Light
output*1 |
4
500 lumens |
|
Technology |
Laser
LCD |
|
LCD
panel | Panel size (mm) |
16
mm diagonal (16:10 aspect ratio) |
|
LCD
panel | Panel size (inch) |
0.64
inch diagonal (16:10 aspect ratio) |
|
LCD
panel | Display method |
Transparent
LCD panel (x 3, R/G/B) |
|
LCD
panel | Drive method |
Active
matrix |
|
LCD
panel | Pixels |
2,304,000
(1920 x 1200) x 3, total of 6,912,000 pixels |
|
LENS |
1.6
x Manual zoom (throw ratio 1.09-1.77 :1), F = 1.60-2.12, f = 15.30-24.64
mm |
|
Light
source |
Laser
diode |
|
Screen
size (diagonal) (mm) |
0.76
- 7.62 m, 16:10 aspect ratio |
|
Screen
size (diagonal) (inch) |
30-300
in, 16:10 aspect ratio |
|
Center-to-corner
uniformity*1 |
85% |
|
Contrast*1 |
3,000,000:1
(all white/all black) (Input signals:PC,LIGHT POWER:NORMAL,PICTURE
MODE:DYNAMIC,DAYLIGHT WIEW:OFF,DYNAMIC CONTRAST:[1],AUTO POWER
SAVE:OFF) |
|
Resolution |
1920
x 1200 pixels |
|
Optical
axis shift | Vertical (from center of screen) |
0
% - +44 % (Manual) |
|
Optical
axis shift | Horizontal (from center of
screen) |
±
20% (Manual) |
|
Keystone
correction range*2 |
Vertical:
±25°, Horizontal: ±35° |
|
Installation |
Horizontal/Vertical,
free 360-degree installation |
|
Terminals
| HDMI 1/2 IN |
HDMI
19-pin x 2 (Compatible with HDCP, Deep Color, 4K/30p signal
input) |
|
Terminals
| COMPUTER 1 IN |
D-sub
15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
|
Terminals
| COMPUTER 2 IN / MONITOR OUT |
D-sub
15-pin (female) x 1 (RGB/YPBPR/YCBCR) (input/output
switching) |
|
Terminals
| VIDEO IN |
Pin
jack x 1 |
|
Terminals
| AUDIO 1/2 IN |
M3
stereo mini-jack x 2 |
|
Terminals
| AUDIO 3 IN |
Pin
jack (L/R) x 1 |
|
Terminals
| VARIABLE AUDIO OUT |
M3
stereo mini-jack x 1 |
|
Terminals
| SERIAL IN |
D-sub
9-pin x 1 for computer control (RS-232C compliant) |
|
Terminals
| LAN |
RJ-45
x 1 for network control, 10Base-T, 100Base-TX, compatible with PJLink™
(Class 2) |
|
Terminals
| USB CONNECTOR |
USB
connector (Type A) x 1 for Memory Viewer function, power supply (DC5V,
maximum 2A*3), optional wireless module AJ-WM50 |
|
Power
supply |
AC
100-240 V AC, 50/60 Hz |
|
Power
consumption |
TBD |
|
Built-in
Speaker |
10
W (monaural) |
|
Operating
noise*1 |
NORMAL:
37dB, QUIET: 27dB |
|
Cabinet
materials |
Molded
plastic |
|
Filter |
Included |
|
|
Filter
cleaning cycle: 20,000 hours (0.08 mg/m3 of particulate matter), 10,000
hours (0.15 mg/m3 of particulate matter) |
|
Dimensions
(W x H x D) (mm) |
399
x 115 x 348 mm (Not including protruding parts)399 x 133 x 348 mm (With
feet at shortest position) |
|
Dimensions
(W x H x D) (inch) |
15
23/32 x 4 17/32 x 13 11/16 inch (Not including protruding parts)15 23/32 x
5 1/4 x 13 11/16 inch (With feet at shortest
position) |
|
Weight
(kg)*4 |
7.2
kg |
|
Weight
(lbs.)*4 |
15.87
lbs. |
|
Operating
environment (℃/M) |
Operating
temperature: 0 °C- 45 °C, operating humidity: 20 %-80 % (no
condensation) |
|
Operating
environment (°F/Feet) |
Operating
temperature: 32 °F -113 °F, operating humidity: 20 %-80 % (no
condensation) |
|
Applicable
software/application |
Logo
Transfer Software, Multi Monitoring & Control Software, Presenter
Light for Windows®, Wireless Projector Apps for
iOS/Android™ |
|
Note |
*1
Measurement, measuring conditions, and method of notation all comply with
ISO/IEC 21118: 2012 international standards. Value is average of all
products when shipped. |
|
|
*2
Around this time, light output will have decreased by approximately 50 %.
IEC62087: 2008 Broadcast contents, NORMALMode, Dynamic Contrast [2], under
conditions with 30 °C (86 °F), 700 m (2,297 ft) above sea level, and 0.15
mg/m3 of particulate matter. Estimated time until light output declines to
50 % varies depending on environment. |
|
|
*3
On standby, power supply is available with Quick Startup set to ON or
Power Management set to Ready. |
|
|
*4
Average value. May differ depending on the actual
unit. |
