17/03
|
Vivotek FD8161 Day & Night Fixed Dome Network Camera - 2 Mega Pixel
2-megapixel H.264 Day & Night Fixed Dome Network Camera FD8161
VIVOTEK FD8161 is a professional-series fixed dome network camera featuring superb megapixel image quality and exceptional bandwidth efficiency. It is especially suitable for wide open spaces such as building entrances and airports, or applications requiring accurate identification of human faces or license plate numbers.
Featuring a 2-megapixel sensor, this camera is able to provide extremely wide coverage with the finest details. With a field of view 6 times larger than a VGA camera, the FD8161 significantly reduces the number of cameras installed.
The FD8161 supports the latest in H.264 compression technology, rastically reducing file sizes by 90%. The cropping function removes unnecessary information and transmits only the designated image to optimize bandwidth and storage usage, and the ePTZ feature enables users to focus on close-up shots of different areas in the cameras view without moving the camera physically. Together with multiple streams which transmit individually configured video feeds simultaneously for viewing on different platforms, the FD8161 is able to meet a diverse set of needs and bandwidth constraints.
The camera also comes equipped with a removable IR-cut filter and IR illuminators (15 meters) to provide great clarity and contrast 24 hours a day. Other advanced features include a PIR (Passive Infrared) sensor, a 3-axis mechanism for flexible instal- lation, 802.3af PoE, SD/SDHC card slot, tamper detection, and SIP-enabled two-way audio. With the included ST7501 32-CH central management software, the FD8161 is the ultimate camera for demanding environments.
Features
- 2-megapixel CMOS Sensor
- 3 ~ 9 mm Vari-focal, Auto-iris Lens
- Removable IR-cut Filter for Day & Night Function
- Built-in IR Illuminators, effective up to 15 Meters
- Real-time H.264, MPEG-4 and MJPEG Compression (Triple Codec)
- Multiple Streams Simultaneously
- ePTZ for Data Efficiency
- Activity Adaptive Streaming for Dynamic Frame Rate Control
- 3-axis Mechanical Design for Ceiling/Wall Mount Installation
- Built-in PIR Sensor for Human Detection
- Built-in 802.3af Compliant PoE
- Built-in SD/SDHC Card Slot for On-board Storage
- Recessed Design with Cable Management for Clean Appearance
System CPU: TI DM365 SoC
Flash: 128MB
RAM: 256MB
Embedded OS: Linux 2.6
Lens f = 3 ~ 9 mm
F 1.2 (wide)
F 2.1 (tele)
auto iris
Board lens
Removable IR-cut filter for day & night function
Angle of View 31.7° ~ 93.0° (horizontal)
23.8° ~ 68.4° (vertical)
Shutter Time 1/5 ~ 1/40,000 sec
Image sensor 1/3.2" CMOS in 1600x1200 Resolution
Minimum Illumination 0 Lux / F1.2 ( IR LED on )
IR Illuminators Built-in IR illuminators, Effective up to 15 meter
Video Compression: H.264, MPEG-4 & MJPEG
Streaming:
Simultaneous multiple streams
H.264 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 multicast streaming
MJPEG streaming over HTTP or HTTPS
Supports activity adaptive streaming for dynamic frame rate control
Supports video cropping for bandwidth efficiency
Supports ePTZ for data efficiency
Supports 3GPP mobile surveillance
Frame rates:
H.264: Up to 30 fps at 1280x720, Up to 15 fps at 1600x1200
MPEG-4: Up to 30 fps at 1280x720, Up to 15 fps at 1600x1200
MJPEG: Up to 30 fps at 1280x720, Up to 15 fps at 1600x1200
Interface:
Audio/Video output
NTSC/PAL video output switch
Image Settings Adjustable image size, quality, and bit rate
Time stamp and text caption overlay
Flip & mirror
Configurable brightness, contrast, saturation, sharpness, white balance and exposure
AGC AWB AES
Automatic, manual or scheduled day/night mode
Supports privacy masks
BLC (Backlight compensation)
Audio Compression
GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps
G.711 audio encoding, bit rate: 64 kbps, µ-Law or A-Law
Interface:
Built-in microphone
External microphone input
Audio output
External/Internal microphone switch
Supports two-way audio via SIP protocol
Supports audio mute
Networking 10/100 Mbps Ethernet, RJ-45
ONVIF support
Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X
Alarm and Event Management Triple-window video motion detection
One D/I and one D/O for external sensor and alarm
Event notification using HTTP, SMTP, or FTP
Local recording of MP4 files
Tamper Detection
On-board Storage SD/SDHC card slot
Stores snapshots and video clips
Security Multi-level user access with password protection
IP address filtering
HTTPS encrypted data transmission
802.1X port-based authentication for network protection
Users 10 clients on-line monitoring at the same time
Dimensions Ø: 143mm x 106 mm
Weight Net: 697 g
LED Indicator System power and status indicator
System activity and network link indicator
Power 12V DC
Power consumption: Max. 6.5 W
802.3af compliant Power-over-Ethernet
Approvals CE C-Tick FCC LVD VCCI
Operating Environments Temperature: 0 ~ 50 °C (32 ~ 122 °F )
Humidity: 90%
Viewing System Requirements OS: Microsoft Windows 2000/XP/Vista/7
Browser: Mozilla Firefox, Internet Explorer 6.x or above
Cell phone: 3GPP player
Real Player: 10.5 or above
Quick Time: 6.5 or above
Installation, Management, and Maintenance 3-axis mechanism for flexible ceiling and wall mount installation
Camera angle adjustment:
Pan range: 350°
Tilt range: 85°
Rotate range: 350°
Installation Wizard 2
32-CH central management software
Supports firmware upgrade
Applications SDK available for application development and system integration
Warranty 24 months
|
|
|
|
|
17/03
|
Olympus F-1AC USB In-Camera Charger - For MJU8000, LI-50B OLYMPUS F-1AC USB In-Camera charger for MJU8000 and LI-50B battery
- Figure 8 Power Cable Not Included
|
|
|
|
17/03
|
Panasonic Lens ET-DLE050 Fixed Focus Lens 0.8;1 - Suits D3500, DW5000 & D5600 DLP ProjectorsPanasonic Lens ET-DLE050 Panasonic Lens ET-DLE050 Fixed focus lens 0.8:1. Suits Panasonic D3500, DW5000 & D5600 DLP projectors
|
|
|
|
17/03
|
Panasonic Lens For ET-DLE410, DW5000EPanasonic LENS ET-DLE410 FOR DW5000E
|
|
|
|
17/03
|
Sony SNCRH164 Surveillance Camera - Network HD Rapid Dome HD Camera
SNCRH164
The SNC-RH164 HD rapid dome IP camera has dual-streaming,H.264, MPEG-4,JPEG formats for HD resolution at up to 30 fps in 16:9 aspect ratio.A heavy-duty,outdoor PTZ with 210 tilt range and 360 endless high-speed panning.Visual Enhancement technology delivers clear images in challenging environment.
