levels)

Eyecup

Interchangeable with separately available EP-16 eyecup

S-OVF (Simulated OVF)

Expands Live View Dynamic Range

Available in the EVF when shooting in PASM modes. Art Filters,
exposure compensation adjustments, and white balance adjustments
will not be reflected.

Live view

Live view

Approx. 100% field of view, exposure compensation preview,
WB adjustment preview, gradation preview, face detection preview
(up to 8 faces), grid line, magnification display (x3/x5/x7/x10/x14),
Display modes: Standard, Histogram, Highlight & Shadow,
Level Gauge, Off (Image Only)

Preview

Preview with depth of field preview lock

Monitor

Monitor type

3.0-inch vari-angle monitor*

 Approx.1037k dots (3:2), electrostatic capacitance touch panel

Touch control

Shutter release, magnification, AF area selection, AF area size adjustment,
frame forward/backward, magnified playback, Live Guide,
Super Control Panel, Art Filter selection, scene mode selection,
Wi-Fi connection, selfie shutter release

Tilting capability

With (mirror display when monitor is in self portrait position)

Brightness /
Colour temperature control

7 levels / 7 levels

Colour tone select

Vivid / Natural

Focusing

AF mode

High-speed imager AF

Focus mode

Single AF (S-AF) / Continuous AF (C-AF) / Manual Focus (MF) /
S-AF + MF / AF tracking (C-AF + TR)

Full-time AF

With

Magnified frame AF /
Magnified AF

Selectable from over 800 AF points

Selectable magnification: x3, x5, x7, x10(Default), x14

Super Spot AF*

Available only when a Micro Four Thirds lens is attached

Face detection AF /
Eye detect AF

With

Eye Detection AF mode : off / nearer-eye priority / right-eye priority /
 left-eye priority

Focusing point /
Focusing point selection

81-area multiple AF / All target, group target area (9-area),
single target(normal), single target(small)

AF illuminator

With

Manual focus assist

Focus ring rotation activates Live View image magnification and/
or focus peaking when in S-AF+MF or MF mode

Peaking function

Activate with Fn button or focus ring

Change peaking settings using the Info button

Colour selection: white, black, red, yellow

Intensity selection: high, normal, low

Back light effect: on, off

Exposure Control (Still)

Metering system
(TTL Image sensor metering)

Digital ESP metering (324-area multi pattern metering),
center-weighted average metering, spot metering, spot metering
with highlight control, spot metering with shadow control

Metering area

EV -2 - 20 (using 17mm F2.8, ISO 100)

Exposure mode

iAUTO, P: Program AE (Program shift can be performed),
 A: Aperture priority AE,

S: Shutter priority AE, M: Manual, Bulb, Time, Scene select  AE,
Art Filter,

Underwater wide / macro*, My Set

Selectable from menu as a function on Fn button

My set can be set to mode dial function

Scene select AE

Portrait, e-Portrait, Landscape, Landscape + Portrait, Sport,
Hand-held Starlight*1, Night scene, Night + Portrait, Children, High Key,
Low Key, DIS mode, Macro, Nature Macro, Candle, Sunset, Documents,
Panorama, Fireworks, Beach & Snow, Fisheye Conv., Wide Conv.,
Macro Conv., Panning, 3D*2

1: 8 images automatically shot and combined into a single image composite

2: For 3D lens(H-FT012 by Panasonic) only, still photo only

ISO sensitivity

AUTO ISO : LOW(approx. 100) 25600 (customizable, Defalut:LOW-1600)

Manual ISO : LOW(approx.100), 200 - 25600, 1/3 or 1 EV steps selectable

Exposure compensation

Still photo 5 EV, movie 3 EV, with selectable EV adjustment steps
(1/3, 1/2, 1)

HDR shooting, monitor and EVF displays only up to 3 EV.

AE lock

Locks with a half-press of the shutter button
(can be set to Fn button as well)

Shutter

Shutter type

Focal-plane shutter / 1/8000 - 60 sec., with selectable EV
adjustment steps (1/3, 1/2, 1)

Bulb/Time: selectable exposure time (1/2/4/8/15/20/25/30 min.),
with 8-min. default setting

Flash

Flash intensity control method

TTL Auto, Auto*, Manual, Super FP*(FP-TTL AUTO, FP-MANUAL)

Available on the external flash

Built-in flash

-

Bundled standard flash

FL-LM3(dustproof and splashproof flash)

GN9.1(ISO100m) / GN=12.9(ISO200m)

Bounce Capability (up and down: 45, 60, 75, 90 degree /
left and right 30, 60, 90, 120, 150, 180 degree)

Powered by the camera

Flash mode

Flash Auto, Redeye, Fill-in, Flash Off, Red-eye Slow sync.(1st curtain),
Slow sync.(1st curtain), Slow sync.(2nd curtain),
Manual(1/1(FULL) - 1/64)

Synchronisation speed

1/250 sec.

 Super FP: 1/125-1/8000 sec.

Flash intensity control

Up to 3 EV in 0.3, 0.5, 1 EV steps selectable

Compatible external flash

FL-50R, FL-36R, FL-20, FL-14, FL-300R, FL-600R

Wireless flash control

Compatible external flash

FL-50R, FL-36R, FL-300R, FL-600R

Control method

Triggered and controlled by the bundled FL-LM3 or FL-600R

(Olympus Wireless RC Flash system compatible)

External Flash control mode

TTL Auto, Auto, Manual, FP-TTL-AUTO, FP-MANUAL

Channel

4 channels

Group No.

4 groups (External flash 3 groups + commander flash* )

FL-LM3 / FL-600R

Drive

Sequential shooting
maximum speed

[Sequential shooting H mode] approx 10.0 fps

IS OFF

Focus and exposure are fixed at the values for the first shot.

[Sequential shooting L mode] approx 5.0 fps

When using the M.ZUIKO DIGITAL ED 12-50mm F3.5-6.3 EZ

Max. recordable pictures

[RAW]  Max. frames (in 5.0 seq. shooting L)  Max. 16 frames (in 10.0 seq. shooting H)

 on sequential shooting*

[JPEG]  Max. frames (in 5.0 seq. shooting L)  Max. 19 frames (in 10.0 seq. shooting H)

When using the M.Zuiko Digital ED 12-40mm F2.8 PRO

With TOSHIBA SDHC UHS-II R260W240 EXCERIA PRO

Self-timer

Operation time: 12 sec., 2 sec., custom (Wait time: 1-30sec., Shot interval: 0.5/1/2/3sec., Number of shots: 1-10, Every time AF: ON/OFF)

Bracketing

Exposure bracketing

2, 3 or 5 frames in 0.3/0.7/1.0EV steps selectable,
7 frames in 0.3/0.7EV steps selectable

AE-BKT can be programmed to the Fn-button.

ISO bracketing

3 frames in 0.3/0.7/1.0EV steps selectable

White balance bracketing

3 frames in 2, 4, 6 steps selectable in each A-B/G-M axis.

Flash bracketing

3 frames in 0.3/0.7/1.0EV step selectable

Art filter bracketing

i-Enhance, Vivid, Natural, Muted, Portrait, Monotone, Custom,
Art Filters selectable

Focus Bracketing Mode

3-999 shots / 1-10 focus steps (movement differential)

Compatible with Micro Four Thirds AF lenses

Focus Stacking Mode

Not available

HDR function

HDR(Auto composite)

HDR1, HDR2 (painting-like)

Maximum shutter speed setting is 1 sec.

Exposure compensation can be performed.

Bracketing for HDR postprocess

3 or 5 frames in 2.0/3.0EV steps selectable,
7 frames in 2.0EV steps selectable.

This function does not execute HDR processing.

HDR function can be assigned to the Fn-button.

Art Filter

Mode (Variation / Effect)

Pop Art (I, II / a.b.c.d.e.f.)

Soft Focus ( - / c.e.)

Pale & Light Colour (I, II / a.b.c.d.f.)

Light Tone ( - / d.f.)

Grainy Film (I, II / b.c.d.g.h)

Pin Hole (I, II, III / d.)

