VIVOTEK IP8355EH is a professional outdoor bullet network camera offering 30 fps @ 1.3-Megapixel resolution with superb image quality.



Featuring the new improved Wide Dynamic Range Technology WDR Pro II, it provides extreme visibility in extremely dark & light environments with 4-shutter capture method. Combined with 3D Noise Reduction Technology, which enables the IP8355EH to capture clear, polished video under low-light conditions and reduce bandwidth from sensor noise, users can identify an increased level of image detail in extremely bright as well as dark environments.



Additionally, as a professional day/night camera, IP8355EH adopts Smart IR technology which prevents overexposure and provides noise reduction to adjust IR lighting intensity instantaneously based on the changes of light in the ambient environment.



To provide top-notch image quality, IP8355EH also comes with a P-iris lens, which controls the iris with extreme precision with its built-in stepper motor. By using software controls, the lens maintains the iris opening at an optimal level at all times, resulting in superior sharpness and depth of field as well as image quality. Furthermore, for installers, properly adjusting the focus of a megapixel network camera can be difficult due to the level of image detail. Therefore, IP8355EH is also designed with VIVOTEK's Smart Focus System to make installation and adjustment easier by using remote focus and zoom adjustment.



The camera's IP67-rated housing is designed to protect the camera body from being immersed in the water, even against the immersion at the depth of at least 1m. Additionally, the wide temperature range further enhances the IP8355EH performance and reliability in extremely cold and hot weather.





System Information CPU Multimedia SoC (System-on-Chip) Flash 256 MB RAM 384 MB

Camera Features Image sensor 1/3" Progressive CMOS Maximum Resolution 1280x1024 (1.3MP) Lens Type Vari-focal, Remote Focus Focal Length f = 3 ~ 9 mm Aperture F1.2 ~ F2.3 Auto-iris P-iris Field of View 34 ~ 80 (horizontal) 27 ~ 62 (vertical) 44 ~ 101 (diagonal) Shutter Time 1/5 sec. to 1/10,000 sec. WDR Technology WDR Pro II Day & Night Removable IR-cut filter for day & night function Smart IR Technology to avoid overexposure Minimum Illumination 0.07 Lux @ F1.2, 50 IRE ( Color ) 0.001 Lux @ F1.2, 50 IRE ( B/W ) Pan / Tilt / Zoom ePTZ: 48x digital zoom (4x on IE plug-in,12x built in) IR Illuminators Built-in IR illuminators, effective up to 30 meters IR LED*4, with Smart IR Technology On-board Storage SD/SDHC/SDXC card slot

Video Compression H.264, MJPEG Maximum Frame Rate In both compression modes: 30 fps @ 1280x1024 Maximum Streams 2 simultaneous streams S/N Ratio 64 dB Dynamic Range 140 dB Video Streaming Adjustable resolution, quality and bitrate Image Settings Time stamp, text overlay, flip & mirror, configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight, compensation, privacy masks, scheduled profile settings, 3D Noise Reduction, EIS

Audio Audio Capability Two-way audio (full duplex) Compression AAC, G.711, G.726 Interface External microphone input Audio output

Network Users Live viewing for up to 10 clients Protocols IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP ONVIF Supported, specification available at www.onvif.org Interface 10Base-T/100 BaseTX Ethernet (RJ-45)

Intelligent Video Video Motion Detection Triple-window video motion detection

Alarm and Event Alarm Triggers Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection Alarm Events Event notification using digital output, HTTP, SMTP, FTP and NAS server File upload via HTTP, SMTP, FTP and NAS server

General Smart Focus System Remote focus Connectors RJ-45 for Network/PoE connection Audio input/output AV output AC 24V power input DC 12V power input Digital input*1 Digital output*1 LED Indicator System power and status indicator Power input DC12V/AC24V IEEE 802.3af PoE Power consumption DC Max. 30W (Heater on) 8W (Heater off) AC Max. 30W (Heater on) 8.8W (Heater off) PoE Max. 11W Dimensions : 85mm x 219 mm Weight Net: 1,314g (Body only) Net: 1,911g (with stand and sunshield) Casing Weather-proof IP67-rated housing Safety Certifications CE, LVD, FCC Class A, VCCI, C-Tick, UL Operating Temperature Starting Temperature: -40C ~ 50C (-40F ~ 122F) PoE: -10C ~ 50C (14F ~ 122F) Working Temperature: -50C ~ 50C (-58F ~ 122F) Warranty 24 months

System Requirements Operating System Microsoft Windows 8/7/Vista/XP/2000 Browser Mozilla Firefox 7~10 (Streaming only) Internet Explorer 7/8/9/10 Other Players VLC: 1.1.11 or above QuickTime: 7 or above



System Information CPU Multimedia SoC (System-on-Chip) Flash 128 MB RAM 256 MB

Camera Features Image sensor 1/2.5" Progressive CMOS sensor Maximum Resolution 1536x1536 Lens Type Fixed Focal Length f = 1.19 mm Aperture F2.0 Field of View 180 (horizontal) 180 (vertical) 180 (diagonal) Shutter Time 1/5 sec. to 1/32,000 sec. WDR Technology WDR enhanced Day & Night Removable IR-cut filter for day & night function Minimum Illumination 0.2 Lux @ F2.0 ( Color ) 0.001 Lux @ F2.0 ( B/W ) Pan / Tilt / Zoom ePTZ 12x digital zoom ( 12x on IE plug-in ) On-board Storage MicroSD/SDHC/SDXC card slot

Video Compression H.264, MPEG-4 & MJPEG Maximum Frame Rate H.264: 15 fps at 1536x1536 MPEG-4: 15 fps at 1536x1536 MJPEG: 15 fps at 1536x1536 Maximum Streams 3 simultaneous streams S/N Ratio Above 62 dB Dynamic Range 57 dB Video Streaming Adjustable resolution, quality and bitrate Image Settings Adjustable image size, quality and bit rate Pixel Calculator Time stamp, text overlay, flip & mirror Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks Scheduled profile settings

Audio Audio Capability Audio input / Audio output ( full duplex ) Compression GSM-AMR AAC G.711 Interface Built-in microphone External microphone input Effective Range 5 meters

Network Users Live viewing for up to 10 clients Protocols IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X Interface 10Base-T/100 BaseTX Ethernet (RJ-45) ONVIF Supported, specification available at www.onvif.org

Intelligent Video Video Motion Detection 5-window video motion detection

Alarm and Event Alarm Triggers Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection Alarm Events Event notification using digital output, HTTP, SMTP, FTP and NAS server File upload via HTTP, SMTP, FTP and NAS server

General Connectors RJ-45 cable connector for Network/PoE connection Audio input Audio output DC 12V power input Digital input*1 Digital output*1 LED Indicator System power and status indicator Power input DC 12V IEEE 802.3af PoE Class 2 Power consumption Max. 5.1 W (DC 12V) Max. 5.3 W (PoE) Dimensions : 139 mm x 43 mm Weight Net: 353 g Safety Certifications CE C-Tick FCC ( Class A ) LVD UL VCCI Operating Temperature -25C ~ 50C (-13F ~ 122F) Warranty 36 Months

System Requirements Operating System Microsoft Windows 7 / Vista / XP / 2000 Browser Mozilla Firefox 7~10 ( Streaming only ) Internet Explorer 7.x or 8.x Other Players VLC: 1.1.11 or above QuickTime: 7 or above