HD Resolution with 30fps
Visibility Enhancer (Auto Contrast Adjustment)
XDNR (Excellent Dynamic Noise Reduction)
DEPA Advanced (Basic Analytics within Camera)
Advanced Audio Detection (V1.1)
ONVIF Compliant
| Image Size
| 1280x720, 1024x576, 800x480, 768x576, 640x480, 640x368, 384x288, 320x240, 320x192 |
| Maximum Frame Rate
| H.264/MPEG-4: 30fps (1280 x 720) JPEG: 10fps (1280 x 720) |
| Minimum Object Distance
| 10 mm (wide) to 800 mm (tele) |
| Electronic shutter speed
| 1/2 to 1/10,000 s |
| Auto gain control
| Auto/Manual (-3 to +18 dB) |
| Exposure Control
| Auto, Full auto, Shutter-priority, Iris-priority, Manual, EV compensation, Backlight compensation |
| Minimum Illumination
| Day : 2.1 lx (XDNR ON VE ON Slow Shutter OFF 50 IRE IP/Analog) Night : 0.19 lx (XDNR ON VE ON Slow Shutter OFF 50 IRE IP/Analog) |
| White Balance Mode
| Auto, Indoor, Outdoor, One-push WB, Manual |
| F-Number
| F1.8 (wide), F2.1 (tele) |
| Horizontal Viewing Angle
| 5.4 to 50 degrees |
| Lens Type
| Auto-focus zoom lens |
| Focal Length
| f=5.1 to 51mm |
| Day/Night function
| Yes. Removable IR Cut Filter |
| Horizontal Resolution
| 480 TVL |
| Compression Format
| H.264, MPEG-4, JPEG |
| Wide-D
| Yes (Visibility Enhancer) |
| Zoom Ratio
| 10x Optical Zoom 12x Digital Zoom |
| Pan Angle
| 360 degrees endless rotation |
| Pan Speed
| 400 degrees/s (max.) |
| Tilt Angle
| 210 degrees (with e-flip) |
| Tilt Speed
| 400 degrees/s (max.) |
| Number of Effective Pixels
| Approx. 2 Megapixel |
| Other Functions
| Visibility Enhancer, XDNR, DEPA Advanced |
| S/N Ratio
| more than 50 dB |
| Audio Compression
| G.711/G.726 |
| Analog Video Ouput
| Composite video (1Vp-p) |
| I/O Port
| Sensor in x 4 Alarm out x 2 |
| External Microphone Input
| Mini-jack (Monaural), MIC IN/LINE IN: 2.2k ohm, 2.45VDC plug-in power |
| Audio Line Output
| Mini-jack (Monaural), Max output level: 1 Vrms |
| Ethernet
| 10BASE-T/100BASE-TX (RJ-45) |
| Serial Interface
| RS-232C, RS-422/RS-485 (PELCO D protocol) |
| Weight
| Approx. 4.3 kg (9 lb 8 oz) |
| Dimensions (W x H x D)
| 238 x 346 mm (9 3/8 x 13 5/8 inches) |
| Power Consumption
| 80 W max. |
| Operating Temperature
| -40 to 50 C |
| Storage Temperature
| -20 to 60 C |
| Supplied Accessories
| Top sunshade, Rotate-and-lock coupling, Waterproof covers, Bolts, Installation manual, CD-ROM (Users guide, SNC toolbox), Wire fixing belt, Cables |
| Protocols
| IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client/server), SMTP, DHCP, DNS,NTP, RTP/RTCP, RTSP, SNMP (MIB-2) |
| Authentications
| IEEE802.1X |
| Operating System
| Windows XP, Windows Vista |
| Processor
| CPU: Intel Core2 Duo 2GHz or higher |
| Web Browser
| Microsoft Internet Explorer Ver6.0, Ver7.0 |
|
|
|
|
17/03
|
Sony SNCRH124 Surveillance Camera - Network HD Rapid Dome HD Camera
SNCRH124
The SNC-RH124 HD rapid dome IP camera has dual-streaming, H.264, MPEG-4, and JPEG formats for HD resolution at up to 30 fps in 16:9 aspect ratio. A compact PTZ with 210 tilt range and 360 endless high-speed panning. Visual Enhancement technology delivers clear images in challenging environments.
