20/10
|
Messoa SAD013 Cable Management Wall Mount - For Messoa Network Camera NOD385, NOD395, NOD398 SAD013
Cable Management Wall Mount, Aluminum, White
Features
For mounting on wall with cable management:
Package Content: Dome cap, Wall mount bracket, and Adaptor plate
Support up to 3kg (6.6 lb)
Compatible with MESSOA Network Camera: NOD385, NOD395, NOD398
Specifications:
Mechanical
|
| Material |
aluminum |
| Color |
white |
| Dimensions (WxHxD) |
Wall mount bracket: 142 x 132 x 190 mm (5.59" x 5.20" x 7.48")
Dome cap: 150 X 150 X 61 mm (5.91" x 5.91" x 2.40")
Adaptor plate: 150 X 150 X 3 mm (5.91 x 5.91 x 0.12) |
| Weight |
1.15kg (2.53 lb) |
Ordering Information
|
| Model |
SAD012 |
|
|
|
|
20/10
|
Messoa SAD014 Cable Management Wall Mount Bracket - For Messoa Network Camera NOD385, NOD395, NOD398 SAD014
L-type wall mount bracket, aluminum, white, compatible with Maven Series outdoor dome models
Features
For mounting on wall:
Support up to 15kg (33 lb)
Compatible with MESSOA Network Camera: NOD385, NOD395, NOD398 For indoor or outdoor installations
Specifications
Mechanical
|
| Material |
aluminum |
| Color |
white |
| Dimensions(WxHxD) |
180 x 140 x 120 mm (7.09" x 5.51" x 4.72") |
| Weight |
0.28 kg (0.62 lb) |
Ordering Information
|
| Model |
SAD014 |
|
|
|
|
20/10
|
Messoa SAD016 Cable Management Wallmount - For Messoa Network Camera NID325, NID335, NID338, PTZ900 SAD016
Features
For mounting on wall with cable management:
Package Content: Dome cap, Wall mount bracket, and Adaptor plate
Support up to 3kg (6.6 lb)
Compatible with MESSOA Network Camera: NID325, NID335, NID338, PTZ900
Specifications:
Mechanical
|
| Material |
aluminum |
| Color |
white |
| Dimensions (WxHxD) |
Wall mount bracket: 142 x 132 x 190 mm (5.59" x 5.20" x 7.48")
Dome cap: 150 X 150 X 61 mm (5.91" x 5.91" x 2.40")
Adaptor plate: 150 X 150 X 3 mm (5.91 x 5.91 x 0.12) |
| Weight |
1.15kg (2.53 lb) |
Ordering Information
|
| Model |
SAD016 |
|
|
|
|
20/10
|
Messoa UFD305 Mini Fixed Dome Network Camera - 1/3" Progressive Scan CMOS Sensor, 2304x1536, H.264, Triple Streaming, WDR, Digital Day/Night, MicoSDXC/SDHC Card Slot, IP67, IK10 - White UFD305
1/3 Lumii sensor, H.264, triple streaming, WDR,digital day/night, micoSDXC/SDHC card slot, IP67,IK10
Overview
The UFD305 is a 3-megapixel mini dome camera designed for low profile installations. Measuring only 11cm in diameter and less than 5cm high, the compact form factor allows the camera to easily adapt to the surroundings, meeting special requirements for discreet surveillance in an unobtrusive manner. The lens is built on a unique spherical stand featuring full-ranged, 3-dimensional pan/tilt maneuvering capability, which enables installers to adjust the camera angle freely for achieving wide coverage when mounting on walls or ceilings. Designed to resist rain and dust, the sturdily-built UFD305 can also be deployed in outdoor environments.
Compact Design Ideal for Discreet Surveillance
The sleek, compact-designed housing allows the camera to be easily installed and blend in the environment for unobtrusive monitoring, which is perfectly suited where discreet, covert surveillance is required.
Ultra Wide Dynamic Range
Compared with standard WDR, the newgeneration WDR features sophisticatedalgorithm to further expand its dynamic range of the lighting conditions. It allows the camera capturing greater scene details in high contrast settings or in scenes with extremely bright and dark areas.
3-dimensional Lens Adjustment
The megapixel lens is built on a unique spherical stand featuring full-ranged, 3-dimensional pan/tilt maneuvering capability, which enables the installers to adjust the camera angle freely when mounting on walls or ceilings.
Triple Streaming with Multiple Video Profiles
The camera supports H.264 and MJPEG streams and allows triple streaming simultaneously. Video streams can be further managed in profiles, enabling flexibility for users to designate bandwidth storage, and other video properties as appropriate.
Specifications
Video
|
| Sensor Type |
1/3" progressive scan CMOS sensor |
| Active Pixels |
2304 x 1536 (HxV) |
| Compression |
H.264 / MJPEG |
| Streaming |
Triple simultaneous streams, multiple video profile setting |
| Resolution |
QXGA(2048x1536), 1080P, 1280x960, 720P, SVGA(800x 600), VGA(640x480), 640x360, QVGA(320x240), 320x180 |
| Max. Frame Rate |
3MP 4:3 (2048x1536) at 15 fps
2MP Full HD 16:9 (1920x1080) at 30/25 fps (NTSC/PAL) |
| Day/Night |
Digital D/N Control |
| Day/Night Mode |
Auto/ BW/ Color |
| Shutter Time |
1/10,000s to 1/7.5s Selectable (60Hz);
1/10,000s to 1/6.25s Selectable (50Hz) |
| Minimum Illumination |
Color: 0.4 lux at 50 IRE, 0.08 lux at 10 IRE, F1.8;
B/W: 0.3 lux at 50 IRE, 0.07 lux at 10 IRE, F1.8
(Shutter speed: 1/35 sec) |
| Video Output |
NTSC: 720x480 @30fps; PAL: 720x576 @25fps |
| Bit Rate Control |
CBR, VBR |
Lens
|
| Lens Type |
Built-in; fixed focal |
| Focal Length |
f=3.6mm, F1.8 |
| View Angle |
H: 83 |
Audio
|
| Audio Communication |
Two-way Audio |
| Compression |
G.711 PCM 8kHz, a/-law support |
| Audio In/Out |
External microphone and speaker |
Image Enhancement
|
| Image Settings |
AES, AWB, AGC
Exposure Mode: AES / ALC / Flickerless / Manual;
White Balance: Auto / Manual;
Backlight Compensation
Configurable Brightness, Contrast, Hue, Saturation, and Sharpness
Gamma Correction |
| WDR |
Enhanced Digital WDR |
| DNR |
Configurable 3DNR setting |
| Privacy Zone |
Yes, up to 8 privacy zones |
| Image Orientation |
Mirror, Flip |
| Frequency Control |
NTSC(60Hz)/ PAL(50Hz) |
| Date & Time Stamp |
Yes |
Intelligent Video & Event Management
|
| Motion Detection |
Yes, 3-level sensitivity |
| Ethernet Detection |
Network loss detection |
| Others |
Optimized i-frame (GOP) setting |
| Events |
Motion detection, ethernet detection |
| Event Actions |
Event snapshot to remote FTP storage/ email recipients,
HTTP event query, HTTP event client pulling |
| Store Category |
Event snapshot, Manual Snapshot, Manual Recording |
Local Storage
|
| Memory Card Slot |
microSDHC/SDXC card support |
| Memory Card Overwrite |
Yes |
Network
|
| Protocol |
ARP, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, RTSP/RTCP/RTP, QoS, SMTP, SNMP, TCP, UDP, UPnP, IEEE802.1X |
| Ethernet |
10Base-T/100Base-TX Ethernet connection for LAN / WAN, RJ-45 |
| ONVIF |
Yes |
| Browser |
Internet Explorer, Chrome, Firefox, Safari |
| Security |
Multiple user access levels with password protection;
IP address filtering
IEEE 802.1X network access control, HTTPS encryption, and digest authentication |
I/O & Controls
|
| Power |
All-in-one tail cable out
Female RJ-45 10BASE-T/100BASE-TX PoE |
| Power LED Indicator |
System power and status indicator |
| Network |
Female RJ-45 |
| Audio In/Out |
1 in / 1 out for external microphone/speaker;
Built-in Microphone |
| Analog Video |
1 x composite video out, micro JST |
| System Reboot |
Reset x 1 |
| Factory Default |
Default x 1, pressing 5 sec for loading factory default |
Power
|
| Power Requirement |
DC12V/ PoE (IEEE 802.3af, class 0) |
| Power Consumption (Max.) |
8.5W |
Mechanical
|
| Dimensions(xH) |
110mm x 47mm (4.33" x 1.85") |
| Weight |
340g (0.75 lb) |
| Protection |
IP66 Certified, IP67/IP68 Compliant
IK10 Compliant |
| Pan/Tilt Adjustment |
3-dimensional spherical lens angle adjustment |
Environmental
|
| Operating Temperature |
-40C ~ 50C (-40F ~ 122F) |
| Operating Humidity |
90% RH, non-condensing |
| Storage Temperature |
-40C ~ 60C (-40F ~ 140F) |
Regulatory
|
| Approvals |
CE, FCC, RoHS |
Ordering Information
|
| Model No. |
NTSC: UFD305-N1-MES;
PAL: UFD305-P1-MES |
| Accessories |
Surface mount: standard package support |
|
|
|
|
20/10
|
Messoa UFD301 Mini Fixed Dome Network Camera - 1/4" Progressive Scan CMOS Sensor, 1280x800, H.264, Triple streaming, WDR, Digital Day/Night, PoE, IP67, IK10, 3-Dimensional Lens Adjustment - White UFD301
1/4 Lumii sensor, H.264, triple streaming, WDR,digital day/night, PoE, IP67, IK10
Overview
The UFD301 is a megapixel mini dome camera designed for low profile installations. Measuring only 11cm in diameter and less than 5cm high, the compact form factor allows the camera to easily adapt to the surroundings, meeting special requirements for discreet surveillance in an unobtrusive manner. The lens is built on a unique spherical stand featuring full-ranged, 3-dimensional pan/tilt maneuvering capability, which enables installers to adjust the camera angle freely for achieving wide coverage when mounting on walls or ceilings. Designed to resist the sturdily-built UFD301 can also be deployed in outdoor environments.
Compact Design Ideal for Discreet Surveillance
The sleek, compact-designed housing allows the camera to be easily installed and blend in the environment for unobtrusive monitoring, which is perfectly suited where discreet, covert surveillance is required.
Ultra Wide Dynamic Range
Compared with standard WDR, the newgeneration WDR features sophisticatedalgorithm to further expand its dynamic range of the lighting conditions. It allows the camera capturing greater scene details in high contrast
settings or in scenes with extremely bright and dark areas.
3-dimensional Lens Adjustment
The megapixel lens is built on a unique spherical stand featuring full-ranged, 3-dimensional pan/tilt manuevering capability, which enables the installers to adjust the camera angle freely when mounting on walls or ceilings.
Triple Streaming with Multiple Video Profiles
The camera supports H.264 and MJPEG streams and allows triple streaming simultaneously. Video streams can be further managed in profiles, enabling flexibility for users to designate bandwidth storage, and other video properties as appropriate.
Specifications:
Video
|
| Sensor Type |
1/4" progressive scan CMOS sensor |
| Active Pixels |
1280 x 800 (HxV) |
| Compression |
H.264 / MJPEG |
| Streaming |
Triple simultaneous streams with multiple video profile |
| Resolution |
720P, SVGA(800x 600), VGA(640x480), 640x360, QVGA(320x240), 320x180 |
| Max. Frame Rate |
HDTV 720p (1280x720) at 30 fps (NTSC) and 25 fps (PAL) |
| Day/Night |
Digital D/N Control |
| Day/Night Mode |
Auto/ BW/ Color |
| Shutter Time |
1/10,000s to 1/7.5s Selectable (60Hz);
1/10,000s to 1/6.25s Selectable (50Hz) |
| Minimum Illumination |
Color: 0.3 lux at 50 IRE, 0.06 lux at 10 IRE, F1.8;
B/W: 0.01 lux at 50 IRE, 0.04 lux at 10 IRE, F1.8
(Shutter speed: 1/15 sec) |
| Video Output |
NTSC: 720x480 @30fps; PAL: 720x576 @25fps |
| Bit Rate Control |
CBR, VBR |
Lens
|
| Lens Type |
Built-in; fixed focal |
| Focal Length |
f=3.6mm, F1.8 |
| View Angle |
H: 63 |
Image Enhancement
|
| Image Settings |
AES, AWB, AGC
Exposure Mode: AES / ALC / Flickerless / Manual;
White Balance: Auto / Manual;
Backlight Compensation
Configurable Brightness, Contrast, Hue, Saturation, and Sharpness
Gamma Correction |
| WDR |
Enhanced Digital WDR |
| DNR |
Configurable 3DNR setting |
| Privacy Zone |
Yes, up to 8 privacy zones |
| Image Orientation |
Mirror, Flip |
| Frequency Control |
NTSC(60Hz)/ PAL(50Hz) |
| Date & Time Stamp |
Yes |
Intelligent Video & Event Management
|
| Motion Detection |
Yes, 3-level sensitivity |
| Ethernet Detection |
Network loss detection |
| Others |
Optimized i-frame (GOP) setting |
| Events |
Motion detection, ethernet detection |
| Event Actions |
Event snapshot to remote FTP storage/ email recipients,
HTTP event query, HTTP event client pulling |
| Store Category |
Event snapshot, Manual Snapshot, Manual Recording |
Network
|
| Protocol |
ARP, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, RTSP/RTCP/RTP, QoS, SMTP, SNMP, TCP, UDP, UPnP, IEEE802.1X |
| Ethernet |
10Base-T/100Base-TX Ethernet connection for LAN / WAN, RJ-45 |
| ONVIF |
Yes |
| Browser |
Internet Explorer, Chrome, Firefox, Safari |
| Security |
Multiple user access levels with password protection;
IP address filtering
IEEE 802.1X network access control, HTTPS encryption, and digest authentication |
I/O & Controls
|
| Power |
All-in-one tail cable out
Female RJ-45 10BASE-T/100BASE-TX PoE |
| Power LED Indicator |
System power and status indicator |
| Network |
Female RJ-45 |
| Analog Video |
1 x composite video out, micro JST |
| System Reboot |
Reset x 1 |
| Factory Default |
Default x 1, pressing 5 sec for loading factory default |
Power
|
| Power Requirement |
PoE (IEEE 802.3af), class 0 |
| Power Consumption (Max.) |
7.7W |
Mechanical
|
| Dimensions(xH) |
110mm x 47mm (4.33" x 1.85") |
| Weight |
340g (0.75 lb) |
| Protection |
IP66 Certified, IP67/IP68 Compliant
IK10 Compliant |
| Pan/Tilt Adjustment |
3-dimensional spherical lens angle adjustment |
Environmental
|
| Operating Temperature |
-40C ~ 50C (-40F ~ 122F) |
| Operating Humidity |
90% RH, non-condensing |
| Storage Temperature |
-40C ~ 60C (-40F ~ 140F) |
Regulatory
|
| Approvals |
CE, FCC, RoHS |
Ordering Information
|
| Model No. |
NTSC: UFD301-N3-MES;
PAL: UFD301-P3-ME |
| Accessories |
Surface mount: standard package support |
|
|
|
|
20/10
|
Messoa SPD970 Speed Dome Network Camera - 1/2.8" Image Sensor (CMOS), 2304x1536, H.264, Triple Streaming, 180X, WDR, ICR Day/Night, PoE+, MicroSD/SDHC Card Slot, 3D Noise Reduction - White SPD970
1/2.8 Lumii sensor, H.264, triple streaming, 180X, WDR, ICR day/night, PoE+, microSD/SDHC card slot
Features
Overview
The SPD970 is a professional 3-megapixel speed dome network camera designed for detailed surveillance in ultra-high definition requiring precise pan, tilt, and zoom capabilities. A true day/night camera, the SPD970 features improved sensitivity backed by proprietary Lumii Technology and 3DNR to provide unprecedented low light image clarity under the cover of darkness. With up to powerful 180X zoom capability, the camera guarantees broad coverage, making itself a perfect solution for monitoring wide area and seeing distant objects. The sturdy design fittingly protects the camera against some extreme vandal and weather conditions.
Ultra Clear Images with 3MP Sensor
The camera is equipped with high-sensitivity 3MP progressive scan CMOS sensor, delivering images in ultra high definition up to 2048 x 1536 at 15 frames per second. The powerful 18X optical zoom and 10X digital zoom ensure distant objects can be detected in fine details.
True Day/Night with Mechanical ICR
The camera is perfect for capturing images under highly variable lighting conditions between day and night, providing superior color images at day time and sharp, noise-free monochrome images in low light to nearly no light environment.
3D Noise Reduction
The 3DNR technology takes traditional DNR a step further, removing digital artifacts and grainy appearance from frame to frame, while maintaining image sharpness at low light settings, which results in more efficient bandwidth utilization and less storage space consumption.
PoE+ Facilitates Easy Installation
With support for Power over Ethernet plus reduces cost and adds flexibility to the camera installation. A single cable connection is needed to view, power, and control the camera. Installation and maintenance costs are reduced since there is no need for separate cables.
Built for Harsh Outdoor Environment
Designed for deployment in challenging environments, the camera is compliant with IP67 and IK10 standards to withstand water, dust, and impacts. The built-in heater allows the camera operating in even the most extreme weather conditions for as low as -40C/F.
Specifications
Video
|
| Sensor Type |
1/2.8 image sensor (CMOS) |
| Active Pixels |
2304 x 1536 (HxV) |
| Compression |
H.264 / MJPEG |
| Streaming |
Triple simultaneous streams with multiple video profile |
| Resolution |
QXGA(2048x1536), 1080P, 1280x960, 720P, SVGA(800x 600), VGA(640x480), 640x360, QVGA(320x240), 320x180 |
| Max. Frame Rate |
3MP 4:3 (2048x1536) at 15 fps;
2MP 16:9 (1920x1080) at 30 fps (NTSC) and 25 fps (PAL) |
| Day/Night |
Mechanical (ICR) D/N Control |
| Day/Night Mode |
Auto/BW/Color |
| Shutter Time |
1/10000s to 1/7.5s Selectable (60Hz) ;
1/10000s to 1/6.25s Selectable (50Hz) |
| Minimum Illumination |
Color: 0.13 lux @10IRE, 0.65 lux @ 50 IRE
B/W: 0.05 lux @10IRE, 0.25 lux @ 50 IRE
(shutter speed: 1/15 sec) |
| Bit Rate Control |
CBR/VBR |
Lens
|
| Type |
Built-in; Varifocal |
| Focal Length |
f=4.7~84.6mm, F1.6~2.8 |
| Focus / Zoom |
Autofocus, motorized / Remote |
| View Angle (FOV) |
H: 58(Wide)~5(Tele)/V:44(Wide)~3.05(Tele) @3MP mode;
H: 56(Wide)~4.05(Tele)/V:32(Wide)~2.05(Tele) @Full HD mode |
| Zoom Limit |
Up to 180X (Optical 18X, Digital 10X) |
| IRIS Control |
Auto |
P/T Operation
|
| Pan Range |
360 continuous |
| Tilt Range |
0~92 |
| Manual Pan Speed |
0.1~120/s, 0.1/s: max dig.optical zoom |
| Manual Tilt Speed |
0.1~ 90/s, 0.1/s: max dig.optical zoom |
| Preset Speed |
Pan: 430/s, Tilt: 200/s |
| Proportional P/T |
Yes |
| Programmable Presets |
128 |
| Auto Patrol Group |
4 |
| Stop Time |
Configurable Dwell time |
| PTZ Functionalities |
Proportional PTZ, Auto Pan, Auto Patrol |
Audio
|
| Audio Communication |
One-way audio |
| Compression |
G711-Alaw, G711-Ulaw, PCM, 8kHz |
| Audio In/Out |
External microphone |
Image Enhancement
|
| Image Settings |
AES, AWB, AGC
Exposure Mode: AES / ALC / Flickerless / Manual;
White Balance: Auto / Manual;
Backlight Compensation;
Configurable Brightness, Contrast, Hue, Saturation, and Sharpness;
Gamma Correction |
| WDR |
Enhanced Digital WDR |
| DNR |
3DNR |
| Privacy Zone |
Yes, up to 8 privacy zones |
| Image Orientation |
Mirror, Flip |
| Frequency Control |
NTSC (60Hz)/ PAL (50Hz) |
| Date & Time Stamp |
Yes |
Intelligent Video & Event Management
|
| Motion Detection |
3-level sensitivity |
| Ethernet Detection |
Network loss detection |
| Others |
Optimized i-frame (GOP) setting |
| Events |
Motion detection, Ethernet detection, external alarm |
| Event Actions |
Event snapshot to remote FTP storage/ email recipients,
Edge recording to SD card,
HTTP event query, HTTP event client pulling,
External output activation, Patrol/Preset activation |
| Store Category |
Event snapshot, Edge recording, Manual Snapshot |
Local Storage
|
| Memory Card Slot |
microSDHC/SDXC;
1 x 16GB, Class 10 microSDHC card included
*the SD card is not covered by the warranty service |
| Memory Card Overwrite |
Yes |
Network
|
| Protocol |
ARP, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, NTP, RTSP/RTCP/RTP, QoS, SMTP, SNMP, TCP, UDP, UPnP, IEEE802.1X, IPv6 |
| Ethernet |
1 x 10/100 base-T Ethernet connection for LAN/WAN, RJ45 |
| PoE |
PoE+ (IEEE 802.3at) |
| ONVIF |
Yes |
| Browser |
Internet Explorer, Chrome, Firefox, Safari |
| Security |
Multiple user access levels with password protection,
IP address filtering;
IEEE 802.1X network access control, HTTPS encryption, and digest authentication |
I/O & Controls
|
| Power |
2-pin Terminal Block / Male RJ-45 |
| Alarm In/Out |
Terminal Block 6 in/1 out |
| Network |
Male RJ-45 |
| Audio In/Out |
Terminal Block 1 in |
| System Reboot |
Reset x 1, 2-pin Terminal Block |
| Factory Default |
Default x 1, 2-pin Terminal Block |
Power
|
| Power Requirement |
AC 24V 10% / PoE+ (IEEE 802.3at)
*PoE is not supported when heater is on |
| Power Consumption (Max.) |
55W (Heater ON), 20W (Heater OFF) |
Mechanical
|
| Dimensions(xH) |
217mm X 324mm (8.54X 12.75) |
| Weight |
3800g (8.14lb) |
| Protection |
IP67, IK10 |
| Battery Backed-up Real-time Clock |
Internal RTC |
| Operating Temperature |
PoE+: -10C ~ 50C ( 14F ~ 122F )
AC24V: -40C ~ 50C (-40F ~ 122F) |
| Operating Humidity |
10~ 90% RH |
| Storage Temperature |
-20C ~ 60C (-4F ~ 140F) |
Regulatory
|
| Approvals |
CE, FCC, RoHS |
Ordering Information
|
| Model No. |
NTSC: SPD970-N2-US-MES;
PAL: SPD970-P2-EU-MES |
| Accessories |
Pendent Mount: SAD702, SAD714
Wall Mount: SAD703, SAD713
Parapet Wall Mount: SAD706
Corner Mount: SAD707
Pole Mount: SAD708
Pipe Extension Bracket: SAD709
Sun Shield: SAD710 |
|
|
|
|
20/10
|
Messoa NCC700 Indoor Cube Network Camera - 1/4" Image Sensor, 1280x1024, H.264 /Motion JPEG, 2-Way Audio, Multiple Streaming, Full Frame Rate, Digital Day/Night, Intelligent Detections, Local Storage - White NCC700
1/4 sensor, multiple streaming, full frame rate, digital day/night, intelligent detections, local storage (Full compatibility with NVR203)
Overview
The NCC700 Cube Network Camera is a smart, compact solution, fit for homes, small businesses, offices or restaurants. The camera brings superior image quality, featuring 1.3-megapixel resolution at full frame rate provided in multiple streaming in H.264 and M-JPEG compression. Function-wise, the camera offers comprehensive monitoring capabilities with digital day/night, intelligent video and event management, and local storage. It is also very easy to install and duly supports plug-and-play when connected and used with the MESSOA Lite NVR Solution, perfect for users who are new to the technology but want to take a leap forward from analog.
