Display |
|
|
Aspect
Ratio |
16x10 |
|
Maximum
Resolution |
WUXGA
1920 x 1200 |
|
Native
Resolution |
WXGA
1280x800 |
|
Contrast
Ratio (typical) |
18,000:1 |
|
|
|
|
Synchronization
Range |
|
|
Horizontal
(Analog/Digital) |
15-100
kHz (RGB: 24 kHz or over) |
|
Vertical |
50-120
Hz |
|
Signal
Compatibility/Connectivity |
|
|
Supported
Video Standards |
NTSC,
NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM |
|
PC
Signal Compatibility |
VGA,
SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA |
|
Sync
Compatibility |
Separate
Sync / Composite Sync / Sync on G |
|
SD/HD
Video Signal Compatibility |
480i,
480p, 576i, 576p, 720p, 1080i, 1080p |
|
Macintosh
Signal Compatibility |
Yes |
|
External
Control |
RS-232,
IR, DDC/CI, USB, LAN |
|
Output
Terminals |
|
|
Audioout: |
1/8
in. stereo (Variable audio out) |
|
Monitor
Out: |
VGA
15-pin D-sub |
|
Input
Terminals |
|
|
RGB1(analog): |
VGA
15-pin D-sub |
|
RGB2(digital): |
HDMI
w/HDCP |
|
RGB3(digital): |
HDMI
w/HDCP |
|
RGB4(digital): |
HDBaseT |
|
Video
1: |
RCA |
|
Audio
1: |
RCA |
|
Audio
2: |
Mini
stereo |
|
|
|
|
Power
Consumption (typical) |
|
|
On |
418W
/ 280W / 2.0W / 0.16W |
|
Power
Requirements |
100-240V
AC, 50/60 Hz |
|
Input
Current |
4.7-1.8A |
|
|
|
|
Environmental
Conditions |
|
|
Operating
Temperature |
41-104°F
/ 5-40°C |
|
Storage |
14-122°F
/ -10-50°C |
|
|
|
|
Limited
Warranty (parts & labor) |
Registered
owners receive a 3-year parts and labor warranty including InstaCare next
business day exchange. One year on lam |
|
|
|
|
Additional
Features |
Manual
keystone correction |
|
|
Wireless
LAN (control only) |
|
|
USB
Viewer |
|
|
Auto
power on |
|
|
ECO
Mode technology |
|
|
Closed
captioning |
|
|
Variable
audio out |
|
|
Carbon
savings meter |
|
|
Virtual
Remote |
|
|
Sleep
timer |
|
|
Built-in
wall color correction |
|
|
Advanced
AccuBlend |
|
|
AutoSense |
|
|
|
|
Optical |
|
|
Display
Technology |
0.64"
LCD |
|
|
|
|
|
|
|
|
|
|
Lamp
Type |
330W
AC |
|
Screen
Size (diagonal) |
30
to 300 in. / 0.76 to 7.6m |
|
Projection
Distance |
2.6
to 44.3 ft. / 0.8 to 13.5m |
|
Lens |
|
|
Zoom: |
1
to 1.7 |
|
Focus: |
Manual |
|
F
number, fnumber: |
F=1.7
to 2.2, f=17.4 to 29.0mm |
|
Light
Output(Lumens) |
5200
(Center) |
|
|
4700
(Eco Off) |
|
|
4050
(Normal Eco) |
|
|
3050
(Eco) |
|
Lamp
Life (up to) |
4000
hours (Eco Off) / 6000 hours (Normal Eco) / 8000 hours
(Eco) |
|
Throw
Ratio |
1.2
to 2.1 |
|
Projector
Angle |
0
to 9.7° tele / 0 to 16.1° wide |
|
Keystone
Correction |
Manual
+/- 20° horizontal, +/- 30° vertical |
|
|
|
|
Mechanical |
|
|
Installation
Orientation |
Floor/Front,
Floor/Rear, Ceiling/Front, Ceiling/Rear |
|
Regulations |
USA
UL 60950-1 / FCC Part15 Class B, Canada CSA 60950-1 / ICES-003 Class B,
NOM |
|
Fan
Noise |
37
dB normal / 34 dB eco |
|
Light
Output |
5200(Center)
|
|
|
4700
(Eco Off) |
|
|
4050
(Normal Eco) |
|
|
3050
(Eco) |
|
Fan
Noise |
37
dB normal / 34 dB eco |
|
Regulations |
USA
UL 60950-1 / FCC Part15 Class B, Canada CSA 60950-1 / ICES-003 Class B,
NOM |