Diorama ( I,II  / d.)

Cross Process (I, II / b.c.d.f.)

Gentle Sepia ( - / a.b.c.d.f.)

Dramatic Tone (I / b.c.d.e.f.)  (II / b.c.d.e.f.g.h)

Key Line (I, II / a.b.c.d.e.)

Water Colour (I, II / a.b.c.d.)

Vintage (I, II, III / a.b.c.d.e.f.i)

Partial Colour (I, II, III / a.b.c.d.e.f)

Art Effect

a. Soft Focus Effect

b. Pin-Hole Effect

c. White Edge Effect

d. Frame Effect

e. Star Light Effect

f. Blur Effect (Top & bottom, Left & Right)

g. B&W Effect (None, Yellow, Orange, Red, Green)

h. Pict. Tone (None, Sepia, Blue, Purple, Green)

i. Shade Effect (Top & bottom, Left & Right)

Colour Ring (for partial colour)

18 colour selectable

Photo Story

Type (Variation / Flame /
 Number of divided parts)

Standard (I, II, III, IV / abcd / ABCD)

Fun Frame (I, II, III / / )

Speed (- / - / AEF)

Zoom in / out (, / a, c / A, G)

Layout (I, II, III, IV / / -)

Frame Effect

a. White Frame

b. White Frame & White Edge Effect

c. Black Frame

d. White Frame & Pin Hole Effect

Aspect & Window Pattern

A. 4:3, 2 frames

B. 4:3, 3 frames

C. 1:1. 2 frames

D. 1:1, 3 frames

E. 1:1, 4 frames

F. 16:9. 5 frames

G. 16:9, 2 frames

Hold function

With

Movie

Recording format

MOV(MPEG-4AVC/H.264) , AVI(Motion JPEG)

Mode / frame rate /
compression method

[MOV]

1920x1080(FHD) / 30p, 25p, 24p / ALL-I(A-I), IPB(SF, F, N)

1920x1080(FHD) / 60p, 50p / IPB(SF, F, N)

1280x720(HD) / 60p, 50p, 30p, 25p, 24p / ALL-I (A-I), IPB(SF, F, N)

60p:59.94fps, 50p:50.00fps, 30p:29.97fps, 25p:25.00fps, 24p:23.98fps

FHD ALL-I (A-I: approx. 77Mbps)

FHD IPB(SF: approx. 52Mbps, F:approx. 30Mbps, N:approx. 18Mbps)

[AVI]

1280x720(HD) / 30p

640x480(SD) / 30p

Frame rates may drop when particular Art Filters and
Movie Effect are used

Class 10 or higher SD card is recommended for shooting movies

UHS-II or UHS-I Class3 card is recommended for ALL-I shooting.

Maximum recording time

[MOV] Approx. 29min

[AVI] HD: Approx. 7min* / SD: Approx. 14min*

Excluding when particular Art Filters are used

Art Filter Movie

With*

Frame rate: lower.

Movie Effect

One-shot Echo / Multi-echo / Art Fade / Old Film

One-push Movie Digital
Conveter

x4

Time Lapse Movie

[AVI]

38402160(4K)/5fps

19201080(FHD)/5fps,10fps,15fps

1280720(HD)/5fps,10fps,15fps,30fps

Photo in Movie

With (mode1 / mode2)

mode1 is available when recording framerate is less than 30p.

Clips

1, 2, 4, 8 sec

 (Further continued shooting possible by pressing movie record button again)

Quick Movie / Slow Movie

With

IS for Movie

M-IS1(Image sensor shift and electronic image stabilizer with multi motion IS),

M-IS2(Image sensor shift with multi motion IS), Off

Field of view may be affected in M-IS1.

Grid Line / Focus Peaking

4 types of grid lines / 4 colours for focus peaking

Time code

Rec run / free run, drop frame / non-drop frame

Live View Output via HDMI

With (GUI* is shown on connected device only, and peaking function is not available when connected by HDMI.)

GUI can be hidden on the connected device by pressing down on INFO button for recording an external drive under the following condition. Movie quality: YCbCr 4:2:2 / Frame rate: same as movie setting (24p, 30p and 60p settings are not recommended.) / Sound recording: not available

Movie picture mode

Flat

Exposure Control

Program AE, aperture priority AE, shutter priority AE, manual

AE Lock

With

Recording(Sound)

Recording format

Wave Format (Stereo linear PCM/16-bit, Sampling frequency 48kHz)

Microphone / Speaker

Stereo/Mono

Microphone function

Wind noise reduction,  Recording volume, Microphone volume limiter

Audio dubbing possible for still pictures (up to 30 sec.)

Linking with Olympus
PCM Recorders

Slate Tone/Synchronised Audio Rec-Movie Rec

LS-100 compatible

White Balance

White balance mode

Auto WB, 7 Preset WBs, 4 Capture WBs, Custom WB(Kelvin setting)

White balance compensation

7 steps in each A-B/G-M axis

Except for Custom WB

Colour Mode

Colour matrix

sRGB, Adobe RGB

Picture Mode

Mode

i-Enhance, Vivid, Natural, Flat, Portrait, Black and White, Custom, e-Portrait, Colour Creator, Art Filter, Underwater

Gradation

Auto, Normal, High Key, Low Key [except Art Filters]

Keystone Compensation

Keystone Compensation

With (can be confirmed on Live View)

High Res Shot

Resolution

Equivalent to 40M pixel sensor (8 shots combined into a single JPEG using sensor shift)

Available in P/A/S/M mode, RAW+JPEG or JPEG.

JPEG: 7296 x 5472 / RAW: 9216 x 6912

RAW data can be developed in-camera.  Development by
PC is possible with the appropriate plug-in.

Shutter Type / Shutter Speed

Electronic shutter / 1/8000 - 8 sec.

Anti-shock Mode

Shutter Type / Shutter Speed

Electronic first curtain shutter  /  1/320* - 60sec

For speeds over 1/320 sec., mechanical shutter
will automatically be selected.

Shutter start delay

0,  1/8,  1/4,  1/2,  1,  2,  4,  8,  15,  30sec

Silent Mode

Shutter Type / Shutter Speed

Electronic shutter  /  1/16000 - 60sec

Shutter start delay

0, 1/8, 1/4, 1/2, 1, 2, 4, 8, 15, 30sec

Live Bulb / Live Time

Update interval time

0.5 sec - 60 sec

Live Composite

Update interval time /
composite method

0.5 sec - 60 sec / Lighten Mode (Bright area prioritization)

Interval Mode

Interval Mode

Interval Time 1sec. - 24 Hours,  Max 999 frames.

Available on making Time-lapse movie automatically

Multi Exposure

Number of picture / Function

2 frames / Auto gain, Exposing on Recorded picture(RAW)

Multi Aspect

Aspect Ratio

4:3(Default) / 3:2 / 16:9 / 1:1 / 3:4

Level Gauge

Detection

2-axis

One push Tele-converter

Magnification

x2

Wi-Fi Function

GPS info. Function

Via smartphone GPS data

Wireless Shooting*

Live View, Rec View, Wireless Touch AF shutter, Self Timer (w/Countdown guidance, Sequential shooting, movie recording capability), Wireless Release, Movie Recording, Power Off, iAuto / ART / P / A / S / M (Live Bulb, Live Time, Composite) and drive mode can be selected.* Aperture, shutter speed, exposure, ISO sensitivity, white balance can be adjusted.*

Shooting with a smartphone

When in private connection

Image Share

File Type: JPEG* , MOV

Connect to up to 4 devices simultaneously.  Marking function for image share.