H.264/MJPEG Multi-profile Streaming
The camera supports multi-profile streaming in H.264 and Motion JPEG compression. H.264 enables optimization for bandwidth and storage efficiency by maximizing compression while maintaining image quality.
NVR Solution Ready
The camera supports plug-and-play when joined with the MESSOA Lite NVR Solution, making installation hassle-free. Ideal for users who are new to IP technology but want to take a leap forward from analog.
Intelligent Video Management
The camera features motion detection, event management and smart encoding, allowing event/region-specific monitoring that help users stay informed when an event takes place, while reducing network and storage loads as only relevant video streams will be recorded.
2-Way Audio
The camera provides two-way audio support with a built-in microphone, allowing listening in on the monitored scene, as well as direct verbal communication with individuals at the scene from a remote location.
Local Storage
The camera comes with a microSD/SDHC card slot for local storage/backup up to 32 GB. It provides uninterupted recording and data loss prevention should the network go down.
Specifications
Video
|
| Sensor Type |
1/4 image sensor |
| Active Pixels |
1280 x 1024 (HxV) |
| Compression |
H.264 /Motion JPEG |
| Streaming |
Simultaneously multi-profile streaming |
| Resolution |
SXGA, VGA, QVGA, 160x120 (1.3 Mega Mode);
720P, 640x360, 160x90 (720p Mode) |
| Max. Frame Rate |
1.3MP (1280x1024) at 30 fps (NTSC/PAL) |
| Day/Night |
Digital D/N Control |
| Day/Night Mode |
Night Mode / Day Mode / Auto / Schedule |
| Shutter Time |
Range from 1/120s to 1/5s Selectable (60Hz);
Range from 1/100s to 1/4s Selectable (50Hz) |
| Minimum Illumination |
1.6 Lux @50IRE
(Shutter speed: 1/15 sec) |
| Bit Rate Control |
Multi-profile bit rate control: CBR/ VBR/ ECBR/ EVBR |
Lens
|
| Type, Focal Length, F-number |
Built-in Fixed lens, f=4.3 mm, F1.8(Megapixel lens) |
| View Angle |
H: 50/ V: 38 (1.3MP Mode)
H: 50/V: 26 (720p Mode) |
Audio
|
| Audio Communication |
Simplex or Full duplex (2-way audio) Selectable |
| Compression |
RTSP: G.711 64kbps, G.726 32kbps Selectable
3GPP: AMR |
| Audio In/Out |
Built-in microphone |
Image Enhancement
|
| Image Settings |
AWB, AES
Exposure Mode: Auto/ Hold/Manual;
White Balance: Auto/ Hold;
Exposure Value, Sharpness, Color, Brightness, Contrast: 101 level sensitivity
3D Noise Reduction (De-Noise): Off/ On |
| Privacy Zone |
Yes; customized threshold privacy zone (up to 8) |
| Image Orientation |
Mirror, Flip |
| Frequency Control |
50Hz, 60Hz |
| Date & Time Stamp |
Yes |
| Test Overlay |
Yes |
Intelligent Video & Event Management
|
| Motion Detection |
Up to 10 customized threshold detection windows with included or excluded options, 101 detected object size or level sensitivity |
| Smart Encoding |
Up to 2 Configurable ROI for better picture quality and bandwidth efficiency |
| Others |
Snapshot, e-PTZ, Optimized i-frame setting, Video Buffer |
| Events |
Motion detection |
| Event Actions |
File upload via FTP, SMTP, SAMBA(NAS) and SD Card; Notification via voice alert, email, HTTP and TCP;
Video and audio recording to SD Card or SAMBA |
| Store Category |
Motion / Schedule
Stores video clips and snapshots |
Local Storage
|
| Memory Card Slot |
Micro SD / Micro SDHC Card up to 32 GB |
| Memory Card Overwrite |
Yes |
Network
|
| Protocol |
IPv4, TCP/IP, UDP, HTTP, SMTP, DNS, DHCP, NTP, FTP, RTP, RTSP, RTCP, ICMP, UPnP, IPv6, HTTPS, DDNS, DIPS, ARP, Bonjour, IGMP, PPPoE, 3GPP, SAMBA |
| Ethernet |
10/100Mbps; 10Base-T/100Base-TX Ethernet connection for LAN / WAN, RJ-45 |
| ONVIF |
YES |
| Browser |
IE Browser 6.0 or above |
| Security |
Two-level access with password protection;
IP address filtering;
HTTPS encrypted data transmission |
I/O & Controls
|
| Power |
DC Jack (2.0mm) |
| Network |
RJ-45 with network LED x2 (Green & Orange) |
| Audio In/Out |
3.5mm Phone Jack 1 out |
| Reset |
More than 5 sec for loading default |
Power
|
| Power Requirement |
DC 12V 10% |
| Power Consumption (Max.) |
3W |
Mechanical
|
| Dimensions(WxDxH) |
52.6 x 35 x 74.5mm (2.07 x 1.38 x 2.93) |
| Weight |
70g (Without Bracket) |
Environmental
|
| Operating Temperature |
0C ~ 40C (32F ~ 104F) |
| Operating Humidity |
20~ 80% RH |
| Storage Temperature |
-20C ~ 60C (-4F ~ 140F) |
Regulatory
|
| Approvals |
CE, FCC, RoHS |
Ordering Information
|
| Model No. |
(MESSOA Brand)
NTSC: NCC700-HN1-US-MES;
PAL: NCC700-HP1-EU-MES
(Non-Brand)
NTSC: NCC700-HN1-US;
PAL: NCC700-HP1-EU |
| Accessories |
Wall mount/Ceiling mount with free pack-in bracket;
12V/1A External power adapter |
|
|
|
|
20/10
|
Messoa SAB009 Pole Adaptor - To Suit Messoa NCR365, NCR368, LPR606, NCR870S, NCR875PRO - White SAB009
Pole Adaptor, Aluminum, White
Features
For mounting on pole: Support up to 15kg (33lb)
Compatible with MESSOA IR Bullet Network Camera: NCR365, NCR368, LPR606, NCR870S, NCR875PRO
Specifications
Mechanical
|
| Material |
aluminum |
| Color |
white |
| Dimensions (WxHxD) |
240 x 179 x 59.7 mm (9.46" x 7.05" x 2.35") |
| Weight |
0.7 kg (1.54 lb)
|
Ordering Information
|
| Model |
SAB009 |
|
|
|
|
20/10
|
Messoa NCR365 Outdoor Bullet Network Camera - 1/3" Image Sensor Optimized For Low-Light Performance, H.264, Triple Streaming, Remote Zoom And Auto Focus, ICR Day/Night, microSDXC/SDHC Card Slot - Silver NCR365
1/3 Lumii sensor, H.264, triple streaming, remote zoom and auto focus, ICR day/night, 30m (98ft) IR, WDR, 3DNR, microSDXC/SDHC card slot, IP67, IK10
Features
Overview
The NCR365 is a professional 3-megapixel bullet camera designed for detail-demanding outdoor surveillance, delivering the ultimate image sharpness and view coverage like no others. A true day/night camera, the NCR365 features enhanced sensitivity backed by proprietary Lumii Low Light Technology, IR night vision and 3DNR to provide superior image clarity in low light conditions. The built-in heater and the weatherproof enclosure ensure the camera is suited for harsh environments. The featured motorized zoom with auto focus, as well as the 3-axis cable management bracket and the external lens adjustment, significantly facilitate installation of this versatile camera.
Motorized Lens for Remote Zoom and Auto Focus
The motor-driven zoom functionality enables configuration over the network to achieve the optimized viewing angle of the monitored area. Auto Focus can be also done with just one simple mouse click, simplifying the installation significantly for faster and easier setup.
3D Noise Reduction
The 3DNR technology takes traditional DNR a step further, removing digital artifacts and grainy appearance from frame to frame, while maintaining image sharpness at low light settings, which results in more efficient bandwidth utilization and less storage space consumption.
Ultra Wide Dynamic Range
Compared with standard WDR, the newgeneration WDR features sophisticated algorithm to further expand its dynamic range of the lighting conditions. It allows the camera capturing greater scene details in high contrast settings or in scenes with extremely bright and dark areas.
Easy Installation with 3-axis Cable Management Bracket
The 3-axis cable management bracket provides a robust mounting platform for tidy installation and camera angle adjustments on a 3-axis plane. It also offers a well-rounded protection of the cable from any water, dust or shock damages.
Triple Streaming with Multiple Video Profiles
The camera supports H.264 and MJPEG streams and allows triple streaming simultaneously. Video streams can be further managed in profiles, enabling flexibility for users to designate bandwidth storage, and other video properties as appropriate.
Specifications
Video
|
| Sensor Type |
1/3" image sensor optimized for low-light performance |
| Active Pixels |
2304 x 1536 (HxV) |
| Compression |
H.264 / MJPEG |
| Streaming |
Triple simultaneous streams with multiple video profile |
| Resolution |
QXGA(2048x1536), 1080P, 1280x960, 720P, SVGA(800x 600), VGA(640x480), 640x360, QVGA(320x240), 320x180 |
| Max. Frame Rate |
3MP 4:3 (2048x1536) at 15 fps
2MP Full HD 16:9 (1920x1080) at 30/25 fps (NTSC/PAL) |
| Day/Night |
Mechanical (ICR) D/N Control |
| Day/Night Mode |
Auto/ BW/ Color |
| Shutter Time |
1/10,000s to 1/7.5s Selectable (60Hz);
1/10,000s to 1/6.25s Selectable (50Hz) |
| Minimum Illumination |
IR LED OFF:
Color: 0.1 lux at 50 IRE, 0.02 lux at 10 IRE, F1.2;
(Shutter speed: 1/15 sec)
IR LED ON: 0 Lux |
| Video Output |
NTSC: 720x480 @30fps; PAL: 720x576 @25fps |
| Bit Rate Control |
CBR, VBR |
Lens
|
| Lens Type |
Built-in; Varifocal |
| Focal Length |
f=3~9mm, F1.2 |
| Focus / Zoom |
Autofocus, motorized / Remote |
| View Angle |
H: 78(Wide)~28(Tele) |
| IRIS Control |
DC IRIS |
IR LEDs
|
| LED Quantity |
48 pcs (850nm) |
| IR Distance |
30 meters (98ft) |
| IR turn on status |
Under 5 Lux by auto control |
| LED Life |
More than 10,000 hours |
Audio
|
| Audio Communication |
Two-way Audio |
| Compression |
G.711-Alaw / G.711-Ulaw, 8kHz |
| Audio In/Out |
External microphone and speaker |
Image Enhancement
|
| Image Settings |
AES, AWB, AGC
Exposure Mode: AES / ALC / Flickerless / Manual;
White Balance: Auto / Manual;
Backlight Compensation
Configurable Brightness, Contrast, Hue, Saturation, and Sharpness
Gamma Correction |
| WDR |
Enhanced Digital WDR |
| DNR |
Configurable 3DNR setting |
| Privacy Zone |
Yes, up to 8 privacy zones |
| Image Orientation |
Mirror, Flip |
| Frequency Control |
NTSC(60Hz)/ PAL(50Hz) |
| Date & Time Stamp |
Yes |
Intelligent Video & Event Management
|
| Motion Detection |
Yes, 3-level sensitivity |
| Ethernet Detection |
Network loss detection |
| Others |
Optimized i-frame (GOP) setting |
| Events |
Motion detection, audio detection, ethernet detection, external alarm |
| Event Actions |
Event snapshot to remote FTP storage/ email recipients,
Edge recording to SD card,
HTTP event query, HTTP event client pulling |
| Store Category |
Event snapshot, Edge recording, Manual Snapshot, Manual Recording |
Local Storage
|
| Memory Card Slot |
microSDHC/SDXC card support |
| Memory Card Overwrite |
Yes |
Network
|
| Protocol |
ARP, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, RTSP/RTCP/RTP, QoS, SMTP, SNMP, TCP, UDP, UPnP, IEEE802.1X |
| Ethernet |
10Base-T/100Base-TX Ethernet connection for
LAN / WAN, RJ-45 |
| ONVIF |
Yes |
| Browser |
Internet Explorer, Chrome, Firefox, Safari |
| Security |
Multiple user access levels with password protection;
IP address filtering
IEEE 802.1X network access control, HTTPS encryption, and digest authentication |
I/O & Controls
|
| Power |
All-in-one tail cable out
2-pin Terminal block/
Female RJ-45 10BASE-T/100BASE-TX PoE |
| Power LED Indicator |
System power and status indicator |
| Alarm In/Out |
Terminal block 1 in / 1 relay out(30V, 1A) |
| Network |
RJ-45 with LED Indicator |
| Audio In/Out |
Terminal block 1 in / 1 out |
| Analog Video |
1 x composite video out, micro JST |
| System Reboot |
Reset x 1 |
| Factory Default |
Default x 1, pressing 5 sec for loading factory default |
Power
|
| Power Requirement |
AC 24V 10% / PoE (IEEE 802.3af)
*Arctic power-on support by PoE at -40C |
| Power Consumption (Max.) |
11.5W |
Mechanical
|
| Dimensions(WxDxH) |
115 x 264 x 110 mm (4.53 x 10.39 x 4.33) |
| Weight |
1600g (3.44 lb) |
| Protection |
IP67 Certified, IP68 Compliant
IK10 Compliant |
Environmental
|
| Operating Temperature |
(On-board heating device) -40C ~ 50C (-40F ~ 122 F) |
| Operating Humidity |
90% RH, non-condensing |
| Storage Temperature |
-20C ~ 60C (-4F ~ 140F) |
Regulatory
|
| Approvals |
CE, FCC, RoHS |
Ordering Information
|
| Model No. |
NTSC: NCR365-N2-MES;
PAL: NCR365-P2-MES |
| Accessories |
Easily adjustable 3-axis and cable-concealed bracket
with standard package |
|
|
|
|
20/10
|
Messoa NCR368 Outdoor Bullet Network Camera - 1/3.2" Progressive Scan CMOS Sensor, 2592x1944, H.264, Ttriple Streaming, Remote Zoom And Auto Focus, microSDXC/SDHC Card Slot - Silver NCR368
1/3.2 Lumii sensor, H.264, triple streaming, remote zoom and auto focus, ICR day/night, 30m (98ft) IR, WDR, 3DNR, microSDXC/SDHC card slot, IP67, IK10
Features
Overview
The NCR368 is a professional 5-megapixel bullet camera designed for detail-demanding outdoor surveillance, delivering the ultimate image sharpness and view coverage like no others. A true day/night camera, the NCR368 features enhanced sensitivity backed by proprietary Lumii Low Light Technology, IR night vision and 3DNR to provide superior image clarity in low light conditions. The built-in heater and the weatherproof enclosure ensure the camera is suited for harsh environments. The featured motorized zoom with auto focus, as well as the 3-axis cable management bracket and the external lens adjustment, significantly facilitate installation of this versatile camera.
Motorized Lens for Remote Zoom and Auto Focus
The motor-driven zoom functionality enables configuration over the network to achieve the optimized viewing angle of the monitored area. Auto Focus can be also done with just one simple mouse click, simplifying the installation significantly for faster and easier setup.
3D Noise Reduction
The 3DNR technology takes traditional DNR a step further, removing digital artifacts and grainy appearance from frame to frame, while maintaining image sharpness at low light settings, which results in more efficient bandwidth utilization and less storage space consumption.
Ultra Wide Dynamic Range
Compared with standard WDR, the newgeneration WDR features sophisticated algorithm to further expand its dynamic range of the lighting conditions. It allows the camera capturing greater scene details in high contrast settings or in scenes with extremely bright and dark areas.
Easy Installation with 3-axis Cable Management Bracket
The 3-axis cable management bracket provides a robust mounting platform for tidy installation and camera angle adjustments on a 3-axis plane. It also offers a well-rounded protection of the cable from any water, dust or shock damages.
Triple Streaming with Multiple Video Profiles
The camera supports H.264 and MJPEG streams and allows triple streaming simultaneously. Video streams can be further managed in profiles, enabling flexibility for users to designate bandwidth storage, and other video properties as appropriate.
