Camerafarm product archive #42158

Image Date Product description Price Buy
05/06

Vivotek AW-FET-080A-120 Unmanaged 8xFE PoE Switch - Megapixel/D1/VGA, MJPEG/MPEG-4/H.264/H.265

Unmanaged 8xFE PoE Switch

AW-FET-080A-120

Technical Specifications

Models: AW- FE T- 080A-120 (120W )

IP Camera Compatibility

Video Resolution: Megapixel/D1/VGA

Video Compression: MJPEG/MPEG-4/H.264/H.265

Ethernet

Fast Ethernet (RJ45): 8

Standards

IEEE 802.3 10-BASE-T (Ethernet): Supported

IEEE 802.3u 100-BASE-TX (Fast Ethernet): Supported

IEEE 802.3x Flow Control (Full-Duplex Flow Control): Supported

IEEE 802.3af Power over Ethernet: Supported

IEEE 802.3at Power over Ethernet Plus: Supproted

Ethernet Performance

MAC Address: 1 K

Buffer Memory: 64KB

Transmission Method: Store and Forward

Backplane: 1.6 Gbps

Auto-MDI/MDI-X, Auto-Negotiation: Supported

Filtering/Forwarding Rates

10Mps: 14,880 pps

100Mbps: 148,000 pps

Transmission Media

10Base T: Cat. 3, 4, 5 UTP/STP

100Base TX: Cat. 5, 5e UTP/STP

PoE Function

Number of PoE Out Ports: 8

Max. PoE Output Power/per Port: 30W

802.3at/af standard Compatible: Yes

Over Current Protection: Supported

Circuit Shorting Protection: Supported

Total PoE Power Budget: 115W

Power Pin Assignment: 1/2(+), 3/6(-)

PoE PD Auto Detection: Yes

General

LED Indicators: Power, LAN ports x8, PoE ports x8

Power Input: 100~240VAC / 50~60Hz, Internal Power 120W Power Module

Power Consumption: 120W

Dimensions: 280 (L) x 182 (W) x 44 (H) mm

Weight: 1.6 kg

Operating Temperature: 0C ~ 50C (32F ~ 122F)

Storage Temperature: -20C ~ 70C (-4F ~ 158F)

Humidity: Operating: 10~90% (Non-condensing), Storage: 10~90% (Non-condensing)

Safety Certifications: CE, C-Tick, FCC, LVD, VCCI

Accessory

Included Accessories: Power cord, QIG, 19" rack mount kit
 Link contains in-depth information about this product Link contains a picture of this product    NA
05/06

Team 1GB Micro SD Card


- With SD Adapter
Team Mini SD 1GB w/ SD Adapter Team Mini SD 1GB with SD Adapter
 Link contains in-depth information about this product Link contains a picture of this product    NA
05/06

Vivotek VT-AM-51A Outoor Dome Adapter

VT-AM-51A Outoor Dome Adapter

"FD8162, FD8163, FD8135H, FD8171, FD8155H, FD8165H, FD8173H FD8335H, FD8362E, FD8363, FD8355EHV, FD8365EHV, FD8373EV, FE8174V, FE8181-V +AM-517: FD8164, FD8154, FD8137H, FD8169, FD8167(-T), FD8138-H, FD8367-(T)V, FD8338-HV, FE8173, FE8174, FE8181"
 Link contains in-depth information about this product Link contains a picture of this product    NA
05/06

D-Link DCS-935L HD Wi-Fi Camera - 1/4" Megapixel Progressive CMOS Sensor, 4x Digital Zoom, Motion Detection With Nightvision, Built-In Microphone, Simultaneous H.264/MJPEG Format Compression - White

mydlink Home Monitor HD


DCS-935L

The mydlink Home Monitor HD allows you to monitor your home, whenever, from wherever. See everything in full colour high definition 720p with sound. The built-in night vision allows you to see up to 5 metres even in complete darkness. Its easy to setup, connects to your home Wi-Fi and can even alert you when motion or sound is detected. Whats more, it works with other mydlink Home smart devices to enable you to create a smart home without complicated setup, installation cost or monthly subscription charges.

