The ViewSonic new short throw projector PJD5353 featuring BrilliantColor technology with 2,500 lumens, XGA 1024 x 768 resolution and 3,000:1 contrast ratio carries out professional business presentation with clear, crisp images and vivid colors. Eco-mode and high-performance energy-saving light bulbs not only reduce the noise level but extend lamp life for up to 6,000 hours and minimize the expense. The short throw lens allows big projected images from short distance, PJD5353 can project a 100-inch wide screen projected image in the distance of just one meter without image blur. The PJD5353 with multiple RGB computer input and output signals is available for users to easily switch the screen and deliver a dynamic presentation in office and classroom. The off to Go mode provides quick shutdown in 0 seconds and turn-on in 3 seconds that incredibly shows the smart and innovative thinking of exhibiting the convenience of business presentation.



PJD5353 projector prevails with leading 2,500 lumens brightness, XGA 1024 768 resolution, and 3,000:1 contrast ratio that meet the projection needs of medium and large conference room presentation. No need to turn off the lights and you can have a clear projection with vivid colors and high-resolution picture texture.



BrilliantColor™ technology
Latest BrilliantColor™ technology delivers vivid color and clear picture quality with all-digital way to enhance projected image. Advanced 6-segment color wheel as well enriches the performance of yellow color and further augments the representation of overall color.



6000-hours high performance long-life light bulbs
In the environment of energy-saving mode, the high-performance long-life light bulbs can last for 6000-hours lamp life, it not only greatly enhances the lamp life of the projector, but minimizes the cost of constantly replacing light bulbs. Compared to other models, the lamp can last for 1,000 to 2,000 hours lamp life than others.



Short throw ratio provides big projection size
The use of high-quality short throw optical lens enable a 100-inch projected image within 1.4 meters, you can enjoy splendid presentation in any environment with the crowds without worrying about projection distance.



0 second shutdown, 3 seconds turn-on, Off to Go Mode saves your time
PJD5353 projector with the efficient off to go mode that enables quick shutdown and turn-on alleviates your burden of long-time waiting, automatic cooling can be conducted even without power plug-in. It also takes only 3 seconds to turn on the projector. Without the burden of complicated procedures, you can enjoy the user-friendly off to go mode more quickly and easily.



Eco-mode saves energy, reduces noise and extends lamp life
Eco-Mode power saving mode meets the environmental needs to provide the most appropriate image brightness performance and reduce unnecessary waste of energy. In terms of fan cooling, eco-mode assists to adjust the power of fan operation and reduces significantly the noise generated by the fan.



RGB computer signal input and output
During presentation, you can connect PJD5353 with two computers individually to easily switch two screens and browse content on the screen, it saves efforts of complicated devices. The built-in RGB computer signal output can simultaneous project and deliver signal to connected screen and computer for you to view the contents on the screen.



LCD		Type		TI DMD 0.55"
		Resolution		1024x768
		Lens		Fixed Focus
Display		Size		40 - 300 inch (measured diagonally)
		Throw Distance		0.5 - 5.0m
		Lamp		180w / 6000 hour rating
		Brightness		2500 Lumens
		Contrast Ratio		3000:1
		Keystone Correction		Vertical digital keystone correction: 40 degrees
		Aspect Ratio		4:3 / 16:9
Audio		Speakers		2w x 1
Input Signal		Video		NTSC M (3.58 MHz), 4.43 MHz PAL (B, D, G, H, I, M, N, 60) SECAM (B, D, G, K, K1, L) 480i and 576i 480p and 576p 720p,1080i, 1080p
		Sync
		Frequency		Fh: 31-100KHz; Fv: 50-120Hz
Compatibility		PC		1024 x 768 @ 60Hz (Native)
		Mac		Up to 1Analog (*May require MAC adaptor)
Connector		RGB Input		DB-15 *2
		RGB Output		DB-15 *1
		Composite Video		RCA-1 *1
		Component Video		Share with RGB (RGB *1)
		Digital Input		HDMI x 1
		Audio		Input:3.5mm Mini-Mono Jack *2; Output:3.5mm Mini-Mono Jack *1
		Control		RS-232 (DB-9 *1)
		USB		*1 (Firmware Update / Mouse)
Power		Voltage		100 ~ 240 Vac 50 / 60 Hz
		Consumption		245 W
Controls		Basic
Operating Conditions		Temperature Humidity		0 - 40 ( C) / 32 - 104 ( F) 10%-80% (non-condensing)
Dimensions		Physical		294mm (W) x 242mm (H) x 84mm (D)
Weight		Net		2.6 kgs
Regulations				RoHCBCCCPSBC-tickKC S A S O C E G O S T - R U k r E r P SVHC list & REACH DoC ULFCC (including ICES-003)cULNOM TUV-SGS




Using less watts per lumen than other comparable projectors. And with a 3000:1 dynamic contrast ratio, its the bright choice for business, education and mobile presenters




Advanced DLP (Digital Light Processing) technology allows you to experience crystal clear, razor-sharp and lifelike images with the same DLP technology that Hollywood relies on. For fast action, the response time is also on the order of 1,000 times faster than similiar LCD based projectors. And with no air filters to clean or change, the latest generation of DLP based projectors from ViewSonic offer amongst the lowest TCO (total cost of ownership) in the industry. Check out the TCO calculators at http://www.viewsonic.com/viewschool/dlp-tco-calculator/






Color is one of the most important characteristics of a good projection system, and the latest BrilliantColor technology delivers stunning all-digital clarity with lifelike color, sharp graphics and outstanding video. The sophisticated 6-segment color wheel enhances the yellow color performance that is key to accurate and vivid color reproduction. With multi-color processing, colors are richer and more vibrant with exquisite and precise detail.


Delivers the best high-definition video and audio quality without losing any degradation. It's perfect for connecting to any high definition home entertainment devices like Blu-ray DVD players, HD gaming consoles and HD receivers.








With support for TIs DLP Link technology, youll have amazing 3D capabilities at your disposal. The projectors embedded emitter function means all thats required to unlock 3D capabilities is a pair of DLP Link compatible glasses, such as the optional ViewSonic PGD-250 active shutter glass kit*.




With only a slight 20% decrease in brightness, the ECO-mode function can extend the life of your lamp by almost 50% and up to 6,000 hours in some cases. Other benefits of ECO-mode operation include reduced power consumption, as well as less heat and audible noise output. Its good for the environment and great for your budget. The ECO-mode function will definitely help lower your total cost of ownership (TCO).





New Slim Design
At only 3.2 inches height and lightweight 5.7 pounds, it´s light and compact, making it ideal for mobility and portability.







Choose a projector that fits your space, as well as your lifestyle and needs. Simply determine your desired image size and then cross reference on this chart to locate the required projection distance. An interactive distance calculator specific to each and every ViewSonic projector is also available here to help calculate desired image size and throw distance based on your screen size.

Backed by our 20+ year reputation for quality and reliability, ViewSonic offers one of the industrys best overall projector warranty with 3-year limited parts, 1-year lamp and first year free Express Exchange service. Dont be fooled by seemingly longer warranties out there in the market that exclude the more vulnerable systems and moving parts.







Product Dimensions (w x h x d): 11.2 3.2 9.2 (in) / 284 82 234 (mm)