Specifications
Video
|
| Sensor Type |
1/3.2" progressive scan CMOS sensor |
| Active Pixels |
2592x1944 (HxV) |
| Compression |
H.264 / MJPEG |
| Streaming |
Triple simultaneous streams with multiple video profile |
| Resolution |
2592x1944, QXGA(2048x1536), 1080P, 1280x960, 720P, SVGA(800x 600), VGA(640x480), 640x360, QVGA(320x240), 320x180 |
| Max. Frame Rate |
5MP 4:3 (2592x1944) at 12 fps
3MP 4:3 (2048x1536) at 15 fps
2MP Full HD 16:9 (1920x1080) at 30/25 fps (NTSC/PAL) |
| Day/Night |
Mechanical (ICR) D/N Control |
| Day/Night Mode |
Auto/ BW/ Color |
| Shutter Time |
1/10,000s to 1/7.5s Selectable (60Hz);
1/10,000s to 1/6.25s Selectable (50Hz) |
| Minimum Illumination |
IR LED OFF:
Color: 0.15 lux at 50 IRE, 0,03 lux at 10 IRE, F1.2;
(Shutter speed: 1/15 sec)
IR LED ON: 0 lux |
| Video Output |
NTSC: 720x480 @30fps; PAL: 720x576 @25fps |
| Bit Rate Control |
CBR, VBR |
Lens
|
| Lens Type |
Built-in; Varifocal |
| Focal Length |
f=3~9mm, F1.2 |
| Focus / Zoom |
Autofocus, motorized / Remote |
| View Angle |
H: 78(Wide)~28(Tele) |
| IRIS Control |
DC IRIS |
IR LEDs
|
| LED Quantity |
48 pcs (850nm) |
| IR Distance |
30 meters (98 ft.) |
| IR turn on status |
Under 5 lux by auto control |
| LED Life |
More than 10,000 hours (50C) |
Audio
|
| Audio Communication |
Two-way Audio |
| Compression |
G.711-Alaw / G.711-Ulaw, 8kHz |
| Audio In/Out |
External microphone and speaker |
Image Enhancement
|
| Image Settings |
AES, AWB, AGC
Exposure Mode: AES / ALC / Flickerless / Manual;
White Balance: Auto / Manual;
Backlight Compensation
Configurable Brightness, Contrast, Hue, Saturation,
and Sharpness
Gamma Correction |
| WDR |
Enhanced Digital WDR |
| DNR |
Configurable 3DNR setting |
| Privacy Zone |
Yes, up to 8 privacy zones |
| Image Orientation |
Mirror, Flip |
| Frequency Control |
NTSC(60Hz)/ PAL(50Hz) |
| Date & Time Stamp |
Yes |
Intelligent Video & Event Management
|
| Motion Detection |
Yes, 3-level sensitivity |
| Ethernet Detection |
Network loss detection |
| Others |
Optimized i-frame (GOP) setting |
| Events |
Motion detection, ethernet detection, external alarm |
| Event Actions |
Event snapshot to remote FTP storage/ email recipients,
Edge recording to SD card,
HTTP event query, HTTP event client pulling |
| Store Category |
Event snapshot, Edge recording, Manual Snapshot, Manual Recording |
Local Storage
|
| Memory Card Slot |
microSDHC/SDXC support |
| Memory Card Overwrite |
Yes |
Network
|
| Protocol |
ARP, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, RTSP/RTCP/RTP, QoS, SMTP, SNMP, TCP, UDP, UPnP, IEEE802.1X |
| Ethernet |
10Base-T/100Base-TX Ethernet connection for
LAN / WAN, RJ-45 |
| ONVIF |
Yes |
| Browser |
Internet Explorer, Chrome, Firefox, Safari |
| Security |
Multiple user access levels with password protection;
IP address filtering; IEEE 802.1X network access control, HTTPS encryption, and digest authentication |
I/O & Controls
|
| Power |
All-in-one tail cable out
2-pin Terminal block/ Female RJ-45 10BASE-T/100BASE-TX PoE |
| Power LED Indicator |
System power and status indicator |
| Alarm In/Out |
Terminal block 1 in / 1 relay out (30V, 1A) |
| Network |
RJ-45 with LED Indicator |
| Audio In/Out |
Terminal block 1 in / 1 out |
| Analog Video |
1 x composite video out, micro JST |
| System Reboot |
Reset x 1 |
| Factory Default |
Default x 1, pressing 5 sec for loading factory default |
Power
|
| Power Requirement |
AC 24V 10% / PoE (IEEE 802.3af)
*Arctic power-on support by PoE at -40C |
| Power Consumption (Max.) |
11.5W |
Mechanical
|
| Dimensions(WxDxH) |
115 x 264 x 110 mm (4.53 x 10.39 x 4.33) |
| Weight |
1600g (3.44 lb) |
| Protection |
IP67 Certified, IP68 Compliant
IK10 Compliant |
Environmental
|
| Operating Temperature |
(On-board heating device) -40C ~ 50C (-40F ~ 122 F) |
| Operating Humidity |
90% RH, non-condensing |
| Storage Temperature |
-20C ~ 60C (-4F ~ 140F) |
Regulatory
|
| Approvals |
CE, FCC, RoHS |
Ordering Information
|
| Model No. |
NTSC: NCR368-N2-MES;
PAL: NCR368-P2-MES |
| Accessories |
Easily adjustable 3-axis and cable-concealed bracket
with standard package |
|
|
|
|
20/10
|
Messoa PTZ900 PTZ Indoor Network Camera - 1/2.8" Image Sensor (CMOS), 10x Optical zoom, H.264, Triple Streaming, WDR, Digital Day/Night, PoE, SDXC/SDHC Card Slot, 3D Noise Reduction - White PTZ900
1/2.8 Lumii sensor, 10x optical zoom, H.264, triple streaming, WDR, digital day/night, PoE, SDXC/SDHC card slot
Features
Overview
The PTZ900 is a 3-megapixel PTZ dome camera designed for indoor pan/tilt/zoom surveillance. The camera presents a uniquely sleek profile with clip-on mounting design for easy installation. Featuring the megapixel 10x optical zoom module built-in with speedy and sharp auto focus when zooming in, the PTZ900 offers high-speed 350 horizontal scanning at up to 300/sec with proportional PTZ support, delivering highly precise and robust pan/tilt performance all the time. Plus the wide area coverage of up to 2048 x 1536, the camera makes a perfect solution for wide, open areas such as shopping malls, parking lots, warehouses and the like.
Unparallel PTZ Capabilities
The cameras 10x optical and 10 digital zoom with auto focus provides a better depth of view when zoomed in. It also delivers precision motorized pan/tilt mechanism, while featuring various surveillance event triggers and handling options, including mission-critical 64 preset go-to and 4 patrol tours guarding.
3D Noise Reduction
The 3DNR technology takes traditional DNR a step further, removing digital artifacts and grainy appearance from frame to frame, while maintaining image sharpness at low light settings, which results in more efficient bandwidth utilization and less storage space consumption.
Ultra Wide Dynamic Range
Compared with standard WDR, the newgeneration WDR features sophisticated algorithm to further expand its dynamic range of the lighting conditions. It allows the camera capturing greater scene details in high contrast settings or in scenes with extremely bright and dark areas.
Triple Streaming with Multiple Video Profiles
The camera supports H.264 and MJPEG streams and allows triple streaming simultaneously. Video streams can be further managed in profiles, enabling flexibility for users to designate bandwidth storage, and other video properties as appropriate.
Specifications:
Video
|
| Sensor Type |
1/2.8" image sensor (CMOS) |
| Active Pixels |
2304 x 1536 (HxV) |
| Compression |
H.264 / MJPEG |
| Streaming |
Triple simultaneous streams with multiple video profile |
| Resolution |
QXGA(2048x1536), 1080P, 1280x960, 720P, SVGA(800x 600), VGA(640x480), 640x360, QVGA(320x240), 320x180 |
| Max. Frame Rate |
3MP 4:3 (2048x1536) at 15 fps;
2MP 16:9 (1920x1080) at 30 fps (NTSC) and 25 fps (PAL) |
| Day/Night |
Digital D/N Control |
| Day/Night Mode |
Auto/ BW/ Color |
| Shutter Time |
1/10000s to 1/7.5s Selectable (60Hz);
1/10000s to 1/6.25s Selectable (50Hz) |
| Minimum Illumination |
Color: 0.08 lux @10IRE, 0.4 lux @ 50 IRE, F1.8
B/W: 0.05 lux @10IRE, 0.25 lux @ 50 IRE, F1.8
(shutter speed: 1/15 sec) |
| Video Output |
NTSC: 720 X 480 @30fps; PAL: 720 X 576 @25fps |
| Bit Rate Control |
CBR, VBR |
Lens
|
| Lens Type |
Built-in; Varifocal |
| Focal Length |
f=6.33~63.3mm, F1.8~2.5 |
| Focus / Zoom |
Autofocus, motorized / Remote |
| Zoom Limit |
Up to 100X zoom (optical 10X, digital 10X) |
| View Angle (FOV) |
H: 41(Wide)~4.5(Tele) |
| IRIS Control |
Auto |
P/T Operation
|
| Pan Range |
-175 ~ 175 continuous |
| Tilt Range |
-90 ~ 30 continuous |
| Pan Speed(Preset) |
Up to 300/s |
| Tilt Speed(Preset) |
Up to 170/s |
| Proportional P/T |
Yes |
| Programmable Presets |
64 preset locations |
| Auto Patrol Group |
4 patrol groups |
| Stop Time |
Configurable Dwell time |
| PTZ Functionalities |
Proportional PTZ, Auto Pan, Auto Patrol, Auto Flip, Power-on Action |
| IRIS Control |
Auto |
Audio
|
| Audio Communication |
Two-Way Audio |
| Compression |
G.711 PCM 8kHz, a/-law support |
| Audio In/Out |
External microphone and speaker |
Image Enhancement
|
| Image Settings |
AES, AWB, AGC, Slow Shutter
Exposure Mode: AES / ALC / Flickerless / Manual;
White Balance: Auto / Manual;
Backlight Compensation;
Configurable Brightness, Contrast, Hue, Saturation, and Sharpness; Gamma Correction |
| WDR |
Enhanced Digital WDR |
| ND Filter |
Yes |
| DNR |
3DNR |
| Privacy Zone |
Yes, up to 8 privacy zones |
| Image Orientation |
Mirror, Flip, Both |
| Frequency Control |
NTSC (60Hz)/ PAL (50Hz) |
| Date & Time Stamp |
Yes |
| Intelligent Video & Event Management |
| Motion Detection |
Yes, 3-level sensitivity |
| Ethernet Detection |
Network loss detection |
| Others |
Optimized i-frame (GOP) setting |
| Events |
Motion detection, Ethernet detection |
| Event Actions |
Event snapshot to remote FTP storage/ email recipients,
Edge recording to SD card, HTTP event query, HTTP event client pulling, External output activation, Patrol/Preset activation |
| Store Category |
Event snapshot, Edge recording, Manual Snapshot |
Local Storage
|
| Memory Card Slot |
1 x SDHC/SDXC slot (card not included) |
Network
|
| Protocol |
ARP, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, NTP, RTSP/RTCP/RTP, QoS, SMTP, SNMP, TCP, TLS/TTLS,UDP, UPnP,
IEEE802.1X , IPv6 |
| ONVIF |
Yes |
| Browser |
Internet Explorer |
| Security |
Multiple user access levels with password protection,
IEEE 802.1X network access control, HTTPS encryption, and digest authentication |
I/O & Controls
|
| Power |
3-pin Spring Terminal |
| Power LED Indicator |
System power and status indicator |
| Alarm In/Out |
Terminal block 1 in / 1 relay out(30V, 1A) |
| Network |
Female RJ-45 with LED Indicator |
| Audio In/Out |
1 in / 1 out |
| Analog Video |
1 x composite video out, micro JST |
| System Reboot |
Reset x 1 |
| Factory Default |
Default x 1, pressing 5 sec for loading factory default |
Power
|
| Power Requirement |
DC 12V & AC 24V 10% / PoE (IEEE 802.3af, class 0) |
| Power Consumption (Max.) |
12W |
Mechanical
|
| Dimensions(xH) |
125mm X 170mm (4.92X 6.69) |
| Weight |
900g (1.92lb) |
Environmental
|
| Operating Temperature |
-10C ~ 50C (-14F ~ 122F) |
| Operating Humidity |
90% RH, non-condensing |
| Storage Temperature |
-40C ~ 60C (-40F ~ 140F) |
Regulatory
|
| Approvals |
CE, FCC, RoHS |
Ordering Information
|
| Model No. |
NTSC: PTZ900-N5-MES;
PAL: PTZ900-P5-MES |
| Accessories |
L-type Wall Mount: SAD011
Pendant Mount: SAD015
Cable Management Wall Mount: SAD016 |
|
|
|
|
20/10
|
Messoa NOD398 Outdoor Dome Network Camera - 1/3.2" Progressive Scan CMOS Sensor, 2592x1944, H.264, Triple Streaming, Remote Zoom And Auto Focus, ICR Day/Night, microSDXC/SDHC Card Slot, IP67, IK10 - White NOD398
1/3 Lumii sensor, H.264, triple streaming, remote zoom and auto focus, ICR day/night, 20m (65ft) IR, WDR, 3DNR, microSDXC/SDHC card slot, IP67, IK10
Features
Overview
The NOD398 is a professional 5-megapixel motorized IP dome camera designed for detaildemanding outdoor surveillance, delivering superior high definition video quality up to 30fps. A true day/night camera, the NOD398 features enhanced sensitivity backed by proprietary Lumii Low Light Technology, IR night vision and 3DNR to provide unprecedented image clarity under the cover of darkness. The built-in heater and the weatherproof enclosure ensure the camera is suited for outdoor deployment. The NOD398 also features installation-facilitating motorized zoom with auto focus and the unique modular design for recessed mount, making it a versatile solution across various applications.
Motorized Lens for Remote Zoom and Auto Focus
The motor-driven zoom functionality enables configuration over the network to achieve the optimized viewing angle of the monitored area. Auto Focus can be also done with just one simple mouse click, simplifying the installation significantly for faster and easier setup.
Flexible Installation with Dual Mount Design
With no extra bracket needed, the cameras detachable modular housing design uniquely allows for the option of recessed in-ceiling mount in addition to surface mount, providing installers with greater flexibility to deploy the camera for discreet installation locations.
3D Noise Reduction
The 3DNR technology takes traditional DNR a step further, removing digital artifacts and grainy appearance from frame to frame, while maintaining image sharpness at low light settings, which results in more efficient bandwidth utilization and less storage space consumption.
True Day/Night with Mechanical ICR
Featuring IR Cut Filter Removable (ICR) function, the camera is perfect for capturing truer color images at day time by filtering out IR. At night, IR is allowed for the camera working in B/W mode and being more sensitive to IR, thereby capturing clearer monochrome images.
Built-in Heater Powered by PoE
The camera is equipped with built-in heater that can be powered by PoE without requiring extra power supply. It is an ideal feature for extreme weather applications, ensuring camera operation at as low as -40 C (-40F).
Specifications
Video
|
| Sensor Type |
1/3.2" progressive scan CMOS sensor |
| Active Pixels |
2592x1944 (HxV) |
| Compression |
H.264 / MJPEG |
| Streaming |
Triple simultaneous streams with multiple video profile |
| Resolution |
2592x1944, QXGA(2048x1536), 1080P, 1280x960, 720P, SVGA(800x 600), VGA(640x480), 640x360, QVGA(320x240), 320x180 |
| Max. Frame Rate |
5MP 4:3 (2592x1944) at 12 fps
3MP 4:3 (2048x1536) at 15 fps
2MP Full HD 16:9 (1920x1080) at 30/25fps (NTSC/PAL) |
| Day/Night |
Mechanical (ICR) D/N Control |
| Day/Night Mode |
Auto/ BW/ Color |
| Shutter Time |
1/10,000s to 1/7.5s Selectable (60Hz);
1/10,000s to 1/6.25s Selectable (50Hz) |
| Minimum Illumination |
IR LED OFF:
Color: 0.15 lux at 50 IRE, 0.03 lux at 10 IRE, F1.2
(Shutter speed: 1/15sec)
IR LED ON: 0 lux |
| Video Output |
NTSC: 720x480 @30fps; PAL: 720x576 @25fps |
| Bit Rate Control |
CBR, VBR |
Lens
|
| Lens Type |
Built-in; Varifocal |
| Focal Length |
f=3~9mm, F1.2 |
| Focus / Zoom |
Autofocus, motorized / Remote |
| View Angle |
H: 78(Wide)~28(Tele) |
| IRIS Control |
DC IRIS |
IR LEDs
|
| LED Quantity |
20 pcs(850nm) |
| IR Distance |
25 meters (82ft) |
| IR turn on Status |
Under 5 lux by auto control |
| LED Life |
More than 10,000 hours |
Audio
|
| Audio Communication |
Two-way Audio |
| Compression |
G.711 PCM 8kHz, a/-law support |
| Audio In/Out |
External microphone and speaker |
Image Enhancement
|
| Image Settings |
AES, AWB, AGC
Exposure Mode: AES / ALC / Flickerless / Manual;
White Balance: Auto / Manual;
Backlight Compensation
Configurable Brightness, Contrast, Hue, Saturation, and Sharpness
Gamma Correction |
| WDR |
Enhanced Digital WDR |
| DNR |
Configurable 3DNR setting |
| Privacy Zone |
Yes, up to 8 privacy zones |
| Image Orientation |
Mirror, Flip |
| Frequency Control |
NTSC(60Hz)/ PAL(50Hz) |
| Date & Time Stamp |
Yes |
Intelligent Video & Event Management
|
| Motion Detection |
Yes, 3-level sensitivity |
| Ethernet Detection |
Network loss detection |
| Others |
Optimized i-frame (GOP) setting |
| Events |
Motion detection, ethernet detection, external alarm |
| Event Actions |
Event snapshot to remote FTP storage/ email recipients,
Edge recording to SD card,
HTTP event query, HTTP event client pulling |
| Store Category |
Event snapshot, Edge recording, Manual Snapshot, Manual Recording |
Local Storage
|
| Memory Card Slot |
microSDXC/SDHC card |
| Memory Card Overwrite |
Yes |
Network
|
| Protocol |
ARP, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, RTSP/RTCP/RTP, QoS, SMTP, SNMP, TCP, UDP, UPnP, IEEE802.1X |
| Ethernet |
10Base-T/100Base-TX Ethernet connection for
LAN / WAN, RJ-45 |
| ONVIF |
Yes |
| Browser |
Internet Explorer, Chrome, Firefox, Safari |
| Security |
Multiple user access levels with passiword protection;
IP address filtering; IEEE 802.1X network access control, HTTPS encryption, and digest authentication |
I/O & Controls
|
| Power |
2-pin Terminal block/ Female RJ-45 10BASE-T/
100BASE-TX PoE |
| Power LED Indicator |
System power and status indicator |
| Alarm In/Out |
Terminal block 1 in / 1 relay out (30V, 1A) |
| Network |
RJ-45 with LED Indicator |
| Audio In/Out |
Terminal block 1 in / 1 out |
| Analog Video |
1 x composite video out, micro JST |
| System Reboot |
Reset x 1 |
| Factory Default |
Default x 1, pressing 5 sec for loading factory default |
Power
|
| Power Requirement |
Heater Drive: AC 24V 10% / PoE (IEEE 802.3af)
*Arctic power-on support by PoE at -50C
Defrost Drive: AC 24V 10% |
| Power Consumption (Max.) |
26W |
Mechanical
|
| Dimensions(xH)) |
147mm x 140mm (5.79 x 5.5) |
| Weight |
1250g (2.76 lb) |
| 3-Axis |
Yes |
| Pan/Tilt Adjustment |
Pan: 0-350(Max.), Tilt: 25-90(Max.), Rotate: 0-350(Max.) |
| Protection |
IP66 Certified, IP67/IP68 Compliant
IK10 Compliant |
Environmental
|
| Operating Temperature |
(On-board heating device) -50C ~ 50C (-58F ~ 122 F) |
| Operating Humidity |
90% RH, non-condensing |
| Storage Temperature |
-20C ~ 60C (-4F ~ 140F) |
Regulatory
|
| Approvals |
CE, FCC, RoHS |
Ordering Information
|
| Model No. |
NTSC: NOD398-N2-MES;
PAL: NOD398-P2-MES |
| Accessories |
Surface Mount & Recessed-mount:
standard package support
Cable Management Wall mount: SAB755
L-type Wall Mount: SAB749-1W
Pendent Mount: SAB755M |
|
|
|
|
20/10
|
Messoa NOD395 Outdoor Dome Network Camera - 1/3" Progressive Scan CMOS Sensor, 2304x1536, H.264, Triple Streaming, Remote Zoom And Auto Focus, ICR Day/Night, MicroSDXC/SDHC Card Slot - White NOD395
1/3 Lumii sensor, H.264, triple streaming, remote zoom and auto focus, ICR day/night, 20m (65ft) IR, WDR, microSDXC/SDHC card slot, IP67, IK10
Features
Overview
The NOD395 is a professional 3-megapixel motorized IP dome camera designed for detail-demanding security applications. A true day/night camera, the NOD395 is backed by proprietary Lumii Low Light Technology as every detail comes through in unprecedented clarity under the cover of darkness, while delivering superior high definition video quality up to full 30 frames per second. Versatile and outdoor-ready, the camera also features easy installation with remote focus and zoom and the rugged enclosure with the unique modular design for flexible deployment options, making it a top-of-the-line solution for professional outdoor/indoor surveillance.
Motorized Lens for Remote Zoom and Auto Focus
The motor-driven zoom functionality enables configuration over the network to achieve the optimized viewing angle of the monitored area. Auto Focus can be also done with just one simple mouse click, simplifying the installation significantly for faster and easier setup.
Flexible Installation with Dual Mount Design
With no extra bracket needed, the cameras detachable modular housing design uniquely allows for the option of recessed in-ceiling mount in addition to surface mount, providing installers with greater flexibility to deploy the camera for discreet installation locations.
3D Noise Reduction
The 3DNR technology takes traditional DNR a step further, removing digital artifacts and grainy appearance from frame to frame, while maintaining image sharpness at low light settings, which results in more efficient bandwidth utilization and less storage space consumption.
True Day/Night with Mechanical ICR
Featuring IR Cut Filter Removable (ICR) function, the camera is perfect for capturing truer color images at day time by filtering out IR. At night, IR is allowed for the camera working in B/W mode and being more sensitive to IR, thereby capturing clearer monochrome images.
Built-in Heater Powered by PoE
The camera is equipped with built-in heater that can be powered by PoE without requiring extra power supply. It is an ideal feature for extreme weather applications, ensuring camera operation at as low as -40 C (-40F).
