128GB Compact Flash Card - Extreme Pro, Up to 160MB/s

Get high-capacity storage, faster shot-to-shot performance, and cinema-quality video with the SanDisk Extreme PRO CompactFlash Memory Card. With transfer speeds of up to 160MB/s, this card offers the fast, efficient performance you expect from the global leader in flash memory cards. This industry-leading memory card is optimized for professional-grade video capture, with a minimum sustained write speed of 65MB/s for rich 4K and Full HD video. Capacities up to 256GB accommodate hours of video and thousands of high-resolution images. So you never miss a scene or shot, this memory card resists extreme temperatures, shock, and other conditions.

• Designed for professional videographers and photographers
• Optimized for 4K video capture
• Transfer speeds of up to 160MB/s
• Shot speeds up to 150MB/s
• VPG-65 for sustained video recording speeds of 65MB/s

Specifications:

• Performance/speed: Up to 160MB/s Read (1067X), 150MB/s Write (1000X)
• Card dimension: 43 mm x 36 mm x 3.3 mm
• Operating temperature: 25C to 85C
• Storage temperature: 40C to -85C
• Compatibility: Compatible with CompactFlash supporting host devices
• Video Performance Guarantee (VPG) enabled
• Applications: Store a variety of digital formats, including RAW and JPEG photos, Full HD videos, music and more
• Support: Lifetime limited warranty
• 1 year downloadable RescuePRO media recovery software , for bringing accidentally deleted images back to life

Capacity: 128 GB
Read Speed: up to 160MB/s
Write Speed: up to 150MB/s
Video Speed: VPG-65
Form Factor: CompactFlash
This industry-leading memory card is optimized for professional-grade video capture, with a minimum sustained write speed of 65MB/s¹ for rich 4K and Full HD video.

SANDISK CF EXTREME PRO 64GB 160MB/150MB/S UDMA 7 & VPG 65

DS-4209 Pro

• Various Display Modes
• Full HD 200fps Monitoring
• HD 270fps Monitoring
• Convenient Control of PTZ and Speed Dome Cameras



DS-4209 Pro offers 1/4/9/12/16/20/25 & 5+1-channel & sequential and full screen display modes. DIGISTOR NVR supports video output via either HDMI or VGA connector for high image quality local display. Users can simultaneously monitor up to 9 channels in 1920 x 1080 (Full HD) and up to 200 fps (frame rate per second) outstanding monitoring performance. Also, users can control the pan, tilt and optical zoom of IP camera in local display interface. Both monitoring and configuration can be accessed in local display.



Frame rate in Full HD/HD local display is based on camera's compression format H.264.



The maximum resolution in live view of local display supports up to Full HD.



The max. FPS might be varied from different environments





Real-time Remote Monitoring

DS-4209 Pro DIGISTOR NVR offers instant monitoring via remote IE browser anytime, anywhere



• Multi-NVR Server Monitoring
• Various Monitoring Modes
• Convenient Control of PTZ and Speed Dome Cameras
• Digital Zoom in/ Zoom out



DIGISTOR NVR lets users monitor remotely via IE browser. In web-based interface, DS-4209 Pro offers 1/4/8/9/10/12/16/20/25/30/36 & 5+1/12+1-channel & sequential and full screen display modes and supports up to 9 channels. DIGISTOR NVR can be a multi-NVR server to connect other DIGISTOR NVR and select a maximum of 144 channels as well as simultaneously monitor other remote NVR sites without installing any extra VMS software. Also, remote monitoring offers control of PTZ camera and lets users view preset positions of the IP camera.





Excellent Video Recording
Smart and scheduled recording



• Various Compression Formats
• Various Recording Modes
• Flexible Threshold of Recorded Videos
• Multi-stream for Monitoring & Recording



DIGISTOR NVR gives users high performance megapixel recording and supports MJPEG, MPEG-4 and H.264 formats. Users can configure different recording schedules such as continuous, schedule, event and audio recording for each camera in high megapixel recording. Users can also set recording percentage or days for keeping videos to overwrite the oldest video files automatically. Furthermore, DIGISTOR NVR supports multi-stream to let users set video format, frame rate, resolution and other features in different conditions to save bandwidth for monitoring and recording.





