CAMERA |
|
|
Sensor |
|
|
Sensor |
1/2.84 type HD CMOS
Pro |
|
Filter |
RGB Primary Colour
filter (Bayer array) |
|
Total
Pixels |
3.09 megapixels (2208 x
1398) |
|
Effective pixels per
sensor |
2.91 megapixels (2136 x
1362) |
|
Minimum
illumination |
TBC |
|
Horizontal
Resolution |
TBC |
|
|
|
Lens |
|
|
Zoom
ratio |
20 x
Optical |
|
Focal
length |
3.67 - 73.4mm (35mm
equivalent: 28.8 - 576mm) |
|
Minimum focus
distance |
60cm (throughout zoom
range); |
|
10mm (Wide MACRO
setting) |
|
ND
filter |
Built-in gradation ND
filter |
|
Zoom
control |
Zoom rockers on body
and handle; |
|
Selectable manual
zoom/focus ring on lens; |
|
Selectable High Speed
and Soft Zoom modes available. |
|
Zoom
speed |
Zoom
Rocker: |
|
Variable speed/Fixed
speed (Fast/Normal/Slow, 16 speed level settings available in each
mode); |
|
Grip
zoom: |
|
Fixed speed
(Fast/Normal/Slow, 16 speed level settings available in each
mode) |
|
Zoom Ring: As operation
speed |
|
Focus
control |
Manual control via
focus ring, automatic (Instant AF, Medium AF, TV AF, Face Detection AF,
Face Only AF), Push AF |
|
Iris
control |
Ring control; Custom
dial control; Full Auto |
|
Aperture
range |
f1.8 -
f16 |
|
Filter
diameter |
58mm |
|
Lens
elements/groups |
10-Dec |
|
Aperture
blades |
8 Blade Circular
Aperture |
|
Image stabilization
system |
Dynamic IS and Powered
IS, 5 Axis image stabilisation |
|
Digital
zoom/Teleconverter |
1.5x; 3x;
6x |
|
|
|
processor |
|
|
Type |
DIGIC DV
4 |
|
Sampling accuracy
(MXF) |
TBC |
|
Bit
Depth |
TBC |
|
|
|
RECORDING |
|
|
Video storage
media |
Type 1 Compact Flash
memory cards (2 card slots); |
|
SD Card x
1 |
|
Dual Format recording,
Double slot (simultaneous) recording and Relay (continuous) recording
possible. |
|
Type |
UDMA4, 30MB/s or faster
(40MB/s or faster for Fast/Slow recording); |
|
SD card Class 4 or
higher, Class 6 & 10 recommended for 35Mbps MP4
recording |
|
|
|
Capacity |
|
|
Recording
time |
128GB CF card: Up to
320 mins (1080/50i @ 50 Mbps) |
|
128GB SD Card: up to 8
Hours (MP4/50P @35Mbps) |
|
Recording file
format |
Material eXchange
Format (MXF) to CF card, MP4 to SD card |
|
Recording
format |
MPEG-2 Long
GOP |
|
50Mbps CBR (4:2:2)
MPEG-2 422P@HL; |
|
35Mbps VBR (4:2:0)
MPEG-2 MP@HL; |
|
25Mbps CBR (4:2:0)
MPEG-2 MP@H14 |
|
MP4:
MPEG-4/AVC/H.264 |
|
35/24/17/9/3
Mbps; |
|
All modes variable bit
rate, 4:2:0 colour sampling |
|
Recording frame rate
(PAL Mode) |
MXF |
|
50Mbps: 1920 x
1080/50i, 25p; 1280 x 720/50p, 25p; |
|
35Mbps: 1920 x
1080/50i, 25p; 1440 x 1080/50i; 1280 x 720/50p, 25p; |
|
25Mbps: 1440 x
1080/50i, 25p |
|
MP4: |
|
35/24Mbps 1920 x 1080:
50P/25P |
|
17Mbps 1280 x 720:
50P |
|
9 Mbps 1280 x 720:
25P |
|
3Mbps 640 x 360:
25P |
|
Slow/Fast
motion |
YES (MXF recording
only) |
|
720p: 12, 15, 18, 20,
21, 22, 23, 24, 25, 26, 27, 28, 30, 32, 34, 37, 42, 45, 48,
50fps |
|
1080p: 12, 15, 18, 20,
21, 22, 23, 24, 25fps |
|
Interval
record |
YES MXF recording only.
2, 6 or 12 frames, 25 time intervals |
|
Frame
record |
YES. 2, 6 or 12
frames |
|
Pre Record (cache
record) |
YES (3
seconds) |
|
Scan
Reverse |
YES.