Overview

Monitor Everything...

This high-definition camera delivers high-quality video for remote viewing on the tablet or smartphone you already own.

mydlink Home App

The mydlink Home smartphone and tablet app is the command centre for the D-Link range of smart home technology devices, enabling you to set, control, monitor and automate.


Product Highlights

mydlink Home app-enabled.

Use the free mydlink Home app to view what your Monitor HD sees, using your tablet or smartphone to control it wherever you are in the world.

Wireless connectivity.

Connect the Monitor HD to your Wireless home network, easily and conveniently, using one-button setup.

Motion detection with night vision.

Never miss a thing with the ability to be notified when motion is detected, and night vision ensures clear images even in low-light conditions, so you can always see what the Monitor HD sees.

HD Clarity

See all the details with high definition 720p colour images with sound.

Easy to Setup

Simply press a button to securely connect to your home Wi-Fi network with Wi-Fi Protected Setup. No additional control hub needed.

High Definition

Monitor your home in crystal clear HD 720p.

See everything in detail, even when zoomed in.

See in the Dark

Built-in night vision function allows you to see up to 5 metres even in complete darkness.

Motion & Sound Detection

Alerts you with push notification whenever motion or sound is detected.

View From Anywhere

View securely over the Internet through your smartphone or tablet. Works with iOS and Android smartphone and tablet* through the free mydlink Home app.

No hidden charges

Do-It-Yourself Simple

Do-It-Yourself Simple

No Installation Fees

No Installation Fees

No Monthly Charges

No Monthly Charge

Mydlink™ Home app is available for iPod, iPhone and iPad devices using iOS version 6.0 or later, and Android devices using Android version 4.0 or later.


Specifications

Camera

Camera Hardware Profile

  • 1/4 Megapixel progressive CMOS sensor
  • 5 metre IR illumination distance
  • Minimum illumination: 0 lux with IR LEDs on
  • Built-in Infrared-Cut Removable (ICR) Filter module
  • 4X digital zoom
  • Lens: Fixed length 2.38 mm
  • Aperture: F2.4
  • Angle of view:
    • (H) 78.44
    • (V) 47.9
    • (D) 85.98
  • Minimum object distance: 434 mm
  • Exposure Time: 1/7.5 to 1/24,000 sec.
  • Built-in microphone

Image Features

  • Configurable image size, quality, frame rate, and bit rate
  • Configurable brightness, contrast, sharpness, saturation and hue
  • Configurable motion detection windows
  • Time stamp and text overlays

Video Compression

  • Simultaneous H.264/MJPEG format compression
  • JPEG for still images

Video Resolution

  • 1280 x 720, 800 x 600, 720 x 480, 640 x 480, 320 x 240 at frame rates up to 30 fps

Audio Compression

  • AAC
  • G.711

Connectivity

  • 802.11b/g/n/ac wireless with WEP/WPA/WPA2 encryption
  • Operates on 2.4 GHz and 5 GHz bands
  • Maximum data rate of 433 Mbps (PHY rate)2

Network

Network Protocols

  • IPV4, ARP, TCP, UDP, ICMP
  • DHCP Client
  • NTP Client (D-Link)
  • DNS Client
  • DDNS Client (D-Link)
  • SMTP Client
  • FTP Client
  • HTTP Server
  • PPPoE
  • RTP, RTSP, RTCP
  • UPnP Port Forwarding
  • HTTPS for configuration
  • Bonjour

Security

  • Administrator and user group protection
  • Password authentication
  • HTTP and RTSP digest authentication

Advanced Features

System Requirements for Web Interfaces

  • Operating system: Microsoft Windows 8/7/Vista/XP SP3 or Mac OS X 10.6 or higher
  • Browser: Internet Explorer 7, Firefox 12, Safari 6, or Chrome 20 or higher

Event Management

  • Motion detection
  • Sound level detection
  • Event notification and uploading of snapshots/video clips via SMTP or FTP