Efficient Event Management



Diversified events and corresponding trigger actions



• Event Recording
• E-Mail Notification
• E-Mail Video Clip
• Buzzer Alarm
• User-defined Digital Output Actions
• Events: Camera connection lost, intelligent motion detection, user-defined digital input and NVR system connection lost
• Actions: Event recording, E-Mail Notification, video clip via E-Mail, buzzer and user-defined digital output



When an event is triggered, such as motion detection or digital input, DIGISTOR NVR can do various actions such as recording video in the server and sending a video clip instantly to users by E-mail. In addition, buzzer can be enabled to sound up to 60 seconds as abnormal events occur. Users can also define digital output actions by themselves, such as fire alarm system.





Intuitive Multi-channel Playback

Intuitive playback and clear interface to view recorded video



• User-friendly Video Search by Date, Time, Channel, Normal Record, Event and Recovered File
• Exporting Recordings
• Taking a Snapshot



 DIGISTOR NVR lets users search the recorded video by selecting date, time, channel number, normal record, event and recovered file. DIGISTOR NVR allows exporting video files in AVI format and during playback users can also take a snapshot and save photo in PC.





Advanced and Reliable Security System



Reliable security choices in DIGISTOR NVR



• Stable and Secure Linux-embedded System
• Detailed Log Information
• User Privilege Management
• Flexible Permission and Prohibition of IP Range for Controlling the Access



DIGISTOR NVR is a Linux-embedded operating system which is efficient to avoid virus attack and hacker intrusion. Compared with PC, Linux-embedded system offers more green and power saving. With over six clear log systems, users can do quick trouble shooting and security control of DIGISTOR NVR. As for privilege management, administrator can add multiple user groups like power user and user to configure live view and playback access. Besides, users can specify IP address or network segment to permit or prohibit specific IP address as white or black list from live view or playback access.





Smart, Simple and Mobile Enhancement
Smart enhancement brings you more convenience





Ingenious USB Backup


Configuration in advance Save time for backup in convenience



Users can set a maximum of days and hours to backup the latest video files and configure the specific channels for duplication in advance. After setting the time and channels, users just need to press USB BACKUP button on the NVR and then export the video files to external USB device. When an urgent need arises, video files are backed up efficiently and quickly.





Superior Hardware Design

DIGISTOR NVR’s excellent hardware performance truly enhances your efficiency



• High Network Throughput for High Megapixel Recording
• Supports up to 4TB Storage Capacity per Hard Disk Drive
• Built-in Advanced RAID Configuration with Hot Swap Design
• Automatic Recovery from DIGISTOR NVR Power Outage
• Built-in GPIO: 4 in 2 out



DIGISTOR NVR is powered by Intel CPU for excellent megapixel recording and provides network throughput up to 360Mbps. DIGISTOR NVR also supports each hard disk drive up to 4TB. Through DIGISTOR NVR, users can configure JBOD, RAID0, RAID1, RAID10 and RAID5 in local display or web-based interface; hot swap design allows users to replace failed HDD without turning off the server. DIGISTOR NVR will also automatically recover when power resumes after an outage and recover missing file caused from power outage. On the other hand, DIGISTOR NVR supports built-in General Purpose I/O for both choices of setting digital input and output.





Various Network Services



Simple and functional complement of network video recorder



• DDNS Service
• NTP Server
• Static IP or DHCP
• Quick UPnP Search for Connecting Camera
• Windows Networking and FTP Service



User can register a domain name from a dynamic DNS (DDNS) provider and enable DDNS in DIGISTOR NVR. DIGISTOR NVR supports NTP (Network Time Protocol) by selecting time zone for synchronizing the date and time. User can flexibly set static IP or DHCP server to enter the network video recorder. With Windows networking and FTP service, DIGISTOR NVR lets user quickly access the video files.



