Acer MR.JMV11.00C Essential P1186 DLP 3D
Projector
Overview
Acer Essential series projectors are best value projectors ideal for everyday
use, at work or home. Make your presentations more compelling and entertainment
more exciting with high brightness, high contrast and DLP® 3D Ready2, while
adhering to your bottom line.
Auto Ceiling Mount Correction
This feature automatically flips the projected image over if the projector is
turned upside down.
Acer EcoProjection
This device is designed to help the planet by automatically reducing standby
power consumption by as much as 80%.
Acer ColorSafe
This technology ensures this device will deliver great color reproduction,
even after years of intensive use.
Acer Dynamic Black
Improves image contrast by dynamically adjusting dark scenes to optimal black
levels.
Wireless Projection
Project content without bothersome cables. Say goodbye to cable clutter and
manual connecting of devices.
Digital Zoom and Pan
This feature allows you to zoom in on specific portions of a projected image
without moving the projector.
Specifications
|
Image |
|
|
Native
Resolution |
800 x
600 |
|
Maximum
Resolution |
1920 x
1200 |
|
Standard Mode
Brightness |
3300
lm |
|
Native Aspect
Ratio |
4:03 |
|
Compatible Aspect
Ratio |
16:09 |
|
Contrast
Ratio |
20,000:1 |
|
Throw
Ratio |
1.94 to 2.16
(51"@78.74") |
|
Digital
Zoom |
2x |
|
Vertical Keystone
Correction |
-40/+40 |
|
Maximum Vertical
Sync |
120
Hz |
|
Maximum Horizontal
Sync |
100
kHz |
|
Minimum Vertical
Sync |
24
Hz |
|
Minimum Horizontal
Sync |
15
kHz |
|
Color
Supported |
1.07 Billion Colors
(30-bit) |
|
|
|
|
Projection
Lens |
|
|
Lens
Type |
Manual
Focus |
|
Manual
Zoom |
|
Minimum Lens
Aperture |
F/2.41 |
|
Maximum Lens
Aperture |
F/2.53 |
|
Minimum Focal
Length |
21.85
mm |
|
Maximum Focal
Length |
24.01
mm |
|
Minimum Diagonal Image
Size |
27" |
|
Maximum Diagonal Image
Size |
25
ft |
|
Minimum Projection
Distance |
47.24" |
|
Maximum Projection
Distance |
38.71
ft |
|
Optical
Zoom |
1.1x |
|
|
|
|
Lamp |
|
|
Lamp
Type |
OSRAM |
|
Number of
Lamps |
1 |
|
Lamp
Power |
195
W |
|
Normal Mode Lamp
Life |
5000
Hour |
|
Economy Mode Lamp
Life |
6000
Hour |
|
ExtremeEco Mode Lamp
Life |
10000
Hour |
|
|
|
Interfaces/Ports |
|
|
HDMI |
Yes |
|
Number of USB
Ports |
1 |
|
USB |
Yes |
|
USB Connector
Type |
Type-A |
|
Number of Composite
Video Ports |
1 |
|
Composite
Video |
Yes |
|
Number of VGA
Inputs |
1 |
|
VGA
In |
Yes |
|
Number Of Audio
Inputs |
1 |
|
Number Of Audio
Outputs |
1 |
|
Audio Line
In |
Yes |
|
Audio Line
Out |
Yes |
|
|
|
|
Technical
Information |
|
|
Projection
System |
DLP |
|
Projection
Method |
Ceiling |
|
|
Front |
|
Rear |
|
Rear
Ceiling |
|
Video
Compatibility |
EDTV |
|
|
HDTV |
|
NTSC |
|
PAL |
|
SDTV |
|
SECAM |
|
Computer
Compatibility |
Mac
PC |
|
|
Windows
PC |
|
|
|
|
Audio |
|
|
Number of
Speakers |
1 |
|
Speaker Output
Power |
3
W |
|
Speaker Output
Mode |
Mono |
|
|
|
Power
Description |
|
|
Power
Supply |
100 V AC~240 V
AC |
|
Input
Voltage |
120 V
AC |
|
|
230 V
AC |
|
Operating Power
Consumption |
235
W |
|
Operating Power
Consumption (Eco Mode) |
195
W |
|
|
|
Physical
Characteristics |
|
|
Fan
Noise |
28 dB Approximate
Economy Mode |
|
|
31 dB Approximate
Standard Mode |
|
Temperature |
32F (0C) to 104F
(40C) |
|
Humidity |
80% Maximum Relative
Humidity |
|
Weight
(Approximate) |
5.29
lb |
|
Form
Factor |
Ceiling
Mountable |
|
|
|
|
Miscellaneous |
|
|
Package
Contents |
P1186 DLP
Projector |
|
AC Power
Cord |
|
Battery for Remote
Control |
|
Quick Start
Guide |
|
Remote
Control |
|
Security
Card |
|
User's Guide
(CD-ROM) |
|
VGA
Cable |
|
Carrying
Case |
|
Optional
Accessories |
Carrying
Case |
|
Dust
Filter |
|
3D
Glasses |
|
Lamp |
|
WirelessCAST
(MWA3) |
|
Ceiling
Mount |
|
WirelessHD-Kit |