Remote Access

Remote Management

  • Configuration accessible via web browser

Mobile support

  • mydlink Home app for iOS and Android1

General

Dimensions

  • 58.0 x 84.5 x 124.9 mm (2.28 inches x 3.33 inches x 4.92 inches)

Weight

  • 160.0 g (5.6 ounces) 5%

Power

  • 5 V DC 1.2 A, 50/60 Hz

Power Consumption

  • 3.5 watts maximum

Temperature

  • Operating: 0 to 40 C (32 to 104 F)
  • Storage: -20 to 70 C (-4 to 158 F)

Humidity

  • Operating: 20% to 80% non-condensing
  • Storage: 20% to 80% non-condensing

Certifications

  • CE
  • CE LVD
  • FCC Class B
  • C-Tick
1. mydlink Home app is available for iPod, iPhone and iPad devices using iOS version 6.0 or later, and Android devices using OS version 4.1 or later.
Link contains in-depth information about this product Link contains a picture of this product    NA
05/06

Pelican IM2750 Storm Case - Three Double-Layered, Soft-grip Handles, Two Padlockable Hasps, In-line Wheels, Telescoping Handle, Four Press & Pull Latches - Black

iM2750

Storm Case

Overview

  • Four Press & Pull Latches
  • Three Double-layered, Soft-grip Handles
  • Two Padlockable Hasps
  • In-line Wheels
  • Telescoping Handle
  • Vortex Valve
  • Flush Powerful Hinges
  • Lightweight Strong HPX Resin
  • Watertight
  • Guaranteed For Life

Interior (L x W x D) 22" x 17" x 12.7" (55.9 x 43.2 x 32.2 cm)





Exterior (L x W x D)

24.6" x 19.7" x 14.4" (62.5 x 50 x 36.6 cm)



Body: Injection Molded HPX high performance resin
Foam: 1.6pcf polyester
Latch: Valox - PBT polybutylene terephthalate
Purge Body: Valox - PBT polybutylene terephthalate
Lid O-Ring: Silicone Sponge
Purge Vent: Gortex membrane
Pins: Stainless Steel or Aluminum
Purge O-Ring: Buna-N , 50-60 Durometer Shore A



Interior (L x W x D)

22" x 17" x 12.7" (55.9 x 43.2 x 32.2 cm)





Exterior (L x W x D)

24.6" x 19.7" x 14.4" (62.5 x 50 x 36.6 cm)





Interior Cubic Volume:

2.75 cubic feet (77.84 cubic decimeter)





Lid Depth:

2" (5.1 cm)





Bottom Depth:

10.7" (27.2 cm)





Total Depth:

12.7" (32.2 cm)





Weight With Foam:

23.4 lbs (10.61 kg)





Weight W/O Foam:

18.5 lbs (8.39 kg)





Buoyancy:

173.4 lbs (78.65 kg)





Range Temperature

-20 / 140 F (-29 / 60 C)





Foam Properties

2" (5.1 cm) Convolute 1.69" (4.3 cm) Diced 1.69" (4.3 cm) Diced 1.69" (4.3 cm) Diced 1.69" (4.3 cm) Diced



Mobility Options

Retractable Handle YES
Maximum Handle Load TBD
Number of Wheels 2

Certificates

ATA 300

Minimum Pack: 1 ea.

Master Pack: 1 ea.



Master Pack Weight

25.2 lbs (11.43 kg)



 Link contains in-depth information about this product Link contains a picture of this product    NA
05/06

Pelican IM2700 Storm Case - Four Press & Pull Latches, Double-Layered, Soft-Grip Handle, Two Padlockable Hasps, Flush Powerful Hinges - Black

iM2700

Storm Case

Overview

  • Four Press & Pull Latches
  • Double-layered, Soft-grip Handle
  • Two Padlockable Hasps
  • Vortex Valve
  • Flush Powerful Hinges
  • Lightweight Strong HPX Resin
  • Watertight
  • Guaranteed For Life

Interior (L x W x D)

22" x 17" x 8" (55.9 x 43.2 x 20.3 cm)

Exterior (L x W x D)

24.6" x 19.7" x 8.6" (62.5 x 50 x 21.8 cm)