Specifications:



Local Display

Display Mode

1/4/9/12/16/20/25 & 5+1-channel & sequential and full screen display modes

Supported Channels
Up to 9 (Total 200fps in Full HD/ 270fps in HD)

Local Monitoring Control

PTZ control, optical zoom, full screen display

Local Configuration
User can set configuration via local display interface

Remote Monitoring

Display Mode

1/4/8/9/10/12/16/20/25/30/36 & 5+1/12+1-channel & sequential and full screen display modes

Supported Channels
Up to 9

Multi-NVR Server Monitoring
Up to 144 Channels

Control

PTZ control, digital zoom, optical zoom, full screen display, video sanpshot and preset position

Audio Status Support
Yes

Alarm Status Support
Yes

Recording Status Support
Yes

Remote Monitoring Support


IE Browser 7.0 or Above
Yes

iPhone iOS 5.0
Yes

Android Phone 2.3 or Above
Yes

Remote Recording

Supported Channels

Up to 9

Recording Mode

1· Recording by schedule/ Continuous recording/ Event recording/No recording/ Audio recording support

2· Automatic recycle/ Keep video days



File Format

AVI format

Video Format

MJPEG/MPEG-4/H.264 (Depending on the camera models)

Maximum Network Throughput

360Mbps (Varied in different environment)

Remote Playback
Multi-channel Playback



Support maximum 4-channel playback simultaneously

Search Mode

Search by date, time, camera number, normal record, event and recovered file

Control

Play, pause, speed control, zoom in/ out, full screen display and video snapshot

Export

Export video files in AVI format and take a snapshot

Event Management

Event



Camera connection lost, motion detection, user-defined digital input and NVR system connection lost

Action



1. Event recording: When motion detection or digital input is triggered, video will be stored in chunks (typically 5 minutes each) in DIGISTOR NVR

2. E-Mail notification: SMTP server service for sending E-Mail

3. Video clip via E-Mail: Pre-time of record: Up to 10 sec (Before event), Post-time of record: Up to 10 sec (After event)

4. Buzzer: Buzzer can be enabled up to sound for 60 seconds

5. User-defined digital output Security Management User Privilege Management



User can be assigned for different levels of privilege

Log System

Hardware log, NVR log, event log, current user log, historical user log and file access log

Access Control

Specify IP address or network segment for the white and black list

Auto Logout

Auto logout idle time limit from configuration page

Operating System

Linux-embedded system

USB Backup

USB BACKUP
Insert external USB device into DigiStor and press USB BACKUP button in 3 seconds to duplicate the video file instantly

Network Service

Protocol Support
HTTP, TCP/IP, DHCP, Static IP, DNS, DDNS, UPnP, FTP, NTP, and SMTP

File Sharing Service
Windows networking, FTP service

Reliability

Disk Management

JBOD, RAID0, RAID1,RAID10 and RAID5 disk configurations

Suggested PC Requirement

Operating System

Microsoft® Windows® XP (32-bit)/ Vista/ 7 (32 and 64-bit)

Browser

Microsoft® Internet Explorer 7.0 or above (32-bit)

CPU

For channels under 16 : Intel® Dual core CPU 3.0 GHz or above.

For channels over 16 : Intel® i5/i7 CPU 3.3 GHz or above.



Memory

For channels under 16 :DDR3 4G or above.

For channels over 16 : DDR3 8G or above.

Suggested Switch Requirement

Switch

Gigabit switch is highly recommended



Specifications:



CPU

Intel



Memory

2GB DDRIII memory

lGB Flash (DOM)



HDD Capacity

Up to 16TB (Storage Capacity per HDD : 4TB)



Number of HDD Supported

2.5"/ 3.5" SATA HDD x 4

(The standard system is shipped without HDD)



HDD Tray

4 x hot-swappable and lockable tray



LAN Port

2 x Gigabit RJ-45 Ethernet port



LED Indicators

HDD 1, HDD 2, HDD 3, HDD 4, eSATA, LAN1, LAN2



USB Connector



6 x USB 2.0:

Frontt x 1: For video backup

Frontt x 1 & Back x 4: Support pen drive, USB mouse, USB keyboard and USB UPS, etc.

eSATA

2 x eSATA port (Reserved)



Buttons

Power, USB backup



GPIO

4 in, 2 out



Output Connector

VGA x1/ HDMI x1 (for local display)



Alarm Buzzer

System warning



Form Factor

Tower



Operation Environment

Temperature 0~40C

Humidity 0~95% R.H.