Specifications
Video
|
| Sensor Type |
1/3" progressive scan CMOS sensor |
| Active Pixels |
2304 x 1536 (HxV) |
| Compression |
H.264 / MJPEG |
| Streaming |
Triple simultaneous streams, multiple video profile setting |
| Resolution |
QXGA(2048x1536), 2304x1296, 1080P, SXGA,720P, 320x180 |
| Max. Frame Rate |
3MP 4:3 (2048x1536) at 15fps
2MP Full HD 16:9 (1920x1080) at 30fps (NTSC) and 25fps (PAL) |
| Day/Night |
Mechanical (ICR) D/N Control |
| Day/Night Mode |
Auto/ BW/ Color |
| Shutter Time |
1/10,000s to 1/7.5s Selectable (60Hz);
1/10,000s to 1/6.25s Selectable (50Hz) |
| Minimum Illumination |
IR LED OFF:
Color: 0.1 lux at 50 IRE, 0.02 lux at 10 IRE, F1.2
(Shutter speed: 1/15 sec)
IR LED ON: 0 lux |
| Video Output |
NTSC: 720 X 480 @30fps; PAL: 720 X 576 @25fps |
| Bit Rate Control |
Controllable bit rate dynamics: CBR, VBR |
Lens
|
| Lens Type |
Built-in; varifocal |
| Focal Length |
f=3~9mm, F1.2 |
| Focus / Zoom |
Auto Focus / Motorized remote focus control |
| View Angle |
H: 78(Wide)~28(Tele) |
| IRIS Control |
DC IRIS |
IR LEDs
|
| LED Quantity |
20 pcs(850nm) |
| IR Distance |
25 meters (82ft) |
| IR turn on Status |
Under 5 lux by auto control |
| LED Life |
More than 10,000 hours |
Audio
|
| Audio Communication |
Two-way audio |
| Compression |
G.711 PCM 8kHz, a/-law support |
| Audio In/Out |
External microphone and speaker |
Image Enhancement
|
| Image Settings |
AES, AWB, AGC
Exposure Mode: AES / ALC / Flickerless / Manual;
White Balance: Auto / Manual;
Backlight Compensation
Configurable Brightness, Contrast, Hue,
Saturation, and Sharpness
Gamma Correction |
| WDR |
Enhanced Digital WDR |
| DNR |
3DNR |
| Privacy Zone |
Yes, up to 8 zones |
| Image Orientation |
Mirror, Flip |
| Frequency Control |
NTSC(60Hz)/PAL(50Hz) |
Intelligent Video & Event Management
|
| Motion Detection |
Multi-windows with selectable sensitivity |
| Audio Detection |
Yes |
| Others |
Optimized i-frame (GOP) setting |
| Events |
Motion detection, Ethernet detection, external alarm |
| Event Actions |
Event snapshot to remote FTP storage (schedule, alarm input, motion)/ email recipients (alarm input, motion)
Edge recording to SD card (alarm, motion, network loss)
HTTP event query
HTTP event client pulling |
| Store Category |
Motion Detection / Alarm / Schedule event snapshot;
Motion Detection / Alarm / Edge recording
Manual Snapshot, Manual Recording |
Local Storage
|
| Memory Card Slot |
microSDXC/SDHC card |
| Memory Card Overwrite |
Yes |
Network
|
| Protocol |
ARP, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, RTSP/RTCP/RTP, QoS, SMTP, SNMP, TCP, UDP, UPnP, IEEE802.1X |
| Ethernet |
10Base-T/100Base-TX Ethernet connection for
LAN / WAN, RJ-45 |
| ONVIF |
Yes |
| Browser |
Internet Explorer, Chrome, Firefox, Safari |
| Security |
Multiple user access levels with password protection;
IP address filtering; IEEE 802.1X network access control,
HTTPS encryption, and digest authentication |
I/O & Controls
|
| Power |
2-pin Terminal block/ Female RJ-45 10BASE-T/
100BASE-TX PoE |
| Power LED Indicator |
System power and status indicator |
| Alarm In/Out |
Terminal block 1 in / 1 relay out (30V, 1A) |
| Network |
Female RJ-45 with LED Indicator |
| Audio In/Out |
Terminal block 1 in / 1 out |
| Analog Video |
1 x composite video out, micro JST |
| System Reboot |
Reset x 1 |
| Factory Default |
Default x 1 |
Power
|
| Power Requirement |
Heater Drive: AC 24V 10% / PoE (IEEE 802.3af)
*Arctic power-on support by PoE at -50C
Defrost Drive: AC 24V 10% |
| Power Consumption (Max.) |
26W |
Mechanical
|
| Dimensions(xH) |
147mm x 140mm (5.78" x 5.51") |
| Weight |
1250g (2.76 lb) |
| 3-Axis |
Yes |
| Pan/Tilt Adjustment |
Pan: 0-350, Tilt: 25-90, Rotate: 0-350(Max.) |
| Protection |
IP66 Certified, IP67/IP68 Compliant
IK10 Compliant |
Environmental
|
| Operating Temperature |
-50C ~ 50C (-58F ~ 122 F) |
| Operating Humidity |
90% RH, non-condensing |
| Storage Temperature |
-20C ~ 60C (-4F ~ 140F) |
Regulatory
|
| Approvals |
CE, FCC, RoHS |
Ordering Information
|
| Model No. |
NTSC: NOD395-N2-MES;
PAL: NOD395-P2-MES |
| Accessories |
Surface Mount & Recessed Mount:
standard package support
Cable Management Wall Mount: SAB755
L-type Wall Mount: SAB749-1W
Pendent Mount: SAB755M |
|
|
|
|
20/10
|
Messoa NID335 Indoor Dome Network Camera - 1/3" Progressive Scan CMOS Sensor, H.264, Triple Streaming, Remote Zoom And Auto Focus, ICR Day/Night, WDR, 3DNR, SDXC/SDHC Card Slot - White NID335
1/3 Lumii sensor, H.264, triple streaming, remote zoom and auto focus, ICR day/night, WDR, 3DNR, SDXC/SDHC card slot
Features
Overview
The NID335 is a professional 3-megapixel IP dome camera designed for detail-demanding indoor surveillance, delivering high quality live view and recorded footage with superior high definition video up to 30fps. A true day/night camera, the NID335 features improved sensitivity backed by proprietary Lumii Low Light Technology and 3DNR to provide unprecedented image clarity under the cover of darkness. The NID335 also features installation-facilitating motorized zoom with auto focus, as well as the enhanced Ultra WDR and local storage to make it a versatile solution for diverse indoor surveillance applications.
Motorized Lens for Remote Zoom and Auto Focus
The motor-driven zoom functionality enables configuration over the network to achieve the optimized viewing angle of the monitored area. Auto Focus can be also done with just one simple mouse click, simplifying the installation significantly for faster and easier setup.
True Day/Night with Mechanical ICRFeaturing IR Cut Filter Removable (ICR) function, the camera is perfect for capturing truer color images at day time by filtering out IR. At night, IR is allowed for the camera working in B/W mode and being more sensitive to IR, thereby capturing clearer monochrome images.
3D Noise Reduction
The 3DNR technology takes traditional DNR a step further, removing digital artifacts and grainy appearance from frame to frame, while maintaining image sharpness at low light settings, which results in more efficient bandwidth utilization and less storage space consumption.
Ultra Wide Dynamic Range
Compared with standard WDR, the new generation WDR features sophisticated algorithm to further expand its dynamic range of the lighting conditions. It allows the camera capturing greater scene details in high contrast settings or in scenes with extremely bright and dark areas.
Easy Installation with 3-axis Adjustment
An ideal feature for wide-area surveillance, the 3-axis angle adjustment makes camera installation easy, allowing installers to adjust the cameras direction and to level the image with ease whether its mounted on walls or on ceilings.
Specifications
Video
|
| Sensor Type |
1/3" progressive scan CMOS sensor |
| Active Pixels |
2304 x 1536 (HxV) |
| Compression |
H.264 / MJPEG |
| Streaming |
Triple simultaneous streams with multiple video profile |
| Resolution |
QXGA(2048x1536), 1080P, 1280x960, 720P, 800x600, VGA (640x480), 640x320, QVGA(320x240), 320x180 |
| Max. Frame Rate |
3MP 4:3 (2048x1536) at 15fps
2MP Full HD 16:9 (1920x1080) at 30fps (NTSC) and 25fps (PAL) |
| Day/Night |
Mechanical (ICR) D/N Control |
| Day/Night Mode |
Auto/ BW/ Color |
| Shutter Time |
1/10,000s to 1/7.5s Selectable (60Hz);
1/10,000s to 1/6.25s Selectable (50Hz) |
| Minimum Illumination |
Color: 0.02 lux at 10 IRE; 0.1 lux at 50 IRE, F1.2
B/W: 0.04 lux at 10 IRE; 0.02 lux at 50 IRE, F1.2
(Shutter speed: 1/15 sec) |
| Video Output |
NTSC: 720x480 @30fps; PAL: 720x576 @25fps |
| Bit Rate Control |
CBR, VBR |
Lens
|
| Lens Type |
Built-in; Varifocal |
| Focal Length |
f=3~9mm, F1.2 |
| Focus / Zoom |
Autofocus, motorized / Remote |
| View Angle |
H: 78(Wide)~28(Tele) |
| IRIS Control |
DC IRIS |
Audio
|
| Audio Communication |
Two-way Audio |
| Compression |
G.711 PCM 8kHz, a/-law support |
| Audio In/Out |
External microphone and speaker |
Image Enhancement
|
| Image Settings |
AES, AWB, AGC
Exposure Mode: AES / ALC / Flickerless / Manual;
White Balance: Auto / Manual; Backlight Compensation
Configurable Brightness, Contrast, Hue, Saturation,
and Sharpness
Gamma Correction |
| WDR |
Enhanced Digital WDR |
| DNR |
Configurable 3DNR setting |
| Privacy Zone |
Yes, up to 8 privacy zones |
| Image Orientation |
Mirror, Flip |
| Frequency Control |
NTSC(60Hz)/ PAL(50Hz) |
| Date & Time Stamp |
Yes |
Intelligent Video & Event Management
|
| Motion Detection |
Yes, 3-level sensitivity |
| Ethernet Detection |
Network loss detection |
| Others |
Optimized i-frame (GOP) setting |
| Events |
Motion detection, ethernet detection, external alarm |
| Event Actions |
Event snapshot to remote FTP storage/ email recipients,
Edge recording to SD card,
HTTP event query, HTTP event client pulling |
| Store Category |
Event snapshot, Edge recording, Manual Snapshot, Manual Recording |
Local Storage
|
| Memory Card Slot |
SDXC/SDHC card support |
| Memory Card Overwrite |
Yes |
Network
|
| Protocol |
ARP, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, RTSP/RTCP/RTP, QoS, SMTP, SNMP, TCP, UDP, UPnP, IEEE802.1X |
| Ethernet |
10Base-T/100Base-TX Ethernet connection for LAN / WAN, RJ-45 |
| ONVIF |
Yes |
| Browser |
Internet Explorer, Chrome, Firefox, Safari |
| Security |
Multiple user access levels with password protection;
IP address filtering; IEEE 802.1X network access control,
HTTPS encryption, and digest authentication |
I/O & Controls
|
| Power |
2-pin Terminal block/ Female RJ-45 10BASE-T/
100BASE-TX PoE |
| Power LED Indicator |
System power and status indicator |
| Alarm In/Out |
Terminal block 1 in / 1 relay out (30V, 1A) |
| Network |
RJ-45 with LED Indicator |
| Audio In/Out |
Terminal block 1 in / 1 out |
| Analog Video |
1 x composite video out, micro JST |
| System Reboot |
Reset x 1 |
| Factory Default |
Default x 1, pressing 5 sec for loading factory default |
Power
|
| Power Requirement |
DC 12V & AC 24V 10% / PoE (IEEE 802.3af, class 0) |
| Power Consumption (Max.) |
7W |
Mechanical
|
| Dimensions(xH) |
125mm x 106mm (4.92" x 4.18") |
| Weight |
500g (1.1 lb) |
| 3-Axis |
Yes |
| Pan/Tilt Adjustment |
Pan: 0-350, Tilt: 15-90, Rotate: 0-350 (Max.) |
Environmental
|
| Operating Temperature |
-10C ~ 50C (-14F ~ 122F) |
| Operating Humidity |
90% RH, non-condensing |
| Storage Temperature |
-40C ~ 60C (-40F ~ 140F) |
Regulatory
|
| Approvals |
CE, FCC, RoHS |
Ordering Information
|
| Model No. |
NTSC: NID335-N5-MES;
PAL: NID335-P5-MES |
| Accessories |
Surface mount: standard package support |
|
|
|
|
20/10
|
Messoa NDR891PRO Outdoor Dome Network Camera - 1/2.7" Image Sensor Optimized For Low-Light Performance, 1920x1080, Triple Simultaneous Streams, True Day/Night with Mechanical ICR - White NDR891PRO
1/2.7" Lumii sensor, 25M (82ft) IR, triple streaming, full frame rate, dual H.264 streams, ICR day/night, IP67, IK10
Features
Overview
The NDR891PRO Full HD Network Camera offers greater coverage with real-time 1080p video quality up to 30fps, twice as many than its predecessor, providing users with exceptional image clarity, smooth video display, and simply a better viewing experience. Featured H.264 dual streaming reduces costs while improving performance. Powered by the proprietary Lumii Technology, the high sensitivity sensor ensures clear and noise-free images across the covered scene in low light conditions. Vandal-resistant and waterproof, the NDR891PRO can withstand harsh impacts and heavy rain in the outdoor environment.
Full HD, Full Frame Rate
With Full HD quality images up to 30 frames per second, the camera offers greater resolutions, more coverage, and much smoother video display, providing exceptional details and better chances for identification. Blurry images are reduced as objects of interest come through in perfect clarity 24/7.
H.264 Dual Streaming
With triple streaming, the camera supports 2 independent H.264 streams simultaneously. This advanced technology greatly saves costs by lowering bandwidth and storage requirement while improving the overall system performance.
True Day/Night with Mechanical ICR
The camera is perfect for capturing images under highly variable lighting conditions between day and night, providing superior color images at day time and sharp, noise-free monochrome images in low light to nearly no light environment.
Intelligent Video Management
The camera features a variety of intelligent video detections, event management and smart encoding, allowing event/region-specific monitoring that help inform security staff right when the event takes place, while reducing network and storage loads as only relevant video streams will be recorded.
Outdoor-ready Design
Both water- and vandal-resistant, the sturdily built dome camera is fully compliant with IP67 and IK10 standards. An optional heater is available for keeping the camera operating in even the most extreme weather conditions.
Specifications
Video
|
| Sensor Type |
1/2.7 image sensor optimized for low-light performance |
| Active Pixels |
1920x1080 (HxV) |
| Compression |
H.264, MPEG-4, MJPEG |
| Streaming |
Triple simultaneous streams |
| Resolution |
1080p, SXVGA, 720P, XGA, SVGA, D1, VGA, 2CIF, CIF |
| Max. Frame Rate |
2MP 16:9 (1920x1080) at 30 fps (NTSC) and 25 fps (PAL) |
| Day/Night |
Mechanical (ICR) D/N Control |
| Day/Night Mode |
Auto |
| Shutter Time |
1/10000s to 1/3.75s Selectable (60Hz);
1/10000s to 1/3.125s Selectable (50Hz) |
| Min. llumination |
IR LED Off (shutter speed: 1/15sec):
0.06 Lux @10IRE; 0.30Lux @50IRE
IR LED On: 0 lux |
| Video Output |
NTSC: 720 X 480@30fps; PAL: 720 X 576@25fps |
| Bit Rate Control |
CBR/VBR (Primary Stream) |
Lens
|
| Type, Focal Length, F-number |
Built-in Mechanical IR Cut Filter varifocal lens, f=3~9mm, F1.2 (Mega pixel lens) |
| View Angle |
H: 93(Wide)~31.7(Tele)/V:68.4(Wide)~23.8(Tele) |
| View Angle Adjustment |
Pan:0-355(Max.); Tilt:0-90(Max.);
Rotate:0-355(Max.) |
| IRIS Control |
DC IRIS |
IR LEDs
|
| LED Quantity |
20 pcs (850nm) |
| IR Distance |
25 meters (82 ft.) |
| IR Activation |
Under 10 Lux with auto-control |
| LED Life |
More than 10,000 hours (50) |
Audio
|
| Audio Communication |
Two-way mono audio, Full-duplex |
| Compression |
G.711, PCM, 8kHz |
| Audio In/Out |
External microphone and speaker |
Image Enhancement
|
| Image Settings |
AWB, AES, AGC
Exposure Mode: Auto/Manual;
White Balance: Auto/Manual;
Backlight Compensation: 5x5 zones selectable;
Sharpness, Saturation, Brightness,
Contrast: 255-level sensitivity |
| Digital WDR |
Yes; 5-level sensitivity |
| Privacy Zone |
Yes; customized threshold privacy zone |
| Image Orientation |
Mirror, Flip |
| Frequency Control |
50Hz, 60Hz |
| Date & Time Stamp |
Yes |
Intelligent Video & Even Management
|
| Motion Detection |
5x5 zones, 5-level sensitivity or customized threshold |
| Face Detection |
3 level sensitivity |
| Audio Detection |
5-level sensitivity or customized threshold |
| Blur Detection |
Customized threshold |
| Ethernet Detection |
Network loss detection |
| Smart Encoding |
Configurable ROI for better picture quality |
| Others |
Snapshot, Smart Focus, e-PTZ, Optimized i-frame setting |
| Events |
Motion detection, face detection, audio detection, blur detection, Ethernet detection, external alarm |
| Event Actions |
File upload via FTP, SMTP and SD Card; Notification via email, HTTP and TCP External output activation; Video and audio recording to SD Card |
| Storage Category |
Alarm / Motion / Schedule / Un-interrupt recording
Stores video clips and snapshots |
Local Storage
|
| Memory Card Slot |
microSD/SDHC Card up to 32 GB |
| Memory Card Overwrite |
Yes |
Network
|
| Protocol |
IPv4, TCP/IP, UDP, HTTP, SMTP, DNS, DHCP, NTP, FTP, RTP, RTSP, RTCP, ICMP, UPnP |
| Ethernet |
10Base-T/100Base-TX |
| PoE |
IEEE 802.3af, Class 3 |
| ONVIF |
Yes |
| Browser |
IE Browser 6.0 or above |
| Security |
Two-level access with password protection |
I/O & Controls
|
| Power |
2-pin terminal block |
| Alarm In/Out |
Terminal block 2 in / 1 out |
| Network |
1 x RJ-45 |
| Audio In/Out |
3.5mm phone jack 1-in / 1-out |
| Analog Video |
1 x BNC, 1.0Vp-p, 75 ohm / 1 x RCA |
| Reset |
System reboot/factory default |
Power
|
| Power Requirement |
DC 12V & AC 24V 10% / PoE(IEEE 802.3af) |
| Power Consumption |
W/O Heater: 8.5W
W/ Heater: 28W(Heater ON), 8.5W (Heater OFF) |
Mechanical
|
| Dimensions (xH) |
141 mm x 121 mm (5.55 x 4.76) |
| Weight |
1.3kg (2.87lb) |
| 3-Axis |
Pan: 0-355, Tilt: 0-70, Rotate: 0-355 |
| Protection |
IP67, IK10, vandal-proof |
| Battery-backed Real-time Clock |
Yes; External RTC |
Environmental
|
| Operating Temp. |
W/O Heater: -10C ~ 50C ( 14F ~ 122F )
W/ Heater: -40C ~ 50C (-40F ~ 122F) |
| Operating Humidity |
10~ 90% RH |
| Storage Temp. |
-20C ~ 60C (-4F ~ 140 F) |
Ordering Information
|
| Model No. |
NTSC:
NDR891PRO-HN5-MES (w/o heater);
NDR891PROH-HN5-MES (w/ heater)
PAL:
NDR891PRO-HP5-MES (w/o heater);
NDR891PROH-HP5-MES (w/ heater) |
| Accessories |
Surface mount: standard package support
Pendent mount: thread 1"
Wall mount: bracket SAB755BP |
|
|
|
|
20/10
|
Messoa NDR722 Indoor Dome Network Camera - 1/2.7" 2MP Progressive Scan CMOS Sensor, 1920x1080, H.264/MPEG4/Motion JPEG, Dual Simultaneous Streams, 7M Night Vision w. Even IR Illumination - White NDR722
1/2.7 Lumii sensor, H.264, 7M (23ft) IR,dual streams, ICR D/N, WDR, built-in mic, PoE
Features
Overview
MESSOA NDR722 is a small-sized full HD IR dome camera designed for maximum flexibility and plug-and-play integration with MESSOA Lite Series NVR. Measuring merely 83mm in diameter, the palm-sized form factor allows the camera to easily blend into the surroundings, meeting unusual requirements for discreet and covert surveillance. The 4mm lens provides wider coverage coupled with the embedded wide-angle IR illuminator, leaving no blind spot undetected. The camera also features PoE and built-in microphone to make it a versatile choice for indoor projects, such as residence, retail stores, boutiques, hotels and offices.
Easy Plug-and-play NVR Solution Ready
The camera supports plug-and-play when joined with the MESSOA Lite Series NVR, making installation hassle-free. It is ideal for users who are new to IP technology but want to take a leap forward from analog.
Superior Video Quality at Full Frame Rate
With video quality up to 30fps, the camera captures every critical moment with smooth video display. Increased frame frequency reduces blurry images and particularly suits motion-sensitive applications.
Compact Design Ideal for Discreet Surveillance
The sleek, compact-designed housing allows the camera to be easily installed and blend in the environment for unobtrusive monitoring, which is perfectly suited where discreet, covert surveillance is required.
7m Night Vision with Even IR Illumination
Built in with the patented matrix IR LED, the camera ensures wide-angle, even illumination up to 7 meters. Further enhanced by its smart sensor design, the camera accurately detects changes in lighting and delivers perfect image quality in low light conditions.
True Day/Night with Mechanical IR Cut Filter
The camera automatically detects changes in light intensity and switches between color and B/W modes. It provides perfect color images by filtering out infrared light at day time and crisp monochrome images at night or any other dark environment.
