The VIVOTEK VS7100 is a professional 1-CH video server for remote surveillance. Embedded with VIVOTEK's VVTK-1000 SoC, it not only provides dual-codec video compression in MPEG-4 and MJPEG formats to efficiently optimize image quality and bandwidth, but also can simultaneously deliver dual streams with different resolutions up to D1 and video quality upon separate devices. Users can easily migrate to an IP-based digital open system from the existing analog close system and meet different requirements for live viewing and recording. The VIVOTEK VS7100 also comes with versatile functions to meet specific applications such as 3GPP mobile surveillance, digital I/O for external sensor and alarm, RS-485 interface for PTZ camera control, and privacy masks and so on. Together with the free-bundled 16-CH recording software, this video server provides a cost-effective solution for a transit from CCTV to IP video.

Features

• Real-time MPEG-4 and MJPEG Compression (Dual Codec)
• Up to D1 Resolution
• Dual Streams Simultaneously
• 3GPP Mobile Surveillance
• Two-way Audio via SIP Protocol
• Digital I/O for External Sensor and Alarm
• Privacy Masks

VIVOTEK VS8102 is a 1-CH video server supporting the high-performance H.264 compression format that drastically reduces file sizes and conserves valuable bandwidth and storage space. With MPEG-4 and MJPEG compatibility, video streams also can be transmitted in either of these formats for versatile applications. The streams can also be individually configured with separate frame rates, resolution, and image quality so as to meet different needs or bandwidth constraints. Users can receive multiple streams simultaneously in different settings for viewing on different platforms such as PCs or mobile phones.

The integrated 802.3af compliant PoE function reduces cabling problems, making the VS8102 a cost-effective surveillance solution. The built-in SD/SDHC card slot offers a convenient and portable storage option to prevent data loss in case of network disconnection. Since all data can be stored on a SD/SDHC card, the on-board storage design significantly reduces bandwidth consumption.

The VS8102 comes with VIVOTEK's ST7501 32-CH central management software for high scalability and easy-to-use operation. With the VS8102, you can upgrade to a full-featured, high-end IP surveillance solution using existing infrastructure.

Features

• Up to 30 fps in D1 Resolution
• Real-time H.264, MPEG-4 and MJPEG Compression (Triple Codec)
• Multiple Streams Simultaneously
• Activity Adaptive Streaming for Dynamic Frame Rate Control
• Built-in 802.3af Compliant PoE
• Two-way Audio via SIP Protocol
• HTTPS Encrypted Data Transmission
• 802.1X Port-based Authentication for Network Protection
• Digital I/O for External Sensor and Alarm
• RS-485 Interface for Scanners, Pan/Tilts
• Built-in SD/SDHC Card Slot for On-board Storage

VIVOTEK IP8161 is a professional-series fixed network camera featuring superb image quality and exceptional bandwidth efficiency. It is especially suitable for wide open spaces such as building entrances and airports, or applications requiring accurate identification, such as human faces in banks or vehicle license plates in parking lots.

Featuring a 2-megapixel sensor, this camera is able to provide a wide field of view with exceptional detail when compared to a standard VGA camera, significantly reducing the number of camera installations. The ePTZ function enables users to focus on close-up shots of different areas in the cameras view without moving the camera physically. Users can quickly move to a target area by simply clicking on the video feed from the camera on their screen. In addition, the IP8161 can deliver user-defined thumbnails for viewing instead of video of an entire scene so as to optimize bandwidth and storage efficiency.

The IP8161 supports H.264 compression technology, drastically reducing file sizes and conserving valuable network bandwidth. With MPEG-4 and MJPEG compatibility, video streams can also be transmitted in either of these formats for versatile applications. The streams can also be individually configured to meet different needs or bandwidth constraints, thereby further reducing bandwidth and storage requirements. Users can receive multiple streams simultaneously in different resolutions, frame rates and image qualities for viewing on different platforms.

Thanks to its day and night function achieved by a built-in removable IR-cut filter, the IP8161 is able to maintain clear images 24 hours a day. Additionally, the IP8161 camera incorporates an adjustment ring to improve lens compatibility with either C- or CS-mount lens, providing system integrators with more flexibility and hassle-free installation for different applications. The built-in SD/SDHC card slot offers a convenient and portable storage option to prevent data loss in case of network disconnection.

Data security with the IP8161 is further enhanced with HTTPS encryption and 802.1x authentication. Together with PoE, QoS, activity adaptive streaming, and the included 32-CH central management software, the IP8161 is indisputably the top choice for reliable and high performance surveillance.

Features

• 2-megapixel CMOS Sensor
• 3 ~ 8 mm Vari-focal, Auto-iris Lens
• Removable IR-cut Filter for Day & Night Function
• Real-time H.264, MPEG-4 and MJPEG Compression (Triple Codec)
• Multiple Streams Simultaneously
• Video Cropping for Bandwidth Saving
• ePTZ for Data Efficiency
• Activity Adaptive Streaming for Dynamic Frame Rate Control
• Tamper Detection for Unauthorized Changes
• Built-in 802.3af Compliant PoE
• Built-in SD/SDHC Card Slot for On-board Storage
• CS- or C-mount Adjustment Ring for Flexible Lens Installation

VIVOTEK IP7361 is a high-end 2-megapixel network bullet camera built for outdoor surveillance. With high resolution video and a combination of outdoor-specific features such as concealed wiring to prevent tampering, the IP7361 is the camera of choice for applications such as parking lots, gas stations, and building exteriors.

