Lens construction
|
|
6 elements in 5 groups (with Nano Crystal Coat) |
|
Picture angle
|
|
2830 (maximum 3750 when fully shifted) |
|
Focal-length scale
|
|
NA |
|
Number of diaphragm blades
|
|
9 (rounded) |
|
Diaphragm
|
|
Electrically automatic/One-touch preset aperture operation |
|
Minimum f/stop
|
|
32 |
|
Lens movement
|
|
Shift and tilt movement at right angles (the two operations can be modified for a surcharge, to move in the same [parallel] direction. The shift lock release knob can also be changed for a larger one, but the changed knob may affect mounting the lens to the camera or lens operation.) Maximum shift amount: 11.5mm Maximum tilt amount:8.5 |
|
Lens rotation
|
|
90 right and left (click-stop for each 30 step) |
|
Closest focusing distance
|
|
0.39 m (1.3 ft.) |
|
Maximum reproduction ratio
|
|
0.5x |
|
Zoom control
|
|
NA |
|
Macro focusing
|
|
NA |
|
Focus-limit switch
|
|
NA |
|
M/A mode
|
|
NA |
|
A-M mode switch
|
|
NA |
|
Focus lock button
|
|
NA |
|
Wight (approx.)
|
|
635 g/22.4 oz. |
|
Dimensions (approx.) (from the cameras lens mounting flange)
|
|
83.5 x 107 mm/3.3 x 4.2 in. |
|
Lens cap
|
|
Snap-on |
|
Lens hood
|
|
HB-22 |
|
Lens case
|
|
CL-1120 |
|
Tripod collar
|
|
NA |
|
External front filter attachment frame
|
|
Does not rotate |
|
External front filter
|
|
77 mm |
|
Slip-on filter
|
|
NA |
|
Built-in/rear filter
|
|
NA |
|
Circular polarizing filter II
|
|
NA |
|
Infrared compensation scale
|
|
NA |
|
Optional accessories
|
|
77 mm screw-in filters |
|
Aperture ring
|
|
Does have |
|
Distance scale
|
|
Does have |
|
Note:
These lenses can be used with the D3, D700 and D300 without any limitation; and can also be used with the following cameras, though some restrictions or limitations on functions exist: D2 series, D1 series, D200, D100, D80, D70 series, D60, D50, D40 series, F6, F5, F4 series, F100, F90X/N90s, F90 series/N90, F80 series /N80 series, F75 series /N75 series, F65 series /N65 series, and PRONEA 600i/6i. |