Vertical/horizontal/both |
|
Photo storage
media |
SD/SDHC/SDXC memory
card |
|
Still
quality |
During video recording:
1920 x 1080 in 1920 x 1080 or 1440 x 1080 mode, |
|
1280 x 720; 1280 x 720
mode |
|
During playback:
1920x1080 |
|
|
|
SYSTEM |
|
|
Panel |
|
|
Type |
Organic
LED |
|
Size |
8.77cm (3.5") Organic
EL (OLED) |
|
Dots |
1.23m (approx.
equivelent) |
|
Image quality
adjustments |
Brightness, contrast,
colour, sharpness, |
|
Adjustable |
YES |
|
Waveform
Monitor |
Yes, selectable on/off;
Line, Line and Spot,Field, RGB, YPbPr |
|
Focus
Assist |
Peaking; Magnifying;
Edge Monitor (using waveform display) |
|
Peaking |
Peaking 1, Peaking 2
(Colour, Gain, Frequency customisable for each) |
|
Zebra |
Level 1; Level 2;
Both |
|
Output via
HDMI |
|
Markers |
On/Off (Aspect ratio,
Safe area, Grid, Horizontal, Centre) |
|
|
|
EVF |
|
|
Size |
1.15cm (0.45
in) |
|
Dots |
1.23m (approx.
equivelent) |
|
Image quality
adjustments |
Brightness, contrast,
colour, backlight |
|
Adjustable |
Vertical tilt, up to
68 |
|
Viewing
Angle |
28.2 |
|
Correction
lens |
+ 2.0 to -5.5
diopter |
|
|
|
Inputs/Outputs |
|
|
Audio
in |
XLR inputs with 48V
phantom power (x2), 3.5mm microphone input jack |
|
Headphone
output |
3.5mm stereo
jack |
|
Video monitor
output |
NO |
|
HDMI |
YES (HDMI mini
connector, output only, 1080/50p output possible) |
|
IEEE 1394
(Firewire) |
NO |
|
USB |
YES (Mini-B, USB 2.0
Hi-Speed, output only) |
|
3G-HD/SD-SDI
output |
NO |
|
Time
code |
NO |
|
Genlock |
NO |
|
LAN |
YES, Ethernet
(1000BASE-T supported) |
|
AV
terminal |
3.5mm mini jack (output
only for video and audio) |
|
DC
input |
YES |
|
Remote Control
Terminal |
2.5mm mini
jack |
|
Colour
Bars |
YES (SMPTE or EBU),
with 1KHz Tone |
|
|
|
Misc |
|
|
Tally
lamp |
YES
(x2) |
|
Accessory
shoe |
YES (cold
shoe) |
|
Custom Button
Assignment |
YES (13 assignable
buttons; select from 28 functions) |
|
Rotating Side
Grip |
Yes. 120 angle of
rotation in 15 increments |
|
Custom
Dial |
NO |
|
|
|
SHOOTING
FUNCTIONS |
|
|
Exposure |
|
|
Exposure
metering |
Standard (centre
weighted), Spotlight, Backlight |
|
Exposure
range |
TBC |
|
Exposure
compensation |
-2 to +2
EV |
|
Auto Exposure
mode |
Full
Auto |
|
Push Auto
Iris |
No |
|
Auto Gain Control
setting |
Full Auto/AGC
Limit/Manual |
|
Auto Gain Control
limit |
3dB, 0dB, 3dB, 6dB,
9dB,12dB,15dB,18dB, 21dB,24dB, 27dB,33dB |
|
Gain
setting |
-6dB / -3dB / 0dB/ 3dB
/ 6dB/ 12dB / 18dB / 24dB / 27dB /33dB / TUNE (0.5 dB increments from 0 to
27 dB) .27dB maximum in Auto mode |
|
|
|
Shutter
speed |
|
|
Control
Modes |
Full Auto / Manual
joystick control (Auto; Speed; Angle; Clear Scan (CS); Slow Shutter (SLS);
IR Slow Shutter) |
|
Shutter
speed |
1/18 to 1/2000
depending on frame rate |
|
Shutter
Angle |
11.25 to 360 depending
on frame rate |
|
Slow Shutter
(SLS) |
1/3, 1/6, 1/12, 1/25
(depending on frame rate) |
|
Clear
Scan |
50i/p: 50 to
250.51Hz; |
|
25p: 25 to
250.51Hz |
|
|
|
Infrared |
|
|
Infrared shooting
mode |
YES (green or
white) |
|
Built-in IR
lamp |
YES |
|
|
|
Custom
Picture |
|
|
Stored
Configurations |
9 (Including Wide
DR) |
|
Storage
Medium |
SD/SDHC memory
card |
|
Gamma |
6 preset
profiles |
|
Master
Pedestal |
-50 to