Excluding MPO file

Easy Connection

QR code setting

Tetherd shooting

Tethered shooting

Via USB connection, with use of Olympus Capture tethering software
(camera can be controlled by both the camera and computer)

Playback

Playback mode

Single-frame, Information display, Index display (4/9/25/100 frames),
Calendar, Enlargement (2x - 14x), Movie (with sound, FF/REW/Pause),
Picture rotation (auto), Slideshow (with sound including BGM,
Slide show effects, replaceable BGM), Light Box display

Information display

Histogram (independent luminance / RGB available),
Highlight/Shadow point warning, AF frame, Photographic information,
OFF

Menu

Languages

34 languages selectable:

- English, French, German, Spanish, Italian, Japanese, Korean, Traditional Chinese, Simplified Chinese, Russian, Czech, Dutch, Danish, Polish,
Portuguese, Swedish, Norwegian, Finnish, Croatian, Slovenian,
Hungarian, Greek, Slovakian, Turkish, Latvian, Estonian, Lithuanian,
Ukrainian, Serbian, Bulgarian, Rumanian, Indonesian, Malay, Thai

Image Editing

Editing function

RAW data edit, Gradation auto, Monochrome, Sepia, Red-eye fix, Saturation, Resize (1280x960, 640x480, 320x240), Trimming, Aspect, e-Portrait, Image Overlay, Postrecording

RAW data edit

RAW data edit based on settings of the camera (including e-Portrait, Colour Creator, Art Filter, ART-BKT). 2 programmable settings, preview capability.

Print

Print function

Print reservation (DPOF), Direct print (PictBridge compatible)

Input/Output

USB/AV/Remote controller
connector

Dedicated multi-connector   [USB: USB2.0 Hi-Speed,  Video: NTSC/PAL selectable, Optional Remote cable RM-UC1 compatible.]

HDMI connector

Micro HDMI (Type-D)

Flash attachment

Hot shoe / Sync. terminal

Microphone input jack

3.5 stereo mini jack

Headphone connector

None / Attachment of HLD-8G optional grip allows connection

PC interface

USB2.0 Hi-Speed

TV interface

HDMI out(HD / stereo), video out(SD / mono)

DC connector

None / attachment of HLD-8 power battery holder allows connection

Power Requirements

Battery

BLN-1 Li-ion battery (included)

Power Battery Holder

HLD-8 Power Battery Holder separately available.

 Allows attachment of an additional BLN-1.

AC Adapter

AC-3 AC adapter* separately available.

HLD-8 Power Battery Holder is required for connection.

Sleep mode

Available (1/3/5 min. off)

Number of recordable pictures

Approx. 310 shots (using BLN-1 and TOSHIBA SD with IS ON,
based on CIPA test standards)

Approx. 750 shots (using BLN-1 and TOSHIBA SD with IS ON and Quick Sleep Mode ON, based on Olympus testing using CIPA test standards)

Battery Life

Approx. 80 minutes* (under standard JEITA testing)

Approx. 150 minutes(when zoom and other operational
functions are not used)

When repeatedly recording at the maximum time of 29 minutes

Dimensions / Weight

Dimensions

123.7(W)85(H)44.5(D)

[CIPA guideline compliant, excluding protrusions]

Weight

Approx. 469g  [CIPA guideline compliant, with BLN-1 battery
and Memory card]

Approx. 417g  [body only]

Operating Environment

Temperature

-10 ~ +40 (when in operation) / -20 ~ +60 (when stored)

Humidity

30 - 90% (when in operation) / 10 - 90% (when stored)

Link to product page    $1,813.80
Olympus E-M5MII Adventure Kit BLK

Olympus OM-D E-M5 Mark II 16.1MP Digital Camera Adventure Kit w. 14-150mm II Lens - Black


- 16.1MP, 4/3 Live MOS Sensor, 5-Axis In Body IS, 5FPS, 3.0" Vari-Angle Monitor, 81-Point-AF, Wifi :: E-M5MII Adventure Kit BLK

Overview



The World’s Most Advanced Image Stabilisation Puts You on Top of Your Shot. The Olympus OM-D E-M5 Mark II.

The 5-axis VCM image stabilisation, which powerfully compensates for any type of camera shake, has improved. Not only has it achieved the world's highest*1compensation performance of 5 shutter speed steps for still images, but image stabilisation for movies has also significantly improved. The dustproof and splashproof construction, hailed as absolutely reliable by many pro photographers, is now also freezeproof for even better reliability under the harshest of conditions. This incredibly mobile body is packed with the latest technologies, including OM-D Movie for cinema-quality, hand-held interchangeable lens camera shooting, and the world's shortest*2shooting time lag, made possible by super-fast autofocusing. Furthermore, a firmware upgrade will be made available to incorporate the latest functions and performance, and to keep the E-M5 Mark II in top condition. The incredibly high performance and excellent mobility the E-M5 Mark II provides opens doors to new shooting experiences.

Features added or improved through firmware version 2.0

  1. 5-axis Sync IS for camera shake compensation equivalent to 6 shutter speed steps[*]
  2. Olympus Capture Version 1.1 tethered shooting software is now supported.
  3. S-OVF (Simulated OVF) has been added to provide a view that is similar to that of the unaided eye.
  4. 4K Time Lapse Movie has been added.
  5. Focus Bracketing has been added for shifting the focus slightly while shooting.
  6. Live Composite shooting can now be controlled remotely using the Olympus Image Share smartphone app.
  7. Dedicated movie picture mode Muted Colour" has been added for colour grading movies.
  8. A slate tone can now be added for convenient movies, has been added.
  9. Synchronised recording start/stop operation between the camera and linear PCM recorder is now supported.
  10. Disable MF clutch now supported.

Top-class, In-body 5-axis Image Stabilisation

The improved in-body 5-axis image stabilisation achieves compensation ability equal to a world's highest*1 5 steps of shutter speed, making hand-held shooting enjoyable, and making it possible to shoot at a telephoto end without worrying about camera shake even in dark locations



Dustproof & Splashproof Compact Body & Lens System

An uncompromised form, designed in pursuit of excellent operability, combines with a dustproof and splashproof camera body and lenses to make shooting in any environment possible.



OM-D Movie Delivers Hand-held Video with Cinema Quality

The further advanced in-body 5-axis image stabilisation enables stable movie recording even during active camera work. The compact, lightweight OM-D allows you to draw out natural expressions of the subjects without making them conscious of the camera. OM-D Movie achieves cinema-quality recordings and amazing mobility.



Capture Your Imagination with Phenomenal Imaging Power

Zuiko Lens Systems were designed specifically for digital cameras and boast amazing optical performance. In combination with the high-quality sensor, image processor, and amazing image stabilisation system, they provide outstanding image quality. The E-M5 Mark II introduces 40M High Res Shot, which is perfect for aritistic photos and landscapes.



Large EVF with Stunning Resolution

E-M5 Mark II features a large, high-resolution EVF that rivals that of full-frame DSLR cameras. The super large EVF display allows you to see 100% field of view with a 1.48x magnification and has a 2.36 million dot high resolution display. Numerous functions that take advantage of the EVF are included, such as Adaptive Brightness Technology for a natural view that is like an optical viewfinder, and Colour Creator for controlling colour as you like.



FAST AF for Amazing High-speed Sequential Shots

High-speed performance hasimproved further, with features such as the FAST AF system now offering the world's shortest*2 shooting time lag, and 5 fps AF-tracking RAW sequential shooting available until the card is full. The E-M5 Mark II is equipped with a high-speed 1/8000 sec. mechanical shutter  used on many high-end SLR cameras. Fast enough that you will never miss even the fastest moving subjects.



More Features

  • 14 Art Filters expand the possibilities of photographic expression
  • Photo Story lets you shoot multiple photos of the same scene to create a single image
  • Two HDR modes and HDR Bracketing (HDR-BKT)
  • Live Composite lets you capture movement of light as solid light trails
  • Live Bulb and Live Time update the image display during exposure
  • LV Boost II convenient for shooting stars
  • Keystone compensation allows tilt-shift photography with any lens
  • The digital level gauge corresponds to vertical and horizontal directions
  • Built-in Wi-Fi and Olympus Image Share
  • Camera control system and the dedicated computer app Olympus Capture
  • Olympus Viewer 3 for smart management of digital workflow
  • Quick Sleep mode enables up to 750 shots
  • Improved, easy to use GUI

Specifications

Product type

Product type

Micro Four Thirds interchangeable lens system camera

Memory

SD Memory Card (SDHC, SDXC, UHS-I, II compatible,
Eye-Fi Card compatible*)

Not compatible with Endless Memory.