HD Resolution with 30fps
Visibility Enhancer (Auto Contrast Adjustment)
XDNR (Excellent Dynamic Noise Reduction)
DEPA Advanced (Analytics within Camera)
Advanced Audio Detection (V1.1)
ONVIF Compliant
| Image Size |
1280x720, 1024x576, 800x480, 768x576, 640x480, 640x368, 384x288, 320x240, 320x192 |
| Maximum Frame Rate |
H.264/MPEG-4: 30fps (1280 x 720) JPEG: 10fps (1280 x 720) |
| Minimum Object Distance |
10 mm (wide) to 800 mm (tele) |
| Electronic shutter speed |
1/2 to 1/10,000 s |
| Auto gain control |
Auto/Manual (-3 to +18 dB) |
| Exposure Control |
Auto, Full auto, Shutter-priority, Iris-priority, Manual, EV compensation, Backlight compensation |
| Minimum Illumination |
Day:1.9 lx (XDNR ON VE ON Slow Shutter OFF 50 IRE IP/Analog) Night:0.17 lx (XDNR ON VE ON Slow Shutter OFF 50 IRE IP/Analog) |
| White Balance Mode |
Auto, Indoor, Outdoor, One-push WB, Manual |
| F-Number |
F1.8 (wide), F2.1 (tele) |
| Horizontal Viewing Angle |
5.4 to 50 degrees |
| Lens Type |
Auto-focus zoom lens |
| Focal Length |
f=5.1 to 51mm |
| Day/Night function |
Yes. Removable IR Cut Filter |
| Horizontal Resolution |
480 TVL |
| Compression Format |
H.264, MPEG-4, JPEG |
| Camera Type |
HD Rapid Dome |
| Wide-D |
Yes (Visibility Enhancer) |
| Zoom Ratio |
10x Optical Zoom 12x Digital Zoom |
| Pan Angle |
360 degrees endless rotation |
| Pan Speed |
400 degrees/s (max.) |
| Tilt Angle |
210 degrees (with e-flip) |
| Tilt Speed |
400 degrees/s (max.) |
| Number of Effective Pixels |
Approx. 2 Megapixel |
| Other Functions |
Visibility Enhancer, XDNR, DEPA Advanced |
| S/N Ratio |
more than 50 dB |
| Audio Compression |
G.711/G.726 |
| Analog Video Ouput |
Composite video (1Vp-p) |
| I/O Port |
Sensor in x 4, Alarm out x 2 |
| External Microphone Input |
Mini-jack (Monaural), MIC IN/LINE IN: 2.2k ohm, 2.45VDC plug-in power |
| Audio Line Output |
Mini-jack (Monaural), Max output level: 1 Vrms |
| Network |
10BASE-T/100BASE-TX (RJ-45) |
| Serial Interface |
RS-232C, RS-422/RS-485 (PELCO D protocol) |
| Weight |
Approx. 2.0 kg (4 lb 6 oz) |
| Power Requirements |
hPoE (V1.1), AC24V, DC12V |
| Dimensions (W x H x D) |
154 x 226 mm (6 1/8 x 9 inches) |
| Power Consumption |
25 W max. |
| Operating Temperature |
0 to +50 C |
| Storage Temperature |
-20 to +60 |
| Supplied Accessories |
Base unit, Mounting bracket, Screws, Cables (Power input, BNC, I/O, Serial), Installation manual, CD-ROM (User' s guide, SNC toolbox), Mounting template, Wire rope |
| Protocols |
IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client/server), SMTP, DHCP, DNS,NTP, RTP/RTCP, RTSP, SNMP (MIB-2) |
| Authentications |
IEEE802.1X |
| Operating System |
Windows XP, Windows Vista |
| Processor |
CPU: Intel Core2 Duo 2GHz or higher |
| Web Browser |
Microsoft Internet Explorer Ver6.0, Ver7.0 |
|
|
|
|
17/03
|
NEC NP2200G LCD Desktop Projector - XGA, 4200 Lumens, 600;1, 1024 x 768, VGA, DVI, Wired LAN
Achieve outstanding performance and energy efficiency during presentations with the NEC NP2200G, an eco-friendly installation projector ideal for higher education and corporate environments. This affordable model delivers remarkably bright images and features easy-to-use networking technologies, high contrast and up to 3000 hours of lamp life (in ECO ModeTM).
Compared to comparable projectors, it consumes less power, starts up and shuts down quicker, and features a carbon footprint meter, longer filter usage time and lamp life (in ECO Mode). Whether in the classroom or boardroom, the NP2200's multitude of advanced technologies allows you to connect with your audience using bright, colourful images and crisp text.
At a glance:
- 4200 lumens brightness
- complete line of (5) bayonet-style lenses
- vertical and horizontal lens shift
- built-in closed captioning enables decoding and display of text information from a video
- virtual Remote (DDC/CI) over the VGA cable to control the projector directly from a computer without the need for additional control cables
- variable audio-out allows the remote control to adjust the volume of self-powered external speakers connected to the projector
- extended lamp life with ECO ModeTM technology increases lamp life of up to 3000 hours, while lowering power consumption
- comprehensive input panel includes 5-BNC, DVI-D with HDCP, 15-pin, RCA and S-Video.
*Please note that the downloads (brochure/installation guide etc) includes the NP1200 & NP3200 - these are models that are not carried in Australia.
