The Brickcom OSD-040D 36x-59 is a high-end, Speed Dome network camera designed to provide high-quality video surveillance for outdoor environments. By offering H.264/M-JPEG/MPEG-4 triple codec compression, it is able to provide a flexible system which does not require high bandwidth or storage capabilities.



The advanced features of the OSD-040D 36x-59 work together to create crystal-clear video surveillance. By adopting a powerful 36x optical zoom lens with auto focus, it can easily provide clear close-up shots of objects. The Sony Super HAD II CCD sensor with Effio DSP(Digital Signal Processor) and removable IR-cut filter significantly improve the light sensitively of the OSD-040D 36x-59, providing excellent surveillance in both day and night settings. When its Wide Dynamic Range (WDR) sensor, the camera can handle extreme variations of brightness within the same sense. The WDR sensor averages out the very bright and very dark areas to create a more even evenly exposed video scene which is close to what the human eye would see.



Along with high-level sensors, the OSD-040D 36x-59 is equipped with a fast and precise pan/tilt mechanical design. The 360o continuous pan and -10o ~190o tilt combine with a rotation speed of 0.5o ~400o per second to provide complete coverage of every angle. With such powerful pan, tilt and zoom capabilities and a weather-proof casing (IP66), this camera is perfect for environments where precision and reliability are key; such as railway stations, airports, warehouses, and production facilities.



Product Name	36x Speed Dome Network Camera
Model Name	OSD-040E 36x: PAL
System hardware	CPU : 500 MHz Flash : 16M RAM : 128M DDR
Image Sensor	Sensor Type : 1/4" Sony Super HAD II CCD Sensor with Sony Effio DSP Sensor Resolution : 720x480(NTSC) 720x576(PAL)
Minimum Illumination	Color : 0.1 Lux B/W: 0.01 Lux
Lenses	36x Optical Zoom Lens Focal Length: f= 3.4 ~ 122.4 mm F number: F1.6 ~ F4.5 Horizontal View Angle : 1.7 ~ 55.8 Removable IR Cut Filter Auto Iris/ Auto Focus
Video	Auto Exposure Control / Auto White Balance / Auto Gain Control Image Compression: H.264 / MPEG4 / MJPEG
Resolution Max. Image	OSD-040E 36x: 720x576: 25 fps
Audio	2-way audio External MIC/Line Input External Audio Output
Network	Ethernet: one 10/100Mbps RJ-45 Supported Protocols : TCP/IP, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP, Samba, PPPoE, UPnP, Bonjour, RTP, RTSP, RTCP
Pan/ Tilt/ Zoom	Pan: 360, 0.5~400/s Tilt: 200(-10~190) , 0.5~400/s Zoom: 36x Optical Zoom 12x Digital Zoom
Interface & Buttons	AC Power In Ethernet Cable Connector General I/O Terminal Block Video Out(BNC) External MIC/Line Input External Audio Output
Power Supply	AC 24V 10%
Consumption Max. Power Supply	65 watt (with Heater)
Environment	Operating Temperature :-45C ~ 50C (-49F~122F) Operating Humidity : 20% ~ 80%
Dimensions	190 x 302.5mm ( 7.5x 11.9 Inches), with sunshield
Weight	2.6 kg (5.7 lbs)
Certification	FCC,CE, IP-66
Warranty	Limited 1-year warranty

Optional camera license packs for installing additional cameras on the Synology Surveillance Station



Synology Camera License Packs are designed for expanding cameras set up on the Synology Surveillance Station. By default, one camera license is installed. By applying the license key on the Surveillance Station user interface, you will be able to set up and manage more than one cameras on the network.



Purchase & Expand Camera Support
Two Packages Available



1 camera license
4 camera licenses