Screen size

17.3mm and 13.0mm

Lens mount

Micro Four Thirds mount

Image sensor

Product type

4/3 Live MOS Sensor

Number of pixels

Approx. 16.1 million pixels.

Total number of pixels: approx. 17.20 million pixels

Aspect ratio

1.33 (4:3)

Dust reduction

Supersonic Wave Filter (image sensor dust reduction system)

Recording (still)

Recording format

DCF, DPOF compatible / Exif, PRINT Image Matching III,
MPO compatible

File format

RAW (12-bit lossless compression), JPEG, JPEG+RAW,
MPO (3D still)

Recording image size

[RAW] 4608 x 3456

[JPEG] 4608 x 3456 to 640 x 480

File size

RAW: 4608(H)x3456(V) (approx. 1/1.5 lossless compressed)
Approx. 17MB

Set1(LF): 4608(H)x3456(V)  (1/4 compressed) Approx. 7.5MB

Set2(LN): 4608(H)x3456(V)  (1/8 compressed) Approx. 3.5MB

Set3(MN): 3200(H)x2400(V) (1/8 compressed) Approx. 1.7MB

Set4(SN): 1280(H)x960(V) (1/8 compressed) Approx. 0.4MB

Image Stabilisation System

Type

Built-in 5-axis* sensor-shift image stabilisation for movie and still photos

 yaw/pitch/roll/vertical shift/horizontal shift

Mode

4 modes (S-IS AUTO, S-IS1, S-IS2, S-IS3), OFF

Live View image stabilisation

Activation by half-pressing shutter button  or  enlarging view

Focal length setting

With

5 axis Sync IS

With

When combined with 5-axis Sync IS compatible M.Zuiko Digital lenses

Stabilisation performance

5.0 EV

Based on CIPA standards, when used with M.Zuiko Digital ED 12-50mm F3.5-6.3 EZ, at focal length of 50mm (35mm equivalent focal length: 100mm), in pitch/yaw direction.

Lens IS prioritye

With

Finder

Type

Eye-level electronic viewfinder,  approx. 2.36M-dot

Field of view /
Viewfinder magnification

Approx. 100% / Approx. 1.30x*1 - 1.48x*2 (-1m-1, 50mm lens, Infinity)

1: at Finder Style 1, 2 (aspect 4:3)

2: at Finder Style 3 (aspect 4:3)

Eye point / Dioptre adjustment
range

Approx. 21mm (-1m-1, Distance from rear lens surface) /
Approx. -4 to +2m-1

Preview

Live View preview with depth of field preview lock

Display Grid

Off / normal grid / golden grid / scale / diagonal / movie grid

Level gauge display

2-axis (horizontal/vertical) level gauge

Viewfinder style

3 styles

Brightness adjustment /
Colour temperature adjustment

Automatic control of adaptive brightness technology /
manual control (7 levels)

Eyecup

Interchangeable with separately available EP-16 eyecup

S-OVF (Simulated OVF)

Expands Live View Dynamic Range

Available in the EVF when shooting in PASM modes. Art Filters,
exposure compensation adjustments, and white balance adjustments
will not be reflected.

Live view

Live view

Approx. 100% field of view, exposure compensation preview,
WB adjustment preview, gradation preview, face detection preview
(up to 8 faces), grid line, magnification display (x3/x5/x7/x10/x14),
Display modes: Standard, Histogram, Highlight & Shadow,
Level Gauge, Off (Image Only)

Preview

Preview with depth of field preview lock

Monitor

Monitor type

3.0-inch vari-angle monitor*

 Approx.1037k dots (3:2), electrostatic capacitance touch panel

Touch control

Shutter release, magnification, AF area selection, AF area size adjustment,
frame forward/backward, magnified playback, Live Guide,
Super Control Panel, Art Filter selection, scene mode selection,
Wi-Fi connection, selfie shutter release

Tilting capability

With (mirror display when monitor is in self portrait position)

Brightness /
Colour temperature control

7 levels / 7 levels

Colour tone select

Vivid / Natural

Focusing

AF mode

High-speed imager AF

Focus mode

Single AF (S-AF) / Continuous AF (C-AF) / Manual Focus (MF) /
S-AF + MF / AF tracking (C-AF + TR)

Full-time AF

With

Magnified frame AF /
Magnified AF

Selectable from over 800 AF points

Selectable magnification: x3, x5, x7, x10(Default), x14

Super Spot AF*

Available only when a Micro Four Thirds lens is attached

Face detection AF /
Eye detect AF

With

Eye Detection AF mode : off / nearer-eye priority / right-eye priority /
 left-eye priority

Focusing point /
Focusing point selection

81-area multiple AF / All target, group target area (9-area),
single target(normal), single target(small)

AF illuminator

With

Manual focus assist

Focus ring rotation activates Live View image magnification and/
or focus peaking when in S-AF+MF or MF mode

Peaking function

Activate with Fn button or focus ring

Change peaking settings using the Info button

Colour selection: white, black, red, yellow

Intensity selection: high, normal, low

Back light effect: on, off

Exposure Control (Still)

Metering system
(TTL Image sensor metering)

Digital ESP metering (324-area multi pattern metering),
center-weighted average metering, spot metering, spot metering
with highlight control, spot metering with shadow control

Metering area

EV -2 - 20 (using 17mm F2.8, ISO 100)

Exposure mode

iAUTO, P: Program AE (Program shift can be performed),
 A: Aperture priority AE,

S: Shutter priority AE, M: Manual, Bulb, Time, Scene select  AE,
Art Filter,

Underwater wide / macro*, My Set

Selectable from menu as a function on Fn button

My set can be set to mode dial function

Scene select AE

Portrait, e-Portrait, Landscape, Landscape + Portrait, Sport,
Hand-held Starlight*1, Night scene, Night + Portrait, Children, High Key,
Low Key, DIS mode, Macro, Nature Macro, Candle, Sunset, Documents,
Panorama, Fireworks, Beach & Snow, Fisheye Conv., Wide Conv.,
Macro Conv., Panning, 3D*2

1: 8 images automatically shot and combined into a single image composite

2: For 3D lens(H-FT012 by Panasonic) only, still photo only

ISO sensitivity

AUTO ISO : LOW(approx. 100) 25600 (customizable, Defalut:LOW-1600)

Manual ISO : LOW(approx.100), 200 - 25600, 1/3 or 1 EV steps selectable

Exposure compensation

Still photo 5 EV, movie 3 EV, with selectable EV adjustment steps
(1/3, 1/2, 1)

HDR shooting, monitor and EVF displays only up to 3 EV.

AE lock

Locks with a half-press of the shutter button
(can be set to Fn button as well)

Shutter

Shutter type

Focal-plane shutter / 1/8000 - 60 sec., with selectable EV
adjustment steps (1/3, 1/2, 1)

Bulb/Time: selectable exposure time (1/2/4/8/15/20/25/30 min.),
with 8-min. default setting

Flash

Flash intensity control method

TTL Auto, Auto*, Manual, Super FP*(FP-TTL AUTO, FP-MANUAL)

Available on the external flash

Built-in flash

-

Bundled standard flash

FL-LM3(dustproof and splashproof flash)

GN9.1(ISO100m) / GN=12.9(ISO200m)

Bounce Capability (up and down: 45, 60, 75, 90 degree /
left and right 30, 60, 90, 120, 150, 180 degree)

Powered by the camera

Flash mode

Flash Auto, Redeye, Fill-in, Flash Off, Red-eye Slow sync.(1st curtain),
Slow sync.(1st curtain), Slow sync.(2nd curtain),
Manual(1/1(FULL) - 1/64)

Synchronisation speed

1/250 sec.

 Super FP: 1/125-1/8000 sec.