Specifications
Video
|
| Sensor Type |
1/2.7"2MPprogressivescanCMOSsensor |
| Active Pixels |
1920x1080 (HxV) |
| Compression |
H.264/MPEG4/Motion JPEG |
| Streaming |
Dual simultaneous streams |
| Resolution |
1920x1080, 1280x720,800x450,640x360,320x180 |
| Max. Frame Rate |
Full HD (1920x1080) at 30/25fps (NTSC/PAL) |
| Day/Night |
Mechanical (ICR) D/N Control |
| Day/Night Mode |
Auto/Day/Night |
| Shutter Time |
Range from 1/7s to 1/30,000s selectable |
| Minimum Illumination |
IR LED Off (shutter speed: 1/30 sec):
0.1 Lux @10IRE; 0.5 Lux @50IRE, IR LED On: 0 lux |
| Bit Rate Control |
Simultaneous stream bit rate control:
CBR/VBR/ECBR/EVBR |
Lens
|
| Lens Type |
Built-in; fixed Lens, |
| Focal Length |
f=4mm, F1.5 |
| View Angle |
H: 77.4/ V: 45.1 |
IR LEDs
|
| LED Quantity |
16 pcs Matrix IR (850nm) |
| IR Distance |
7 meters (23 ft.) |
| IR turn on status |
Under 10 Lux by auto control (light sensor), threshold adjustable in UI |
| LED Life |
More than 10,000 hours (50C) |
Audio
|
| Compression |
ACC, G.711-Law, PCM, 8kHz |
| Audio In/Out |
Built-in microphone |
Image Enhancement
|
| Image Settings |
AWB, AES, AGC;
Flickerless Mode: On/Off
Exposure & Gain Mode: Auto/Manual;
White Balance: Auto/Fixed;
Sharpness, Saturation, Brightness, Contrast: 17 level sensitivity;
Exposure: 15 level sensitivity |
| Digital WDR |
Yes; 8 level sensitivity |
| DNR |
Auto/On/Off |
| Privacy Zone |
Yes; customized threshold privacy zone (up to 8) |
| Image Orientation |
Mirror, Flip |
| Frequency Control |
50Hz, 60Hz |
| Date & Time Stamp |
Yes |
| Test Overlay |
Yes |
Intelligent Video & Event Management
|
| Motion Detection |
Up to 3 customized threshold detection windows, 101 detected object size or level sensitivity |
| Ethernet Detection |
Network Fail detection |
| Others |
Snapshot, digital Zoom, Optimized i-frame setting |
| Events |
Motion/Tamper detection, Manual Trigger, Network Fail, Periodically Trigger |
| Event Actions |
File upload via FTP, SMTP and SAMBA; Notification via FTP, and email; Video and audio recording to SAMBA |
| Store Category |
Alarm/Motion/Schedule/Un-interrupt recording
Stores video clips and snapshots |
Network
|
| Protocol |
IPv4,IPv6, HTTP,HTTPS,SMTP,FTP,DHCP,NTP, TCP/IP, UPnP,RTSP/RTP/RTCP,DNS,DDNS,
PPPoE,IGMP,QoS,Bonjour,Samba,Multicast. |
| Ethernet |
10Base-T/100Base-TX Ethernet connection for LAN/WAN, RJ-45 |
| ONVIF |
Yes |
| Browser |
IE Browser 8.0 or above, Chrome, Firefox, Safari |
| Security |
Three-level access with password protection |
I/O & Controls
|
| Power |
DC Jack (2.0mm) |
| Power LED Indicator |
Yes |
| Network |
RJ-45 with LEDs (Networkindicator) |
| Audio In/Out |
Built-in Microphone |
| Reset |
Within 1 sec for rebooting system; more than 10 sec untilredLEDstartstoflash for loading default |
| BicolorLED |
Power&SystemStatus |
Power
|
| Power Requirement |
DC 12V 10% / PoE (IEEE 802.3af) |
| Power Consumption |
7W (Max.) |
Mechanical
|
| Dimensions (xH) |
83mm x 73.3mm ( 3.27 x 2.89) |
| Weight |
300g (0.66 lb) |
| Battery Backed-up Real-time Clock |
Yes; Internal RTC |
| Pan/Tilt Adjustment |
Tilt: from 28 to 70 (Max.) |
Environmental
|
| Operating Temperature |
0C ~ 50C (32F ~ 122F) |
| Operating Humidity |
20~ 90% RH |
| Storage Temperature |
-10C ~ 55C ( 14F ~ 131F ) |
Regulatory
|
| Approvals |
CE, FCC, RoHS |
Ordering Information
|
| Model No. |
NTSC: NDR722-N1-MES;
PAL: NDR722-P1-MES; |
| Accessories |
Ceiling Mount Metal Bracket
Wall Mount Bracket (optional) : SAD002 |
|
|
|
|
20/10
|
Messoa NCR772 Outdoor Bullet Network Camera - 1/2.7" 2MP Progressive Scan CMOS Sensor, 1920x1080, H.264/MPEG4/Motion JPEG, Built-In IR LED Provides Night Vision Up To 10 Meters - White/Black NCR772
1/2.7 Lumii sensor, H.264, 10M (33ft) IR, dual streams, ICR D/N, WDR, PoE, IP67
Overview
MESSOA NCR772 is a mini-sized, high-performance bullet-type Full HD IR camera designed for maximum flexibility and plug-and-play integration with MESSOA Lite Series NVR. Measuring just 10cm in length, the compact yet versatile form factor makes the camera a perfect solution for applications demanding discreet and non-intrusive installations, such as boutiques and retail shops. The built-in IR LED provides night vision up to 10 meters. The IP67-rated water-resistant metallic housing also adds assurance to the cameras durability and reliable operation in a wide range of indoor/outdoor environments.
Easy Plug-and-play NVR Solution Ready
The camera supports plug-and-play when joined with the MESSOA Lite Series NVR, making installation hassle-free. It is ideal for users who are new to IP technology but want to take a leap forward from analog.
Superior Video Quality at Full Frame Rate
With video quality up to 30fps, the camera captures every critical moment with smooth video display. Increased frame frequency reduces blurry images and particularly suits motion-sensitive applications.
Compact Design Ideal for Discreet Surveillance
The sleek, compact-designed housing allows the camera to be easily installed and blend in the environment for unobtrusive monitoring, which is perfectly suited where discreet, covert surveillance is required.
10m Night Vision with Even IR Illumination
Built in with IR LED, the camera provides night vision up to 10 meters. The IR illuminator is further enhanced by its smart sensor design to accurately detect changes in lighting and to deliver perfect image quality in low light conditions.
Outdoor-ready Design Ensures Camera Durability
The camera is perfectly suited for both indoor and outdoor environments with its IP67-rated water-resistant housing, which ensures protection against heavy rain and dust.
Specifications:
Video
|
| Sensor Type |
1/2.7"2MPprogressivescanCMOSsensor |
| Active Pixels |
1920 x 1080 (HxV) |
| Compression |
H.264/MPEG4/Motion JPEG |
| Streaming |
Dual simultaneous streams |
| Resolution |
1920x1080, 1280x720, 800x450,640x360,320x180 |
| Max. Frame Rate |
Full HD (1920x1080) at 30/25ps (NTSC/PAL) |
| Day/Night |
Mechanical (ICR) D/N Control |
| Day/Night Mode |
Auto/Day/Night |
| Shutter Time |
Range from 1/7s to 1/30,000s |
| Minimum Illumination |
IR LED Off (shutter speed: 1/30 sec):
0.2 lux @10IRE; 0.8 lux @50IRE; IR LED On: 0 lux |
| Bit Rate Control |
Simultaneous stream bit rate control:
CBR/VBR/ECBR/EVBR |
Lens
|
| Lens Type |
Built-in, Fixed |
| Focal Length |
f=4mm, F1.8 |
| View Angle |
H: 84.8/ V: 45.2 |
IR LEDs
|
| LED Quantity |
12 pcs (850nm) |
| IR Distance |
10 meters (33 ft.) |
| IR turn on status |
Under 10 Lux by auto control (light sensor), threshold adjustable in UI |
| LED Life |
More than 10,000 hours (50C) |
Image Enhancement
|
| Image Settings |
AWB, AES, AGC;
Flickerless Mode: On/Off
Exposure & Gain Mode: Auto/Manual;
White Balance: Auto/Fixed;
Sharpness, Saturation, Brightness, Contrast: 17 level sensitivity;
Exposure: 15 level sensitivity |
| Digital WDR |
Yes; 8 level sensitivity |
| DNR |
Auto/On/Off |
| Privacy Zone |
Yes; customized threshold privacy zone (up to 8) |
| Image Orientation |
Mirror, Flip |
| Frequency Control |
50Hz, 60Hz |
| Date & Time Stamp |
Yes |
| Test Overlay |
Yes |
Intelligent Video & Event Management
|
| Motion Detection |
Up to 3 customized threshold detection windows, 101 detected object size or level sensitivity |
| Ethernet Detection |
Network Fail detection |
| Others |
Snapshot, digital Zoom, Optimized i-frame setting |
| Events |
Motion/Tamper detection, Manual Trigger, Network Fail, Periodically Trigger. |
| Event Actions |
File upload via FTP, SMTP and SAMBA; Notification via FTP, and email; Video recording to SAMBA |
| Store Category |
Alarm/Motion/Schedule/Un-interrupt recording
Stores video clips and snapshots |
Network
|
| Protocol |
IPv4, IPv6, HTTP,HTTPS,SMTP,FTP,DHCP,NTP,TCP/IP, UPnP,RTSP/RTP/RTCP,DNS,DDNS,
PPPoE,IGMP,QoS,Bonjour,Samba,Multicast |
| Ethernet |
10Base-T/100Base-TX Ethernet connection for LAN/ WAN, RJ-45 |
| ONVIF |
Yes |
| Browser |
IE Browser 8.0 or above, Chrome, Firefox, Safari |
| Security |
Three-level access with password protection |
I/O & Controls
|
| Power |
DC Jack (2.0mm) |
| Power LED Indicator |
Yes |
| Network |
RJ-45 with LEDs (Networkindicator) |
| Reset |
Within 1 sec for rebooting system; more than 10 sec untilredLEDstartstoflash for loading default |
| BicolorLED |
Power&SystemStatus |
Power
|
| Power Requirement |
DC 12V 10% / PoE (IEEE 802.3af) |
| Power Consumption |
9W (Max.) |
Mechanical
|
| Dimensions(xH) |
60mm x 114mm ( 2.36 x 4.49) |
| Weight |
548g (1.21 lb) w/o bracket |
| Protection |
IP67 |
| Battery Backed-up Real-time Clock |
Yes; Internal RTC |
Environmental
|
| Operating Temperature |
-10C ~ 50C ( 14F ~ 122F ) |
| Operating Humidity |
20~ 90% RH |
| Storage Temperature |
-10C ~ 55C ( 14F ~ 131F ) |
Regulatory
|
| Approvals |
CE, FCC, RoHS |
Ordering Information
|
| Model No. |
NTSC: NCR772-N1-MES;
PAL: NCR772-P1-MES; |
| Accessories |
Wall Mount Stand |
|
|
|
|
20/10
|
Canon IXUS500HSR Digital Camera - Silver
- 10.1MP, 12x Optical Zoom, 28mm Lens, 3.0 inch LCD, Full HD Video IXUS 500 HS
Super Zoom, Super Stylish and Super Slim
Introducing the new IXUS 500 HS, an amazing compact camerawith beautiful styling and featuring a 12x Optical Zoom, allowing you to get closer to the action. The IXUS 500 HS also features FULL High Definition Movie Recording, 10.1 Megapixel High- Sensitivity CMOS Sensor, DiG!C 5 Image Processor and Intelligent IS.
At a glance
Huge 12x Optical Zoom and 28mm Wide Lens
Get closer to the action with a 12x Optical Zoom in a super slim camera.
Quality Images
High Sensitivity CMOS for better noise reduction delivering outstanding quality images in low light.
DiG!C 5 Image Processor
Achieves the most natural looking images with reduced noise and improved white balance.
Intelligent Image Stabilisation
Automatically choose the correct image stabilisation to use in different shooting situations.
3.0" LCD
A 3.0 inch type LCD with 461k dots for crystal clear playback and viewing.
Creative Filters
Fish Eye, Miniature, Toy Camera, Monochrome, Super Vivid, Poster, Colour Accent & Colour Swap.
Detailed Specifications
Sensor / Image Processor
Effective Number of Pixels / SizeApprox. 10.1 MP High Sensitivity CMOS / 1/2.3-inch
ProcessorDiG!C 5
Lens
Focal Length (optical)4.0 (W) - 48.0 (T) mm
35mm film equivalent28 (W) - 336 (T) mm
f/numberf/3.4 - 6.3 (W), f/5.6 - 9.0 (T)
Shutter Speed15 - 1/4000 sec.
ZoomOptical approx 12x; Digital approx. 48x
Image StabilizerOptical (Lens Shift Type), approx 4 steps
Focusing
Focus SystemTTL Autofocus
Focusing FrameFace Detect AiAF 2, Fixed Frame
Focusing RangeNormal: 5cm - infinity (W), 1m - infinity (T). Macro: 1cm - 50cm (max. wide angle)
Shooting Functions
Face DetectionAuto Focus, Auto Exposure, White Balance, Flash Exposure, Auto Red-Eye correction, Smile Smart Shutter, Wink Self-Timer, FaceSelf-Timer3 Blink Detection
Other Shooting FeaturesTouch Shutter, Servo AF, AF-Point Zoom, Size Select, AF Lock, AF Assist Beam, Intelligent Contrast Correction, Date Stamp, ZoomPlus, Digital Tele-converter, Focus Check, Night Display
Continuous Shooting (Large/Fine)Normal: approx. 2.8 shots/sec, High-speed Burst: approx. 6.8 shots/sec
Self-timerApprox. 10 sec or 2 sec delay, Custom, Smile, Wink Self-Timer, Face Self-Timer
Control/Balance
Light Metering MethodEvaluative, Centre weighted average, Spot
Exposure Control MethodProgram AE, AE Lock, Intelligent Contrast Correction
Exposure Compensation2 stops in 1/3-stop increments
Sensitivity (Equivalent Film Speed)Auto, ISO 100/200/400/800/1600/3200
White Balance ModesAuto , Daylight , Cloudy , Tungsten , Fluorescent , Fluorescent H , Custom
LCD Screen
LCD Screen3.0 type wide TFT (approx 461,000 dots) 4:3 aspect ratio and brightness adjustment (5 levels). Quick bright LCD
Flash
Flash Modes / FunctionsAuto, on, off, Slow Synchro
Flash RangeNormal: 50cm - 2.1m (W) 1.0m - 1.5m (T)
Selectable Shooting Modes
Shooting ModesIntelligent Auto (with Scene Detection), P, Movie Digest, Portrait, Kids & Pets, Smart Shutter, High-speed Burst, Best Image Selection, Handheld Night Scene, Low Light, Fish-eye Effect, Miniature Effect, Toy Camera Effect, Monochrome, Super Vivid, Poster Effect, Colour Accent, Colour Swap, Beach, Foliage, Snow, Fireworks, Long Shutter, iFrame Movie, Super Slow Motion Movie
My ColoursVivid, Neutral, Sepia, Black & White, Positive Film, Lighter Skin Tone, Darker Skin Tone, Vivid Blue, Vivid Green, Vivid Red
Image Recording Format
Still imageJPEG Compression (EXIF 2.3 Compliant)
Colour Space and JPEG CompressionsRGB; Superfine, Fine
MoviesMOV (Image Data: H.264; Audio Data: Linear PCM stereo)
Recording Pixels and recording capacity on a 8GB card
Still Images and Capacity (at Fine Image Setting)[16:9] Large 3648 x 2048, Medium 1 2816 x 1584, Medium 2 1920 x 1080, Small 640 x 360 [3:2] Large 3648 x 2432, Medium 1 2816 x 1880, Medium 2 1600 x 1064, Small 640 x 424 [4:3] Large 3648 x 2736, Medium 1 2816 x 2112, Medium 2 1600 x 1200, Small 640 x 480 [1:1] Large 2736 x 2736, Medium 1 2112 x 2112, Medium 2 1200 x 1200, Small 480 x 480
Movie Frame Rate[iFrame Movie] 1280 x 720 (30fps) [Super Slow Motion] 640 x 480, 320 x 240 [Miniature Effect] 1280 x 720, 640 x 480 [Others] Full HD 1920 x 1080 (24fps), HD 1280 x 720 (30fps), 640 x 480 (30fps)
Other Operations
Playback OperationsMovie Digest, Red-eye Correction, Intelligent Contrast Correction, Trimming, Resize, Slideshow, Index, Magnified, Focus Check, Favourites, Hints and Tips display, Auto Rotate, Histogram, Overexposure Warning, Transition, MyCategory, MyColours, Filter by Date, Smart Shuffle, Group Playback
Direct Printing, PictBridgeYes
Interface
Supported Operating SystemsPC: Windows 7 SP1, Windows Vista SP2, Windows XP SP3; Mac: OS X v10.6 - v10.7
Computer I/FUSB Hi-Speed and HDMI output
Video OutputPAL or NTSC selectable
Audio OutputStereo
Memory StoragemicroSD Memory Card, microSDHC Memory Card, microSDXC Memory Card
Menu Languages30 languages
General Features
BatteryRechargeable Lithium-ion Battery NB-9L
Shooting Capacity (full charge)Approx. 190 shots; Playback approx. 4 hrs
Dimensions (W x D x H)87.1 x 53.9 x 19.2 mm (ex. Protruding parts)
WeightApprox. 135g (camera body only)
Disclaimers
1If no face is detected, AiAF (9 points) is used
2When number of detected faces increases, the shutter is released at 2 sec delay. However if no face is detected for 30 seconds or more, the shooting operation will start automatically.
3Control to incorporate facial brightness in Face Detect AF
4Fixed to center
5Motion Detection - Camera automatically sets the optimal speed according to shooting mode, subject brightness and subject movement and camera shake.
6Compatible printer required for direct printing
|
|
|
|
20/10
|
Canon 700DB EOS 700D Digital SLR Camera - 18MP (Black)
- 3.0" Touchscreen TFT, Image Stabilization, Live View
- Body Only EOS 700D DSLR
All it needs is your imagination.
Ignite your creativity with the most powerful entry-level DSLR. Enjoy the amazing image quality and extremely accurate focusing that comes with theEOS 700DDiG!C 5 processor, 18 megapixel image sensor and superior AF system. Powerful features such as amazing low light performance, the easiest and smoothest FULL HD movie recording and the speed of capturing up to 5 frames per second will help take your creative photography further.
Amazing Low Light Performance
Capture incredibly high detail, even when the light gets low. ISO 100-25600.
Easy Access to Creative Modes
Creative and Scene modes to put your unique spin on your images.
Fast Shooting
Never miss a moment with high speed continuous shooting.
Incredibly smooth and easy FULL HD videos
Easily capture incredibly smooth and professional looking Full HD movies.
Get in Touch with your Creativity
Explore different angles, as well as allowing touch-focus and touch-shutter.
Detailed Specifications
Imaging
Imaging Sensor/Effective PixelsCMOS / 18.0 MP
Effective Sensor Size22.3x 14.9 mm
A/D Resolution Power14-bit
Colour Filter SizePrimary Colours, APS-C
35mm Focal Length Equivalent1.6X
Image Recording
MediumSD/SDHC/SDXC/UHS-I
Image Size
LargeApprox. 17.90 megapixels (5184 x 3456)
MediumApprox. 8.00 megapixels (3456 x 2304)
Small 1Approx. 4.50 megapixels (2592 x 1728)
Small 2Approx. 2.50 megapixels (1920 x 1280)
Small 3Approx. 350,000 pixels (720 x 480)
RAWApprox. 17.90 megapixels (5184 x 3456)
Movie Shooting (8GB Card)
1920 x 1080 (FULL HD)30/25/24 fps, 22min @ 330MB/min
1280 x 720 (HD)60/50 fps, 22min @ 330MB/min
640 x 480 (HD)30/25 fps, 1hr 32min @ 82.5MB/min
Viewfinder
Coverage (vertical/horizontal)95%
Dioptric Adjustment-3 to +1m dpt
Auto Focus
AF Points9 AF points
Exposure Control
Shooting Modes12 standard modes
Metering Segments63 zone TTL full aperture
Metering ModesEvaluative, Partial, Spot, Centre-weighted average
ISO Speed RangeISO 100-12800 (expandable to ISO 25600)
Exposure Compensation1/3 or 1/2-stop increments Normal: 5; Manual, AEB: 2
Shutter
Shutter Speed1/4000 sec 30, bulb, X-sync 1/200 sec.
Flash Control
E-TTL II AutoflashYes
Built-in Flash / Guide NumberYes / 13
Speed
Shooting Speed5 fps
White Balance
Settings8
WB BracketingYes
General Features
LCD Monitor3 Vari Angle TFT Colour Liquid Crystal (Approx. 1,040,000 dots)
Custom Functions/SettingsAug-24
Integrated Cleaning SystemYes
Live ViewYes (Live View Shooting, Movie Servo AF, Remote Live View Shooting, Face Detection, AF Mode, Manual, Magnified View, Multi Aspect Ratio, Exposure Simulation display)
External InterfaceHi-Speed USB/ HDMI / Stereo Audio OUT/ External Microphone IN / Remote Control Terminal (RS-60E3)
Wireless Remote Control ShootingYes (RC-6)
BatteryLithium Ion LP-E8
Chassis MaterialStainless steel and polycarbonate with glass fibre
Dimensions (W x H x D) mm133.1 x 99.8 x 78.8 mm
Weight excl. battery (g)525
|
|
|
|
20/10
|
Canon 700DSK EOS 700D Digital SLR Camera - 18MP (Black)
- 3.0" Touchscreen TFT, Image Stabilization, Live View
- Super Kit including EF-S 18-135mm f/3.5-5.6 IS STM Lens EOS 700D DSLR
All it needs is your imagination.