+50 |
|
Master
Black |
-50 to +50 for each of
R,G,B |
|
Black
Gamma |
Adjustable height,
width and apex |
|
Low Key
Saturation |
-50 to +50 adjusts
colour saturation in low brightness area |
|
Knee |
Adjusts over exposure
characteristic (Automatic, Slope, Point, Saturation) |
|
Sharpness |
Adjustment for Detail
level, Detail frequency, Coring, HV balance, Detail limit, Knee Aperture,
Level Depend, Ingredient Ratio |
|
Noise
reduction |
Off, Automatic, On (1
to 12) |
|
Skin
detail |
Effect Level (Low,
Middle, High), Hue, Chroma, Area, Y Level |
|
Selective Noise
Reduction |
Effect Level (Low,
Middle, High), Hue, Chroma, Area, Y Level |
|
Colour
matrix |
Normal 1 -4, Cine 1 -
2, Wide DR Matrix and Hue -18 - +18, Colour Gain -50 -
+50 |
|
White
balance |
-50 to +50 white
balance offset for R,G,B |
|
Colour
correction |
Area selection / area
revision of two areas |
|
Setup
level |
-50 to +50
On/Off |
|
Clip 100%
IRE |
Limits output to 100%
after setup adjustment |
|
Wireless LAN
standards |
IEEE 802.11b/g/n
(2.4GHz band) / IEEE 802.11a/n (5GHz band) |
|
Supported Wi-Fi
Functions |
Rec start/stop, 3 speed
focus control, 3 speed zoom control, WB
mode/adjust, |
|
Iris, Shutter,Colour
Temperature,Assign Button,ND Auto/Off |
|
Supported Browser for
Remote Operation |
Internet Explorer 8 or
later, Safari (iOS), Safari (MacOS), Android standard
browser |
|
Remote Operation
Control Features |
Aperture, Focus, WB,
shutter Speed, Gain, Exposure Compensation, Shooting Mode, Slot select,
Start/Stop Recording |
|
Live view image
Resolution |
Camera setting mode:
680 x 383; Simplified setting: 284 x 160 |
|
Authentication
Systems |
Open/WPA-PSK/WPA2-PSK |
|
Encryption |
WEP64, WEP128, TKIP,
AES |
|
GPS Information
(Optional Accessory) |
Latitude/Longtitude/Elevation,
Coordinated Universal Time (UTC) |
|
|
|
White
balance |
|
|
Auto |
YES in Full Auto
Mode |
|
Preset |
A, B, Preset (Daylight,
Tungsten), Colour Temperature |
|
Countup
system |
Regen, RecRun, FreeRun,
External, Hold |
|
Start value
setting |
"00:00:00:00",
Set/Reset selectable |
|
|
|
Audio |
|
|
Recording |
16-bit 4ch or 2ch (48
kHz) linear PCM |
|
Control |
Audio limiter,
Auto/manual settings via control cials on handle |
|
Microphone
attenuation |
YES |
|
Microphone level
meter |
YES |
|
|
|
ACCESSORIES |
|
|
Supplied |
Data Import Utility,
Battery pack BP-955, DC cable DC-930, Compact power adapter CA-930,
Wireless controller WL-D6000, Eyecup, Lens Hood with Barrier, Microphone
Holder Unit, Mains Cable. |
|
|
|
Optional |
Wide Converter WA-H58,
Teleconverter TL-H58, , BP-975, Tripod Adapter TA-100, Zoom Remote Control
ZR-2000, Tripod Base TB-1, GPS Receiver GP-E2, Remote Controller RC-V100,
Filter (58mm) Protect/ND8xL/ND4xL. |
|
|
|
Battery |
|
|
Backup power
supply |
TBC |
|
Power
Consumption |
MAX 8.2 W
(approx.) |
|
Continuous Recording
Time |
260 mins (MXF
recording) 270 mins (MP4 recording) with suppiled
BP-955 |
|
|
|
MISCELLANEOUS |
|
|
Dimensions |
Approx 160 x 201 x
353mm (including lens hood with barrier, Eye Cup and microphone
holder) |
|
Weight (camera
only) |
1510g (3.3
lb) |
|
Weight (fully
equipped) |
1910g (4.2
lb) |
|
Operating Temperature
range |
-5C to +45C, 60%
relative humidity |