Flash intensity control

Up to 3 EV in 0.3, 0.5, 1 EV steps selectable

Compatible external flash

FL-50R, FL-36R, FL-20, FL-14, FL-300R, FL-600R

Wireless flash control

Compatible external flash

FL-50R, FL-36R, FL-300R, FL-600R

Control method

Triggered and controlled by the bundled FL-LM3 or FL-600R

(Olympus Wireless RC Flash system compatible)

External Flash control mode

TTL Auto, Auto, Manual, FP-TTL-AUTO, FP-MANUAL

Channel

4 channels

Group No.

4 groups (External flash 3 groups + commander flash* )

FL-LM3 / FL-600R

Drive

Sequential shooting
maximum speed

[Sequential shooting H mode] approx 10.0 fps

IS OFF

Focus and exposure are fixed at the values for the first shot.

[Sequential shooting L mode] approx 5.0 fps

When using the M.ZUIKO DIGITAL ED 12-50mm F3.5-6.3 EZ

Max. recordable pictures

[RAW]  Max. frames (in 5.0 seq. shooting L)  Max. 16 frames (in 10.0 seq. shooting H)

 on sequential shooting*

[JPEG]  Max. frames (in 5.0 seq. shooting L)  Max. 19 frames (in 10.0 seq. shooting H)

When using the M.Zuiko Digital ED 12-40mm F2.8 PRO

With TOSHIBA SDHC UHS-II R260W240 EXCERIA PRO

Self-timer

Operation time: 12 sec., 2 sec., custom (Wait time: 1-30sec., Shot interval: 0.5/1/2/3sec., Number of shots: 1-10, Every time AF: ON/OFF)

Bracketing

Exposure bracketing

2, 3 or 5 frames in 0.3/0.7/1.0EV steps selectable,
7 frames in 0.3/0.7EV steps selectable

AE-BKT can be programmed to the Fn-button.

ISO bracketing

3 frames in 0.3/0.7/1.0EV steps selectable

White balance bracketing

3 frames in 2, 4, 6 steps selectable in each A-B/G-M axis.

Flash bracketing

3 frames in 0.3/0.7/1.0EV step selectable

Art filter bracketing

i-Enhance, Vivid, Natural, Muted, Portrait, Monotone, Custom,
Art Filters selectable

Focus Bracketing Mode

3-999 shots / 1-10 focus steps (movement differential)

Compatible with Micro Four Thirds AF lenses

Focus Stacking Mode

Not available

HDR function

HDR(Auto composite)

HDR1, HDR2 (painting-like)

Maximum shutter speed setting is 1 sec.

Exposure compensation can be performed.

Bracketing for HDR postprocess

3 or 5 frames in 2.0/3.0EV steps selectable,
7 frames in 2.0EV steps selectable.

This function does not execute HDR processing.

HDR function can be assigned to the Fn-button.

Art Filter

Mode (Variation / Effect)

Pop Art (I, II / a.b.c.d.e.f.)

Soft Focus ( - / c.e.)

Pale & Light Colour (I, II / a.b.c.d.f.)

Light Tone ( - / d.f.)

Grainy Film (I, II / b.c.d.g.h)

Pin Hole (I, II, III / d.)

Diorama ( I,II  / d.)

Cross Process (I, II / b.c.d.f.)

Gentle Sepia ( - / a.b.c.d.f.)

Dramatic Tone (I / b.c.d.e.f.)  (II / b.c.d.e.f.g.h)

Key Line (I, II / a.b.c.d.e.)

Water Colour (I, II / a.b.c.d.)

Vintage (I, II, III / a.b.c.d.e.f.i)

Partial Colour (I, II, III / a.b.c.d.e.f)

Art Effect

a. Soft Focus Effect

b. Pin-Hole Effect

c. White Edge Effect

d. Frame Effect

e. Star Light Effect

f. Blur Effect (Top & bottom, Left & Right)

g. B&W Effect (None, Yellow, Orange, Red, Green)

h. Pict. Tone (None, Sepia, Blue, Purple, Green)

i. Shade Effect (Top & bottom, Left & Right)

Colour Ring (for partial colour)

18 colour selectable

Photo Story

Type (Variation / Flame /
 Number of divided parts)

Standard (I, II, III, IV / abcd / ABCD)

Fun Frame (I, II, III / / )

Speed (- / - / AEF)

Zoom in / out (, / a, c / A, G)

Layout (I, II, III, IV / / -)

Frame Effect

a. White Frame

b. White Frame & White Edge Effect

c. Black Frame

d. White Frame & Pin Hole Effect

Aspect & Window Pattern

A. 4:3, 2 frames

B. 4:3, 3 frames

C. 1:1. 2 frames

D. 1:1, 3 frames

E. 1:1, 4 frames

F. 16:9. 5 frames

G. 16:9, 2 frames

Hold function

With

Movie

Recording format

MOV(MPEG-4AVC/H.264) , AVI(Motion JPEG)

Mode / frame rate /
compression method

[MOV]

1920x1080(FHD) / 30p, 25p, 24p / ALL-I(A-I), IPB(SF, F, N)

1920x1080(FHD) / 60p, 50p / IPB(SF, F, N)

1280x720(HD) / 60p, 50p, 30p, 25p, 24p / ALL-I (A-I), IPB(SF, F, N)

60p:59.94fps, 50p:50.00fps, 30p:29.97fps, 25p:25.00fps, 24p:23.98fps

FHD ALL-I (A-I: approx. 77Mbps)

FHD IPB(SF: approx. 52Mbps, F:approx. 30Mbps, N:approx. 18Mbps)

[AVI]

1280x720(HD) / 30p

640x480(SD) / 30p

Frame rates may drop when particular Art Filters and
Movie Effect are used

Class 10 or higher SD card is recommended for shooting movies

UHS-II or UHS-I Class3 card is recommended for ALL-I shooting.

Maximum recording time

[MOV] Approx. 29min

[AVI] HD: Approx. 7min* / SD: Approx. 14min*

Excluding when particular Art Filters are used

Art Filter Movie

With*

Frame rate: lower.

Movie Effect

One-shot Echo / Multi-echo / Art Fade / Old Film

One-push Movie Digital
Conveter

x4

Time Lapse Movie

[AVI]

38402160(4K)/5fps

19201080(FHD)/5fps,10fps,15fps

1280720(HD)/5fps,10fps,15fps,30fps

Photo in Movie

With (mode1 / mode2)

mode1 is available when recording framerate is less than 30p.

Clips

1, 2, 4, 8 sec

 (Further continued shooting possible by pressing movie record button again)

Quick Movie / Slow Movie

With

IS for Movie

M-IS1(Image sensor shift and electronic image stabilizer with multi motion IS),

M-IS2(Image sensor shift with multi motion IS), Off

Field of view may be affected in M-IS1.

Grid Line / Focus Peaking

4 types of grid lines / 4 colours for focus peaking

Time code

Rec run / free run, drop frame / non-drop frame

Live View Output via HDMI

With (GUI* is shown on connected device only, and peaking function is not available when connected by HDMI.)

GUI can be hidden on the connected device by pressing down on INFO button for recording an external drive under the following condition. Movie quality: YCbCr 4:2:2 / Frame rate: same as movie setting (24p, 30p and 60p settings are not recommended.) / Sound recording: not available

Movie picture mode

Flat

Exposure Control

Program AE, aperture priority AE, shutter priority AE, manual

AE Lock

With

Recording(Sound)

Recording format

Wave Format (Stereo linear PCM/16-bit, Sampling frequency 48kHz)

Microphone / Speaker

Stereo/Mono

Microphone function

Wind noise reduction,  Recording volume, Microphone volume limiter

Audio dubbing possible for still pictures (up to 30 sec.)

Linking with Olympus
PCM Recorders

Slate Tone/Synchronised Audio Rec-Movie Rec

LS-100 compatible

White Balance

White balance mode

Auto WB, 7 Preset WBs, 4 Capture WBs, Custom WB(Kelvin setting)

White balance compensation

7 steps in each A-B/G-M axis

Except for Custom WB

Colour Mode

Colour matrix

sRGB, Adobe RGB

Picture Mode

Mode

i-Enhance, Vivid, Natural, Flat, Portrait, Black and White, Custom, e-Portrait, Colour Creator, Art Filter, Underwater

Gradation

Auto, Normal, High Key, Low Key [except Art Filters]

Keystone Compensation

Keystone Compensation

With (can be confirmed on Live View)

High Res Shot

Resolution

Equivalent to 40M pixel sensor (8 shots combined into a single JPEG using sensor shift)

Available in P/A/S/M mode, RAW+JPEG or JPEG.

