AVM459B
2 Megapixel Vari-focal IP Camera
- Equipped with a vari-focal lens of f2.8 ~ 12mm, suitable for various monitoring environments
- 2M Pixeles, 1080P HD
- Solid Light enhance night vision up to 35 meters
Need a clear solution for outdoor day & night monitoring? AVM459B is the one you need.
This 2 megapixel camera, AVM459B, is an ourdoor-use IR camera with Solid Light, and supports HD image display, allowing users to have clear and sharp monitoring pictures. Its IR projection distance could reach up to 35 meters for dark area monitoring, suitable for places like factories or warehouses.
It's also capable of connecting external alarm devices, such as a buzzer or magnetic contacts, for function scalability. What's more, POE (power-over-ethernet) is also available for this camera.
For data storage, in addition to AVTECH NVRs, this camera also supports MicroSD card and ONVIF standard that makes it compatible with other brands' NVR and competitive regarding video storage.
External Alarm I/O Accessories
This camera supports all kinds of N.O. / N.C. type alarm sensors to extend the flexibility of IP surveillance. For example, active infrared sensor, smoke detector, magnetic contacts, etc.
Product Specifications
General
| Image Sensor |
1/2.9" Sony CMOS image sensor |
| Min. Illumination |
1 Lux / F1.4, 0 Lux (LED ON) |
| S/N Ratio |
More than 48dB (AGC off) |
| Electronic Shutter |
1/2 to 1/10,000 sec |
| Lens |
f2.8 ~ 12mm / F1.4 ~ F2.8 |
| Viewing Angle |
Wide: 109 (Horizontal) /
76 (Vertical) /
116 (Diagonal)
Tele: 24 (Horizontal) /
13.5 (Vertical) /
27(Diagonal)
|
| IR LED |
2 Units (Solid Light) |
| IR Effective Range |
IR enhanced mode: up to 35M / Default : up to 25M |
| IR Shift |
Yes |
| IRIS Mode |
AES |
| White Balance |
ATW |
| AGC |
Auto |
| IP Rating |
IP66 |
| Operating Temperature |
-20~40 |
| Power Source (10%) |
12V / 1A |
| Power consumption (10%) |
12.5W Max (PoE) ; 12.5W Max (PoN) ; 10.25W (DC Adapter) |
| Current Consumption (10%) |
Up to 855mA |
| Net Weight |
0.91 kg |
Video
| Video Compression |
H.264 / MPEG4 / MJPEG |
| Resolution |
SXGA / 720P / VGA / QVGA / 1080P |
| Frame Rate |
30 FPS |
| Multiple Video Streaming |
4(H.264, MJPEG, MPEG4) |
| Number of Online Users |
1-10 |
| Supported Protocols |
DDNS / PPPoE / DHCP / NTP / SNTP / TCP/IP / ICMP / SMTP / FTP / HTTP / RTP / RTSP / UPnP / RTCP / IPv4 / Bonjour / DNS / UDP / IGMP / QoS |
| LAN Speed |
10/100 Based-T Ethernet |
| LAN Port |
Yes |
| Security |
- Multiple user access levels with password
- IP address filtering
- Digest authentication
|
| Remote Access |
- Internet Explorer on Windows operating system
- 16CH Video Viewer on Windows & MAC operating system
- EagleEyes on iPhone, iPad & Android mobile devices
|
Others
| Mobile Surveillance |
Android / iOS |
| ONVIF Compatible |
Yes (Profile S) |
| POE (Power-over-Ethernet) |
Yes (IEEE 802.3af) |
| Event Notification |
FTP / Email / SMS |
| External Alarm Device Connection |
Yes |
| Digital Pan / Tilt / Zoom |
Yes |
| Motion Detection |
Yes |
| RTC (real-time clock) |
Yes |
| Minimum System Requirements |
- AGP graphics card, Direct Draw, 32MB RAM
- Windows 7, Vista & XP, DirectX 9.0 or later
- Internet Explorer 7.x or later
- 2GB RAM
- Intel core i3 or higher, or equivalent AMD
|
| Note |
microSD card slot |
| Current Consumption(10%) |
mA |
