| Technical details |
|---|
| International Protection (IP) code | IP65 |
| IK code | IK07 |
| Colour | Yes |
| Number of displays supported | 1 |
| Maximum number of cameras supported | 1 |
| Connectivity technology | Wired |
| Display |
|---|
| Display technology | TFT |
| Display resolution | 1024 x 600 pixels |
| Touchscreen type | Capacitive |
| Touchscreen | Yes |
| Display diagonal | 17.8 cm (7") |
| Design |
|---|
| International Protection (IP) code | IP65 |
| Proper use | Indoor & outdoor |
| IK code | IK07 |
| Outdoor unit housing material | Aluminium |
| Product colour | Aluminium, White |
| Control type | Buttons, Touch |
| Network |
|---|
| Power over Ethernet (PoE) | Yes |
| Supported network protocols | RTSP;RTMP;HTTP/HTTPS;DNS; UPnP;RTP;SIP;SSH; ONVIF ;P2P |
| Camera |
|---|
| Viewing angle, vertical | 87.1 ° |
| Viewing angle, horizontal | 160 ° |
| Megapixel (approx.) | 2 MP |
| Maximum image resolution | 1280 x 720 pixels |
| Maximum frame rate | 30 fps |
| Field of view (FOV) angle | 176.7 ° |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.5 mm (1 / 2.5") |
| Power |
|---|
| Indoor unit power type | DC |
| Outdoor unit power type | DC |
| Operational conditions |
|---|
| Door station operating temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Packaging data |
|---|
| Mounting kit | Yes |
| Indoor unit included | Yes |
| Outdoor unit included | Yes |
2-wire IP Villa Door Station- Anodized alumimum front panel
- CMOS low ilumination 2MP HD colorful 160 ° fisheye camera
- Video intercom function
- Access control function that supports for two locks
- Use the app to talk to visitors or unlock the door remotely on your
- Compatible with 2-wire and RJ45 interfaces
- IK07 & IP65
- Supports H.265 incoding
- Support surface and flush mount
- PoE
IP Indoor Monitor- 2.5D screen glass
- 7" TFT capacitive touch screen
- 6-channel alarm input and 1-channel alarm output
- Supports standard PoE or power over 2-wire switch
- H.265 video coding (H.264 by default)
- Supports 2-wire digital communication
- Supports daisy chain topology
2-wire Switch- Supports connecting through RJ45 port
- Supports guide rail mount