JPEG: 7296 x 5472 / RAW: 9216 x 6912

RAW data can be developed in-camera.  Development by
PC is possible with the appropriate plug-in.

Shutter Type / Shutter Speed

Electronic shutter / 1/8000 - 8 sec.

Anti-shock Mode

Shutter Type / Shutter Speed

Electronic first curtain shutter  /  1/320* - 60sec

For speeds over 1/320 sec., mechanical shutter
will automatically be selected.

Shutter start delay

0,  1/8,  1/4,  1/2,  1,  2,  4,  8,  15,  30sec

Silent Mode

Shutter Type / Shutter Speed

Electronic shutter  /  1/16000 - 60sec

Shutter start delay

0, 1/8, 1/4, 1/2, 1, 2, 4, 8, 15, 30sec

Live Bulb / Live Time

Update interval time

0.5 sec - 60 sec

Live Composite

Update interval time /
composite method

0.5 sec - 60 sec / Lighten Mode (Bright area prioritization)

Interval Mode

Interval Mode

Interval Time 1sec. - 24 Hours,  Max 999 frames.

Available on making Time-lapse movie automatically

Multi Exposure

Number of picture / Function

2 frames / Auto gain, Exposing on Recorded picture(RAW)

Multi Aspect

Aspect Ratio

4:3(Default) / 3:2 / 16:9 / 1:1 / 3:4

Level Gauge

Detection

2-axis

One push Tele-converter

Magnification

x2

Wi-Fi Function

GPS info. Function

Via smartphone GPS data

Wireless Shooting*

Live View, Rec View, Wireless Touch AF shutter, Self Timer (w/Countdown guidance, Sequential shooting, movie recording capability), Wireless Release, Movie Recording, Power Off, iAuto / ART / P / A / S / M (Live Bulb, Live Time, Composite) and drive mode can be selected.* Aperture, shutter speed, exposure, ISO sensitivity, white balance can be adjusted.*

Shooting with a smartphone

When in private connection

Image Share

File Type: JPEG* , MOV

Connect to up to 4 devices simultaneously.  Marking function for image share.

Excluding MPO file

Easy Connection

QR code setting

Tetherd shooting

Tethered shooting

Via USB connection, with use of Olympus Capture tethering software
(camera can be controlled by both the camera and computer)

Playback

Playback mode

Single-frame, Information display, Index display (4/9/25/100 frames),
Calendar, Enlargement (2x - 14x), Movie (with sound, FF/REW/Pause),
Picture rotation (auto), Slideshow (with sound including BGM,
Slide show effects, replaceable BGM), Light Box display

Information display

Histogram (independent luminance / RGB available),
Highlight/Shadow point warning, AF frame, Photographic information,
OFF

Menu

Languages

34 languages selectable:

- English, French, German, Spanish, Italian, Japanese, Korean, Traditional Chinese, Simplified Chinese, Russian, Czech, Dutch, Danish, Polish,
Portuguese, Swedish, Norwegian, Finnish, Croatian, Slovenian,
Hungarian, Greek, Slovakian, Turkish, Latvian, Estonian, Lithuanian,
Ukrainian, Serbian, Bulgarian, Rumanian, Indonesian, Malay, Thai

Image Editing

Editing function

RAW data edit, Gradation auto, Monochrome, Sepia, Red-eye fix, Saturation, Resize (1280x960, 640x480, 320x240), Trimming, Aspect, e-Portrait, Image Overlay, Postrecording

RAW data edit

RAW data edit based on settings of the camera (including e-Portrait, Colour Creator, Art Filter, ART-BKT). 2 programmable settings, preview capability.

Print

Print function

Print reservation (DPOF), Direct print (PictBridge compatible)

Input/Output

USB/AV/Remote controller
connector

Dedicated multi-connector   [USB: USB2.0 Hi-Speed,  Video: NTSC/PAL selectable, Optional Remote cable RM-UC1 compatible.]

HDMI connector

Micro HDMI (Type-D)

Flash attachment

Hot shoe / Sync. terminal

Microphone input jack

3.5 stereo mini jack

Headphone connector

None / Attachment of HLD-8G optional grip allows connection

PC interface

USB2.0 Hi-Speed

TV interface

HDMI out(HD / stereo), video out(SD / mono)

DC connector

None / attachment of HLD-8 power battery holder allows connection

Power Requirements

Battery

BLN-1 Li-ion battery (included)

Power Battery Holder

HLD-8 Power Battery Holder separately available.

 Allows attachment of an additional BLN-1.

AC Adapter

AC-3 AC adapter* separately available.

HLD-8 Power Battery Holder is required for connection.

Sleep mode

Available (1/3/5 min. off)

Number of recordable pictures

Approx. 310 shots (using BLN-1 and TOSHIBA SD with IS ON,
based on CIPA test standards)

Approx. 750 shots (using BLN-1 and TOSHIBA SD with IS ON and Quick Sleep Mode ON, based on Olympus testing using CIPA test standards)

Battery Life

Approx. 80 minutes* (under standard JEITA testing)

Approx. 150 minutes(when zoom and other operational
functions are not used)

When repeatedly recording at the maximum time of 29 minutes

Dimensions / Weight

Dimensions

123.7(W)85(H)44.5(D)

[CIPA guideline compliant, excluding protrusions]

Weight

Approx. 469g  [CIPA guideline compliant, with BLN-1 battery
and Memory card]

Approx. 417g  [body only]

Operating Environment

Temperature

-10 ~ +40 (when in operation) / -20 ~ +60 (when stored)

Humidity

30 - 90% (when in operation) / 10 - 90% (when stored)

Link to product page    $1,813.80
Olympus E-PL8 SLK  (White)

Olympus PEN E-PL8 16MP Mirrorless Digital Camera Single Lens Kit w. 14-42mm EZ Lens - White


- 16.1MP, 4/3 Live MOS Sensor, 3-Axis In Body IS, 8.5FPS, 3.0" Tilting Touch LCD, 81-Point-AF, Wifi :: E-PL8 SLK (White)

Overview



PEN E-PL8 AT A GLANCE

When you see the Olympus PEN E-PL8, you cant resist the urge to pick it up and hold it. With its sleek contemporary design, it looks more like a beautiful accessory and less like a traditional camera. Premium materials and finishes add to the luxurious appearance and feel. The compact PEN E-PL8 fits into a handbag and is ready anytime you need spectacular photos or videos - youll be an instant hit on your social newsfeeds. The flip touchscreen monitor provides easy operation, and the powerful in-camera creativity tools let you express your individual style. It doesn't just take great pictures. It makes an impression.

16 Megapixel Live MOS Sensor

1/4000 Sec Mechanical Shutter

180 Tilt Touch LCD Monitor

3-Axis Image Stabilization

Video Clips

Touch AF and Shutter Release

TruePic VII Image Processor

Full HD 1080p Video

Built-in Wi-Fi

STYLE THAT GOES ANYWHERE

Youre attending a wedding and want to look your best. Take along the camera that looks amazing too. The PEN E-PL8s premium materials and finishes, from the leather grain to intricately-textured dials to the brushed aluminum, turn this beautiful camera into a high-end accessory. Every inch of the E-PL8 has been thoughtfully considered, like the modern rounded corners and the embossed Olympus PEN logo. Even after hours of capturing friends and family at a wedding reception, this lightweight, compact camera will feel comfortable in your hand.

EASY TO USE. EVEN WHEN TAKING SELFIES.