Ignite your creativity with the most powerful entry-level DSLR. Enjoy the amazing image quality and extremely accurate focusing that comes with theEOS 700DDiG!C 5 processor, 18 megapixel image sensor and superior AF system. Powerful features such as amazing low light performance, the easiest and smoothest FULL HD movie recording and the speed of capturing up to 5 frames per second will help take your creative photography further.
Amazing Low Light Performance
Capture incredibly high detail, even when the light gets low. ISO 100-25600.
Easy Access to Creative Modes
Creative and Scene modes to put your unique spin on your images.
Fast Shooting
Never miss a moment with high speed continuous shooting.
Incredibly smooth and easy FULL HD videos
Easily capture incredibly smooth and professional looking Full HD movies.
Get in Touch with your Creativity
Explore different angles, as well as allowing touch-focus and touch-shutter.
Detailed Specifications
Imaging
Imaging Sensor/Effective PixelsCMOS / 18.0 MP
Effective Sensor Size22.3x 14.9 mm
A/D Resolution Power14-bit
Colour Filter SizePrimary Colours, APS-C
35mm Focal Length Equivalent1.6X
Image Recording
MediumSD/SDHC/SDXC/UHS-I
Image Size
LargeApprox. 17.90 megapixels (5184 x 3456)
MediumApprox. 8.00 megapixels (3456 x 2304)
Small 1Approx. 4.50 megapixels (2592 x 1728)
Small 2Approx. 2.50 megapixels (1920 x 1280)
Small 3Approx. 350,000 pixels (720 x 480)
RAWApprox. 17.90 megapixels (5184 x 3456)
Movie Shooting (8GB Card)
1920 x 1080 (FULL HD)30/25/24 fps, 22min @ 330MB/min
1280 x 720 (HD)60/50 fps, 22min @ 330MB/min
640 x 480 (HD)30/25 fps, 1hr 32min @ 82.5MB/min
Viewfinder
Coverage (vertical/horizontal)95%
Dioptric Adjustment-3 to +1m dpt
Auto Focus
AF Points9 AF points
Exposure Control
Shooting Modes12 standard modes
Metering Segments63 zone TTL full aperture
Metering ModesEvaluative, Partial, Spot, Centre-weighted average
ISO Speed RangeISO 100-12800 (expandable to ISO 25600)
Exposure Compensation1/3 or 1/2-stop increments Normal: 5; Manual, AEB: 2
Shutter
Shutter Speed1/4000 sec 30, bulb, X-sync 1/200 sec.
Flash Control
E-TTL II AutoflashYes
Built-in Flash / Guide NumberYes / 13
Speed
Shooting Speed5 fps
White Balance
Settings8
WB BracketingYes
General Features
LCD Monitor3 Vari Angle TFT Colour Liquid Crystal (Approx. 1,040,000 dots)
Custom Functions/SettingsAug-24
Integrated Cleaning SystemYes
Live ViewYes (Live View Shooting, Movie Servo AF, Remote Live View Shooting, Face Detection, AF Mode, Manual, Magnified View, Multi Aspect Ratio, Exposure Simulation display)
External InterfaceHi-Speed USB/ HDMI / Stereo Audio OUT/ External Microphone IN / Remote Control Terminal (RS-60E3)
Wireless Remote Control ShootingYes (RC-6)
BatteryLithium Ion LP-E8
Chassis MaterialStainless steel and polycarbonate with glass fibre
Dimensions (W x H x D) mm133.1 x 99.8 x 78.8 mm
Weight excl. battery (g)525
|
|
|
|
20/10
|
Canon 1200DKB EOS 1200D Digital SLR Camera - 18MP (Black)
- 3.0" LCD, Image Stabilization, Live View, Face Detection
- Single Kit with EF-S 18-55mm f/3.5-5.6 III Lens EOS 1200D
The easy way to capture magic moments.
If you're craving better quality images than what youre getting on your phone or compact camera, but youre worried a DSLR cameras might be too difficult to use, then the EOS 1200D is the camera for you.
Designed for first-time DSLR owners who want impressive results straight out of the box, you can capture those magic moments no matter what your skill level with the EOS 1200D. With easy to use automatic shooting modes, a 18.0 MP APS-C CMOS sensor and Canons DiG!C 4 processor, the EOS 1200D is always ready to go. And for the budding videographer, you can share your story with Full HD movie recording (1080p) and Video Snapshot mode making the EOS 1200D the perfect companion for both DSLR quality images and videos.
18.0 MP APS-C CMOS Sensor
Perfect for creating large-scale prints, captured using an 18.0 MP APS-C CMOS sensor & Canons DIGIC 4 processor.
9-Point AF System
Ensures that no matter what you are shooting, the entire scene is captured in striking, detailed quality.
Clear Previews
Review your images on a bright 3" LCD screen.
Creative Filters
A choice of creative filters such as Miniature effect, Fish-eye and Toy camera, can be applied.
Full HD Movie Recording
Tell your story with Full HD movie recording (1080p) and Video Snapshot mode.
Scene Intelligent Auto
Picks camera settings, making great photography easy so that you can focus on capturing that magic moment.
Specifications
Detailed Specifications
EOS 1200D Technical Specifications
Image Sensor
TypeApprox. 22.3 mm x 14.9 mm
Effective PixelsApprox. 18.0 Megapixels
Total PixelsApprox. 18.7 Megapixels
Aspect Ratio0.126388889
Low-Pass FilterBuilt-in / Fixed
Sensor CleaningManual cleaning and Dust Delete Data acquisition
Colour Filter TypePrimary Colour
Image Processor
TypeDIGIC 4
Lens
Lens MountEF / EF-S
Focal LengthEquivalent to 1.6x the focal length of the lens
Focusing
TypeTTL-CT-SIR with a CMOS sensor
AF System / Points9 AF points (f/5.6 cross type at centre)
AF Working RangeCentre AF point: EV 0 -18 (at 23C & ISO100)
Other AF points: EV 1 -18 (at 23C & ISO100)
AF ModesOne Shot
AI FocusAI Servo
AF Point SelectionAutomatic Selection, Manual Selection
Selected AF Point DisplaySuperimposed in viewfinder and indicated on LCD monitor
Predictive AF(7)Yes, up to 10 m
AF LockLocked when shutter button is pressed half way in One Shot AF mode
AF Assist BeamIntermittent firing of built-in flash or emitted by optional dedicated Speedlite
Manual FocusSelected on lens
Exposure Control
Metering ModesTTL full aperture metering with 63-zone SPC
(1) Evaluative metering (linked to all AF points)(2) Partial metering at center (approx. 10% of viewfinder)(3) Center weighted average metering
Metering RangeEV 1-20 (at 23C with 50 mm f/1.4 lens ISO100)
AE LockAuto: In 1-shot AF mode with evaluative metering exposure is locked when focus is achieved
Manual: By AE lock button in creative zone modes
Exposure Compensation+/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB)
AEB3 shots +/- 2 EV, 1/2 or 1/3-stop increments
ISO Sensitivity(8)AUTO(100-6400), 100-6400 in 1-stop increments
ISO can be expanded to H: 12800During Movie shooting: Auto (100-6400), 100-6400 (Whole stop increments)
Shutter
TypeElectronically-controlled focal-plane shutter, with electronic first curtain
Speed30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)
White Balance
TypeAuto white balance with the imaging sensor
SettingsAWB, Daylight, Shade, Cloudy, Tungsten, White Fluorescent Light, Flash, Custom
White Balance Compensation:1. Blue / Amber +/-92. Magenta / Green +/-9
Custom White BalanceYes, 1 setting can be registered
WB Bracketing+/-3 levels in single level increments
3 bracketed images per shutter releaseSelectable Blue / Amber bias or Magenta / Green bias
Viewfinder
TypePentamirror
Coverage (Vertical / Horizontal)Approx. 95%
MagnificationApprox. 0.80x[1]
EyepointApprox. 21 mm (from eyepiece lens center)
Dioptre Correction-2.5 to +0.5 m-1 (dioptre)
Focusing ScreenFixed
MirrorQuick-return half mirror (Transmission: reflection ratio of 40:60, no mirror cut-off with EF600mm f/4 or shorter)
Viewfinder InformationAF information: AF points, focus confirmation light
Exposure information: Shutter speed, aperture value, ISO speed (always displayed), AE lock, exposure level/compensation, exposure warning, AEBFlash information: Flash ready, high-speed sync, FE lock, flash exposure compensation, red-eye reduction lightImage information: Highlight tone priority (D+), monochrome shooting, maximum burst (1 digit display), White balance correction, SD card information
Depth of Field PreviewYes, assigned to SET button with C.Fn-9-4
Eyepiece ShutterOn strap
LCD Monitor
Type7.5cm (3.0") TFT, approx. 460k dots
CoverageApprox. 100%
Viewing Angle (Horizontally/Vertically)Approx. 170
Brightness AdjustmentAdjustable to one of seven levels
Display Options(1) Quick Control Screen
(2) Camera settings
Flash
Built-in Flash GN (ISO 100, meters)9.2
Built-in Flash CoverageUp to 17 mm focal length (35 mm equivalent: 27 mm)
Built-in Flash Recycle TimeApprox. 2 seconds
ModesAuto, Manual Flash On / Off
Red-Eye ReductionYes with red eye reduction lamp
X-Sync1/200sec
Flash Exposure Compensation+/- 2EV in 1/2 or 1/3 increments
Flash Exposure BracketingYes with compatible External Flash
Flash Exposure LockYes
Second Curtain SynchronisationYes
HotShoe / PC TerminalYes / No
External Flash CompatibilityE-TTL II with EX series Speedlites, wireless multi-flash support (with optional accessory)
External Flash ControlVia camera menu screen, except for wireless radio flash shooting settings
Shooting
ModesScene Intelligent Auto, No Flash, Creative Auto, Portrait, Landscape, Close-up, Sports, Night Portrait, Movie, Program AE , Shutter Priority AE, Aperture Priority AE, Manual
Picture StylesAuto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Defined (x3)
Colour SpacesRGB and Adobe RGB
Image ProcessingHighlight Tone Priority
Auto Lighting Optimizer (4 settings)Long exposure noise reductionHigh ISO speed noise reduction (4 settings)Auto Correction of Lens Peripheral IlluminationBasic+ (Shoot by ambience selection, Shoot by lighting or scene type)Creative Filters (Grainy B / W, Soft focus, Toy camera, Miniature effect, Fish-eye) during image playback only
Drive ModesSingle, Continuous, Self timer (2s, 10s + remote,
10s + continuous shots 2 10)
Continuous ShootingMax. Approx. 3fps for approx. 69 JPEG images (1), 6 images RAW (2) (10)
Live View Mode
TypeElectronic viewfinder with image sensor
CoverageApprox. 100% (Horizontally and Vertically)
Frame Rate30 fps
FocusingManual Focus
(Magnify the image 5x or 10x at any point on screen)Autofocus: Quick mode, Live mode
MeteringReal-time evaluative metering with image sensor
Active metering time can be changed
Display OptionsGrid overlay, Histogram
File Type
Still Image TypeJPEG: Fine, Normal (Exif 2.30 compliant) / Design rule for Camera File system (2.0)
RAW: RAW (14bit, Canon original RAW 2nd edition)Digital Print Order Format [DPOF] Version 1.1 compliant
RAW + JPEG Simultaneous RecordingYes, RAW + Large JPEG
Image SizeJPEG 3:2: (L) 5184 x 3456, (M) 3456 x 2304, (S1) 2592 x 1728, (S2) 1920 x 1280, (S3) 720 x 480
JPEG 4:3: (L) 4608 x 3456, (M) 3072 x 2304, (S1) 2304 x 1728, (S2) 1696 x 1280, (S3) 640 x 480JPEG 16:9: (L) 5184 x 2912, (M) 3456 x 1944, (S1) 2592 x 1456 (S2) 1920 x 1080, (S3) 720 x 400JPEG 1:1: (L) 3456 x 3456, (M) 2304 x 2304, (S1) 1728 x 1728, (S2) 1280 x 1280, (S3) 480 x 480RAW: (RAW) 5184 x 3456
Movie TypeMOV: (Video: H.264, Sound: Linear PCM, recording level can be manually adjusted by user)
Movie Size1920 x 1080 (29.97, 25, 23.976 fps)
1280 x 720 (59.94, 50 fps)640 x 480 (30, 25 fps)
Movie LengthMax duration 29 min 59 sec, Max file size 4 GB
FoldersNew folders can be manually created and selected
File Numbering(1) Consecutive numbering
(2) Auto reset(3) Manual reset
Other Features
Custom Functions11 Custom Functions with 33 settings
Metadata TagUser Copyright Information (can be set in camera)
Image Rating (0 5 stars)
Intelligent Orientation SensorYes
Playback Zoom1.5x 10x enabled in 15 steps
Display Formats(1) Single Image with information (2 levels)
(2) Single Image(3) Index Display (4 / 9 / 36 / 100 images)(4) Jump Display (1/10/100 images, by Date, by Folder, Movies only, Stills only, by Rating)
Slide ShowImage Selection: All Images, by Date, by Folder, Movies,
Stills, RatingPlayback Time: 1 / 2 / 3 / 5 / 10 or 20 secondsRepeat: On / OffTransition Effect: Off, Slide 1, Slide 2, Fade 1, Fade 2, Fade 3Background Music: On / Off
HistogramBrightness: Yes
RGB: Yes
Highlight AlertYes (Shooting information display only)
Image Erase / ProtectionErase: Single image, all images in folder, checkmarked images, unprotected images
Protection: Erase protection of one image at a time
Menu Categories(1) Shooting menu (x4)
(2) Playback menu (x2)(3) Setup menu (x3)(4) My Menu
Menu Languages25 Languages
English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean and Japanese
Firmware UpdateUpdate possible by the user
Interface
ComputerHi-Speed USB
OtherVideo Output (PAL / NTSC) (integrated with USB terminal), HDMI mini output (HDMI-CEC compatible)
Direct Print
Canon PrintersCanon Compact Photo Printers and PIXMA Printers supporting PictBridge
PictBridgeYes
Storage
TypeSD card, SDHC card or SDXC card
SUPPORTED OPERATING SYSTEM
PC & MacintoshWindows XP inc. SP3 / Vista inc. SP2 (excl. Starter Edition) / 7 inc. SP1(excl. Starter Edition) / 8 / 8.1
OS X v10.7-10.9 (Intel processor required)
Software
Browsing and PrintingImageBrowser EX
Image ProcessingDigital Photo Professional
OtherPhotoStitch, EOS Utility, Picture Style Editor
Power Source
Batteries1 x Rechargeable Li-ion Battery LP-E10
Battery LifeApprox. 500 (at 23C, AE 50%, FE 50%)[2]
Approx. 410 (at 0C, AE 50%, FE 50%)
Battery Indicator4 levels
Power SavingPower turns off after 30 sec or 1, 2, 4, 8 or 15 mins
Power Supply and Battery ChargersAC Adapter Kit ACK-E10, Battery charger LC-E10, LC-E10E
Physical Specifications
Body MaterialsCarbon fibre / glass fibre-reinforced polycarbonate resin
Operating Environment0 40 C, 85% or less humidity
Dimensions (W x H x D)129.6 x 99.7 x 77.9 mm
Weight (body only)Approx. 480g (CIPA testing standard, including battery and memory card)
Footnotes
EOS 1200D[1] with 50 mm lens at infinity, -1 m -1 dpt[2] Based on the CIPA Standard and using the batteries and memory card format supplied with the camera, except where indicated
|
|
|
|
20/10
|
Canon 100DMTK EOS 100D Digital SLR Camera - 18MP (Black)
- 3.0" Touchscreen LCD, Image Stabilization, Live View
- EF-S 18-55mm f/3.5-5.6 IS STM Lens, EF-S 55-250mm f/4-5.6 IS STM Lens EOS 100D DSLR
Small and light, with no compromise.
With the EOS 100D, you dont get weighed down by a bulky, unmanageable camera and you dont need to compromise on quality either. This Entry Level DLSR Camera has a compact, lightweight body, making it the perfect companion, wherever you go. With its 18MP CMOS sensor and DiG!C 5 image processor, you can capture all of lifes amazing moments, in all their glorious colour and detail. Using the cameras seven creative filters, you can put your own unique spin on every image you create, and with the ability to capture four frames per second, you wont miss a moment of the action. You can also check out movies and stills as you capture them using LiveView on the cameras 3 high-resolution touch screen LCD monitor.
At a glance
Amazing Image Quality
Capture every detail with 18-megapixel resolution.
Fantastic Low-light Performance
Enjoy hand-held shooting in low light without using flash.
In-Camera Cropping - No Need for a Computer!
No need for a PC, use the in-camera crop feature.
New Hybrid CMOS AF II
Faster and more accurate continuous focus in Live View.
Optimise the Settings for your Scene with Special Scene Modes
Special scene modes to help you capture the moment.
Detailed Specifications
Imaging
Imaging Sensor/Effective PixelsCMOS / 18.0 MP
Effective Sensor Size22.3x 14.9 mm
A/D Resolution Power14-bit
Colour Filter SizePrimary Colours, APS-C
35mm Focal Length Equivalent1.6X
Image Recording
MediumSD/SDHC/SDXC/UHS-I
Image Size
LargeApprox. 17.90 megapixels (5184 x 3456)
MediumApprox. 8.00 megapixels (3456 x 2304)
Small 1Approx. 4.50 megapixels (2592 x 1728)
Small 2Approx. 2.50 megapixels (1920 x 1280)
Small 3Approx. 350,000 pixels (720 x 480)
RAWApprox. 17.90 megapixels (5184 x 3456)
Movie Shooting (8GB Card)
1920 x 1080 (FULL HD)30/25/24 fps, 22min @ 330MB/min
1280 x 720 (HD)60/50 fps, 22min @ 330MB/min
640 x 480 (HD)30/25 fps, 1hr 32min @ 82.5MB/min
Viewfinder
Coverage (vertical/horizontal)95%
Dioptric Adjustment-3 to +1m dpt
Auto Focus
AF Points9 AF points
Exposure Control
Shooting Modes12 standard modes
Metering Segments63 zone TTL full aperture
Metering ModesEvaluative, Partial, Spot, Centre-weighted average
ISO Speed RangeISO 100-12800 (expandable to ISO 25600)
Exposure Compensation1/3 or 1/2-stop increments Normal: 5; Manual, AEB: 2
Shutter
Shutter Speed1/4000 sec 30, bulb, X-sync 1/200 sec.
Flash Control
E-TTL II AutoflashYes
Built-in Flash / Guide NumberYes / 9.4
Speed
Shooting Speed4 fps
White Balance
Settings8
WB BracketingYes
General Features
LCD Monitor3.0 TFT Colour Liquid Crystal (Approx. 1,040,000 dots)
Custom Functions/SettingsAug-24
Integrated Cleaning SystemYes
Live ViewYes (Live View Shooting, Movie Servo AF, Remote Live View Shooting, Face Detection, AF Mode, Manual, Magnified View, Multi Aspect Ratio, Exposure Simulation display)
External InterfaceHi-Speed USB/ HDMI / Stereo Audio OUT/ External Microphone IN / Remote Control Terminal (RS-60E3)
Wireless Remote Control ShootingYes (RC-6)
BatteryLithium Ion LP-E12
Chassis MaterialAluminium and polycarbonate with glass fibre
Dimensions (W x H x D) mm116.8 x 90.7 x 69.4 mm
Weight excl. battery (g)370
|
|
|
|
20/10
|
Canon D30BL PowerShot D30 Digital Camera - Blue
- 12.1MP, 5x Optical Zoom, Focal Length (35mm Equivalent); 28mm to 140mm, 3.0" LCD, Image Stabilization, Intelligent ISO Mode, Waterproof, Shockproof PowerShot D30
Capture every adventure.
The PowerShot D30 is ideal for daring adrenaline seekers capable of shooting underwater action at depths as low as 25m. It delivers superior image quality and striking natural colours even in low-light conditions. Always ready for adventure, its shockproof for drops of up to 2.0m, freeze proof to -10 C and dustproof making it equally ideal for a snow trek, rock-climbing, or underwater explorations. With a durable body thats both slim and lightweight, you can throw the PowerShot D30 into a rucksack full of gear with confidence, knowing you can take it almost anywhere and shoot beautiful images, time after time.
Dustproof
Dustproof to IP6X rating.
Freezeproof
Negative 10 degrees cold resistant capability.
GPS to Tag & Log your Journey
Perfect for travelling, log all your photos and display with Google maps.
Shock Resistance to 2m Drop
Withstands the tough situations you throw it at.
Freezeproof
Beautiful results even in low light, with a 12.1 Megapixel HS System.
Waterproof to 25m
Tough enough to go 25m deep.
Detailed Specifications
Image Sensor
Type1/2.3 type back-illuminated CMOS
Effective PixelsApprox. 12.1M
Colour Filter TypePrimary Colour
Image Processor
TypeDIGIC 4 with iSAPS technology
Lens
Focal Length5.0 25.0 mm (35 mm equivalent: 28 140 mm)
ZoomOptical 5x
Digital Approx. 4.0x (with Digital Tele-Converter Approx. 1.5x or 2.0x and Safety Zoom [1] ). Combined Approx. 20x
Maximum f/numberf/3.9 f/4.8
Construction12 elements in 10 groups (2 UD lenses, 3 double-sided aspherical lens, 1 single-sided aspherical lenses)
Image StabilizationYES lens shift-type, Approx. 1.5-stop[2]. Intelligent IS
Focusing
TypeTTL
AF System / PointsAiAF (Face Detection / 9-point), 1-point AF
(fixed to centre)
AF ModesSingle, Continuous (only available in Auto mode), Servo AF / AE [3] , Tracking AF, Underwater Macro, Quick
AF Point SelectionSize (Normal, Small)
AF LockYES
AF Assist BeamYES
Manual FocusYES
Closest Focusing Distance1 cm (W) from front of lens in macro
Exposure Control
Metering modesEvaluative (linked to Face Detection AF frame),
Centre-weighted average, Spot (Centre)
AE LockYES
Exposure Compensation+/- 2 EV in 1/3 stop increments. Enhanced i-Contrast for automatic dynamic range correction.