The IP7361 boasts high-definition 2-megapixel (1600 x 1200) resolution, allowing for the delivery of extremely detailed images and coverage 6 times larger than a VGA camera. To maximize the benefit of the 2-megapixel sensor, the IP7361 employs several innovative technologies for optimized bandwidth efficiency. The ePTZ function enables users to quickly move to a target area for close-up shots without moving the camera physically. Users can also receive only the portions of the images they are interested in via the cropping function. Furthermore, multiple video streams can be delivered simultaneously in different resolutions, frame rates, and image qualities for viewing on different platforms so as to meet different needs or bandwidth constraints. The IP7361 also offers activity adaptive streaming support that dynamically allocates bandwidth according to the video content and trigger state.

Aimed at outdoor surveillance, the IP7361 features auto-iris capability to protect the lens from damage induced by direct sunlight. To adapt to changing lighting conditions throughout the day, the camera is furnished with a removable IR-cut filter and IR illuminators for superior image quality around the clock. The IP7361 also comes with an IP67-rated housing that offers protection against rain and dust to ensure functional operation in all types of weather conditions. For easy management and protection against tempering and vandalism, the IP7361 is also equipped with a mounting bracket that conceals all cables within.

With other advanced features such as tamper detection, 802.3af compliant PoE, SD/SDHC card on-board storage, and two-way audio via SIP protocol, the IP7361 is a truly a full-fledged surveillance solution for outdoor environments.

Features

• 2-megapixel CMOS Sensor
• 3 ~ 9 mm Vari-focal, Auto-iris Lens
• Removable IR-cut Filter for Day & Night Function
• Built-in IR Illuminators, effective up to 25 Meters
• Real-time MPEG-4 and MJPEG Compression (Dual Codec)
• Multiple Streams Simultaneously
• ePTZ for Data Efficiency
• Weather-proof IP67 rated Housing
• Built-in 802.3af Compliant PoE
• Two-way Audio via SIP Protocol
• Built-in SD/SDHC Card Slot for On-board Storage
• Mounting Bracket with Cable Management for Protected Installation

Providing detail not seen on conventional surveillance cameras, the GV-IP Camera 1.3M features a 1.3 megapixel CMOS that delivers superb video image quality. Through the use of progressive scan CMOS sensor, the GV-IP Camera 1.3M is able to reproduce ultra smooth video images of fast moving objects without any pixilated edges. With high definition up to 1280 x 960 and up to 4 times higher resolution than conventional VGA/ D1 cameras, the GV-IP Camera 1.3M allows users to monitor critical areas with greater detail than ever. Moreover, with simultaneous/dual video stream and support for compliant Power-over-Ethernet (PoE) which simplifies the cabling. It allows users to view both MJPEG images and MPEG-4 videos with improved efficiency while conserving valuable bandwidth.

In providing our customers with a more complete, cost-effective IP surveillance solution, our GV-IP Camera 1.3M can seamlessly integrate with our GV-NVR software system that comes with advanced monitoring and various other video management features. When connected with the GV-IP Camera 1.3M, special web interface support functions such as privacy mask, visual automation, picture-in-picture (PiP) view and picture-and-picture (PnP) view are also made available for facilitating detail monitoring.

Progressive scan CMOS captures the entire scene of a moving object at the same time. Even and odd fields are scanned simultaneously. It reproduces smooth video quality without pixilated edges.

It provides up to 4 times higher resolution than common VGA/D1 cameras.

VIVOTEK's new product RX7101 is a network video receiver, which can cost-effectively have your network-based video appliances including IP cameras and video servers connected with analog video devices like TV sets, analog monitors, or any other existing analog video switches. Newly released RX7101, supporting VIVOTEK's 7000-series network cameras and video servers, can quickly convert MJPEG(*) or MPEG-4 digital videos into analog signals and easily output them to existing analog systems. With the Ethernet interface, users can easily get access to switch the settings of each device within the system through the build-in web page and the configuration installed in RX7101 will automatically guide you to establish quick connections at system boot. The flexible RX7101 can receive one channel of D1 video stream or 4 channels of CIF video streams.

Features

• Real-time MPEG-4 and Motion JPEG decoding
• Up to 1-channel D1 real time decoding
• Up to 4-channel CIF real time decoding
• Quad or sequential display in multi-channel mode
• GSM-AMR and MPEG-4 AAC audio decoding
• RS-485 Interface for Scanners, Pan/Tilts

> 7" TFT LCD display
> View individual pictures (JPEG) and slide shows with MP3 music on the background
> Resolution : 1024 x 768 pixels
> Easy control windows, single photo, music and photo music mode
> Multi-language : English, French, German, Italian
> Supports MS, SD, MMC, XD, CF Cards, USB2.0
> Supported JPEG, MP2, MP3, WMA, MPEG1/2/4(DIVX), AVI
> Wooden frames available in Size: 7", 10", 12", 15"