Traveling to new places is always an adventure. Using your camera shouldnt be. Thats why the PEN E-PL8 has a unique flip monitor thats also a touch screen. All of the primary functions are in one place right at your fingertips. Of course, whats an overnight trip, week-long vacation, or dream honeymoon without selfies in cool locations? The PEN E-PL8 automatically shifts into Selfie Mode when the monitor is flipped down. Sophisticated imaging technology ensures spectacular-looking selfies, even in low light or at night

PRO QUALITY PHOTOGRAPHY FOR EVERYONE

Your toddler is growing up quickly and you want shots youll appreciate for years to come. The PEN E-PL8 helps you get photos even a professional will appreciate. In iAuto, the intelligent E-PL8 instantly chooses the best of 42 modes ensuring the perfect picture. Use Live Guide to adjust the look of an image before you take it like blurring an images background. Plus, the E-PL8 automatically compensates for motion blur with its in-body 3-Axis Image Stabilization System perfect for getting clear, crisp shots while chasing your kids down the soccer field.

CREATIVELY CAPTURE YOUR LIFE

Spending time with family and friends is always at the top of your to-do list. Its a chance to shoot your best stills and video. With the E-PL8, its also a chance to get creative. Fourteen Art Filters - including the Partial Color filter - give your images and video a unique, personalized look. When youre at a big family birthday, use the video Clips feature to edit together snippets of video and add music to easily create a fun video, all in camera. And when youre out on the town with friends, use the nighttime Live Composite Mode to capture stunning cityscapes and stars youll always treasure

INSTANTLY SHARE EVERY MOMENT

When loved ones are around, everyone wants to get in the photo. Its easy with the PEN E-PL8. Use the cameras built-in Wi-Fi and fast QR code setup to link your smart device with the free Olympus Image Share app, then remotely control the camera, frame the shot, and trip the shutter. Spontaneous everyday moments of your kids, your family, and your life can be instantly and wirelessly uploaded and shared. Its an easy way of keeping everyone important to you updated about your life

LENSES & ACCESSORIES THAT MAKE A PERFECT MATCH

Olympus M.Zuiko lenses are fast, compact and lightweight, a perfect match for the PEN E-PL8. The M.Zuiko 14-42mm IIR is an ideal starter lens for everyday shooting, while the M.Zuiko 14-42mm EZ keeps the size compact and convenient. The M.Zuiko 40-150mm R has excellent zoom range for travel, and the M.Zuiko 12-50mm Macro lets you shoot beautiful close-ups and portraits. Best of all, you can add a soft leather neck strap, customized body jacket, or multi-purpose case to create a camera look thats all your own

Specifications

Sensor Effective Resolution / Type

16.1 Megapixel Live MOS

Processor

TruPic VII

Focusing System

F.A.S.T. AF (Contrast Detection)

Image Stabilization System

3-Axis In Body Image Stabilization

Rear Monitor

3.0" Tilting Touch LCD

Creative Features

Live Composite, Selfie Mode, Selfie Video, Clips Mode

Sequential Shooting Speed

8.5fps [H] mode 3.7fps [L] mode mechanical shutter.

Special Features

Easy image sharing via Wi-Fi and OI.Share App

Sensor / Dust Reduction

Sensor Type

4/3 Live MOS Sensor

Effective Pixels

16.1 million

Total Pixels

17.2 million

Filter Array

Primary color filter (RGB)

Aspect Ratio & Area

4:3 / 17.3 x 13.0mm

Dust Reduction

Super Sonic Wave Filter

Processor

Processor Type

Olympus TruePic VII

Focusing System

AF System Type

High-speed imager AF (Contrast detection)

Focus Modes

Single AF (S-AF) / Continuous AF (C-AF) / Manual Focus (MF) / S-AF + MF / AF tracking (C-AF + TR) With Full-time AF (Automatic activation when shooting selfie movies)

Full Time AF

Available

Magnified Frame

AF

Selectable from over 800 AF points

Enlarged view check by magnify button

Magnification x5, x7, x10(Default), x14 selectable

* Super Spot AF only available when a Micro Four Thirds lens is attached

Face Detection AF / Eye Detection

Available / Available Eye Detection AF mode: Off / Nearer-eye priority / Right-eye priority / Left-eye priority

Focusing Points / Focusing Points Selection Mode

81-area multiple AF (Contrast detection AF),

All target, Group target area (3x3-area),

Single target(Standard Target Size/Small Target Size)

AF Illuminator

Available

AF Targeting Pad

Available *Activate / deactivate with double tap on rear monitor

Manual Focus Assist * Customize Function

Live view image is magnified when the focus ring is rotated. (at S-AF+MF or MF mode)

Peaking Function

"Activate with Fn button or focus ring

Change peaking settings using the Info button

Color selection: white or black

Image Stabilization

System Type

Built-in (Image sensor shift type for movie & still, 3-axis* image stabilization) *yaw/pitch/roll

Modes

4 modes (S-I.S.AUTO,S-I.S.1, S-I.S.2, S-I.S.3), OFF

Live View Image Stabilization

Activation by half-pressing shutter release or enlarging view.

Focal Length Setting

Yes

IS For Finder Image

Available (by half-pressing the shutter button or enlarging operation)

Stabilization Performance

3.5 EV Steps *Based on CIPA measurement conditions.

When using M.Zuiko Digital ED 14-42mm F3.5-5.6 EZ (focal length=42mm (35mm equivalent with 84mm)

Lens IS Priority

Yes

Shutter / Sequential Shooting

Shutter Type

Computerized focal-plane, high-speed, mechanical shutter

Shutter Speed

1/4000 - 60 sec. (1/3, 1/2, or 1EV steps selectable) Bulb/Time: default setting 8min. (1/2/4/8/15/20/25/30 min. selectable) Electronic first curtain shutter1 : 1/320 - 60 sec. 1. When Anti-shock mode is set to 0 sec.

Sequential Shooting Maximum Speed

Sequential shooting H mode1: approx 8.5 fps

1. Focus and exposure are fixed at the values for the first shot, IS off.

Sequential shooting L mode: approx 3.7 fps (when using M.Zuiko Digital ED 14-42mm f/3.5-5.6 EZ lens)

Max Recordable Pictures in Sequential Shooting

[RAW] Max. 20 frames (in 3.7 seq. shooting L) Max. 16 frames (in 8.5 seq. shooting H)

[JPEG] Max. frames (in 3.7 seq. shooting L) Max. 64 frames (in 8.5 seq. shooting H)

* When using the M.Zuiko Digital ED 14-42mm f/3.5-5.6 EZ

* With TOSHIBA SDHC UHS-IEXCERIA 32G

Self Timer

Operation time: 12 sec., 2 sec., custom (Wait time: 1-30sec., Shot interval: 0.5/1/2/3sec., Number of shots: 1-10, Every time AF: Off/On)

Anti-shock Mode

Electronic first curtain shutt

Monitor

Rear Monitor Type

3.0 tilting touch monitor*

*Approx 1037k dots (3:2) electrostatic capacitance touch screen

Rear Monitor Size

3.0 / 7.6 cm

Touch Control

Shutter release, magnification, AF area selection, AF area size adjustment, frame forward/backward, magnified playback, Live Guide, Super Control Panel, Art Filter mode selection, scene mode selection, Wi-Fi connection, clips, movie effect, movie teleconverter When in Selfie Mode: Shutter release, e-Portrait, custom self-timer, movie, exposure compensation

Tilting Capability

Upward tilting angle : up to 80 degrees

Downward tilting angle : up to 180 degrees

*mirror display when monitor is in selfie position

Brightness / Color Temp Control (Rear Monitor)

7 levels / 7 levels

Color Tone Select

Vivid / Natural

Live View

Approx. 100% field of view,

Exposure compensation preview,
WB adjustment preview,

Gradation auto preview, Face detection preview (up to 8 faces),

Grid line, Histogram, Magnification display (x5/x7/x10/x14), Normal, Highlight & Shadow, Level Gauge, Off

Preview

Preview with depth of field preview lock (must be assigned to button to activate)

Live View Boost

Yes (does not reflect ceratin adjustments such as exposure compensation)

Field of View

Approx. 100%

Display Mode

Normal Mode, Histogram Mode, Level gauge, Highlight and shadow, Off

Monitor Information

Aperture value, Shutter speed, Auto Bracket, AE Lock, AF mode, IS, Shooting Mode, Battery Check, Myset, Internal Temperature Warning, Face / Eye Detection, Histogram, Number of storable still pictures, Record mode, ISO, Sequential shooting, Self-timer, White Balance, Metering Mode, AF confirmation mark, Exposure Compensation Value, Spot metering Area Flash Mode, Flash Status, Flash intensity Control, Super FP, Focal length, Tone control, Eye-Fi condition, Digital teleconverter, Battery check

Display of Face Detection

Max 8 frames of face detection can be displayed.