Power Supply

Input: 100-240V AC, 50/ 60Hz



Output: 250W



Security Design

K-Lock security slot for theft prevention



Power Consumption

Operation: 54~65W (with 4 x 500GB HDD installed and in RAID 5 building process)



Fan

2 x quiet cooling fan (7cm, 12V DC)



H/ W Dimensions

245.8(D) x 205.3(W) x 184.94(H) mm

9.68(D) x 8.08(W) x 7.28(H) inch



Color Box Dimensions

303(D) x 250(W) x 317(H) mm

11.93(D) x 9.84(W) x 12.48(H) inch



Carton Dimensions

520(D) x 325(W) x 345(H) mm

20.47(D) x 12.80(W) x13.58(H) inch



Color Box Shipping Weight

Net Weight(kg/PC):4.43

Gross Weight(kg/PC):6.1

Gross Weight(kg/CTN):12.2

DS-4016

• Multi-NVR Server Monitoring
• Various Monitoring Modes
• Convenient Control of PTZ and Speed Dome Cameras
• Digital Zoom in/ Zoom out

• Various Compression Formats
• Various Recording Modes
• Flexible Threshold of Recorded Videos
• Multi-stream for Monitoring & Recording

• Event Recording
• E-Mail Notification
• E-Mail Video Clip
• Buzzer Alarm
• User-defined Digital Output Actions
• Events: Camera connection lost, intelligent motion detection, user-defined digital input and NVR system connection lost
• Actions: Event recording, E-Mail Notification, video clip via E-Mail, buzzer and user-defined digital output

• User-friendly Video Search by Date, Time, Channel, Normal Record, Event and Recovered File
• Exporting Recordings
• Taking a Snapshot

• Stable and Secure Linux-embedded System
• Detailed Log Information
• User Privilege Management
• Flexible Permission and Prohibition of IP Range for Controlling the Access

• Monitoring Everywhere via iPhone and Android Operating System
• Intelligent EZ Search of NVR
• Trouble Free Installation in 5 Steps

• Backup with Day, Hour and Channel Preset
• Efficient Hardware USB Backup Button

• High Network Throughput for High Megapixel Recording
• Supports up to 3TB Storage Capacity per Hard Disk Drive
• Built-in Advanced RAID Configuration with Hot Swap Design
• Automatic Recovery from DIGISTOR NVR Power Outage
• Built-in GPIO: 4 in 2 out

• DDNS Service
• NTP Server
• Static IP or DHCP
• Quick UPnP Search for Connecting Camera
• Windows Networking and FTP Service

• Multi-NVR Server Monitoring
• Various Monitoring Modes
• Convenient Control of PTZ and Speed Dome Cameras
• Digital Zoom in/ Zoom out

• Various Compression Formats
• Various Recording Modes
• Flexible Threshold of Recorded Videos
• Multi-stream for Monitoring & Recording

• Event Recording
• E-Mail Notification
• E-Mail Video Clip
• Buzzer Alarm
• User-defined Digital Output Actions

• Events: Camera connection lost, intelligent motion detection, user-defineddigital input and NVR system connection lost
• Actions: Event recording, E-Mail Notification, video clip via E-Mail, buzzer and user-defined digital output



When an event is triggered, such as motion detection or digital input, DIGISTOR NVR can take various actions such as recording video in the server and sending a video clip instantly to users by E-mail. In addition, buzzer can be enabled to sound up to 60 seconds as abnormal events occur. Users can also define digital output actions by themselves, such as fire alarm system.