ISO SensitivityAUTO, 100, 200, 400, 800, 1600, 3200
Shutter
Speed1 1/1600 sec. (factory default)
15 1/1600 sec. (total range varies by shooting mode)
White Balance
TypeTTL
SettingsAuto (including Face Detection WB), Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H, Underwater, Custom
Colour Matrix
TypesRGB
LCD Monitor
Monitor7.5 cm (3.0") PureColor II LCD (TFT) Approx. 461,000 dots
CoverageApprox. 100%
BrightnessAdjustable to one of five levels. Sunlight LCD mode
Flash
ModesAuto, Manual Flash On / Off, Slow Synchro
Slow Sync SpeedYES fastest speed 1/1600 sec.
Red-Eye ReductionYES
Flash Exposure CompensationFace Detection FE, Smart Flash Exposure
Flash Exposure LockYES
Built-in Flash Range30 cm 3.5 m (W) / 1.0 m 3.0 m (T)
Shooting
ModesSmart Auto (32 scenes detected), P, Movie Digest, Portrait, Smart Shutter (Smile, Wink Self-Timer, FaceSelf-Timer), Handheld Night Scene, Low Light (3.0 MP), Fish-eye Effect, Miniature Effect, Toy Camera Effect, Monochrome, Super Vivid, Poster Effect, Color Accent, Color Swap, Underwater, Underwater Macro, Snow, Fireworks, Long Shutter, Stitch Assist
Modes In MovieSmart Auto (21 scenes detected), P, Portrait, Miniature Effect, Monochrome, Super Vivid, Poster Effect, Color Accent, Color Swap, Underwater, Snow, Fireworks, iFrame Movie, Super Slow Motion Movie
Photo EffectsMy Colors (My Colors Off, Vivid, Neutral, Sepia, Black & White, Positive Film, Lighter Skin Tone, Darker Skin Tone, Vivid Blue, Vivid Green, Vivid Red)
Drive ModesSingle, Continuous, Self-Timer
Continuous ShootingApprox. 1.9 shots/sec. (until memory card becomes full)[4][5]
Recording Pixels/Compression
Image Size4:3 (L) 4000 x 3000, (M1) 2816 x 2112, (M2) 1600 x 1200, (S) 640 x 480
16:9 (L) 4000 x 2248, (M1) 2816 x 1584, (M2) 1920 x 1080, (S) 640 x 3603:2 (L) 4000 x 2664, (M1) 2816 x 1880, (M2) 1600 x 1064, (S) 640 x 4241:1 (L) 2992 x 2992, (M1) 2112 x 2112, (M2) 1200 x 1200, (S) 480 x 480Resize in playback (M2, S, XS*)*XS is half the length and width of S
CompressionFine
Movies(Full HD) 1920 x 1080, 24 fps, (HD) 1280 x 720, 30 fps, (L) 640 x 480, 30 fps
Super Slow Motion Movie (L) 640 x 480, 120 fps, (M) 320 x 240, 240 fpsMiniature Effect (HD, L) 6 fps, 3 fps, 1.5 fpsMovie Digest (L) 30 fpsiFrame Movie (HD) 30 fps
Movie Length(Full HD & HD) Up to 4 GB or 29 min. 59 sec.[6]
(L) Up to 4 GB or 1 hour[5]
File Types
Still Image TypeJPEG compression, (Exif 2.3 [Exif Print] compliant) / Design rule for Camera File system, Digital Print Order Format [DPOF] Version 1.1 compliant
MoviesMOV [Video:MPEG-4 AVC / H.264, Audio: Linear
PCM (monaural)]
GPS LogLOG [NMEA 0183 message format compliant]
Direct Print
Canon PrintersCanon SELPHY Compact Photo Printers and Canon Inkjet Printers supporting PictBridge
PictBridgeYES
Other Features
GPSYES- GPS tagging, GPS Logger, automatic time update.
Red-Eye CorrectionYES during shooting and playback
My Camera / My MenuStart-up image and camera sounds customisation
My CategoryImage tagging feature
Intelligent Orientation SensorYES
HistogramYES
Playback ZoomApprox. 2x 10x
Self TimerApprox. 2 or 10 sec. or Custom
Menu LanguagesEnglish, German, French, Dutch, Danish, Finnish, Italian, Norwegian, Swedish, Spanish, Simplified Chinese, Chinese (traditional), Japanese, Russian, Portuguese, Korean, Greek, Polish, Czech, Hungarian, Turkish, Thai, Arabic, Ukrainian, Romanian, Farsi, Malaysian,Indonesian, Vietnamese
Interface
ComputerHi-Speed USB (MTP, PTP) dedicated connector (Mini-B compatible)
OtherHDMI Mini Connector (HDMI-CEC compatible), A/V output (PAL/NTSC)
Memory Card
TypeSD, SDHC, SDXC
Supported Operating System
PC & MacintoshWindows 8 / 8.1 / 7 SP1 / Vista SP2 / XP SP3
Mac OS X 10.7 / 10.8 / 10.9
Software
Browsing & PrintingImageBrowser EX
OtherCameraWindow, PhotoStitch, Map Utility
Power Source
BatteriesRechargeable Li-ion Battery NB-6LH (battery and charger supplied)
Battery LifeApprox. 300 shots (Measured with GPS features off) Approx. 300 min. playback. More than 48 hours using only GPS Logger
A/C Power SupplyOptional, AC Adapter Kit ACK-DC40
Physical Specifications
Operating Environment-10 40 C, 10 90% humidity
Waterproof to 25 m(IEC/JIS IP Protection Rating IPX8 equivalent)Dustproof(IEC/JIS IP Protection Rating IP6X equivalent)Shockproof to 2.0 m drop(MIL Standard 810F Method 516.5)[8]
Dimensions (W x H x D)109.4 x 68.0 x 27.5 mm
WeightApprox. 218 g (including battery and memory card)
Footnotes
PowerShot D30[1] Depending on the image size selected.[2] Values at maximum optical focal length. Cameras whose focal length exceeds 350 mm (35 mm equivalent) are measured at 350 mm.[3] Some settings limit availability.[4] Under conditions where the flash does not fire.[5] Depending on memory card speed / capacity / compression setting.[6] The following Speed Class memory cards are required for maximum record time: (HD) 1280 x 720 Speed Class 4 or above. (Full HD) 1920 x 1080 Speed Class 6 or above. (iFrame) 1280 x 720 Speed Class 6 or above.[7] GPS use may be restricted in certain countries or regions. Use of GPS should comply with the laws and regulations of the country and area in which it is being operated including any restriction on the use of electronics.[8] The shock resistant testing methods are unique to this product and do not guarantee against damage or malfunction of the product.
|
|
|
|
20/10
|
Canon HFR506 Legria HF R506 Camcorder - Black
- SD, SDXC, SDHC Card Slot, HD 1080p, 32x Optical Zoom, 3.0" LCD, Image Stabilization, Night Recording, Face Detection, Self-Timer Canon LEGRIA HF R506
LEGRIA HD Camcorders
Product Overview
Canon LEGRIA HF R506
Capture the key moments in life - superb quality movies with ease
Compact, lightweight and easy to use the LEGRIA HF R506 gets you closer in Full HD with a big 57x Advanced zoom while optical Intelligent IS keeps movies steady. Ideal for capturing family memories.
- Optical Intelligent IS automatically switches between four modes to combat shake
- Canon HD Video lens with 57x Advanced zoom; Full HD CMOS sensor
- Capture memories of up to three children as they grow using Baby Mode
- Showcase and share, capture superb quality movies in AVCHD and MP4 formats
- Movies that sound as good as they look with Audio Scene Select
Full HD
Steady shots in every situation
Steady shooting on the move
Full HD CMOS sensor
57x Advanced Zoom
DIGIC Processing Power
28Mbps AVCHD recording
35 Mbps MP4 recording
Capture precious memories
Perfect audio to match the scene
7.5cm capacitive touch screen
Add a cinematic feel to movies
Add fun effects to movies
Open LCD for quick start
Optical Intelligent IS
Intelligent IS the perfect solution to camera shake. It automatically detects the scene and selects exactly the right optical image stabiliser settings from 4 modes to counteract movement and prevent blur. Advanced dynamic mode corrects roll and tilt movements that can occur when walking, ensuring sharp, steady videos.
57x Advanced zoom; Full HD CMOS
The genuine Canon HD video lens features a versatile 57x Advanced Zoom that lets you capture all the detail in even far away subjects. The 3.28 megapixel Full HD CMOS sensor delivers superb image quality and excellent colour reproduction even in low light.
Baby Mode
Easily capture the first steps, first words - and a host of other magical memories - of up to three children as they grow with advanced Baby Mode. Register each childs date of birth in-camera, and add colourful stamps and animations to record height and weight. All footage is automatically saved to the relevant baby album.
Superb quality recording
Bring out the best of Full HD with progressive recording at the highest rates for AVCHD (28Mbps) and MP4 (35Mbps). Whether youre showcasing or sharing, simply select the ideal format and choose from a range of recording rates.
Advanced image processing
The powerful DIGIC DV4 imaging processor ensures higher image quality in low light and a substantial reduction in image distortion as it works together with the optical image stabiliser.
Audio Scene Select
Make your movies sound as good as they look with Audio Scene Select. Select from 5 scene modes and audio settings are optimised automatically to match the scene youre shooting. So whether youre filming speech at a wedding or music at a concert, you can enjoy immersive, realistic audio.
Easy operation
Enjoy simple, intuitive fingertip control of shooting and playback functions with a high-resolution 7.5cm (3.0) capacitive Touch-screen LCD. Opening the LCD panel quick starts the camcorder, so youll never miss a shot.
Cinema-Look filters; Touch Decoration
Get creative with Cinema-Look Filters - select from 7 adjustable colour-grading filters to capture the perfect movie scene or add fun effects to your movies without a PC using Touch Decoration.
SDXC card slot
Record Full HD movies direct to an SDXC memory card. Widely available in a choice of sizes, SDXC cards let you easily capture and share hours of footage.
Specifications:
| Recording Formats |
AVCHD/MP4 |
| Recording Medium |
SDXC/SDHC/SD memory card |
| Max Recording Time* |
Variable total, depending on memory card size
64GB SDXC card (not supplied): AVCHD mode, 24hrs 30mins
MP4 Mode, 34hrs 45mins
|
| Type |
1/4.85" CMOS |
| Total pixels |
3.28 megapixel |
| Effective Pixels: Movie |
2.07 megapixels |
| Effective Pixels: Still |
2.07 megapixels (16:9) |
| Filter |
Bayer pattern filter |
| Advanced Zoom |
57x |
| Optical Zoom |
32x |
| Digital Zoom |
1140x |
| Focal length |
2.8mm - 89.6mm |
| 35mm Equivalent Focal Length |
32.5mm - 1853mm / (38.5mm-1232mm: Advanced zoom off) |
| Maximum aperture |
f1.8 to 4.5 |
| Minimum focusing distance |
10mm |
| Image Stabilizer |
Optical Image Stabiliser:
Intelligent IS with Advanced Dynamic Mode |
| Image Processor |
DIGIC DV 4 |
| Face Detection Technology |
YES |
| Screen size |
7.5cm (3.0") Touchscreen LCD, 100% view |
| Pixels |
230,000 dots |
| Touchscreen |
YES - capacitive type touch panel |
| Manual adjustment |
Brightness, backlight |
| Remote Control & Streaming |
NO |
| Movie Uploader |
NO |
| Playback via Browser |
NO |
| Media Server |
NO |
| Web Service |
NO |
| Baby Mode |
YES - register up to 3 children |
| Direct storage to external HDD |
NO |
| Minimum Lux. |
4 lux |
| Night Mode |
Low Light (0.4 lux) |
| Auto Gain Control limit adjustment |
NO |
| Auto/Manual |
YES / YES |
| Control |
AUTO: Face Detection AF / TV AF
MANUAL: Touchscreen LCD, Touch Focus |
| Manual Focus Assist |
YES (Magnification) |
| Creative Features |
Cinema-Look Filters
Touch Decoration |
| Smart AUTO |
YES (38 scenes) |
| Program AE |
AUTO;
M mode: P,SCN (Portrait, Sports, Snow, Beach, Sunset, Night, Low Light, Spotlight, Fireworks);
Cinema mode: P
Baby Mode |
| Backlight Compensation |
YES (automatic or user control) |
| Type |
TTL |
| Auto |
YES |
| Set/Preset |
YES: Daylight,Tungsten |
| Maximum |
1/2000th sec. |
| Slow |
1/2 sec. |
| Fade |
Auto Fade, Wipe |
| Effect |
NO |
| Image Effects |
NO |
| Custom Functions |
NO |
| Custom Control |
YES (Touch panel operations) |
| Capture image size |
1920 x 1080 (not Cinema mode) |
| Continuous shooting mode |
NO |
| Auto Exposure Bracketing |
NO |
| Simultaneous Photo Recording |
YES |
| Photo Button |
Touchscreen LCD |
| REC. review/REC. search |
NO/NO |
| Recording mode |
Four AVCHD recording quality modes.
50P: 1920 x 1080, 28Mbps;
MXP 50i/PF25: 1920x1080, 24Mbps;
FXP 50i/PF25: 1920x1080, 17Mbps;
LP 50i/PF25: 1440x1080, 5Mbps
Four MP4 quality recording modes
50p: 1920 x 1080, 35Mbps;
25p: 1920 x 1080, 24Mbps,
25p: 1920 x 1080, 17Mbps,
25p: 1280 x 720, 4Mbps |
| Video Snapshot |
YES |
| Pre REC |
YES |
| Dual Shot |
NO |
| Multi Media Card |
YES |
| Secure Digital Card |
SD / SDHC / SDXC |
| Movie Recording |
YES |
| Internal Data Transfer |
NO |
| System |
Dolby Digital 2ch (AC-3 2ch) |
| Audio Scene Select |
YES |
| Zoom Microphone |
NO |
| Manual Rec. level control |
YES |
| Headphone |
YES |
| Microphone |
NO |
| USB |
YES (Mini-AB, USB 2.0 Hi-Speed, output only) |
| AV |
YES (output only) |
| Component |
NO |
| HDMI |
YES (HDMI Mini Connector: output only |
| Built-in charger |
YES |
| Quick Start |
YES (using LCD screen) |
| Easy Web Upload |
NO |
| Convert to MP4 |
NO |
| Type |
Lithium Ion |
| Intelligent Battery System |
YES |
| Battery included in the kit |
BP-718 |
| Max recording time (included battery)* |
2h 10mins |
| Long life Battery |
BP-727 |
| Longer recording time** |
3hrs 15mins |
| W x H x D |
53 x 57 x 116mm |
| Weight |
235g |
| Max Recording Time* |
For both AVCHD and MP4, class 4 or higher-speed memory cards are recommended.
When AVCHD/MP4 recording has continued for 12 hours, it will automatically stop and then start again automatically |
| Effective Pixels: Movie |
Advanced Zoom ON, 16:9 recording mode, wide end
Image Stabiliser mode set to Standard or Off |
| Recording mode |
For both AVCHD and MP4, class 4 or higher-speed memory cards are recommended.
Variable bit rate used in all recording modes |
- * 4Mbps MP4 recording mode
- ** Normal LCD brightness and optional long life BP
|
|
|
|
20/10
|
Canon HFG25 Camcorder - Black
- 32GB Flash Memory, SD, SDXC, SDHC Card Slot, HD 1080p, 10x Optical Zoom, 3.5" LCD, Image Stabilization, Face Detection, Night Recording, Self-Timer, Dual Shot
Canon LEGRIA HF G25
LEGRIA HD Camcorders
Overview
Canon LEGRIA HF G25
Wide angle HD lens, exceptional audio and full manual controls unleash your creativity.
Designed to match the creative passion of video enthusiasts, the LEGRIA HF G25 features a wide angle lens, extensive manual controls and exceptional audio for stunning HD movies.
Benefits
- Canon HD Video Lens
- Canons advanced HD CMOS PRO sensor
- Full manual control
- Optical Intelligent IS
- Audio Scene Select
- 8.8cm touch screen LC
- Instant AF; Face Detection
- Protective lens hood
- 32GB internal memory
- 2x SDXC slots
Key Features
Full HD
HD Video Lens
Superb low-light shooting
Wide Angle Lens
Steady shots in every situation
Perfect audio to match the scene
Steady shooting on the move
Professional Audio
32GB built-in memory + SDXC slot
Dual SDXC card slots
8.8cm Wide LCD Screen
Touch Screen
8-Bladed Iris
Instant Auto Focus
Detailed Features
30.4mm Wide angle lens
Canons high performance HD Video lens technology delivers a superb 30.4mm, F1.8 lens with a smooth, 10x optical zoom, and 8-Blade iris for natural looking de-focus effects.
Advanced HD CMOS Pro Sensor
The advanced HD CMOS PRO sensor gives you superb low light performance and a wide dynamic range. The sensor originally designed and manufactured by Canon for its professional camcorders has further improved light transmittance providing an extra 20%. boost in low-light sensitivity.
Full manual control
A manual lens ring allows intuitive control of focus. Full manual control of exposure, aperture, shutter speed and gain is possible via the touch screen LCD. A custom key and manual dial put you in complete control of your creativity.
Optical Intelligent Image Stabilisation
Intelligent IS is the perfect solution to combat camera shake. It automatically detects the scene and selects exactly the right optical Image Stabilizer settings from 4 modes to counteract movement and prevent blur. It ensures sharp, detailed videos in every situation leaving you free to concentrate on shooting.
Audio Scene Select
Its simple to make your movies sound as good as they look with Audio Scene Select and a high-sensitivity, built-in zoom microphone. Just select from 5 scene modes and audio settings are optimised automatically to match the scene youre shooting. Optional Canon 5.1 surround and Wireless mics are also available.
High-resolution 8.8cm Touch-screen
A high-resolution 920k dot, 8.8cm touch screen LCD is optimised for shooting in HD and provides 100% coverage of the scene. A retractable, colour viewfinder adds to your shot-framing options.
Instant AF; Face Detection
Instant AF provides fast and accurate focussing for pin-sharp HD quality. Face Detection automatically optimises camcorder settings for perfectly focussed and exposed people shots.
Protective lens hood with barrier
A large lens hood that shuts out unwanted flare from external light sources is included as standard. It incorporates a fast-opening lens barrier that automatically protects without the need for a separate lens cap. So you will always be ready to shoot.
32GB memory plus 2x SDXC slots
Full HD AVCHD video is recorded at up to 24mbps to 32GB built-in flash memory for over 12 hours recording. Dual SDXC card slots and Relay Recording ensure enough capacity for the most ambitious movie projects.
Specifications
| Recording Formats |
AVCHD |
| Recording Medium |
32GB built-in flash memory;
SDXC/SDHC/SD memory cards (2 slots);
Double slot recording possible
Relay recording possible |
| Max Recording Time* |
Variable total, depending on memory card size
Internal memory: 12hrs 15mins,
64GB SDXC card: 24hrs 30mins, (not supplied) |
| Type |
1/3 type advanced HD CMOS PRO |
| Total pixels |
2.37 megapixel |
| Effective Pixels: Movie |
2.07 megapixels |
| Effective Pixels: Still |
2.07 megapixels (16:9) |
| Filter |
Bayer pattern filter |
| Advanced Zoom |
NO |
| Optical Zoom |
10x |
| Digital Zoom |
40x/200x |
| Focal length |
4.25 - 42.5mm |
| 35mm Equivalent Focal Length |
30.4 - 304mm |
| Maximum aperture |
f1.8 to f2.8 |
| Minimum focusing distance |
20mm |
| Image Stabilizer |
Optical Image Stabiliser:
Intelligent IS |
| Filter diameter |
58mm |
| Wide Attachment |
YES (optional WD-H58W) |
| Image Processor |
DIGIC DV III |
| Face Detection Technology |
YES |
| Screen size |
8.8cm (3.5") Touchscreen LCD, 100% view |
| Pixels |
922,000 dots |
| Touchscreen LCD |
YES |
| Manual adjustment |
Brightness, backlight |
| Direct storage to external HDD |
NO |
| Screen size |
0.61cm (0.24"), 100% view |
| Pixels |
260,000 dots |
| Minimum Lux. |
1 lux |
| Night Mode |
Low Light (0.1 lux) |
| Auto Gain Control limit adjustment |
YES |
| Auto/Manual |
YES / YES |
| Control |
AUTO: Face Detection AF/Face Only AF/Instant AF/Medium AF/TV AF
MANUAL: Lens ring, Touchscreen LCD, Focus Preset |
| Manual Focus Assist |
YES (Magnification, Peaking, Edge Monitor) |
| Creative Features |
Cinema-Look Filters
Story Creator
Touch Decoration |
| Smart AUTO |
YES (38 scenes) |
| Program AE |
AUTO;
M mode: P, Tv, Av, M (manual exposure), SCN (Portrait, Sports, Snow, Beach, Sunset, Night, Low Light, Spotlight, Fireworks);
Cinema mode: P, Tv, Av, M |
| Zebra |
YES |
| Backlight Compensation |
YES (automatic or user control) |
| Type |
TTL |
| Auto |
YES |
| Set/Preset |
YES: Set 1, Set 2, Daylight, Shade, Cloudy, Tungsten, Fluorescent, Fluorescent H, Colour Temperature |
| Maximum |
1/2000th sec. |
| Slow |
1/2 sec. |
| Fade |
Auto Fade, Wipe |
| Effect |
NO |
| Image Effects |
NO |
| Custom Functions |
Brightness, Contrast, Sharpness, Colour Depth |
| Custom Control |
YES (plus Control Dial) |
| Capture image size |
1920 x 1080 (not Cinema mode) |
| Continuous shooting mode |
YES (during playback only) |
| Auto Exposure Bracketing |
NO |
| Simultaneous Photo Recording |
YES |
| Selecting AF Frame Function |
NO |
| Histogram |
NO |
| Photo Button |
Touchscreen LCD |
| Photo Burst |
YES |
| Self timer |
10 sec
2 sec with wireless remote |
| REC. review/REC. search |
YES/NO |
| LP mode |
Five recording quality modes.
