Camera |
|
|
Sensor |
1/2.8" 1080p 60fps
Exmor CMOS |
|
Effective Picture
Elements |
Approx. 2.1
megapixels |
|
Output
Resolution |
Auto |
|
1080p@60, [email protected],
1080p@50, 1080i@60, [email protected], 1080i@50, 1080p@30, [email protected],
1080p@25, 720p@60, [email protected], 720p@50 |
|
Minimum
Illumination |
0.3 lux (IRE50, F1.6,
30fps) |
|
S/N
Ratio |
>
50dB |
|
Gain |
Auto /
Manual |
|
TV
Line |
800 (Center/Wide), 700
(Corner/Wide) |
|
Shutter
Speed |
1/1s
1/32,000s |
|
Exposure
Control |
Auto, Manual, Priority
AE (Shutter, IRIS), BLC |
|
White
Balance |
Auto / Indoor / Outdoor
/ One-push / Manual (2500 10000) |
|
Optical
Zoom |
30X |
|
Digital
Zoom |
12X |
|
Horizontal Viewing
Angle |
67 (Wide) 2.3
(Tele) |
|
Focal
Length |
f = 4.3 mm (Wide) 129
mm (Tele) |
|
Aperture
(Iris) |
F = 1.6 (Wide) 4.7
(Tele) |
|
Minimum Working
Distance |
0.01 m (Wide), 1.2 m
(Tele) |
|
Pan/Tilt
Angle |
Pan: +- 170, Tilt: +90
/ -30 |
|
Pan/Tilt Speed
(manual) |
Pan: 0.1 100/sec, Tilt:
0.1 100/sec |
|
Preset
Speed |
Pan: 200 /sec, Tilt:
200 /sec |
|
Preset
Position |
10 (IR), 255
(RS-232) |
|
Camera Control -
Interface |
RS-232 (DIN9) / RS-422
(RJ45) |
|
Camera Control -
Protocol |
VISCA
(RS-232/RS-422/IP), CGI (IP) |
|
Processing |
Noise Reduction (2/3D),
Flip, Mirror |
|
Power
Frequency |
Auto / 50Hz /
60Hz |
|
Audio |
|
|
Channel |
2ch
(Stereo) |
|
Codec |
AAC-LC
(48/44.1/32/24K), G.711/PCM |
|
Sample
Rate |
48/44.1/32/24/16/8Khz |
|
Interface |
|
|
Video
Output |
3G-SDI, HDMI, IP,
USB |
|
Audio
Output |
3G-SDI, HDMI, IP,
USB |
|
Audio
Input |
MIC / Line
in |
|
General |
|
|
Power
Requirement |
AC100V-AC240V to
DC12V/5A |
|
PoE |
POE+ (IEEE 802.3at),
Class 4 |
|
Operating
Condition |
Temperature: 0C +40C ;
Humidity: 20% 80% |
|
Storage
Condition |
Temperature: -20C +60C
; Humidity: 20% 95% |
|
Dimensions |
L=180 mm, W= 145 mm, H=
183.5 mm |
|
Weight |
1.62
kg |
|
Application |
Indoor |
|
Security |
Kensington
slot |
|
Remote
Control |
Infrared |
|
Accessories |
Remote control, 12V/5A
power adapter |
|
IP
Streaming |
|
|
Resolution |
1920x1080, 1280x720,
960x540, 640x480 |
|
Network Video Compress
Format |
H.264 (High Profile),
MJPEG |
|
Maximum Frame
Rate |
H.264: 60fps
(1920x1080), MJPEG: 30fps (1920x1080) |
|
Bit-rate Control
Mode |
VBR/CBR
(selectable) |
|
Range of Bit-rate
Setting |
512Kbps
32Mbps |
|
Network
Interface |
10/100/1000Base-T |
|
Multi-stream
Capability |
2 |
|
Network
Protocol |
IPv4, TCP, UDP, ARP,
IMCP, IGMP, HTTP, DHCP, RTP/RTCP, RTSP, VISCA over IP |
|
USB |
|
|
Connector |
Micro-USB
2.0 |
|
Video
Format |
YUV, MJPEG,
H.264 |
|
Maximum Video
Resolution |
Up to
1080p |
|
USB Video
Class |
UVC1.1 |
|
USB Audio
Class |
UAC1.0 |
|
Web
UI |
|
|
Live Video
Preview |
Yes |
|
Camera PTZ
Control |
Pan / Tilt / Zoom /
Focus / Preset Control |
|
Camera / Image
Adjustment |
Exposure / White
Balance / Picture |
|
Network
Configuration |
DHCP, IP Address,
Gateway, Subnet Mask, DNS |
|
Software
Tools |
|
|
Device IP Searching,
Configuration Tool |
Windows
Application |
|
Warranty |
|
|
Camera |
3
Years |
|
Accessories |
1
Year |