Specifications
Display: 3 x 2.03 cm (0.8") p-Si LCD Panel with MLA (Aspect Ratio 4:3)
Lamp: 300 W (264 W Eco Mode )
Lamp Life [hrs]: 2000 (3000 Eco Mode )
Brightness: 14200 ANSI Lumens (approx. 88% in Eco Mode )
Contrast Ratio: 1600:01:00
Lens: F= 1.72.2, f= 24.432.5 mm
Diagonal: min. / max. [cm]76 (30"); 1,270 (500")
Projection Distance [m]: 1.2 21.9
Projection Factor: 1.5 2 : 1
FrequencyHorizontal: 15100 kHz (RGB: 24 kHz or more); Vertical: 50 120 Hz
Resolution
Native Resolution: 1024 x 768 (XGA)
Supported Resolutions: 1600 x 1200 (UXGA); 1400 x 1050 (SXGA+); 1280 x 1024 (SXGA); 1280 x 768 (WXGA) with Advanced AccuBlend Technology; 1280 x 720 (HDTV 720p); 1152 x 900 (SGI, SUN); 1152 x 870 (Mac); 1024 x 768 (XGA); 832 x 624 (Mac); 800 x 600 (SVGA); 768 x 576 (PAL 15.6 kHz); 720 x 576 (SDTV 557p); 720 x 480 (SDTV 480p); 640 x 480 (VGA/Mac); 640 x 480 (NTSC 15.7 kHz)
Inputs
ComputerAnalogInput: 1 x Mini D-sub 15-pin, compatible to component (YPbPr); 1 x 5BNC, shared with Component Signal (YPbPr)
Output: 1 x Mini D-sub 15 pin
Computer DigitalInput: 1 x DVI-D (with HDCP)
VideoInput: 1 x RCA
S-VideoInput: 1 x Mini DIN 4-pin
AudioInput: 2 x 3.5 mm Stereo Mini Jack for Computer analog and digital; 1 x RCA Stereo for Video and S-Video
Output: 1 x 3.5 mm Stereo Mini Jack (variable) for Computer 1, 2, 3 (DVI-D), Video or S-Video
PC ControlInput: 1 x D-Sub 9 pin (RS-232) (male)
Video Signals: NTSC; NTSC 4.43; PAL; PAL-M; PAL-N; PAL60; SECAM
Audio Functions [W]: 2 x 5 (stereo)
Zoom / Focus: AdjustmentManual; Manual
Benefits3 x Security System; Auto Color Correction; Auto Power-ON Function; Carbon Savings Meter ; Help Function; IR Remote Control; LAN; Lens Shift (vertical 0.5 max., horizontal 0.1 max.); On/Off Timer; Plug&Play; Quick Lens Replacement and 5 Optional Lenses; Quick-Start -/Direct-Power-Off Function; Virtual Remote for direct PC control; Keystone Correction (V=+/- 30)
Remote ControlAspect Ratio; Automatic Picture Adjustment; Eco Button; Freeze-function; Help-function; Magnify-function; Page Control; Picture Mute; Source Select; Type RJ-45
Dimensions and weight
Dimensions (W x H x D) [mm]: 399 x 150 x 358 (without lens and feet)
Weight [kg]: 7.4
Power Supply: 100-240 V AC; 50 - 60 Hz
Power Consumption [W]: 381 Normal Mode; 334 Eco Mode ; 0.5 Stand-by Mode
Calorific Value: max. 1351 BTU (1 KWh= 3,412.14 British Thermal Unit)
Fan Noise [dB (A)]: 34; < 30 Eco Mode
Safety and ErgonomicsCE; RoHS ; TV GS
Warranty
2 years parts and labour
Shipping contents
CD-Rom with NEC Projector User Supportware; IR remote control; Lens Cap; Projector; Users Manual; Mini D-SUB Signal Cable (1.8 m); Power Cord (1.8 m)
|
|
|
|
17/03
|
View Sonic PJD-5112 DLP Portable Projector - SVGA, 2700 Lumens, 2800;1, 800x600, VGA, 2W x1 Speaker
Digitally clear, dynamic presentations
The PJD5112 is a DLP powerhouse that delivers sharp and bright images for virtually any environment. Its 3D ready with support for up to 120Hz frame rates. BrilliantColor technology produces more vibrant colors, while the high brightness and contrast ratio make this projector shine in the classroom or meeting room. The extensive input options, including two RGB inputs and one RGB output, and integrated 2-watt stereo speakers deliver a truly dynamic multimedia experience. This projector even features closed captioning for the hearing impaired. The PJD5112 is ideal for use at home or in amy small corporate settings.
 Bright in virtually any setting with lumens
Packs 2700 ANSI lumens in just 2.66kg(5.86 lb), and with a high 2800:1 contrast ratio (typ), your presentations are guaranteed to be vibrant even in the brightest office environment.
BrilliantColor technology
Latest BrilliantColorTM Technology delivers stunning all-digital clarity with life-like colour, sharp graphics and outstanding video. The sophisticated 6-segment colour wheel enriches the yellow colour performance that is key to accurate and vivid color reproduction.
Closed captioning
Integrated closed captioning decoder for the hearing impaired.
DLP Technology
Stunning all digital clarity delivers lifelike color, sharp graphics, and outstanding video.
Eco-mode extends lamp life
Extend the life of your lamp up to 5000 hours** and reduce noise output.
Off-to-Go feature
The direct off feature allows the busy presenter to simply unplug the projector and go without waiting for the usual cool down phase. This feature also protects lamp life from sudden power blackout.
Specifications:
| |
Model Number: PJD5112 |
|
 |
|
Download datasheet PDF
Acrobat Reader required. |
 |
|
|
|
|
|
| LCD |
|
Type |
|
0.55" Digital Micromirror Device(DLP) |
| |
|
Resolution |
|
800x600, 1600x1200 compressed |
| |
|
Lens |
|
1.2 Manual optical zoom / Manual optical focus |
|
| Display |
|
Size |
|
30 - 300 inch (measured diagonally) |
| |
|
Throw Distance |
|
1.2 - 10.0m |
| |
|
Lamp |
|
180watt (RLC-050) / 3500 hour rating |
| |
|
Brightness |
|
2700 Lumens |
| |
|
Contrast Ratio |
|
2800:1 |
| |
|
Keystone Correction |
|
Vertical digital keystone correction:+/- 40 degrees |
| |
|
Aspect Ratio |
|
4:3 (native) & 16:9 |
|
| Audio |
|
Speakers |
|
2W x 1 |
|
| Input Signal |
|
Video |
|
NTSC M(3.58MHz), 4.43MHz, PAL(B, D, G, H, I, M, N, 60), SD 480i and 576i(24fps, 25fps and 30fps), ED 480p and 576p(24fps, 25fps and 30fps), HD 720p, 1080i (24fps, 25pfs and 30fps) |
| |
|
Sync |
|
H/V separated |
| |
|
Frequency |
|
Fh: 31-100KHz; Fv: 50-120Hz |
|
| Compatibility |
|
PC |
|
VGA to UXGA |
| |
|
Mac |
|
Up to 1152x864 (may require Mac Adapter) |
|
| Connector |
|
RGB Input |
|
2 15-pin mini D-sub |
| |
|
RGB Output |
|
1 15-pin mini D-sub |
| |
|
Composite Video |
|
1 RCA jack |
| |
|
S-Video |
|
1 4-pin mini-DIN |
| |
|
Audio |
|
Input: 2 x 3.5mm mini jack; Output: 1 x 3.5mm mini jack |
| |
|
Control |
|
1 RS-232 (8 Pin Mini-Din) |
|
| Power |
|
Voltage |
|
90~240VAC(Auto Switching), 50 / 60Hz(universal) |
| |
|
Consumption |
|
235W (Typical) / <1W (Stand-by m |
|
| Controls |
|
Basic |
|
POWER, Keystone/ Arrow keys, Left/ BLANK, MENU/ EXIT, Right/ Panel key lock, AUTO, MODE/ ENTER, SOURCE |
| |
|
OSD |
|
Picture: Brightness, contrast, color setting, keystone, aspect ratio, image, white intensity, gamma, 3D sync, 3D sync invert.