MXP: 1920x1080, 24Mbps;
FXP: 1920x1080, 17Mbps;
XP+: 1440x1080, 12Mbps;
SP: 1440x1080, 7Mbps;
LP: 1440x1080, 5Mbps |
| Progressive shooting mode |
YES (25p) |
| x.v.Color |
NO |
| Video Snapshot |
YES |
| Pre REC |
YES with assigned button |
| Dual Shot |
YES |
| Colour Bars and Test Tone |
NO |
| Still image |
NO |
| Date |
YES (date select, calendar, timeline, 3D Flip) |
| Multi Media Card |
NO |
| Secure Digital Card |
SD / SDHC / SDXC |
| Movie Recording |
YES |
| Internal Data Transfer |
MOVIE: Yes (internal memory to card A, card A to B)
STILLS: Yes (internal memory to card A, card A to B) |
| System |
Dolby Digital 2ch (AC-3 2ch);
5.1ch surround sound (via Optional SM-V1 microphone) |
| Audio Scene Select |
YES |
| Zoom Microphone |
YES (customisable frequency response and directionality) |
| Manual Rec. level control |
YES |
| Headphone |
YES |
| Microphone |
YES |
| USB |
YES (Mini-AB, USB 2.0 Hi-Speed) |
| DV |
NO |
| Direct Print |
NO |
| Analogue-in |
NO |
| AV |
YES (output only) |
| S-video |
NO |
| Component |
YES (output only) |
| HDMI |
YES (HDMI Mini Connector: v1.3, out only, CEC supported) |
| LANC |
YES |
| Built-in charger |
YES |
| Quick Start |
YES (mini Advanced Accessory Shoe) |
| DV Network Solution Disk |
NO |
| Application software |
YES |
| USB cable |
YES |
| Easy Web Upload |
YES |
| Convert to MP4 |
NO |
| HD -> SD conversion |
YES |
| Type |
Lithium Ion |
| Intelligent Battery System |
YES |
| Battery included in the kit |
BP-808 |
| Max recording time (included battery) |
1hr 55mins |
| Long life Battery |
BP-827 |
| Longer recording time** |
6hrs 05mins |
| W x H x D |
95 x 82 x 210mm (with lens hood) |
| Weight |
565g (with lens hood) |
| Max Recording Time* |
Class 4 or higher SDHC card required for 1920x1080 recording, Class 2 or higher SDHC card recommended for other recording modes, Memory card not supplied
Max recording time for MP4 is 30 mins and the max file size is 4GB, when either of these conditions are met recording will stop automatically
Recording for more than 12 hours continuously is not possible |
| LP mode |
Variable bit rate used in all recording modes
Class 4 or higher SDHC card required for 1920x1080 recording, Class 2 or higher SDHC card recommended for other recording modes, Memory card not supplied |
- (*): LP recording mode
- (**): Normal LCD brightness and optional long life BP
|
|
|
|
20/10
|
Canon SX600HSBK Digital Camera - Black
- 16MP, 18x Optical Zoom, Focal Length (35mm Equivalent); 25mm to 450mm, 3.0" LCD, Image Stabilization, Live View, Face Detection, 1080p HD Movie
PowerShot SX600 HS
A compact travel zoom-camera
The PowerShot SX600 HS strikes the right balance between a cameras zoom capabilities and its compactness, making it an ideal travel Zoom-Camera. The slim design packs a high-powered 18x zoom lens but when the lens is retracted, the SX600 is incredibly slim and compact and can easily slip into any pocket.
- DIGIC4+
- 25mm 450mm (18x Optical) with 36x ZoomPlus
- Full HD Movie
Addition of Web Service
With Google Drive now supported on your camera, you can now upload pictures seamlessly to Google Drive via the Canon Image Gateway in addition to YouTube, Twitter, Email, Flickr and Facebook.
Eco Mode
Eco mode (darkening of the LCD monitor when camera is not in use) has been improved by reducing the signal amount read from the image sensor by about one third of the usual amount, thereby reducing the power consumed by the camera engine.
36x ZoomPlus
Zoom in on the details of those dynamic architectural and scenic landscapes with the 36x ZoomPlus.
Specifications
| Imaging Processor |
DIGIC 4+ |
| Image Sensor |
|
| Camera Effective Pixels |
Approx. 16.0 megapixels |
| Lens |
Focal Length: |
18x zoom: |
4.5 (W) - 81.0 (T)mm
(35mm film equivalent: 25 (W) - 450 (T)mm) |
| Focusing Range: |
5cm (2.0in.) - infinity (W), 1m (3.3 ft.) - infinity (T) |
| Macro: |
Macro: 5 - 50cm (W) (2.0in. - 1.6 ft. (W)) |
| Image Stabilizer (IS) System: |
Lens-shift type |
| LCD Monitor |
Size: |
3.0-inch type |
| Effective Pixels: |
Approx. 461,000 dots |
| Aspect Ratio: |
4:3 |
| Focus |
|
| Control System |
Autofocus: Continuous, Servo AF |
| AF Frame |
Face AiAF, Tracking AF, Center |
| Metering System |
Evaluative, Center-weighted average, Spot |
| ISO Speed (Standard Output Sensitivity, Recommended Exposure Index) |
AUTO, ISO 100 - ISO 3200
1-step increments |
| Shutter Speed |
1 - 1/2000 sec.
15 - 1 sec. (Shooting long exposures) |
| Aperture |
Type |
Circular diaphragm |
| f/number |
f/3.8 / f/11 (W), f/6.9 / f/20 (T) |
| Flash |
Modes: |
Auto, On, Slow Synchro, Off |
| Range: |
50cm - 3.5m (W), 1.0 - 2.0m (T)
(1.6 - 11ft. (W), 3.3 - 6.6ft. (T)) |
| Shooting Specifications |
|
| Shooting Modes |
Hybrid Auto, Creative Shot, Auto, P, Portrait, Smart
Shutter*, High-speed Burst, Handheld NightScene,
Low Light, Fish-eye Effect, Miniature Effect, Toy
Camera Effect, Monochrome, Super Vivid, Poster
Effect, Snow, Fireworks, Long Shutter
*Smile, Wink Self-timer, Face Self-timer
Shooting movies is possible with the movie button |
| Continuous Shooting |
Approx. 3.9 shots/sec. (In P mode)
Approx. 10.5 shots/sec. (In high-speed burst HQ mode) |
| Number of Recording Pixels |
Still Images: |
4:3
Large: 4608 x 3456, Medium 1: 3264 x 2448,Medium 2: 2048 x 1536, Small: 640 x 480
|
| Aspect Ratios: |
16:9 / 3:2 / 4:3 / 1:1 |
| Movies: |
Digest Movie: 1280 x 720
Miniature Effect: 1280 x 720 / 640 x 480
Other than the above: 1920 x 1080* / 1280 x 720 /
640 x 480
*Frame Rate: 30fps |
| Number of Shots (CIPA Compliant) |
Approx. 290 |
| Number of Shots (CIPA Compliant) Eco Mode |
Approx. 430 |
| Movie Recoding Time (Actual Usage Time) |
Approx. 1hr |
| Power Source |
Battery Pack NB-6LH |
| Dimensions (CIPA compliant) |
103.8 x 61.0 x 26.0mm (4.09 x 2.40 x 1.02in.) |
| Weight (CIPA compliant) |
Approx. 188g (6.63oz.) (including the battery and
memory card)
Approx. 164g (5.78oz.) (camera body only) |
| Other features |
Mobile Device Connect Button, NFC compatibility |
|
|
|
|
20/10
|
Canon SX600HSR Digital Camera - Red
- 16MP, 18x Optical Zoom, Focal Length (35mm Equivalent); 25mm to 450mm, 3.0" LCD, Image Stabilization, Live View, Face Detection, 1080p HD Movie
PowerShot SX600 HS
A compact travel zoom-camera
The PowerShot SX600 HS strikes the right balance between a cameras zoom capabilities and its compactness, making it an ideal travel Zoom-Camera. The slim design packs a high-powered 18x zoom lens but when the lens is retracted, the SX600 is incredibly slim and compact and can easily slip into any pocket.
- DIGIC4+
- 25mm 450mm (18x Optical) with 36x ZoomPlus
- Full HD Movie
Addition of Web Service
With Google Drive now supported on your camera, you can now upload pictures seamlessly to Google Drive via the Canon Image Gateway in addition to YouTube, Twitter, Email, Flickr and Facebook.
Eco Mode
Eco mode (darkening of the LCD monitor when camera is not in use) has been improved by reducing the signal amount read from the image sensor by about one third of the usual amount, thereby reducing the power consumed by the camera engine.
36x ZoomPlus
Zoom in on the details of those dynamic architectural and scenic landscapes with the 36x ZoomPlus.
Specifications
| Imaging Processor |
DIGIC 4+ |
| Image Sensor |
|
| Camera Effective Pixels |
Approx. 16.0 megapixels |
| Lens |
Focal Length: |
18x zoom: |
4.5 (W) - 81.0 (T)mm
(35mm film equivalent: 25 (W) - 450 (T)mm) |
| Focusing Range: |
5cm (2.0in.) - infinity (W), 1m (3.3 ft.) - infinity (T) |
| Macro: |
Macro: 5 - 50cm (W) (2.0in. - 1.6 ft. (W)) |
| Image Stabilizer (IS) System: |
Lens-shift type |
| LCD Monitor |
Size: |
3.0-inch type |
| Effective Pixels: |
Approx. 461,000 dots |
| Aspect Ratio: |
4:3 |
| Focus |
|
| Control System |
Autofocus: Continuous, Servo AF |
| AF Frame |
Face AiAF, Tracking AF, Center |
| Metering System |
Evaluative, Center-weighted average, Spot |
| ISO Speed (Standard Output Sensitivity, Recommended Exposure Index) |
AUTO, ISO 100 - ISO 3200
1-step increments |
| Shutter Speed |
1 - 1/2000 sec.
15 - 1 sec. (Shooting long exposures) |
| Aperture |
Type |
Circular diaphragm |
| f/number |
f/3.8 / f/11 (W), f/6.9 / f/20 (T) |
| Flash |
Modes: |
Auto, On, Slow Synchro, Off |
| Range: |
50cm - 3.5m (W), 1.0 - 2.0m (T)
(1.6 - 11ft. (W), 3.3 - 6.6ft. (T)) |
| Shooting Specifications |
|
| Shooting Modes |
Hybrid Auto, Creative Shot, Auto, P, Portrait, Smart
Shutter*, High-speed Burst, Handheld NightScene,
Low Light, Fish-eye Effect, Miniature Effect, Toy
Camera Effect, Monochrome, Super Vivid, Poster
Effect, Snow, Fireworks, Long Shutter
*Smile, Wink Self-timer, Face Self-timer
Shooting movies is possible with the movie button |
| Continuous Shooting |
Approx. 3.9 shots/sec. (In P mode)
Approx. 10.5 shots/sec. (In high-speed burst HQ mode) |
| Number of Recording Pixels |
Still Images: |
4:3
Large: 4608 x 3456, Medium 1: 3264 x 2448,Medium 2: 2048 x 1536, Small: 640 x 480
|
| Aspect Ratios: |
16:9 / 3:2 / 4:3 / 1:1 |
| Movies: |
Digest Movie: 1280 x 720
Miniature Effect: 1280 x 720 / 640 x 480
Other than the above: 1920 x 1080* / 1280 x 720 /
640 x 480
*Frame Rate: 30fps |
| Number of Shots (CIPA Compliant) |
Approx. 290 |
| Number of Shots (CIPA Compliant) Eco Mode |
Approx. 430 |
| Movie Recoding Time (Actual Usage Time) |
Approx. 1hr |
| Power Source |
Battery Pack NB-6LH |
| Dimensions (CIPA compliant) |
103.8 x 61.0 x 26.0mm (4.09 x 2.40 x 1.02in.) |
| Weight (CIPA compliant) |
Approx. 188g (6.63oz.) (including the battery and
memory card)
Approx. 164g (5.78oz.) (camera body only) |
| Other features |
Mobile Device Connect Button, NFC compatibility |
|
|
|
|
20/10
|
Canon 1200DTKB EOS 1200D Digital SLR Camera - 18MP (Black)
- 3.0" LCD, Face Detection, Orientation Sensor, Live View
- Twin Kit With EF-S 18-55mm f/3.5-5.6 III Lens, EF 75-300mm f/4-5.6 III Lens EOS 1200D Twin Kit with EF-S 18-55mm f/3.5-5.6 III Lens and EF 75-300mm f/4-5.6 III Lens
The easy way to capture magic moments. "If you're craving better quality images than what you're getting on your phone or compact camera, but you're worried a DSLR cameras might be too difficult to use, then the EOS 1200D is the camera for you.
Designed for first-time DSLR owners who want impressive results straight out of the box, you can capture those magic moments no matter what your skill level with the EOS 1200D. With easy to use automatic shooting modes, a 18.0 MP APS-C CMOS sensor and Canon's DiG!C 4 processor, the EOS 1200D is always ready to go. And for the budding videographer, you can share your story with Full HD movie recording (1080p) and Video Snapshot mode - making the EOS 1200D the perfect companion for both DSLR quality images and videos.
Specifications
| Battery Information |
| Battery Chemistry: |
Lithium Ion (Li-Ion) |
| Battery Model Supported: |
LP-E10 |
| Battery Size Supported: |
Proprietary Battery Size |
| Number of Batteries Supported: |
1 |
| Built-in Devices |
| Built-in Devices: |
Microphone |
| Built-in Devices: |
Speaker |
| Controls/Indicators |
| Camera Modes: |
Shooting Modes:
- Scene Intelligent Auto
- No Flash
- Creative Auto
- Portrait
- Landscape
- Close-Up
- Sports
- Night Portrait
- Movie
|
| Self Timer: |
10 Second |
| Self Timer: |
2 Second |
| Display & Graphics |
| Display Resolution: |
460000 Pixel |
| Display Screen Type: |
LCD |
| Effective Camera Resolution: |
18 Megapixel |
| Image Sensor Size: |
2.23 mm x 1.49 mm |
| Image Sensor Type: |
CMOS |
| Screen Size: |
7.6 cm (3") |
| Total Camera Resolution: |
18.7 Megapixel |
| Touchscreen: |
No |
| White Balance Modes: |
- AWB
- Daylight
- Shade
- Cloudy
- Tungsten
- Flash
- Custom
- White Fluorescent Light
|
| Exposure |
| Exposure Control: |
- Program AE
- Aperture Priority AE
- Shutter Priority
- Manual
|
| ISO Sensitivity: |
Auto |
| ISO Sensitivity: |
ISO 100 |
| ISO Sensitivity: |
ISO 1600 |
| ISO Sensitivity: |
ISO 200 |
| ISO Sensitivity: |
ISO 3200 |
| ISO Sensitivity: |
ISO 400 |
| ISO Sensitivity: |
ISO 6400 |
| ISO Sensitivity: |
ISO 800 |
| Longest Shutter Speed: |
30 Second |
| Shortest Shutter Speed: |
1/4000 Second |
| Flash |
| Built-in Flash: |
Yes |
| External Flash: |
Optional |
| Flash Modes: |
Auto Flash |
| Flash Modes: |
Flash Exposure Compensation |
| Flash Modes: |
Flash OFF |
| Flash Modes: |
Flash ON |
| Flash Modes: |
Rear Curtain Sync |
| Flash Modes: |
Red-eye Reduction |
| Flash Modes: |
X-sync |
| General Information |
| Brand Name: |
Canon |
| Manufacturer Part Number: |
1200DTKB |
| Manufacturer Website Address: |
http://www.canon.com |
| Manufacturer: |
Canon, Inc |
| Marketing Information: |
The easy way to capture magic moments. "If you're craving better quality images than what you're getting on your phone or compact camera, but you're worried a DSLR cameras might be too difficult to use, then the EOS 1200D is the camera for you.
Designed for first-time DSLR owners who want impressive results straight out of the box, you can capture those magic moments no matter what your skill level with the EOS 1200D. With easy to use automatic shooting modes, a 18.0 MP APS-C CMOS sensor and Canon's DiG!C 4 processor, the EOS 1200D is always ready to go. And for the budding videographer, you can share your story with Full HD movie recording (1080p) and Video Snapshot mode - making the EOS 1200D the perfect companion for both DSLR quality images and videos. |
| Product Line: |
EOS |
| Product Model: |
1200D |
| Product Name: |
EOS 1200D Digital SLR Camera |
| Product Type: |
Digital SLR Camera |
| Image |
| Aspect Ratio: |
16:9 |
| Image Formats: |
JPEG |
| Image Formats: |
RAW |
| Maximum Image Resolution: |
5184 x 3456 |
| Interfaces/Ports |
| Analog Video Out: |
Yes |
| HDMI: |
Yes |
| PictBridge: |
Yes |
| USB: |
Yes |
| Lens |
| Aperture Range: |
f/3.5 to 5.6 (Lens 1) - f/4 to 5.6 (Lens 2) |
| Autofocus Points: |
9 |
| Digital Zoom: |
No |
| Focal Length: |
18 mm to 55 mm (Lens 1) - 75 mm to 300 mm (Lens 2) |
| Focus Modes: |
Auto |
| Focus Modes: |
Manual |
| Image Stabilization: |
No |
| Lens Construction: |
11 Elements in 9 Groups - 13 Elements in 9 Groups (Lens 2) |
| Lens Mount Type: |
Canon EF/EF-S |
| Optical Zoom: |
3.1x (Lens 1) - 4x (Lens 2) |
| Memory |
| Memory Card Supported: |
Secure Digital (SD) Card |
| Memory Card Supported: |
Secure Digital Extended Capacity (SDXC) |
| Memory Card Supported: |
Secure Digital High Capacity (SDHC) Card |
| Miscellaneous |
| Features: |
Continuous Shooting Mode |
| Features: |
External Flash Shoe |
| Features: |
Face Detection |
| Features: |
Live View |
| Features: |
Orientation Sensor |
| Features: |
Time Lapse Function |
| Green Compliance Certificate/Authority: |
REACH |
| Green Compliance Certificate/Authority: |
RoHS |
| Green Compliance Certificate/Authority: |
WEEE |
| Green Compliant: |
Yes |
| Language Supported: |
Arabic |
| Language Supported: |
Chinese (Traditional) |
| Language Supported: |
Czech |
| Language Supported: |
Danish |
| Language Supported: |
Dutch |
| Language Supported: |
English |
| Language Supported: |
Finnish |
| Language Supported: |
French |
| Language Supported: |
German |
| Language Supported: |
Greek |
| Language Supported: |
Hungarian |
| Language Supported: |
Italian |
| Language Supported: |
Japanese |
| Language Supported: |
Korean |
| Language Supported: |
Norwegian |
| Language Supported: |
Polish |
| Language Supported: |
Portuguese |
| Language Supported: |
Romanian |
| Language Supported: |
Russian |
| Language Supported: |
Simplified Chinese |
| Language Supported: |
Spanish |
| Language Supported: |
Swedish |
| Language Supported: |
Thai |
| Language Supported: |
Turkish |
| Language Supported: |
Ukrainian |
| Package Contents: |
- EOS 1200D Digital SLR Camera
- EF-S 18-55mm f/3.5-5.6 III Lens
- EF 75-300mm f/4-5.6 III Lens
|
| Platform Supported: |
Mac |
| Platform Supported: |
PC |
| Network & Communication |
| GPS: |
No |
| Physical Characteristics |
| Camera Assembly: |
Body with Lens Kit |
| Colour: |
Black |
| Depth: |
77.9 mm |
| Height: |
99.7 mm |
| Weight (Approximate): |
480 g |
| Width: |
129.6 mm |
| Video |
| HD Movie Mode: |
Yes |
| Maximum Frame Rate: |
60 fps |
| Maximum Video Resolution: |
1920 x 1080 |
| Video Formats: |
H.264 |
| Video Formats: |
MOV |
| Viewfinder |
| Maximum Diopter Adjustment: |
0.5 |
| Minimum Diopter Adjustment: |
-2.5 |
| Viewfinder Type: |
SLR |
| Warranty |
| Limited Warranty: |
24 Month |
|
|
|
|
Previous Page
|
Next Page
|
|