• User-friendly Video Search by Date, Time, Channel, Normal Record, Event and Recovered File
• Exporting Recordings
• Taking a Snapshot

• Stable and Secure Linux-embedded System
• Detailed Log Information
• User Privilege Management
• Flexible Permission and Prohibition of IP Range for Controlling the Access

• Monitoring Everywhere via iPhone and Android Operating System
• Intelligent EZ Search of NVR
• Trouble Free Installation in 5 Steps

• Backup with Day, Hour and Channel Preset
• Efficient Hardware USB Backup Button

• High Network Throughput for High Megapixel Recording
• Supports up to 3TB Storage Capacity per Hard Disk Drive
• Built-in Advanced RAID Configuration with Hot Swap Design
• Automatic Recovery from DIGISTOR NVR Power Outage
• Built-in GPIO: 4 in 2 out

• DDNS Service
• NTP Server
• Static IP or DHCP
• Quick UPnP Search for Connecting Camera
• Windows Networking and FTP Service

• 1-Megapixel CMOS Sensor
• Compact Design
• Real-time H.264 and MJPEG Compression (Dual Codec)
• 30 fps @ 1280x800
• Two-way Audio
• Removable IR-cut Filter for Day and Night Function
• Built-in IR Illuminators, Effective up to 6 Meters
• Built-in MicroSD/SDHC Card Slot for On-board Storage
• Built-in IEEE 802.11b/g/n WLAN
• Wi-Fi Protected Setup (WPS) for Easy and Secure Wireless Network Connection

• 1-Megapixel CMOS Sensor
• Compact Design
• Real-time H.264 and MJPEG Compression (Dual Codec)
• 30 fps @ 1280x800
• Two-way Audio
• Removable IR-cut Filter for Day and Night Function
• Built-in IR Illuminators, Effective up to 6 Meters
• Built-in MicroSD/SDHC Card Slot for On-board Storage

System Information CPU Multimedia SoC (System-on-Chip) Flash 16 MB RAM 128 MB

Camera Features Image sensor 1/4" Progressive CMOS Maximum Resolution 1280x800 Lens Type Fixed-focal Focal Length f = 3.6 mm Aperture F 1.8 Field of View 60 (horizontal) 39 (vertical) 70 (diagonal) Shutter Time 1/5 sec. to 1/32,000 sec. Day & Night Removable IR-cut filter for day & night function Minimum Illumination 0.3 Lux, 50 IRE ( Color ) 0.001 Lux, 50 IRE ( B/W ) Pan / Tilt / Zoom ePTZ: 16x digital zoom (4x on IE plug-in, 4x built-in) IR Illuminators Built-in IR illuminators, effective up to 6 meters IR LED*6 On-board Storage Micro SD/SDHC/SDXC card slot

Video Compression H.264 & MJPEG Maximum Frame Rate H.264: 30 fps at 1280x800 MJPEG: 30 fps at 1280x800 Maximum Streams 2 simultaneous streams S/N Ratio Above 62 dB Video Streaming Adjustable resolution, quality and bit rate Configurable video cropping for bandwidth saving Image Settings Adjustable image size, quality and bit rate Time stamp, text overlay, flip & mirror Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks Scheduled profile settings

Audio Audio Capability Audio input/output (full duplex) Compression G.711 Interface Built-in microphone External line output Effective Range 5 meters

Network Users Live viewing for up to 10 clients Protocols IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X ONVIF Supported, specification available at www.onvif.org Interface 10Base-T/100 BaseTX Ethernet (RJ45)

Intelligent Video Video Motion Detection Triple-window video motion detection

Alarm and Event Alarm Triggers Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection Alarm Events Event notification using HTTP, SMTP, FTP and NAS server File upload via HTTP, SMTP, FTP and NAS server

General Connectors RJ-45 for Network connection Terminal block*2 for digital input Terminal block*2 for audio out DC-Jack for DC 12V power input LED Indicator System power and status indicator Power input 12V DC Power consumption Max. 3.0W Dimensions 46mm (D) x 80mm (W) x 80mm (H) Weight 123 g Safety Certifications CE, LVD, FCC Class B, VCCI, C-Tick Operating Temperature 0C ~ 40C ( 32F ~ 122F ) Warranty 24 months

System Requirements Operating System Microsoft Windows 7/Vista/XP/2000 Browser Mozilla Firefox 7~10 (streaming only) Internet Explorer 7.x or 8.x Other Players VLC: 1.1.11 or above   QuickTime: 7 or above