Computer Image: Frequency, tracking, H position, V position.
Video Image: Saturation, sharpnes, tint. Setting: Menu position, projection, signal type, lamp hour, lamp hour reset, filter mode, filter hours, filter hours reset, power saving, auto source, ECO mode, high altitude, OSD timeout.
Advance: Blank screen, password word, screen capture, start up screen, text shot, digital zoom, DCR, close captions, brilliant color, |
|
| Operating Conditions |
|
Temperature
Humidity |
|
0C - 40C (32F - 104F)
10%-80% (non-condensing) |
|
| Dimensions |
|
Physical |
|
280mm (W) x 114mm (H) x 218mm (D) |
|
| Weight |
|
Net |
|
2.7 kgs |
|
| Regulations |
|
|
|
CB, ROHS, WEEE, UL / cUL, FCC-B, ICES-003, NOM, PSB, C-tick, EK, CE, TUV / GOST-R, Hygienic, UKrSEPRO, CCC |
|
|
|
|
17/03
|
BenQ Projector Remote - To Suit MP612 and more BenQ Projector Remote
KEYS AVAILABLE: 1. Power
2. Freeze
3. Left Arrow,
4. Blank
5. Digital Zoom buttons ( +,-)
6. Menu/Exit
7. Up/Down arrows and Keystone
8. Auto
9. Right arrow
10. Source
11. Mode/Enter
12. Timer on
13. Timer set up
COMPATIBILITY : BenQ Projector Models :
MP511+, MP512, MP522, CP270, MP512 ST, MP522 ST,
MP623, MP624, MP612, MP612C, MP622, MP622C, MP511, MP513
* The remote control exemplifies the ultimate in user-friendly design
and key layout for maximum ease of use
|
|
|
|
17/03
|
Kodak 7" Digital Photo Frame - aSi TFT Active Matrix, 800x480, 16;9, Widescreen, 500;1, USB, Card Reader, 1GB Internal Memory
KODAK EASYSHARE S730 Digital Frame
Wouldnt it be great if you could take your frame off the shelf and pass it around so everyone could enjoy your picture collection? The new KODAK EASYSHARE S730 Digital Frame allows you to share your pictures with family and friends anywhere in your home thanks to the rechargeable battery. The S730 Digital Frame is the first frame to include the innovative Picture Finder feature which helps you easily navigate and explore the up to 8000 pictures you can load on this amazing frame.
Unplug and sharebring pictures back into your life
The KODAK EASYSHARE S730 Digital Frame allows you to share your pictures with family and friends anywhere in your home.
- Cordless, so pictures can go where you gotake the frame off your shelf and bring pictures back into your life
- The one-hour rechargeable battery makes sharing pictures around the home simple and convenient
Picture Finder feature
- The S730 Digital Frame is the first to include the innovative Picture Finder feature
- Choose any image and Picture Finder will find more pictures from that date
- Store up to 8,000 pictures[1]on your frame with 1 GB internal memory
- Use the two available SD card slots to view and enjoy even more pictures
Viewing excellence
View your pictures on the 7 in. 15:9 wide digital display featuring patented KODAK Color Science Technology for crisp detail and vibrant colors.
Simple to use
- Kodaks Quick Touch Border with motion sensor makes it easy to operate your frame, allowing you to scroll through your photos, and more
- Four exciting viewing modes: slideshow, dynamic collage, clock, and calendar
- Plug-and-playinsert your memory card or USB flash drive with your digital pictures and your slideshow automatically begins
Environmentally responsible operation
- ENERGY STAR qualified for efficient power consumption
- Mercury-free panel
- Programmable timer automatically shuts down power at preferred times
- Make your frame even more energy efficient by upgrading your firmware
Easily access and transfer pictures
- KODAK EASYSHARE Software, Digital Frame Edition (included), makes it simple to browse and edit your pictures
- The convenient drag-and-drop feature is perfect for transferring pictures right to your frame or onto a memory card or USB drive
- Create multimedia slideshows on your desktop using pictures, videos, and music and easily transfer them to your frame
Set the mood with music
- Listen to your MP3s with built-in speakers
- Play back your favorite videos and slideshows with sound
Product Specifications
| Image file formats |
JPEG, EXIF 2.2
|
| Audio formats |
MP3, PCM, ADPCM, MPEG 1 layer (1, 2, 3)
|
| Video formats |
MOV, AVI, MPEG, MPEG4
|
| Dimensions |
8.9 6.1 1.5 in.
|
| Display size |
7 in. diagonal
|
| Display area |
6.0 3.6 in.