Body: Injection Molded HPX high performance resin

Foam: 1.6pcf polyester

Latch: Valox - PBT polybutylene terephthalate

Purge Body: Valox - PBT polybutylene terephthalate

Lid O-Ring: Silicone Sponge

Purge Vent: Gortex membrane

Pins: Stainless Steel or Aluminum

Purge O-Ring: Buna-N , 50-60 Durometer Shore A

Specifications


Interior (L x W x D)

22" x 17" x 8" (55.9 x 43.2 x 20.3 cm)





Exterior (L x W x D)

24.6" x 19.7" x 8.6" (62.5 x 50 x 21.8 cm)





Interior Cubic Volume:

1.73 cubic feet (49.03 cubic decimeter)





Lid Depth:

2" (5.1 cm)





Bottom Depth:

6" (15.2 cm)





Total Depth:

8" (20.3 cm)





Weight With Foam:

14.4 lbs (6.53 kg)





Weight W/O Foam:

11.1 lbs (5.03 kg)





Buoyancy:

112.58 lbs (51.07 kg)





Range Temperature

-20 / 140 F (-29 / 60 C)





Foam Properties

2" (5.1 cm) Convolute 1.81" (4.6 cm) Diced 1.81" (4.6 cm) Diced



Mobility Options

Maximum Handle Load TBD

Certificates

ATA 300

Minimum Pack: 1 ea.

Master Pack: 2 ea.



Master Pack Weight

30 lbs (13.61 kg)
Link contains in-depth information about this product Link contains a picture of this product    NA
05/06

Pelican iM2620 Storm Case - Two Press & Pull Latches, One Double-Layered, Soft-grip Handle, Two Padlockable Hasps, In-line Wheels - Black

iM2620

Storm Case

Overview

  • Two Press & Pull Latches
  • One Double-layered, Soft-grip Handle
  • Two Padlockable Hasps
  • In-line Wheels
  • Telescoping Handle
  • Vortex Valve
  • Flush Powerful Hinges
  • Lightweight Strong HPX Resin
  • Watertight
  • Guaranteed For Life

Interior (L x W x D): 20" x 14" x 10" (50.8 x 35.5 x 25.4 cm)

Exterior (L x W x D): 21.2" x 16" x 10.6" (53.8 x 40.6 x 26.9 cm)

Body: Injection Molded HPX high performance resin

Foam: 1.6pcf polyester

Latch: Valox - PBT polybutylene terephthalate

Purge Body: Valox - PBT polybutylene terephthalate

Lid O-Ring: Silicone Sponge

Purge Vent: Gortex membrane

Pins: Stainless Steel or Aluminum

Purge O-Ring: Buna-N , 50-60 Durometer Shore A

Specifications


Interior (L x W x D)

20" x 14" x 10" (50.8 x 35.5 x 25.4 cm)





Exterior (L x W x D)

21.2" x 16" x 10.6" (53.8 x 40.6 x 26.9 cm)





Interior Cubic Volume:

1.62 cubic feet (45.88 cubic decimeter)





Lid Depth:

2" (5.1 cm)





Bottom Depth:

8" (20.3 cm)





Total Depth:

10" (25.4 cm)





Weight With Foam:

14.5 lbs (6.58 kg)





Weight W/O Foam:

12.5 lbs (5.67 kg)





Buoyancy:

101.62 lbs (46.09 kg)





Range Temperature

-20 / 140 F (-29 / 60 C)





Foam Properties

2" (5.1 cm) Convolute 1.75" (4.4 cm) Diced 1.75" (4.4 cm) Diced 1.75" (4.4 cm) Diced



Mobility Options

Maximum Handle Load TBD
Number of Wheels 2

Certificates

ATA 300

Minimum Pack: 1 ea.

Master Pack: 1 ea.



Master Pack Weight

14.5 lbs (6.58 kg)
Link contains in-depth information about this product Link contains a picture of this product    NA
05/06 Pelican IM2200 Storm Case with Foam Link contains in-depth information about this product Link contains a picture of this product    $356.40