Exposure Control / Flash

Metering System

Digital ESP metering (324-area multi pattern metering), Center weighted average metering, Spot metering, Spot metering with highlight control, Spot metering with shadow control (TTL Image sensor metering)

Metering Range

EV -2 - 20 (at normal temperature, 17mm f2.8, ISO 100)

Exposure Mode

i Auto (Live Guide can be performed) , P: Program AE (Program shift can be performed), A: Aperture priority AE, S: Shutter priority AE, M: Manual (Live Bulb, Live Time and Live Composite), Photo Story,Scene select AE,Art Filter, Underwater wide/macro1, Custom Mysets 1-42

1. Assign to a button to activate

2. Myset can be assigned to mode dial positions (replacing the original modes)

Scene Select AE

Portrait, e-Portrait, Landscape, Landscape + Portrait, Sport, Hand-held Starlight1, Night scene, Night + Portrait, Children, High Key, Low Key, DIS mode, Macro, Nature Macro, Candle, Sunset, Documents, Panorama, Fireworks, Beach & Snow, Fisheye Conv., Wide Conv., Macro Conv., Panning, 3D2

1. 8 images automatically shot and combined into a single image composite

2. For 3D lens (H-FT012 by Panasonic) only, still photo only

ISO Sensitivity

Auto: ISO LOW (approx. 100) - 25600 (customizable, default ISO LOW - 1600)

Manual: ISO LOW (approx. 100) - 25600 in 1/3 or 1 EV ISO steps

Exposure Compensation

Still photo 5 EV, movie 3 EV in 1/3, 1/2, 1 EV steps selectable

*HDR shooting, monitor and EVF displays only up to 3 EV

Locks with a half-press of the shutter button
(can be set to Fn button as well)

Flash Intensity Control Method

TTL Auto, Auto*, Manual, super FP*(FP-TTL AUTO, FP-MANUAL)

* Available with external flash

Bundled Flash

FL-LM1 - TTL flash, GN = 7 (ISO100m) / GN = 10 (ISO200m)

Flash Mode

Auto, Red Eye Reduction, Slow Sync (1st curtain sync), Slow Sync (2nd curtain sync), Slow Sync (2nd curtain sync) + Red Eye Reduction, Fill-in, Manual (1/1 (FULL) to 1/64), Flash Off

Synchronization Speed

Differs by flash unit and mode. FL-LM1: 1/250 sec., FL-50R: 1/180 sec., Other: 1/200 sec. Super FP: 1/125 to 1/4000 sec., RC: 1/160 sec.

Flash Intensity Control

Up to 3 EV in 1/3, 1/2, 1 EV steps selectable

Wireless Flash Control Method

Triggered and controlled (Olympus Wireless RC Flash system) Commander flash : FL-LM1, FL-600R, FL-900R

External Flash Intensity Type

TTL Auto, Auto, Manual, FP-TTL-AUTO, FP-MANUAL

Channel No.

4 channels

Group No.

4 groups: 3 external flash + 1 commander flash

Memory / Image Recording (File Format)

Compatible Memory

SD Memory Card (SDHC, SDXC, UHS-I/II compatible, Eye-Fi Card compatible* ) *Not compatible with Endless Memory.

Recording Format

DCF 2.0, Exif 2.3

File Format

RAW (12-bit lossless compression), JPEG, RAW+JPEG, MPO(3D still)

Recording Image Size

[RAW] 4608 x 3456 pixels

[JPEG] 4608 x 3456 pixels - 640 x 480 pixels

White Balance / Color Mode

White Balance Mode

Auto WB, 7 Preset WBs, 4 Capture WBs, Custom WB(Kelvin setting)

White Balance Compensation*

7 steps in each A-B/G-M axis * Except for Custom WB

Color Mode

sRGB, Adobe RGB

Brackting / HDR

Exposure Bracketing

2, 3 or 5 frames in 0.3/0.7/1.0EV steps selectable, 7 frames in 0.3/0.7EV steps selectable

ISO Bracketing

3 frames in 0.3/0.7/1.0EV steps selectable

White Balance Bracketing

3 frames in 2, 4, 6 steps selectable in each A-B/G-M axis.

Flash Bracketing

3 frames in 0.3/0.7/1.0EV step selectable

Art Filter Bracketing

i-Enhance, Vivid, Natural, Muted, Portrait, Monotone, Custom, Underwater, Art Filters selectable

HDR (Auto Composite)

HDR1,HDR2 (painting like)

*ISO sensitivity is fixed at 200 and maximum shutter speed is 4 sec.

Bracketing for HDR post-process

3 or 5 frames in 2.0 or 3.0EV steps, 7 frames in 2.0EV steps.

*This function is for capturing images for post production HDR processing, and does not execute HDR processing.

Creative Features

Picture Mode

i-Enhance, Vivid, Natural, Muted, Portrait, Monotone, Custom, e Portrait, Underwater, Art Filters

Gradation

Auto, Normal, High Key, Low Key [except Art Filters]

Adjustment Parameter

4 levels (Auto, Normal, High key, Low key)

Filter Effect (B&W Filter)

Neutral, Yellow, Orange, Red, Green for Monotone

Picture Tone

Neutral, Sepia, Blue, Purple, Green for Monotone

Art Filter

Fourteen in-camera Art Filters are enhanced by new filter variations, art effects and bracketing. You can use Art Filters in all shooting modes as well as filming 1080 HD movies.

Art Filter Modes

Pop Art (I, II / a.b.c.d.e)

Soft Focus ( - / c.e)

Pale & Light Color (I, II / a.b.c.d)

Light Tone ( - / d)

Grainy Film (I, II / b.c.d.f.g)

Pin Hole (I, II, III / d.)

Diorama ( - / d.)

Cross Process (I, II / b.c.d.)

Gentle Sepia ( - / a.b.c.d.)

Dramatic Tone (I / b.c.d.e) (II/ b.c.d.e.f.g)

Key Line (I, II / a.b.c.d.e.)

WaterColor (I, II / a.c.d.)

Vintage (I, II, III / a.b.c.d.e.f.i.)

Partial Color (I, II, III / a.b.c.d.e.f.)

Art Effect

a. Soft Focus Effect

b. Pin-Hole Effect

c. White Edge Effect

d. Frame Effect

e. Star Light Effect

f. Defocus Effect

g. B&W Effect (Yellow, Orange, Red, Green)

h. Picture Tone (Sepia, Blue, Purple, Green)

i. Shade Effect (Top & Bottom, Left & Right)

Color Ring (for partial color)

Photo Story

With Photo Story, users can shoot a normal, everyday scene from multiple viewpoints and combine them into one image. Simply turning the mode dial to Photo Story, youll be provided with different formats to choose from, and everyday occurrences will become memorable scenes.

Type (Variation / Frame Effect / Window / Aspect)

Standard ,,, / a, b, c, d / A, B, C, D

Speed ( - / - /A, E, F)

Zoom in / out (,/ a, c / A, G)

Layout ,,,/ NA / NA

Can select picture mode for each frame.

Fun Frame (, , //)

Frame Effect (photo story)

a. White Frame

b. White Frame & White Edge Effect

c. Black Frame

d. White Frame & Pin Hole Effect

Aspect Window / Pattern (photo story)

A. 4:3/2Frames

B. 4:3/3Frames

C. 1:1/2Frames

D. 1:1/3Frames