|
| Display resolution |
800 480 pixels
|
| Aspect ratio |
15:9
|
| Display type |
aSi TFT active matrix
|
| Display backlight |
LED
|
| Display brightness |
250 NITs (typical)
|
| Contrast ratio |
500:1 (typical)
|
| Supported Memory Card Formats |
dual slot 6-in-1 reader: Secure Digital (SD/SDHC), Multimedia Card (MMC), MEMORY STICK (MS), MS PRO/MS PRO DUO, XD-Picture Card (xD)
|
| USB mass storage |
USB High-Speed Type A
|
| Memory |
1 GB internal memory available
|
| Display modes |
full screen, collage, clock, calendar
|
| Power consumption |
- 11.75 watts (frame running and charging battery)
- 5.7 watts (frame running in slideshow mode)
|
| Rechargeable Battery |
Ni-MH (internal, 3.6 V)
|
| Power supply |
12 V DC 1.5 Amp
|
| Operating temperature |
32 to 104 F (0 to 40 C)
|
| Storage temperature |
-4 to 140 F (-20 to 60 C)
|
- Specifications
- System Requirements
Package Contents
- KODAK EASYSHARE S730 Digital Frame
- Power supply with 6 ft cord
- USB cable
- AC plug(s)
- Cleaning cloth
- User Guide
- KODAK EASYSHARE Software, Digital Frame Edition
|
|
|
|
17/03
|
Vivotek AM1010 Pendant Mount Kit - 20cm, 1 Piece Vivotek AM1010 Pendant Mount Kit (20cm) (1 piece)
Steel Material, White colour, Supports SD7151, SD7313, SD7323
|
|
|
|
17/03
|
Epson EH-TW3500 LCD Home Theatre Projector - 1800 Lumens, 36000;1, 1920x1080, Full HD, HDMI Epson EH-TW3500
Epson is pleased to introduce the Epson EH-TW3500 Home Theatre Projector. Delivering beautiful 1080p High Definition Home Theatre for a viewing experience that is truly larger than life, the EH-TW3500 is the latest release from the worlds number one projector manufacturer Epson.
KEY FEATURES:
- 36,000:1 High Contrast Ratio Bright whites and deep blacks for stunning image quality
- Full 1080p High Definition Bring the power of the worlds leading video standard into your own living room
- Up to 96.3% Lens Shift Allowing for maximum flexibility of installation, without the need for keystoning, therefore maintaining the Full High Definition image.
- High Performance Cinema Filter Improved design delivers a wider colour space and superior colour purity
- 3LCD Technology 3LCD technology achieves brighter, more natural images and smoother, sharper video playback.
The Epson EH-TW3500 is the latest high performance home theatre projector from Epson. Designed with the power to deliver beautiful 1080p High Definition images that are truly larger than life. The EH-TW3500 is aimed at the home theatre enthusiast seeking an entry point to gaining the full High Definition home theatre experience. The EH-TW3500 can be used on a table top, or as the centrepiece of a full home theatre installation.
36,000:1 High Contrast Ratio
Through enhancements to Epsons high performance 3LCD optical engine and E-TORL lamp technology, the EH-TW3500 is capable of delivering a spectacular 36,000:1 contrast ratio. The result? Higher light output, deeper darker blacks, rich, vivid colours and a contrast ratio usually reserved for much more expensive, high end products.
Full 1080p High Definition
Boasting dual HDMI (High Definition Multimedia Interface) digital terminals, the EH-TW3500 delivers full high definition on a grand scale. Experience the drama of your favourite movie, the excitement of the big game
High Performance Cinema Filter
A beautiful image requires the best treatment to ensure accurate colour reproduction. For this reason, the EH-TW3500 features a unique, Epson designed cinema filter. Crucial to achieving a wide colour gamut and colour purity, this innovative technology optically adjusts the primary colours (Red, Green, Blue) with exceptional balance and precision for incredibly accurate colour reproduction.
Powerful Lens Technology
A major contributor to the image quality produced by the EH-TW3500 is its cinema quality lens technology. Powerful x2.1 zoom and lens shift capability makes projector placement a breeze whilst maintaining optimal image quality.
3LCD Technology
At the heart of the EH-TW3500 is Epsons world-leading Crystal Clear Fine 3LCD technology. This advanced projection system uses three individual LCD panels to give form to images with silky smooth movement and fresh, natural colours.
Broad Selection of Connectivity Ports and Optional Cable Cover
With high performance, purpose built Home Theatre users in mind, Epson has included a broad selection of connectivity ports, including two HDMI, in the EH-TW3500. A stylish cover to hide away the rear connection ports and cables is available as an optional extra.
Specifications:
PRODUCT TYPE Home Theatre Projectors
PRODUCT NAME EH-TW3500
PRODUCT CODE V11H336053
PROJECTION SYSTEM RGB Liquid Crystal Display
PROJECTION METHOD Front / Rear / Ceiling Mount
SPECIFICATION OF MAIN PARTS
LCD Size 0.74 inches wide D7 panel with MLA
Driving method Poly-Silicon TFT Active Matrix
Native resolution 1080P Full HD (1920 x 1080)
Pixel number 6,220,800 pixels (1920 x 1080 pixels) x 3
Aspect ratio 16:9
Pixel arrangement Stripe
Refresh Rate 50Hz or 60Hz (based on input signal)
PROJECTION LENS Type manual: zoom / focus
F-number 2.0 - 3.17
Focus length 22.5 - 47.2mm
Zoom ratio 1.0 : 2.1
LAMP Type 200 W UHE E-TORL Lamp
SCREEN SIZE (PROJECTED DISTANCE) 30 to 300 inch (0.87m to 9.03m) (Wide)
30 to 300 inch (1.88m to 19.15m) (Tele)
LENS SHIFT RANGE Vertical: 96.3% max. (upward & downwards)
Horizontal: 47.1% max. (Left and Right)
BRIGHTNESS Normal Mode 1800 lumens
Colour Mode ( Dynamic, Zoom: Wide, Lens shift: V 5:5 / H Centre ) Colour Light Output 1800 lumens
(Colour mode: Dynamic, Zoom: Wide, Lens shift: V 5:5 / H Center, Auto iris: Off)
CONTRAST 36000:1 (Colour mode: Dynamic, Power consumption: Normal, Zoom: Wide, Lens shift: V 10:0 / H Center)
Contrast = 100% White (Iris: Open) / Black (Iris: Close) )
COLOUR PROCESSING Full 10 bit
COLOUR REPRODUCTIVITY Full Colour (1.07 Billion Colours)
COLOUR SPACE 115% of NTSC
VIDEO QUALITY Interlace - Progressive conversion 3D Y/C separation, Noise reduction
EFFECTIVE SCANNING FREQUENCY RANGE (Digital)
PIXEL CLOCK 13.5MHz to 150MHz
HORIZONTAL 15 to 80KHz
VERTICAL 24, 50 to 85Hz
ADJUSTMENT FUNCTION
PROJECTOR / REMOTE CONTROL Brightness / Contrast / Tint / Saturation / Input signal etc.
TILT ANGLE 0 to 8 degrees
KEYSTONE CORRECTION N/A
EPSON CINEMA FILTER Controlled automatically with colour mode (ON: Theatre Modes / Natural, OFF: Living Room / Dynamic)
AUTO IRIS Controlled automatically adjusting to video source
(Available at colour mode except x.v.Colour, User selectable High Speed/Normal/Off on OSD)
EPSON SUPER WHITE
Controlled automatically adjusting to video source (Available at Natural / Theatre / Theatre black 1 / Theatre black 2, User selectable On/Off on OSD)
2:2 Pull Down (1080p/24fps)
On/Off (Default off, HDMI & Component input)
ANALOGUE RGB I/O
DISPLAY PERFORMANCE Native 1080p Resize 1280 x 1024 / 1360 x 768 / 1024 x 768 / 800 x 600 / 640 x 480
INPUT SIGNAL Signal type Separate signal Video signal Analog (0.7V p-p,75 ohm/ Mac0.714Vp-p, 75ohm) Sync.signal Separate (positive & negative, bi-polarity 2-5Vpp) / Composite (positive & negative, bi-polarity 2-5Vpp) / Sync-on-green (negative, 0.3Vpp)
INPUT TERMINAL Video Mini D-sub 15 pin x 1 Blue molding
VIDEO I/O
COMPONENT INPUT
INPUT SIGNAL Video standard 480i / 576i / 480p / 576p / 720p / 1080i / 1080p Video signal Component Video (Analog Y level 0.7V 75 ohm / Cr Cb level +/-0.35V 75 ohm / sync. negative 0.3V or 3-state +/-0.3V on Y) INPUT TERMINAL RCA x 3 (Red / Green / Blue)
COMPOSITE / S VIDEO
INPUT SIGNAL Video standard NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM Video signal Composite Video (1.0Vpp / Sync.negative, 75 ohm) / S-Video (Luminous 0.714Vpp, Chrominous 0.286Vpp, 75 ohm)
INPUT TERMINAL S-Video Mini DIN x1 Composite Video RCA (Yellow) x 1
LOCK FUNCTION Operation Lock & child-lock
OPERATING TEMPERATURE 5°C to 35 °C (41°F to 95 °F) at 20% ~ 80% Humidity
DIRECT POWER ON Yes
COOL-DOWN PERIOD Approx 16 seconds
POWER SUPPLY VOLTAGE 100-240 VAC ±10%, 50/60Hz
POWER CONSUMPTION 269W (Normal Mode)
DIMENSIONS
EXCLUDE FEET 450mm(W) x 360mm(D) x 136mm(H)
MAXIMUM DIMENSION 450mm(W) x 390mm(D) x 145mm(H)
WEIGHT Approx. 7.3 kg
FAN NOISE
HIGH BRIGHTNESS MODE 29dB (Colour mode: Dynamic)
WHISPER MODE 22dB (Colour mode: Theatre Black 1 and 2)
ACCESSORIES
POWER CORD 3m
REMOTE CONTROL Stick type (backlight)
BATTERY Alkaline, AA x2 (Included)
USER'S MANUAL Included (CD-Rom)
LENS CAP Included
|
|
|
|
17/03
|
Epson EH-DM3 LCD Home Theatre Projector - 2000 Lumens, 960x540, HDMI, Built-In DVD Player Epson EH-DM3
Overview:
Epson is pleased to introduce the Epson EH-DM3 All-In-One Home Theatre! Featuring built in DVD/DivX player, virtual surround sound stereo speakers and a host of automatic set-up features, the Epson EH-DM3 Home Theatre delivers amazing results in a stylish user friendly package. The Epson EH-DM3 is anywhere, anytime, entertainment simplicity.
KEY FEATURES:
- All-In-One Simplicity With the EH-DM3 the DVD Player and virtual surround sound stereo speakers are built in. Simply plug the EH-DM3 into a power point, and youre ready for the full big screen experience
- Automatic Set-up The EH-DM3 automatically senses the ambient light level in a room and selects the most appropriate theatre colour mode to suit. It can even sense the projected image and adjust the vertical keystone to give you a sharp, square image.
- Highly Portable Small, light weight and featuring an inbuilt carry handle, the EH-DM3 is a complete take anywhere entertainment system.
- Broad Connectivity Options Including HDMI With the EH-DM3 you can connect to a multitude of devices including gaming consoles, your digital set-top box, TV tuner, Foxtel and BluRay players.
- Gaming, Music, and Photo slide-shows Project your favourite gaming console or PC for a bigger, more exciting experience! You can even run photo slideshows from a USB memory device or CD / DVD or listen to your favourite music CDs.
All-In-One Home Theatre
An all-in-one design concept offering portability, simple connectivity, inbuilt CD/DVD/DivEX player and high quality stereo speakers, the Epson EH-DM3 offers a large screen experience like never before. Achieve a brilliant wide-screen performance anywhere anytime.
Enjoy action-packed DVDs, sporting events and gaming, share your digital photos on the big-screen, watch your favourite Foxtel programs or simply enjoy listening to your favourite Music CDs. With the Epson EH-DM3, convenience and simplicity combine in one high performance unit.
With no need for untidy video or audio cables, viewing a DVD is as simple as positioning the EH-DM3 connecting the power, and pressing play. Whether you use it for your kids parties, an at home karaoke night, a video gaming marathon, outdoor cinema in the backyard, or simply to project your favourite movie onto the wall in the lounge room, the EH-DM3 will be central to all of your home entertainment experiences! And once the party is over, simply connect directly to your PC or notebook computer and youre ready for Monday mornings presentation to a new business prospect.
Mobility
Small and light weight, the EH-DM3 is highly portable. With a built in easy-to-hold handle its a pleasure to bring along when visiting friends or relatives.
Bright and Sharp
The Epson EH-DM3 delivers superb image brightness and colour contrast. Capable of brightness levels of up to 2,000 lumens light output and 2,000 lumens colour light output. And thanks to the power of 3LCD technology, the EH-DM3 delivers both colours and whites of unequalled quality.
Built-in DVD Player and Virtual Surround Sound Stereo Speakers
A beautiful image accompanied by rich, stereo sound without the need for untidy, complex cabling. The EH-DM3 delivers when and where you want the full home theatre experience. Play DVD movies, or photo slide show on the big screen, or listen to audio CDs all from this one convenient home entertainment unit.
E-TORL
Exclusive to Epson, E-TORL lamp technology delivers light projection efficiency with minimal light diffraction and the elimination of light leakage.
Simple Connectivity including USB / PC and HDMI Ports Connect a gaming console, video camera, set-top box or even a PC. The EH-DM3 is easy to use and will enhance your entertainment and presentation experience to a new level.
Specifications:
Product Type - Home Theatre Projector
Product Name - ED-DM3
Product Code - V11H319253
Projection Method - Front
Specifications Of Main Parts
LCD
- Size - 0.55inches wide
- Driving Method - Poly-Silicon TFT Active Matrix
- Pixel Number - 960 x 540 Pixels
- Native Resolution - 540p
- Aspect ratio - 16:9
- Pixel Arrangement - Stripe
Projection LEDS
- Type - Digital Zoom and Manual Focus
- F-Number 1.44
- F-Numer 16.6mm
- Zoom Ratio - Digital Zoom 1.0 - 1.35
- Lens Cover - Slide lens shutter (manual)
Lamp
- Type - 200W UHE ETOR Lamp
Optical System - Dichroic Mirror Separation & Prism Combine Method
Screen Size (Projected Distance)
- 30-300inches (0.89 - 9.1m)
- 60" screen 1.80m
Light Output
- Normal 2,000lm (Colour mode: Dynamic)
- Eco 1,000lm (Colour mode: Theatre)
Colour Light Output
- 2,000lm (Colour mode: Dynamic)
Sound
- Output - Stereo Speaker (10W x 2 / 8ohm)
- Mode - DVD: Concert, Drama, Action, Sci-Fi (Science Fiction)
- CD : Classic, Jazz, Rock, Digital
Colour Reproduction
- Full colour (16.77 million colours)
Analouge RGB I/O
- Display performance - Resize 1280x1024/1024x768/800x600/640x480
Video I/O
- Display Performance - Input Signal Video Standard - NTSC/NTSC4.43/PAL/M-PAL/N-PAL/PAL60/SECAM
- Input Terminal Video - Composite Video - RCA x 1- Component Video: RCA x 1
- Audio - RCA x 1 (in common with Analouge RGB)
HDMI
- Display Performance - Native 720x480 pixel (480p)
- Version - Ver 1.3a (Specific features IS NOT supported)
- Video Standard 480i/576i/480p/576p/720p/1080i/1080p
- Video Signal TMDS(TMDS is signal for HDMI)
- Audio Signal Linear PCM
- Input Terminal - HDMI x 1 (HDCP)
Output Signal
- Audio Analouge - Head phone: 25mW / 32ohm
- Audio Digital - SPDIF (1VRMS)
OUTPUT TERMINAL
AUDIO ANALOGUE Headphone : Stereo jack (3.5mm)
AUDIO DIGITAL RCA x 1 (Orange)
DVD UNIT
LOADING Slot
MEDIA DVD Video (Zone 4) & DVD Audio, VCD, SVCD, AudioCD, MP3 (CD/DVD),
WMA (CD/DVD), JPEG ,DivX (CD/DVD), DivX Ultra (CD/DVD), Dual Disk
DVD-R/RW, DVD+R/RW, DVD-ROM, CD-R/RW, CD-ROM
DVD-VR (w/wo CPRM)
DVD Audio support Video part only
SURROUND SOUND Dolby Digital, DTS Digital Surround, MTK Surround
AUDIO FORMAT Dolby Digital, DTS, MP3, MPEG-2, LPCM
FUNCTION DVD Player, Playing from USB flash drive or USB memory card reader, etc
CONTROL I/O
USB I/O USB Type B (For support only)
MEMORY I/O
USB I/O USB Type A ( For Photo Viewer)
KEYSTONE CORRECTION Vertical: -15 to +15 degrees
MICROPHONE
INPUT SIGNAL -50dBV~-40dBV (0dB=1V/Pa,1kHz)
INPUT TERMINAL Monaural mini jack
OPERATING TEMPERATURE
5°C to 35°C (41°F to 95°F) (20% to 80% Humidity)
Thermal shut down > 45 °C
Cool-down period Instant Off
Start-up period Approx: 4 seconds
POWER SUPPLY VOLTAGE 100-240 VAC ±10%, 50/60Hz
DIMENSIONS
EXCLUDING FEET 335mm(W) x 239mm(D) x 127mm(H)
MAXIMUM DIMENSION 335mm(W) x 239mm(D) x 136mm(H)
WEIGHT Approx. 4.2kg
FAN NOISE
Normal Mode 32dB
Eco Mode 28dB
ACCESSORIES
POWER CORD 3.0m
CARRY CASE Included
REMOTE CONTROL Stick type
USER MANUALS Included
BATTERY AA x 2
|
|
|
|
Previous Page
|
Next Page
|
|
